DOGA GX80 User manual

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 1
DOGA BRUSHLESS ELECTRIC
SCREWDRIVERS GX 30 VOLTS
INSTRUCTIONS MANUAL

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 2

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 3
Warning p 4
1. Scheme . p 5
2. Optional products p 5
3. Description . p 5
4. Main features p 5
5. Model composition p 6
6. Models p 6
6.1 Standard p 6
6.2 Soft stop (Shockless p 6
6.3 Timer & Auto reverse p 6
7. Opération p 7
7.1 Standard Driver p 7
7.2 Option # Soft start + Double hit p 8
7.3 Timer & Auto reverse p 9
7.4 Torque curve p 12
8. Exploded view p 14
8.1 Drawing for GX080, GX120 p 14
8.2 Drawing for GX080P, GX120P p 15
9. Spart List p 16

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 4
WARNING
1. Keep the working area clean.
Avoid wearing the harmful clothes to the electric shock.
2. Don't touch the electrical parts after opening the cover. It may be dangerous for the electric shock.
3. Always keep the power off during contact the electrical parts.
4. Before the power on, always check the electric concerned.
5. Be sure that the any live parts should not be touched to the steel parts.
6. Use the rated power voltage for each models
7. Be careful the earth line not to touch the electric parts or lead on power.
8. Never use the non-specified parts.
9. Never lubricate aerosol oil the electrical part including the motor
10. The wires should not be damaged by sharp edge, soldering iron or any pulling force when close the cover.
11. All solder points should be protected by the shrink cable
12. Be aware that the motor can be damaged by the impact or hit.

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 5
1. Scheme
25W Brushless motor equipped screwdiver with the torque control system by the
mechanical clutch working with the spring. the range of torque : 0.5 - 12 Kgf.cm
2. Optional products
1) Soft stop, ESD and Clean room operation
---> Semi conductor, optical, storage and LCD products industry
2) Automation market with the long lasting life time with less maintenance
---> Mobile phone, LCD products and automatic fastening system industry
3. Description
Grip : Dia 30 mm
Length : 220 mm
Weight : less 400 gr
Torque range : 0.5 - 12 Kgf.cm
Voltage : DC 30V
4. Main features
STANDARD
- Brushless DC motor equipped
- Built in BLDC drive circuit
- Sensor operated for Start, FOR/REV selecting, Torque limit
- Optional Soft start, Double hit
- Soft stop (shockless) models available
- Over Current, voltage and heat Protection
- Screw pick-up accessories by the vacuum
- LED display of alarm status

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 6
5. Model composition
GX  -○○○ ◇
① ② ③ ④
① Series : GX
② Operation
(Empty) : Standard screwdriver
A : Automation - Dir ect signal s tart and clamping flange
S : Soft Stop (Shcokless) - lower shock when it stops
T : Timer & Auto Reverse
③ Maxim torque value of the range ( Kgf.cm )
080 = 8.0 Kgf.cm
120 = 12.0 Kgf.cm
④ Start type
: Lever start
P : Push start
6. Models
6.1 STANDARD
No load speed
Model Torque High Low Start Controller
GX80 0.5 - 8.0 Kgf.cm 1, 000 670 LEVER
GX120 0.8-12.0 Kgf.cm 700 460 LEVER
GX80P 0.5 - 8.0 Kgf.cm 1, 000 670 PUSH
GX120P 0.8-12.0 Kgf.cm 700 460 PUSH
XS -38D
# Option 1) Soft Start & Double Hit ...... Add suffix "+" / ex) GX80+
6.2 SOFT STOP (Shockless) Driver
No load speed
Model Torque High Low Start Controller
GXS80 0.5 - 8.0 Kgf.cm 1, 000 670 LEVER
GXS120 0.8-12.0 Kgf.cm 700 460 LEVER XS -38D
# Option 1) Soft Start ...... Add suffix "+" / ex) GXS80+
6.3 TIMER & AUTO REVERSE
No load speed
Model Torque High Low Start Controller
GXT80 0.5 - 8.0 Kgf.cm 1, 000 670 LEVER
GXT120 0.8-12.0 Kgf.cm 700 460 LEVER XS -38D

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 7
7. Operation
7.1 Standard Driver
1) Start, Stop and Direction
- Auto stop immediately at the target torque in both direction (FOR-REV)
- Free stop when release the lever or pressure (PTS)
- Sliding sensor switch for rotating FOR-REV
2) Front panel
3) Alarm display by LED color
Over Voltage
Blink Orange color stop the driver immediately over DC33V.
Automatically reset below DC33V.
Over Heat
Blink Red color stop the driver immediately over 70℃.
Automatically reset below 70℃.
Over Load
Blink Green & Orange color stop the driver immediately over 2.5A.
Automatically reset below 2.5A load.
Motor Drive
Motor drive lamp.

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 8
7.2 " + " Option - Soft start + Double hit
1) Front panel
- DOUBLE HIT
Press the DOUBLE HIT button. It repeat OFF and ON
Default : OFF
1st : ON ( LED Orange )
* When the motor run, LED will be Green
- SOFT START
It repeats OFF- 0.2s - 0.4s - 0.6 by pressing the SOFT START button.
Default : OFF
1st : ON soft start for 0.2s / LED Orange
2nd : ON soft start for 0.4s / LED Orange blinking 1 time
3rd : ON soft start for 0.6s / LED Orange blinking 2 times
2) Alarm display by LED color by 2 LED lights
Over Voltage
Blink Orange color stop the driver immediately over DC33V.
Automatically reset below DC33V.
Over Heat
Blink Red color stop the driver immediately over 70℃.
Automatically reset below 70℃.
Over Load
Blink Green & Orange color stop the driver immediately over
2.5A. Automatically reset below 2.5A load.
Motor Drive
Motor drive lamp.

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 9
7.3 TIMER AND AUTO REVERSE SCREWDRIVER ( GXT Driver )
1) Start, Stop and Direction
-One triggering by the lever makes 3 steps sequence in a cycle
Step 1 2 3
Sequence first RUN stop HOLD reverse RUN
Rotating
direction
Clockwise or
Counterclockwise by F/R
switch - Reverse
Activating Run and stop for set time
or stop at the target torque Stop and hold for set time
Rotate to reverse untill
releasing the lever or
stop at the target torque
Or set angle
Angle setting 0 - 15 sec / 24 steps
→
0 - 6 sec / 14 steps
→
0 - 5 sec / 24 steps
- Immediate stop whenever the start lever is released
- Sliding F/R switch works for ① rotating direction (FOR-REV) with the lever pressed
and ② time up/down (Increase / Decrease) with two angle/time set buttons
( first RUN TIME and stop HOLD TIME )
-To cancel the sequence, lease the lever in any process
2) Front panel

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 10
3) Operating
■ Angle setting for first RUN
① Keep the
first Run button pressed over 2 sec. For angle setting.
Then press one by one for the desired rotating angle.
② Select the R position of F/R switch for increasing set angle or F position for decreasing set angle.
③ Keep the
first Run button pressed over 2 sec. Fir Lock & operating mode.
Click 0
1
st 2 nd 3 rd 4 th 5 th 6 th 7 th 8 th 9 th 10 th 11 th 1 21 31 41 51 61 71 8 1 9 2 0 2 1 2 2 2 32 4
Angle
In
turn
Off
1/42/43/415/46/47/429/410/411/434567891
0 1 1 1 2 1 3 1 41 5
LED
O
G R G R G R G R G R G R G R G R G R G R G R G O
■ Time setting for stop HOLD
① Keep the stop time button pressed over 2 sec. Then click the stop time button one by one for desired
stop holding time.
② Select the R position of F/R switch for increasing set time or F position for decreasing set time.
③ Keep the
stop time button pressed over 2 sec. For Lock & operating mode.
Click 0
1
st 2 nd 3 rd 4 th 5 th 6 th 7 th 8 th 9 th 10 th 11 th 12 th 13 th 14 th
Angle
In turn
Off
0.1 0.3 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6
LED
Orange
G R G R G R G R G R G R G O

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 11
■ Rotating speed setting
① Keep the both
first Run & stop time buttons pressed over 2 sec. for unlock.
Then click one by one for the desired rotating speed.
② Select the R position of F/R switch for increasing speed or F position for decreasing speed.
③ Keep the first Run button pressed over 2 sec. For Lock & operating mode.
■ Angle setting for Reverse RUN
① Keep the both first Run & stop time buttons pressed over 2 sec. for unlock.
Then click stop time button one by one for the desired angle.
② Select the R position of F/R switch for increasing set angle or F
position for decreasing set angle.
③ Keep the stop time button pressed over 2 sec. for Lock & operating mode.
Click
0
1
st 2 nd 3 rd 4 th 5 th 6 th 7 th 8 th 9 th 10 th 11 th 1 21 31 41 51 61 71 8 1 9 2 0 2 1 2 2 2 32 4
Angle
In
turn
Off
1/42/43/415/46/47/429/410/411/434567891
0 1 1 1 2 1 3 1 41 5
LED O
G R G R G R G R G R G R G R G R G R G R G R G O

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 12
4) Applications
■ Time setting example
- Driver speed : 1,000 rpm ( GXT80 )
- Screw : 20 thread with 1mm pitch
Applications upon the different settings
F/R switch First RUN Stop HOLD Applications with different sequence in a
cycle
FOR off off
Normal screwdriver in Forward rotation
Forward fastening and stop at the set
torque
Normal screwdriver
REV off off Normal screwdriver in Reverse rotation
FOR 0.5s Max (4.7)
① fasten screw 8 turns ( 12mm height )
② Stop
③ Release the lever
Timer stop
REV 0.3s Max (4.7)
① Loosen screw 5 turns ( 5mm height )
② Stop
③ Release the lever
Tapper or Insert
fastening FOR 0.5s off
① Start Forward rotating and make
thread or fasten screw 8 turns
② Stop
③ Rotate reverse direction immediately
till the lever released
Wire
inserting on
terminal
block
REV 0.2s 1.0s
① Loosen screw 3 turns
② Stop for 1.0 seconds ( wire inserting )
③ Fasten screw with the set torque

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 13
7.4 SOFT STOP SCREWDRIVER ( GXS Driver )
Soft Stop screwdriver has special designed clutch with the bearing of one way
direction rotating. This driver can control the torque for clockwise fastening.
It will have the stall torque in counterclockwise (Reverse) rotation.
Don't loosen the screw over 12 Kgf.cm of tightening torque
Be careful to loosen the screw which was fastened with the other tool.
1) Main features of GXS
- High torque repeatability
- Low G-shock Less than 5G ( Bronze spring ), 10G ( Silver spring )
- ESD Free option available ( 0 ohm by Chrome plate, Less than 10k ohm by conductive case )
- Accessories available ( Vacuum screw pick-up )
- Available with automation system
2) Low G-shock
G-shock test GX80 29G in Hard joint
G-shock test GXS80 5G in Hard joint

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 14
- G-shock is very different according to the joint characteristic, set torque and rotating speed.
- Hard joint, higher torque and speed makes much G-shock than Soft joint, lower torque and speed
- GXS screwdriver shows approx. 2.5 G to 10 G in different condition.
- G-shock Test report ( Hard joint M4 screw fastening )
Test condition
Screwdriver GXS80
Sensor
direction Torque set
at scale Speed (rpm) Reading (G) Duration of
shock (mS)
7 High (1,000) 4.09 0.3
1 High (1,000) 4.49 0.4
7 Low (700) 2.97 0.6
X
1 Low (700) 3.44 0.4
7 High (1,000) 5.28 0.5
1 High (1,000) 2.59 0.2
7 Low (700) 3.21 0.3
Y
1 Low (700) 2.26 0.4
3) Accurate torque control
- Low (0.3 Kgf.cm) to High torque range ( GXS120 )
Torque spring Torque range Scale
① Bronze (dia 1.2) 0.3 - 1.2 Kgf.cm 0 - 7
② Silver (dia 1.8) 1.0 - 6.2 Kgf.cm 0 - 5
③ Black (dia 2.0) 2.0 - 10.5 Kgf.cm 0 - 7
- Highest repeatability in clutch system screwdriver
( less than 3S average 3% between 1 to 10 Kgf.cm of torque range )

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 15
8. Exploded view
8.1 Drawing for GX Lever start

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 16
8.2 Drawing For GX Push to start

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 17
9. Parts List For GX Series
No-
LEVER No- PUSH Code Part Name Réf. GX80 GX120 GXT80 GXT120 GX80P GX120P GXS80 GXS120
1 1 PFE1801 ADJUSTER 1 1 1 1 1 1 1 1
2 2 PFE1132 TORQUE SPRING HOLDER ASSY 1 1 1 1 1 1 1 1
PFE1815 TORQUE SPRING [SILVER] 80 1 1 1 1 1 1 1 1
PFE1816 TORQUE SPRING [BLACK] 120 1 1 1 1
PFE1817 TORQUE SPRING [BRONZE] 1 1 1 1 1 1 1 1
3 3
PFE1814 TORQUE SPRING [GOLD] 1 1 1 1 1 1 1 1
4 4 PSW2201 WRENCH BOLT [M HEX M2.5x5L] 3 3 3 3 3 3 3 3
5 5 PFE1131 TOP COVER ASSY 1 1 1 1 1 1 1 1
PFE1973 BIT SOCKET RING ¼’’ 1 1 1 1 1 1 1 1
6 6
PFE1974 BIT SOCKET RING B 4mm
PFE1410 BIT COLLAR ¼’’ 1 1 1 1 1 1 1 1
7 7
PFE1414 BIT COLLAR B 4mm
PFE1964 COLLAR SPRING ¼’’ 1 1 1 1 1 1 1 1
8 8
PFE1965 COLLAR SPRING B 4mm
9 9 PFE1955 C-RING [5103-31] 1 1 1 1 1 1 1 1
10 10 PFF1123* SLEEVE ASSY 1 1 1 1 1 1 1 1
PAL1927 STEEL BALL [ 1.5] ¼’’ 2 2 2 2 2 2 2 2
11 11
PAL1928 STEEL BALL [ 2] 4mm
PFE1412 BIT SOCKET A ¼’’ 1 1 1 1 1 1 1 1
12 12
PFE1403 BIT SOCKET E 4mm
13 13 PFE1413 HOLDER PIN 1 1 1 1 1 1 1 1
14 X PFE1946 BEND WASHER 1 1 1 1 1 1
15 X PFE1920 THRUST BEARING [F5-11] 1 1 1 1
16 X PFE1907 BALL BEARING [MR105] 1 1 1 1 1 1
17 14 PFE1327 NEEDLE PIN 3 3 3 3 3 3 3 3
X 15 PFE1113 MAGNET HOLDER ASSY 1 1
18 X PFE1118 BEARING COVER ASSY [LEVER] 1 1 1 1 1 1
X 16 PFE1119 BEARING COVER ASSY [PUSH] 1 1
19 X PFFZ511A* SENSOR ASSY [LEVER] 1 1 1 1 1 1
X 17 PFFZ512A* SENSOR ASSY [PUSH] 1 1
20 18 PSW2211 SCREW [M PHILIPS M2.3x8L] 2 2 2 2 2 2 2 2
21 X PFE1908 BALL BEARING [MF105] 1 1 1 1 1 1
19 PFE1319 SLIDE RING 1 1 1 1 1 1
22 X PFF1319 SLIDE RING 1 1
X 20 PFE1114 PUSH SHAFT ASSY 1 1
X PFE1302 SHAFT 1 1 1 1 1 1
23 PFF1121 SHAFT ASSY GXS 1 1
24 21 PAL1932 STEEL BALL [ 4] 2 2 2 2 2 2 2 2
25 22 PFE1910 ROLLER 2 2 2 2 2 2
PFE1105 CLUTCH ASSY 1 1 1
23 PFE1106 CLUTCH ASSY B 1 1 1
PFF1105 CLUTCH ASSY GXS80 1
26 X PFF1106 CLUTCH ASSY B GXS120 1
27 24 PSW2207
SCREW [M PHILIPS M2.6x6L FLAT
HEAD] 6 6 6 6 6 6 6 6
28 25 PFE1201A GEAR CASE 1 1 1 1 1 1 1 1
PFE1211 2ND IDLE GEAR 80 4 4 4 4
29 26
PFE1212 2ND IDLE GEAR 120 4 4 4 4
30 27 PFE1915 CENTER PIN 1 1 1 1 1 1 1 1
PFE1102 1ST GEAR HOLDER ASSY 80 1 1 1 1
31 28
PFE1103 1ST GEAR HOLDER ASSY B 120 1 1 1 1
PFE1216 1ST IDLE GEAR 80 4 4 4 4
32 29
PFE1217 1ST IDLE GEAR B 120 3 3 3 3
33 30 PFE1947 WASHER 1 1 1 1 1 1 1 1
34 31 PFE1903 SNAP RING [R21] 1 1 1 1 1 1 1
PFE1235 PINION GEAR 1 1 1 1
35 32
PFE1236 PINION GEAR B 1 1 1 1
41 41 PSW2205 SCREW [M PHILIPS M2.3x5L] 1 1 1 1 1 1 1 1
42 42 QFE0325A EARTH WIRE 1 1 1 1 1 1 1 1
43 43 PFF4005A MOTOR SET 1 1 1 1 1 1 1 1
44 44 PSW2202 SCREW [M PHILIPS M2.6x5L] 2 2 2 2 2 2 2 2
45 45 PFF1120D UPPER HOUSING ASSY 1 1 1 1 1 1 1 1
QFF0406A WINDOW LABEL GX 1 1 1 1 1 1
QFF0408A WINDOW LABEL GXT 1 1
46 46
QFF0407A WINDOW LABEL GX+
PFF1115 LEVER ASSY 1 1 1 1 1 1
47 X
PFF1115B LEVER ASSY ESD 1 1 1 1 1 1
PFF1819 ATTACHMENT 1 1
X 47
PFF1819B ATTACHMENT ESD 1 1
48 48 PFFZ537A** AMP PCB SET FOR AS 1 1 1 1 1 1 1 1
PFFZ538A** CONTROL PCB SET FOR AS GX, GXS 1 1 1 1 1 1
49 49
PFFZ539A** CONTROL PCB SET FOR AS GXT 1 1
*If your tool serial number is < to 7117001, you must order sleeve assy ( item 10) and sensor assy ( item 19 for lever
start or item 17 for push to start) by pair. They can not be replaced separately.
**Items 48 and 49 have to be ordered by pair. They can not be replaced separately.

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 18
50 50 PFF1723 BUTTON CAP 1 1 2 2 1 1 1 1
51 51 PFF1824C NUT 1 1 1 1 1 1 1 1
52 52 PFF1719 CONNECTOR LOCK COVER 1 1 1 1 1 1 1 1
53 53 PFF1824 NUT 1 1 1 1 1 1 1 1
54 54 PAL1840 LEVER PIN 1 1 1 1
55 X PFE1841 LEVER SPRING 1 1 1 1 1 1
56 55 PFF1830 SWITCH LOCK 1 1 1 1 1 1 1 1
57 56 PFF1842A STAND OFF 2 2 2 2 2 2 2 2
58 57 PELZ318 6PIN CONNECTOR N 1 1 1 1 1 1 1 1
59 58 PFF1802 HOUSING NUT 1 1 1 1 1 1 1 1
60 59 PFF1828B LOWER HOUSING 1 1 1 1 1 1 1 1
61 60 PSW2602 SCREW [T TORX 2.6x10L] 3 3 3 3 3 3 3 3
62 61 PFF1130 SWITCH COVER ASSY 1 1 1 1 1 1 1 1
63 62 PAL1803 HOOK 1 1 1 1 1 1 1 1
64 63 PELZ932A CABLE 6PIN [3M,STANDARD] 1 1 1 1 1 1 1 1
A X PFF1306 SHAFT [CAM CLUTCH TYPE] GXS 1 1
PELZ318 6PIN CONNECTOR : For PELZ932A CABLE 6PIN only.(Applied from s/n.8077011)

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 19

DOGA BRUSHLESS ELECTRIC SCREWDRIVERS / GX SERIE 20
06.17.60007.06/10
