Dogtrace d-control 600 User manual

EN
User guide
d–control 600,1000,1600
Electronic training collar

2
Declaration of Conformity
We:
VNT electronics s.r.o.
Smetanovo náměstí 104
570 01, Litomyšl
IČO: 64793826
declares under own responsibility that the product:
Electronic training collar
Dogtrace d-control 600, 1000 and 1600
is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC from 9. 3. 1999
meets requirements of General Licence of The Czech Telecommunication Oce according to
general licence no. VO-R/10/05.2014-3, and corresponds to the following standards:
ETSI EN 301 489-1 V1.9.2
ETSI EN 301 489-3 V1.6.1
ETSI EN 300 220-2 V.2.4.1
ETSI EN 60950-1:2006
The product is safe under conditions of standard use in accordance with the user guide.
The Declaration of Conformity is based on following dates:
Measuring report no.: 6440-7600/2008 issued by certicated laboratory
no.1103 VTÚPV Vyškov
Measuring report no.: 6440-697/2008 issued by certicated laboratory
no.1103 VTÚPV Vyškov
This declaration of Conformity is created in exclusive responsibility of producer.
In Litomyšl 28.8.2014
Ing. Jan Horák
executive director
Tel.: [phone]
[e-mail]
www.dogtrace.com

3
Hereby, VNT electronics s.r.o. , declares that this d-control 600, 1000, 1600 is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Thank you for purchasing the product Dogtrace d-control 600, 1000 or 1600
from VNT electronics s.r.o., Czech Republic.
Before using your product, please read the instructions in this user guide carefully
and keep it for future reference.
The electronic training collars d-control are intended only to train animals. They are not
intended to harm, injure or to cause fear.
Do not use the electronic training collars for dogs with health problems (e.g. heart
disease, epilepsy, etc.) or for dogs with behavioral disorders (aggressive dogs etc).
The collar should never be worn for more than 12 hours a day. Long-term eect of
contact points on the dog’s skin can cause skin irritation. If a rash or sore skin is found,
do not use the collar until it has healed.
Never connect a leash to the electronic collar; this could cause excessive pressure on the
contact points or mechanical damage of the receiver.
In case of any problems or for further advice do not hesitate to contact a professional
trainer.
Do not place the transmitter close to objects which are sensitive to magnetic eld, this
could cause a permanent damage.
Receiver and transmitter batteries need to be replaced every two years, even if the kit
has not been used. Never leave at batteries inside of the device - it could damage your
device.
The person with a personal instrument to support heart activity (pacemaker,
debrillator) must respect the relevant precautionary measures. The d-control emits a
certain stationary magnetic eld.
Important notice

4
ECMA
VNT electronics s.r.o., professional producer of the dog training equipment, which is
manufactured and sold under the brand name Dogtrace, is a proud and active member of
the Electronic Collar Manufacturers Association.
ECMA was founded in Brussels in 2004 as a result of increasing awareness from dierent
manufacturers concerning the necessity of regulating their industry.The main target of the
association is to develop and produce reliable training systems of high quality, which are
safe for the animals and improve the communication between pets and their owners. All
members of the ECMA provide you with both technical and training guides that contain
instructions and advice for safe use of electronic training equipment and enable all dog
owners to use the training systems in an eective, responsible and humane way. All ECMA
member´s products meet the latest technical requirements which ensure minimum
production standards and safety features and enable training while protecting animal
welfare.
The ECMA is convinced that the electronic training collars are eective and humane
training tools when used responsibly and combined with an appropriate reward.
For more information please visit www.ecma.eu.com

5
Contents
Important notice................................................................ 3
ECMA........................................................................... 4
Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction .................................................................... 6
Package contents ............................................................... 7
Optional accessories ............................................................ 7
Product description............................................................. 8
Transmitter preparation ......................................................... 9
Receiver preparation........................................................... 10
Programming (pairing) of the transmitter and the receiver...................... 12
The basics of a training collar usage............................................ 14
External remote control - one touch............................................ 17
For the best results ............................................................ 18
Troubleshooting ............................................................... 19
Maintenance .................................................................. 20
Technical specications ........................................................ 21
Warranty terms and conditions................................................. 22
Certicate of warranty ......................................................... 24

6
Introduction
The electronic training collar Dogtrace d–control, consisting of the transmitter and the
receiver, is a modern, safe, reliable and eective training tool. d-control training collar
enables you to make corrections that are suited to your dog‘s temperament and the
distraction level of the moment, at the right time and with maximum training eciency.
However, making corrections to your dog’s unwanted behaviour is only a small part of
what you can do with the d-control.
Features of d-control 600, 1000 and 1600
The electronic training collars d-control 600, 1000 and 1600 feature with audible beeb
tone, electronic stimulation impuls and booster function. Booster function allows you to
select any intensity of stimulation impulse (00-30), but normally higher than selection of
the standard stimulation impulse. This button is a quick option for dealing with extreme
situations, when your dog on a standard set level of stimulation impulse did not respond
and you need to act promptly with a higher intensity of the stimulation impulse.
Transmitter and waterproof receiver is designed mainly for a professional sport and police
training, but can be also used in everyday life during common training. It is possible to
use the d-control to train one or two dogs at once.
range up to 600, 1000 or 1600 m
waterproof receiver
audible beep tone
momentary and continuous stimulation
30 stimulation levels
expands to train two dogs
backlit LCD

7
Package contents
Optional accessories
transmitter with belt clip
reciver (with the strap)*
2 pairs of contact points (12 mm and 17 mm)*
1 lithium battery CR2 3V*
2 alkaline batteries AA 1,5 V *
test discharge lamp*
lanyard
user guide and certicate of warranty
DVD - How to train your dog
carrying case
(* 2 x in set d–control 602, 1002, 1602)
spare rubber seal for the receiver
spare screws
spare contact points (8, 10, 12, 17, 21 mm)
dummy receiver (with the strap)
woven and plastic collars - various colours
spare batteries

8
1 2
5
3
4
Product description
TRANSMITTER RECEIVER WITH THE STRAP
LCD PANEL
TRANSMITTER − 1 - LCD panel, 2 - button for booster, 3 - button for stimulation
impulse, 4 - button for audbile beep tone, 5 - button for power ON/OFF,
6 - buttons for stimulation level selection, 7 - buttons for dog selection 1 or 2
RECEIVER WITH THE STRAP − 1 - target (half-round red indicator),
2 - LED indicators, 3 - contact points, 4- strap
LCD PANEL - DISPLAY − 1 - transmission indicator, 2 - battery power indicator,
3 - indicator of stimulation level, 4 - indicator of dog selection 1 or 2,
5 - indicator of nick (A) or continuous (B) stimulation impuls
2
3
4
7
6
5
1
6
7
4
12
3

9
Transmitter preparation
Battery insertion and replacement
1. Screw out screw from the battery cover using a cross-head screwdriver and carefully
remove the lid.
2. Insert two alkaline AA batteries into the battery compartment with a correct polarity
(according to the polarity indicated with the “+” symbol in the battery compartment).
Wrong polarity may damage the unit.
3. Put the battery cover back and screw in the screw adequately. Checking the transmitter
battery status.
The battery power indicator on LCD shows the battery status:
– fully charged battery
– medium charged battery
– at battery
If the battery is at, insert new AA alkaline batteries into the battery compartment. Check
that the transmitter is working corectly.
Switching ON/OFF
To turn on: press down for 1 second the ON/OFF button , turning ON is indicated
by backlit LCD.
To turn o: press down for 1 second the ON/OFF button , turning OFF is indicated
by extinction of the LCD.

10
Battery insertion and replacement
1. Screw out 4 screws from the battery cover using a cross-head screwdriver and remove
the lid.
2. Insert the lithium CR2 3V battery into the battery compartment with a correct polarity
(according to the polarity indicated with the “+” symbol in the battery compartment –
see the Fig.). A wrong polarity may damage the unit.
When you insert the battery for the rst time, or if the
battery is removed longer than a few tens of minutes, you
will hear an audible beep tone indicating the correct
installation of the battery.
3. Make sure that the rubber seal is clean and correctly
seated in its groove. Clean any dirt from the seal.
4. Put the battery cover of the receiver back and screw in the
4 screws adequately.
Receiver preparation
Battery polarity indicator
Note: When you replace the battery quickly, you
may not hear the audible beep tone of the collar.
Checking the receiver battery status
The status of the battery is indicated by LED indicators on the side of the receiver.
(see chapter: Product description – Receiver)
The batterry is fully charged – when switched on, green LED is ashing.
The battery is low – when switched on, red LED is ashing.
When the battery is low or at, insert a new CR2 3V lithium battery into the receiver.
Check the correct function.

11
Receiver preparation Switching the receiver ON / OFF
To turn the receiver ON / OFF ( or for programming the transmitter with the receiver) is used
a magnetic switch, marked with the red target on the receiver. The receiver is activated
when the magnet in bottom of the transmitter, is enclosed to the red target on the receiver.
Switching ON
Move the red target of the receiver towards the bottom of the transmitter for 1 second
(see the Fig.). The red LED indicator of the receiver will lit up, afterwards the green LED
indicator will start blinking. The receiver is prepared for use.
Switching OFF
When switching OFF, follow the same steps as when switching ON.
Move the red target of the receiver towards the bottom of the transmitter - the green LED
indicator of the receiver will lit up, afterwards the red LED indicator will lit up.
Caution: To extend the battery life, it is necessary to turn
o the receiver and transmitter whenever the training of
your dog is nished. If you do not use the device for a
long time, we recommend you to remove the batteries
out.
IMPORTANT: When turning the receiver ON hold
the red target of the receiver close to the red target
of the transmitter for about 1 second. When the
targets are close to each other for longer than
5 seconds the receiver will switch to the pairing
(programming) mode of the transmitter with the
receiver. This programming mode is indicated by
alternate ashing of the red and green LED indicator.
If this occurs, follow the chapter Programming
(pairing) the transmitter with the receiver.
The position where the receiver
is turned ON/OFF and where
the transmitter is being paired
with the receiver.

12
Programming (pairing) of the transmitter and the receiver
Each transmitter has its own RF operational code. The pairing needs to be done to make
the receiver and transmitter operate together. When you receive a new set the pairing is
done by manufacturer. The pairing is done, when you need to use dierent transmitter
or receiver (for example when bought a new one).
The transmitter is made for training of two dogs, so you can pair it with two receivers. Use
the buttons /to choose the right dog.
Pairing of the button with the rst receiver
1. Turn ON your transmitter.
2. The receiver has to be turned OFF.
3. Press the button for the rst receiver choice.
4. Move the lower part of the transmitter to the target on your receiver (see the Fig. on
page 11) and hold in position so the green LED is steadily lit. After approximately
5 seconds it will switch to the pairing /programming mode, indicated by ashing of
the red and green LED at the same time (4x).
5. Then take your transmitter away from the receiver and press down the audible beep
tone button on your transmitter. If you hear the beep tone the pairing has been
successful.
Pairing of the button with the second receiver
Press the button for the second receiver choice and follow the steps as for the rst
receiver above (this can be followed when you use d-control 600, 1000 or 1600 with a
new purchased receiver or when you purchased d-control 602, 1002 or 1602).
IMPORTANT: Before programming is started make sure that no one else uses his/her
d–control in your neighbourhood. Your receiver could randomly receive the code
from another transmitter and get paired with it. If this happens, program your receiver
once again, using your transmitter.

13
Reprogramming of your receiver
The receiver can be programmed repeatedly without restraint using the same transmitter
or another (see the section Programming (pairing) of the transmitter and the receiver).
Choice of the contact points
The stimulation is transferred on your dog‘s skin through the steel contact points of the
receiver. Each set contains 2 types of contact points. Sucient length of the contact points
has to have a contact with the dog‘s skin, enabling the device to operate correctly. If you
have a short-haired dog use the 12 mm contact points, if you have a long-haired dog
replace them with the longer 17 mm contact points supplied in the kit. Screw the contact
points onto the screws of the receiver - see the picture: Receiver in the chapter Product
description. Tighten them manually and carefully (do not use a key – this could damage the
product).
Fitting the collar
The strap with the receiver (receiver collar) must be tightened enough so that the contact
points are in contact with the skin of the dog. We recommend you to t the collar on the
standing dog. When you can t two ngers between the collar and your dog‘s neck, the
collar with the receiver are tightened enough. If a dog has long or thick hair, it is suitable to
Example: Button is paired with 3 receivers, they can be programmed one by one or
we can set all 3 in pairing regime and then press button for audible beep tone. All these
receivers will perform the same action at the same time when pressing function button.
This can be used for two collars on the neck of one dog, or for the training of higher
number of dogs, where we give the same commands to all of them at the same time.
TIP: If your dog has very long hair, you can order 21 mm long contact points. When
your dog has a dry skin in the area where the contact points are, it is good to lubricate
the dog‘s skin with a vaseline, hand cream, or baby oil - which enables a correct
transfer of stimulation impulses.
TIP: It is possible to program an unlimited number of receivers to a one transmitter.

14
The basics of a training collar usage
The trainer’s elementary knowledge of the dog training is the prerequisite for using
the training collar.
If you don´t have this knowledge, we recommend you to contact a training center, a
cynology club, or a school for dogs where you will learn the basic communication with
your dog.
You can start using the collar for the 6 months old dog, which have undergone the
basic training and is familiar with basic obedience commands including „sit“, „down“,
„stay“ or at least „stop it“, „leave it“.
Require these commands along with the audible beep tone, so your dog will create a
connection between them.
After a command that is successfully executed, you should always reward or encourage
your dog, so the dog will be happy to fulll your commands and a desire to fulll your
commands will grow.
You must not consider the executed command as the absolute obviousness and
punish disobedience - your dog would soon lose an interest.
If you are not sure that your dog will obey you after recall, start training on a tracking
rope.
Your dog will have to get used to the collar; let the dog wear the collar for a few days,
WARNING: If the collar is too loose, the receiver is likely to move and the repeating
friction can irritate the skin of your dog. Furthermore, in this case is not ensured a
reliable contact of contact points with the skin and a proper function of the training
collar. We do not recommend to leave the collar positioned at the same place for
more than several hours, because it could irritate the skin. If it is necessary to wear the
collar for long periods, change regularly the position on the neck of your dog. A collar
with a receiver that is overly tight, can cause pressure sores on the skin in the contact
area of the contact points. If this happens, do not use the training collar until all traces
of irritation are gone.
trim the hair in the area of the contact points or to switch to the longer contact points to
ensure a consistent contact.

15
but do not use it so that your pet does not discover the connection with its attachment
and eects.
Armative and ecient training requires some time: don‘t hurry!
Select a well-known environment your dog is used to.
Choose the right moment to press the button; exactly at the moment when your dog
does something what is not allowed.
In case of any problems and for further advice, please do not hesitate to contact a
professional trainer.
Transmitter – button functions
Audible beep tone
The receiver on dog‘s collar begins to emit an audible beep tone (an acoustic signal). This
command can precede a stimulation impuls. It is also a very eective warning tool. You
can use the acoustic signal instead of the command: Come! / Heel! In this case it replaces
a whistle, the dog always perceives its sound in the same intensity. It‘s very important
always to use the beep sounds in the same way in order not to confuse your dog. While
transmitting the audible beep tone, the green LED indicator of the receiver is emitting a
light.
Stimulation
This function enables you to send your dog a warning in the form of an electronic
stimulation impulse transmitted by two contact points located in the receiving collar.
Purpose of the stimulation is not to hurt the dog. Impulse is very uncomfortable for dog,
and the dog makes very soon a link between the command, beep tone and the
uncomfortable feeling on the neck. Eventually you will only need minimum number of
the stimulation impulses because your dog will connect them very quickly with
disobeying your commands. During the pressing of the stimulation button the red
indicator light on the receiver will be ON. The length of stimulation impulse is limited to
a maximum of 8 seconds even when button is pressed for long period.
The choice of stimulation level:
It is important to choose correctly the stimulation level for your dog, that is why it is nely
adjustable in 30 levels. Each dog has dierent sensitivity, the right stimulation level can´t

16
be set by guess. Start from the lowest level. When your dog doesn't react to the low level
stimulation, gradually set the level higher, and carry on until you see slight reaction.
Stimulation impulse should never create fear or pain.
The choice of momentary (nick) or continuous stimulation impulse
Stimulation impulse features functions A and B, which are switched by repetitive press of
button /or 2 for the choice of the dog and can be used for all the levels of set
stimulation.
Continuous impulse - B
When you hold the stimulation button pressed, the stimulation is emitted for whole
period of time, but maximum 4 seconds. Continuous stimulation is to be used as a rst
step of the training. For the rst time it should be used in the well known area. As the
stimulation is longer and continuous you are better to use lower intensity and rather than
the intensity of the impulse use its length.
Momentary (nick) impulse - A
No matter how long the stimulation button is pressed, the transmitter emits only a
momentary (nick) impulse. This function is used for correction of dog behavior. Nick
impulses are normally used in advanced training, when the dog has been trained with
continuous impulses. It is possible that you will need to use a higher level of stimulation
than with continuous impulse.
Booster - preset stimulation
This function enables you to use dierent preset stimulation level than it is set on the
button of the main stimulation impulse . Function booster can also simulate a
function of the continuous impulse or help to solve crisis situations. Stimulation is emitted
as long as the booster button is pressed, but maximum 8 seconds.
On the booster button can be set any intensity of the stimulation (00-30) dierent to
what you have selected for main stimulation button. The number on the display shows
main stimulation button setting. Checking intensity of the booster button can be made
only when the booster button is pressed. Beware: Do not check the intensity, when the
dog wears the collar!

17
External remote control - one touch
The external remote is very helpful addition of the transmitters d-control 610, 1010,
1610. d-control models equipped with this accessory are suitable especially for
professional dog sport and hunting training. They may be also used while jogging,
cycling, horse riding etc.
These models have same functions as basic models
d-control (audible beep tone, stimulation impuls and
booster). Standard models d-control are not edited
for the connection of the external remote.
Without any need of manipulation with transmitter
and by pressing one button only you activate the
pre-set stimulation impuls. Other functions can be
activated by pressing transmitter buttons.
Booster button setting:
Press continuously button for the choice of the dog 1 or 2 (button for receiver 1 or
for receiver 2 according to required pairing), until you see on LCD symbol 1/2
ashing. With the buttons choose requiered intensity of the stimulation
impulse on the booster button. Conrm the choice by short button press /.
Control buttons
These buttons are used for prompt setting of the stimulation intensity in the receiving
collar. It is possible to set up 30 levels, which are indicated by numbers 1–30 on the LCD.
When the stimulation level setting is changed, the LCD will lit up for 3 seconds.
Control buttons
These buttons are used for selection of the dog 1 or 2. You can set dierent stimulation
level for each dog, which will stay saved when switched over to another dog.

18
For the best results
The training collar d-control 600, 1000 and 1600 can be used up to 600, 1000, 1600 m
working range. The maximum range depends on many factors - weather, terrain,
vegetation and so on. To ensure maximum working range of the device:
Do not cover the transmitter antenna.
When transmitting commands, hold the transmitter in a vertical position, away from
the body and above your head.
Check the battery in the transmitter and in the receiver, replace it if necessary.
maximum range regular range minimum range
Using training collar in winter
When using d-control in winter, please keep in mind:
Low humidity – causes less skin conductivity. It is necessary to provide better
conductivity between the contact points of the receiver and the dog‘s skin. This can be
achieved by lubricating the dog’s skin in the area of contact with vaseline, baby oil, hand
lotion, etc.

19
1. Read again this user guide and make sure the problem is not caused by a at battery or
incorrect use.
2. Make sure the batteries are inserted with the correct polarity.
3. If the transmitter does not communicate with the receiver, try to program
communication - see chapter: Programming (pairing) of the transmitter and the
receiver.
4. If it seems, that the dog does not respond to the stimulation impulse:
Check again the battery in the transmitter and in the receiver.
Test the receiver‘s functions with a test discharge lamp (see 5th paragraph of this
chapter).
Check whether you have choosen correct length of the contact points (see chapter:
Choosing the contact points) and ensure contact points are well tightened and in
contact with your dog‘s skin (see chapter: Fitting the collar).
If the dog has dry skin, moisten the skin.
5. Check the correct function of the stimulation impulse.
By using test discharge lamp you can easily check correct function of the stimulation
impulse:
Make sure that the receiver is turned OFF.
Place the test discharge lamp in contact with each of the contact points - loosen the
contact points, insert the lamp‘s outlets under the contact points so they are in the
Troubleshooting
Thicker fur dog – it is necessary to tighten the collar so that the permanent contact
with the dog‘s skin is ensured. If the fur is too thick, it is recommended to cut the hair or
choose a longer type of contact points.
Battery properties change – temperatures below 0 °C slow down chemical reactions
in batteries. To ensure a performance of repetitive stimulation impulses (especially of
higher levels), it is recommended to insert a new battery into the receiver for the winter
time. During the training, observe continuously dog‘s reactions and increase the
stimulation level as needed.

20
It is important to keep the device clean. Never use volatile substances eg.: thinner, gasoline
or other cleaners. To clean your d-control use a soft, damp cloth and neutral detergent if
necessary.
The transmitter and the receiver (collar) is waterproof only on condition of the good
state of the seal.We recommend you to replace the rubber seal, which is placed under
the cover of the battery compartment of the transmitter and the receiver, once a year.
Clean the rubber seal and make sure that the rubber seal is correctly seated in its groove
every time you change the batteries; tighten the screws using adequate power.
If the device is not used for a longer time, take out the batteries from the battery
compartment.
touch with the screw and tighten them (see
picture).
Turn ON the transmitter and the receiver.
Select stimulation function button.
The test discharge lamp will increase a light
intensity when increasing stimulation level.
6. If the problem still persists, contact the dealer.
Maintenance
Note: When is the level set to 00 there is no
stimulation. When you use test discharge lamp
the stimulation impulse is weaker than without
discharge lamp.
Picture showing test lamp attachment
