Doka Ringlock Operator's manual

© by Doka GmbH, A-3300 Amstetten
999817902 10/2022
en-GB
-
Ringlock
User Information
Instructions for assembly and use (Method statement)
© by Doka GmbH, A-3300 Amstetten

2999817902 - 10/2022
User Information Ringlock

User Information Ringlock
3999817902 - 10/2022
Contents
4Introduction
4Elementary safety warnings
7Declaration of Conformity and Approvals
8Foreword
9Quality Factors & Designation
10 Safety Guidelines and Safe Use
14 Ringlock Overview
14 Ringlock Node Connection
15 Instructions for Scaffolding Construction
16 Supplementary Components
17 Component Identification
19 Color Coded Components
20 Scaffold
20 Erection Guidelines
22 Safety Harness Connection Points
26 Falling Object Protection
27 Assembly of Facade Scaffold
30 Ground Adjustment
31 Bridging Solutions
32 Stair Way Access Assembly on a Facade
Scaffold
34 Ladder Access
35 Brick Guard
36 Corner solutions
38 Circular Scaffolds
39 Birdcage Scaffolding
41 Plank Arrangement
43 Raised Ledger System (RLS)
44 Suspended Scaffolding
46 Cantilever
48 Gaps in Platforms
50 Methods of Stabilising Scaffolds
52 Rebar Scaffold
53 Mobile Scaffolds
54 Ringlock Shoring
55 Erection Guidelines for 4 Leg Stair Tower
56 4-Leg Aluminum Stair Tower General
Arrangement
57 4 Leg Aluminum Stair Tower Erection
Guidelines Steps
60 Ringlock Aluminum Stair Tower (4 Leg)
Layout
61 Ringlock Stair Tower (4 Leg) Quantity Lists
62 Erection Guidelines for 10 Leg Stair Tower
63 Stair Tower General Arrangement (10 Leg)
64 Notes on Safe Use of Stair Towers
65 10-Leg Stair Tower Erection Guidelines
Steps
68 Ringlock Stair Tower (10 Leg) Layout
69 Stair Tower (10 Leg) Quantitiy Lists
70 General
70 Lifting by crane
72 Tying and Bracing Patterns
77 Additional Safety Guidelines
80 Guide to Dismantling Ringlock Scaffolds
81 Comparison of the article list of Doka and AT-
PAC
86 Article list

4999817902 - 10/2022
Introduction User Information Ringlock
Introduction
Elementary safety warnings
User target groups
▪This booklet is aimed at all persons who will be work-
ing with the Doka product or system that it describes.
It contains information on the standard design for
setting up this system, and on correct, compliant uti-
lisation of the system.
▪All persons working with the product described
herein must be familiar with the contents of this
booklet and with all the safety instructions it contains.
▪Persons who are incapable of reading and under-
standing this booklet, or who can do so only with dif-
ficulty, must be instructed and trained by the cus-
tomer.
▪The customer is to ensure that the information mate-
rials provided by Doka are up to date and available
to all users, and that they have been made aware of
them and have easy access to them at the usage
location.
▪In the relevant technical documentation and scaf-
folding utilisation plans, Doka shows the workplace
safety precautions that are necessary in order to use
the Doka products safely in the usage situations
shown.
In all cases, users are obliged to ensure compliance
with national laws, standards and regulations
throughout the entire project and to take appropriate
additional or alternative workplace safety precau-
tions where necessary.
Hazard assessment
▪The customer is responsible for drawing up, docu-
menting, implementing and continually updating a
hazard assessment at every job-site.
This booklet serves as the basis for the site-specific
hazard assessment, and for the instructions given to
users on how to prepare and utilise the system. It
does not substitute for these, however.
Remarks on this booklet
▪This document can be used as general Instructions
for Assembly and Use (Method Statement) or be
incorporated into site-specific Instructions for
Assembly and Use (Method Statement).
▪The graphics, animations and videos in this doc-
ument or app sometimes depict partially assem-
bled assemblies and may require additional
safety equipment and/or measures to comply
with safety regulations.
The customer must ensure all applicable regulations
are complied with, even if they are not shown or
implied in the graphics, animations and videos pro-
vided.
▪Individual sections contain further safety
instructions and/or special warnings as applica-
ble.
Planning
▪Provide safe workplaces for those using the scaffold
(e.g. for when it is being erected/dismantled, modi-
fied or repositioned etc). It must be possible to get to
and from these workplaces via safe access routes!
▪If you are considering any deviation from the
details and instructions given in this booklet, or
any application which goes beyond those
described in the booklet, then revised static cal-
culations must be produced for checking, as well
as supplementary assembly instructions.
Regulations; industrial safety
▪All laws, Standards, industrial safety regulations and
other safety rules applying to the utilisation of our
products in the country and/or region in which you
are operating must be observed at all times.
▪If a person or object falls against, or into, the side-
guard component and/or any of its accessories, the
component affected may only continue in use after it
has been inspected and passed by an expert.

User Information Ringlock Introduction
5999817902 - 10/2022
Rules applying during all phases of
the assignment
▪The customer must ensure that this product is
erected and dismantled, reset and generally used for
its intended purpose in accordance with the applica-
ble laws, standards and rules, under the direction
and supervision of suitably skilled persons.
These persons' mental and physical capacity must
not in any way be impaired by alcohol, medicines or
drugs.
▪Doka products are technical working appliances
which are intended for industrial /commercial use
only, always in accordance with the respective Doka
User Information booklets or other technical docu-
mentation authored by Doka.
▪The stability and load-bearing capacity of all compo-
nents and units must be ensured during all phases of
the construction work!
▪Strict attention to and compliance with the functional
instructions, safety instructions and load specifica-
tions are required. Non-compliance can cause acci-
dents and severe injury (risk of fatality) and consid-
erable damage to property.
▪Sources of fire in the vicinity of the scaffold, specially
hatch decks with plywood top, are prohibited. Heat-
ers are permissible only when used correctly and sit-
uated a correspondingly safe distance from the scaf-
fold.
▪Customer must give due consideration to any and all
effects of the weather on the equipment and regards
both its use and storage (e.g. slippery surfaces, risk
of slipping, effects of the wind, etc.) and implement
appropriate precautionary measures to secure the
equipment and surrounding areas and to protect
workers.
▪All connections must be checked at regular intervals
to ensure that they are secure and in full working
order.
In particular threaded connections and wedged con-
nections have to be checked and retightened as nec-
essary in accordance with activity on the jobsite and
especially after out-of-the-ordinary occurrences (e.g.
after a storm).
▪It is strictly forbidden to weld Doka products – in par-
ticular anchoring/tying components, suspension
components, connector components and castings
etc. – or otherwise subject them to heating.
Welding causes serious change in the microstruc-
ture of the materials from which these components
are made. This leads to a dramatic drop in the failure
load, representing a very great risk to safety.
It is permissible to cut individual tie rods to length
with metal cutting discs (introduction of heat at the
end of the rod only), but it is important to ensure that
flying sparks do not heat and thus damage other tie
rods.
The only articles which are allowed to be welded are
those for which the Doka literature expressly points
out that welding is permitted.
Assembly
▪The equipment/system must be inspected by the
customer before use, to ensure that it is in an accept-
able condition. Steps must be taken to exclude com-
ponents that are damaged, deformed, or weakened
due to wear, corrosion or rot (e.g. fungal decay).
▪Using our safety and scaffolding systems together
with those of other manufacturers can create risks
that may lead to injury and damage to property. This
requires separate verification by the user.
▪The equipment/system must be assembled and
erected in accordance with the applicable laws,
standards and rules by trained customer personnel
whilst maintaining any applicable safety inspections
that may be required.
▪It is not permitted to modify Doka products; such
modifications constitute a safety risk.

6999817902 - 10/2022
Introduction User Information Ringlock
Transporting, stacking and storing
▪Observe all country-specific regulations applying to
the handling of scaffolding. For system scaffolding
the Doka slinging means stated in this booklet must
be used – this is a mandatory requirement.
If the type of sling is not specified in this document,
the customer must use slinging means that are suit-
able for the application envisaged and that comply
with the regulations.
▪When lifting, always make sure that the unit to be
lifted and its individual parts can absorb the forces
that occur.
▪Remove loose parts or secure them so that they can-
not slip out of position and drop.
▪When lifting scaffolding or scaffolding accessories
with a crane, no persons must be carried along, e.g.
on working platforms or in multi-trip packaging.
▪All components must be stored safely, following all
the special Doka instructions given in the relevant
sections of this document!
Maintenance
▪Only original Doka components may be used as
spare parts. Repairs may only be carried out by the
manufacturer or authorised facilities.
Miscellaneous
The weights as stated are averages for new material;
actual weights can differ, depending on material toler-
ances. Dirt accretions, moisture saturation, etc. can
also affect weight.
We reserve the right to make alterations in the interests
of technical progress.
Eurocodes at Doka
The permissible values stated in Doka documents
(e.g. Fperm = 70 kN) are not design values (e.g. FRd =
105 kN)!
▪It is essential to avoid confusing permissible values
with design values!
▪Doka documents will continue to state the permissi-
ble values.
Allowance has been made for the following partial fac-
tors:
▪γF= 1.5
▪γM, timber = 1.3
▪γM, steel = 1.1
▪kmod = 0.9
Consequently, all the design values for an EC design
calculation can be determined from the permissible val-
ues.
Symbols used
The following symbols are used in this document:
DANGER
This is a notifier drawing attention to an
extremely dangerous situation in which non-
compliance with this notifier will lead to death
or severe, irreversible injury.
WARNING
This is a notifier drawing attention to a dan-
gerous situation in which non-compliance
with this notifier can lead to death or severe,
irreversible injury.
CAUTION
This is a notifier drawing attention to a dan-
gerous situation in which non-compliance
with this notifier can lead to slight, reversible
injury.
NOTICE
This is a notifier drawing attention to a situa-
tion in which non-compliance with this noti-
fier can lead to malfunctions or damage to
property.
Instruction
Indicates that actions have to be performed
by the user.
Sight-check
Indicates that you need to do a sight-check
to make sure that necessary actions have
been carried out.
Tip
Points out useful practical tips.
Reference
Cross-references other documents.

User Information Ringlock Introduction
7999817902 - 10/2022
Declaration of Conformity and Approvals
Ringlock is a modular scaffold system, that enables
users to quickly and efficiently erect, use, and disman-
tle temporary work structures. The Ringlock system is
based on the trademarked AT-PAC Ringlock system,
which in turn, conforms to European standards
EN 12810 and EN 12811.
Ringlock is also compliant with The National Access &
Scaffolding Confederation (NASC) Code of Practice for
System Scaffold within the United Kingdom.
Please refer to table in the chapter 'Comparison of the
article list of Doka and AT-PAC'.
The Ringlock Scaffolding System is certified by the
Deutsches Institut für Bautechnik (DIBt), under
approval number Z-8.22-992.
98179-000-01

8999817902 - 10/2022
Introduction User Information Ringlock
Foreword
These instructions for assembly and use regulate the
assembly, modification and dismantling of the Ringlock
modular scaffolding system from Doka. This document
provides general information and instructions as well as
safety measures and necessary actions when using the
Ringlock modular scaffolding system. Further possible
assembly variants and applications can be found in the
additional technical documents from Doka.
Doka's Ringlock modular scaffolding system enables
users to Assemble, use and dismantle temporary work
scaffolding quickly and efficiently. The Ringlock modu-
lar scaffolding system meets the requirements of
EN 12810 and EN 12811 and has the German general
building authority (DIBT) approval Z-8.22-992. The Rin-
glock modular scaffolding system is also equally suita-
ble for erecting shoring structures in accordance with
EN 12812.

User Information Ringlock Introduction
9999817902 - 10/2022
Quality Factors & Designation
Quality Factors
All of Doka Ringlock products are engineered to meet
the highest quality standards based on three simple
factors:
▪Material
We only use the highest quality steel in our products.
Our steel is certified and tested, it conforms to or
exceeds industry standards no matter the location or
climate.
▪Fit
Doka products are engineered with versatility and
usability in mind. Our modified product designs
increase efficiencies and productivity, saving your
projects time and money.
▪Finish
Where applicable, our products are finished and pro-
tected by hot-dipped zinc galvanizing. This method
of finishing maximizes the utilization and extends the
product life.
For additional information on Ringlock system compo-
nents please consult your local Doka representative.
Designation
The Designation of Ringlock in accordance with
EN 12810-1:2003 is:
Scaffold EN 12810 - 3D - SW06/307 - H2 - B - LS
Service Load Class 3 may be extended from Service
Load Class 1 to Service Load Class 6 if required
although there are restriction on bay length for Service
Load Classes 5 and 6. This User Information only con-
siders Service Load Class 1 to Class 3 as the general
loading required of a system scaffold under normal cir-
cumstances.
Service Load Class 3: The following combinations of
platform width and bay length are also available:
SW06/73 to SW06/307
CLADDING: Maximum permissible heights and tie pat-
terns are given for both unsheeted, debris netted and
sheeted scaffolds.
For more information on products not found within this
document or the Ringlock Brochure please consult your
local Doka representative, or online at www.doka.com.
Node capacities 1.65 Safety Factor
The Ringlock modular scaffold system may be used as
a work and protective scaffold according to EN 12811
with load class 3. The system dimensions of the stand-
ard design are bay length L ≤3.072m and bay width b
= 0.732m. The maximum height of the top scaffold layer
is 24m plus the spindle extension. If the actions on the
framework from the traffic load do not exceed the ser-
vice value of the loads specified in EN 12811, Table 3,
the standard design can be used without further verifi-
cation. According to EN 12810, the following designa-
tion must be used for the standard designation of the
Ringlock scaffold system as a facade scaffold:
Scaffolding EN 12810-3D-SW06/307-H2-A-LS
All the decks of the Ringlock modular scaffold system
can be used as overhead protection. The following
information provides an overview of the most important
characteristic valuesof the Ringlock modular scaffold
and is taken from the general building approval / gen-
eral type approval Z-8.22-992.
The Ringlock modular framework node has the follow-
ing design values of stresses (γF= 1.5; γM, steel = 1.1):
NRd = ± 36.8 kNm)
Mx,Rd = ± 58.5 kNcm)
Vz,Rd = ± 27.3 kN)
My,Rd+= ± 132 kNcm
My,Rd-= ± 121 kNcm
Vy,Rd = ± 11.1 kN
Mx,Rd = ± 45.3 kNcm)

10 999817902 - 10/2022
Introduction User Information Ringlock
Safety Guidelines and Safe Use
The guidance given here is not intended to replace any
relevant local/regional standards, Company Proce-
dures, Work at Height Regulations and other legisla-
tion, but is a practical guide to good scaffolding practice
using Ringlock System scaffolding. Please refer to the
latest versions of EN 12810, EN 12811, the NASC
Guidance Notes and current legislation prior to starting
your work.
The assembly, modification or dismantling of the Rin-
glock system may only be carried out by professionally
qualified personnel ('authorized person'). The instruc-
tions and specifications of DIN 4420, EN 12811 and
DGUV Information 201-011 'Instructions for handling
work and protective equipment' as well as the regula-
tions of the technical rules for operational safety TRBS
2121 or any other local/regional specific rule must be
observed.
Before working on the Ringlock scaffold, a hazard anal-
ysis must be carried out considering the special fea-
tures of the individual case. The result must be
recorded in a risk assessment and the personnel must
be instructed. Particular attention should be paid to
technical protective measures against falls from a
height and to the measures required for possible res-
cue operations. If the use of personal protective equip-
ment against falls from a height (PPE) is required, the
information on anchor points in the relevant section
must be observed.
Damaged or improperly modified scaffolding compo-
nents must not be used and must be replaced immedi-
ately with sound material.
Scaffolding components should be stored and trans-
ported in such a way that the risk of damage is avoided.
Scaffolding components must not be thrown. If neces-
sary, the use of lifting equipment must be checked.
After completion of the assembly work and before each
use, an inspection must becarried out to ensure that the
equipment is in proper condition. Work may only be car-
ried out on approved and apparently faultless scaffold-
ing, see also the following sections.

User Information Ringlock Introduction
11999817902 - 10/2022
Safety Guidelines and Safe Use
▪Ensure that you follow your Company’s safe systems
of work at all times.
▪Ensure that your staff erecting, dismantling or modi-
fying any Ringlock scaffold are licensed to carry out
the task.
▪Ensure that all persons erecting, dismantling or mod-
ifying the scaffold structure are working to the latest
version of the applicable standards and current leg-
islation.
▪Ensure all Personal Protective Equipment (PPE) is
suitable and sufficient and worn as appropriate.
▪Consideration should also be given as to where addi-
tional hazards may be present whilst scaffolding
operations are taking place, such as overhead power
cables, roadways, schools and if public protection is
required, if the scaffold is to be sheeted, who is
responsible for the design.
▪Ringlock scaffold structures are recommended to be
inspected and recorded:
- Prior to being put into use for the first time
- After any alteration or adverse weather
- After any event likely to affect its stability
- Regular intervals as per site requirements or
Company procedures but generally not exceed-
ing 30 days
▪Access and egress should be considered as early as
practicable, for both the scaffold operatives and the
end user in mind. Ladders should be used by the
scaffolders when erecting, modifying or dismantling
any Ringlock scaffold. Ledgers and brace compo-
nents etc. must not be used as a means of support.
Ensure that access and egress routes including lad-
ders and stairways, are kept clear.
Below is the hierarchy of measures to consider when
selecting methods to prevent a person falling at
access and egress points:
- Install staircases
- Install ladder Access Bays with Single Lift Lad-
der
- Install ladder Access Bays with Multiple Lift Lad-
ders
- Install internal ladder access with protection i.e.
ladder trap/handrails etc.
- Install external ladder access using the Ringlock
adjustable Swing Gate
▪Employers have an obligation to ensure that Work at
Height is::
- Properly planned
- Appropriately supervised
- Done in a safe manner 'so far as is reasonably
practicable'
- Include planning for emergencies & rescue
- Weather conditions do not jeopardise health and
safety
▪Before allowing people or materials on the Ringlock
scaffold, ensure that it has been erected correctly
and complies with the specified requirements and all
applicable legislation.
▪Ensure that all people using the Ringlock scaffold
are aware of the purpose for which it is intended to
be used and the maximum loading to which it can be
subjected.
▪Ensure users understand that any unauthorised
modification to the Ringlock scaffold or removal of
components could cause a safety hazard. Alteration
or extensions should be carried out only by a
licensed person.
▪Provide barriers and warning notices to prevent
access to incomplete sections of scaffolding.
▪Do not overload and ensure that crane and forklift
drivers understand loading restrictions on each part
of the scaffold structure.
▪Because of the increased use of mechanical lifting
plant on site there is an increased possibility for scaf-
folding components to become fouled/caught. When
using cranes or other mechanical lifting devices near
any Ringlock scaffold care should be taken to ensure
that nothing catches under any part of the scaffold.
Otherwise uplift could occur with potentially danger-
ous consequences.
▪Pigtail Pins/ Toggle Pins or Standard Leg Locks are
available to positively fix standards together if your
Method Statement/Risk Assessment indicates that
uplift cannot be eliminated.
▪Scaffold access should be secured when not in use
to prevent unauthorised access onto scaffolding.
Ladders should be kept in a storage compound or
container.
▪Consider enclosing the base of the scaffolding to
prevent climbing, especially near occupied prem-
ises.
▪Consider the environment particularly with respect to
pedestrian and vehicle movements.
If you are in any doubt regarding any information con-
tained within this Safety Manual and User Guide,
please contact your local Doka representative.

12 999817902 - 10/2022
Introduction User Information Ringlock
Never Always
Never Throw Ringlock scaffold equipment or any
other materials up or down.
Never Undertake work at height when there is a
potential to fall without wearing your safety
harness correctly and clipping the lanyard
to a secure anchor point.
Never Do any overhead or street work without dis-
playing warning signs, or segregating oth-
ers from the live working zone (barriers).
Never Use any defective / modified equipment.
Never Overload the scaffold you are erecting,
altering or dismantling with spare materials.
Never Rest scaffold equipment against an object if
there is a potential for it to fall.
Never Leave partly erected or dismantled scaf-
folds in an unsafe condition, (always ensure
adequate signage is displayed to warn oth-
ers).
Never Accept an instruction from a customer or
anyone else that does not comply with
safety regulations or current legislation.
Never Leave an exposed edge where people or
building materials could fall.
Never Remove ties except when using trained
operatives, working to your agreed site
requirements and instructions without tech-
nical advice.
Never Remove guardrails, toeboards, or brick
guards except when using trained opera-
tives, working to your agreed site require-
ments and instructions.
Never Remove components or adapt the Ringlock
scaffolding with non-genuine equipment.
Never Create gaps in platform by removing Rin-
glock Steel Planks from platform thus leav-
ing an exposed edge.
Never Work on or use a Ringlock scaffold which is
being erected or dismantled.
Never Remove ladders or staircases.
Never Overload the scaffold.
Never Undermine the scaffold by digging trenches
or foundations under or adjacent to it.
Never Add sheeting or netting to scaffold without
the approval of the scaffold designer.
Never Forklift loads directly onto access scaffold
(instead, use a loading tower).
WARNING
➤Never take risks!
The odds are against you!
Always Ensure all on-site users know for what pur-
pose the Ringlock scaffold is intended and
the load it is designed to support.
Always Prepare the ground for the scaffold and the
load it will impose.
Always Ensure that you provide agreed storage
areas for your Ringlock scaffolding on site
to reduce handling and prevent tripping
hazards.
Always Keep access routes clear.
Always Inspect your scaffold each time before use.
Always Inspect your scaffolds and issue reports.
Always Give consideration to the use of a tagging
system i.e. Scaftag.
Always Prevent access to incomplete and/or
unsafe scaffolds and ensure that you have
'scaffold not to be used' signs in place.
Always Inform the Scaffolding Manager if the scaf-
fold gets damaged, repairs can then be
arranged.
Always Protect scaffold from damage by site plant.
Always Ensure loads on the platform are evenly dis-
tributed.
Always Consider the weight of the materials you are
loading on the scaffold and instruct opera-
tives on maximum loading.
Always Instruct forklift driver on maximum loading.
Always Instruct the operatives who will be using the
scaffold not to make any adaptations.
Always Report scaffold defects to scaffolding con-
tractor - you may be saving a life.
WARNING
➤Always look after your Ringlock Scaffolding!
Be safe!

User Information Ringlock Introduction
13999817902 - 10/2022
Safety Guidelines and Safe Use
Working areas must not be placed on top of
each other at the same time.
Children must not be allowed on scaffolding.
Modifications to the scaffold may only be by the
scaffold erector.
The sum of all loads in a bay must not exceed
the value of the specified load class.
Pay attention to possible danger of falling
between scaffolding and building.
Use only existing ladders or stairs for ascent
and descent.
Keep the hatches closed in the Ladder Hatch
Decks.
Leave a sufficiently wide passage on the deck-
ing when storing materials.
Do not jump off from the scaffold. Do not endanger the stability of the structure by
excavation.
Do not place any material on cantilever and on
the brickguard.
981 -2 -0579 93
981 -2 -0979 93
98
1-2-
0
7
993
2
981 -2 -0679 93
981 -2 -1079 93
981 -2 -0379 93
981 -2 -0779 93
981 -2 -1179 93
981 -2 -0479 93
98
1-2-
08
7
993
981 -2 -179 93 2

14 999817902 - 10/2022
Ringlock Overview User Information Ringlock
Ringlock Overview
Ringlock Node Connection
Ringlock node connection consists of Standards with
rosettes every 0.5m and horizontal members with a
cast end captive wedge (Ledger and Transom). When
connected together the Ledger ends and rosettes cre-
ate a very strong connection. This connection transmits
the forces throughout the scaffold structure.
The Ringlock rosette has a diameter of 123mm and has
been manufactured with 8- trapezoidal slots, 4-small
and 4-large. The smaller holes represent the 90 degree
angle at the Ledgers and Transoms are installed. The
larger trapezoidal holes accommodate the Diagonal
Bay Braces.
If the needed, the Ledgers can be installed in the larger
holes, allowing up to 15-degrees of rotation. This pro-
vides added flexibility to clear obstacles when neces-
sary.
It is recommended that a 500g hammer is used to
secure the Ringlock wedge, when the hammer
rebounds, the wedge is secure.
To make a Connection:
981 -298-0179
1
981 -299-0179
2
981 - 0-0179 30
3
981 - -0179 301
4
981 - 2-0179 30
5
981 - -0179 303
6

User Information Ringlock Ringlock Overview
15999817902 - 10/2022
Instructions for Scaffolding Construction
Thanks to the flexibility of the wedge connection, the
Ringlock modular scaffolding system can be used for
everything from simple façade scaffolding to complex
industrial support scaffolding. The relevant characteris-
tic values such as stiffness and load-bearing capacity
of the scaffolding system can be found in the approval
certificate Z-8.22-992.
Vertical Standard
The robust Ringlock is made of high-quality steel. For
maximum flexibility, rosettes are welded to the vertical
standards at 50 cm intervals, to which up to 8 compo-
nents can be connected using the widely used and
proven wedge connection.
Ringlock rosette
▪Each rosette has eight openings. The smaller open-
ings are generally used to help guide the scaffolding
to make 90 degree connections, whereas the larger
opening enable connections at variable angles to be
achieved.
▪Unless erecting a scaffold around a circular building
structure, align the Base Collar rosettes so that one
of the small openings in the rosette points in the
Ledger direction. The small openings at right angles
to the first will automatically align the Transoms at 90
degrees.
▪The larger openings are generally used for connect-
ing the diagonal braces.
Ringlock Ledger
The ledgers can be easily installed by sliding the tran-
som head onto the rosette and then wedging it in place.
The wedges are permanently connected to the ledger
and, as an assembly aid, allow a rigid connection to be
made even when the wedge is only loosely inserted.
Before the components are loaded, the tight fit between
the wedge and the rosette or vertical stem must be
achieved with a 500g hammer until impact is felt. The
disassembly of the ledgers is done in reverse order:
The wedge is loosened by hitting it from below with a
hammer and pulled out of the rosette by hand.
98
17
9
-2
0
2-
0
1

16 999817902 - 10/2022
Ringlock Overview User Information Ringlock
Supplementary Components
The Ringlock Scaffold system can be complemented
with the following components:
▪Aluminum Tube Ø 48.3mm x 4mm minimum thick-
ness per EN 39
▪Steel Tube Ø 48.3mm x 3.2mm minimum thickness
per EN 39
▪Scaffolding couplers per EN 74
▪Wood Plank per relevant European Standard.
Scaffolding couples can be connected to all Ø 48.3mm
tubular Ringlock components with the exception of all
Ringlock vertical Bay Braces.
When Wood Planks are lapped and used as working
platform in conjunction with Ringlock System, addi-
tional guardrails must be installed to meet the minimum
guardrail height (95cm) in accordance to EN 12811-1.
Overlapping Wooden Planks
Butting Wooden Planks

User Information Ringlock Ringlock Overview
17999817902 - 10/2022
Component Identification
The following diagram represents the most common
Ringlock components used. Most scaffold structures
are made from these basic components yet the Rin-
glock system comes with a variety of accessories for all
your scaffolding requirements.
ASide Bracket or Console Bracket
BStandard
CStarter Base Collar
DBase Jack
EBay Brace
FLedger
GAlum Stair Platform
HSteel Plank
IToeboard

18 999817902 - 10/2022
Ringlock Overview User Information Ringlock
ABase Jack
BStarter Base Collar
CStandard
DBay Brace
ELedger
FGuardrail (Ledger)
GWall Tie
HToeboard
ISteel Plank
JAlum Hatch Deck with Ladder
AAlum Stair Platform
BAlum Stair Outer Guardrail
CAlum Stair Filler Guardrail
DAlum Stair Inner Guardrail
ELanding Ledger with Spigot

User Information Ringlock Ringlock Overview
19999817902 - 10/2022
Color Coded Components
A new feature offered by Doka is the horizontal compo-
nents manufactured with a colourcoded identification
label. This process allows the scaffolder to easily match
particular components for each size of the bay to be
erected. (For example: An Green Ledger 2.57m will
work with an Green Diagonal and an Green Plank.)
98
1- -
0
17
930
7
98
1- -
0
17
9 308
98
1- -
0
17
9 309
98
1- -
0
17
93
1
0
98
1- -
0
17
93
11
98
1- -
0
17
93
12
98
1- -
0
17
93
1
3
98
1- -
0
17
93
14
98
1- -
0
17
93
1
5
98
1- -
0
17
93
1
6

20 999817902 - 10/2022
Scaffold User Information Ringlock
Scaffold
Erection Guidelines
Recommendations
Prior to Erecting Ringlock the following is recom-
mended:
▪The job site should be inspected to ensure that the
ground or other supporting structure is strong
enough to safely support the self-weight of the scaf-
fold and the imposed loads on the platforms. In addi-
tion, please make yourself aware of the proximity of
power lines, overhead obstructions and weather
conditions. These could pose a possible danger dur-
ing the erection, use and dismantling of Ringlock and
should be evaluated and adequately addressed in
accordance with the requirements for provision of
Risk Assessments and Method Statements.
▪Check the condition of the building façade at the pro-
posed tie locations.
▪The spacing of the Standards should be in accord-
ance with the relevant layouts, if available.
▪If design drawings of the scaffold are required, check
the requirements of the local authority with respect to
what must be shown on the drawings (load rating,
erection/dismantling instructions etc.).
▪All equipment should be inspected prior to use to
ensure that it is in good condition and is serviceable.
Damaged or deteriorated equipment must not be
used.
▪Avoid storing or handling scaffold components below
or close to electrical power lines. Check the require-
ments of the authority having jurisdiction for the
exclusions zones.
▪Care must be taken when scaffolding work is in close
proximity to exposed and insulated electrical lines
and hidden electrical cables (for example, cable con-
cealed behind a surface where a scaffold anchor is
to be fitted).
▪Be aware of all Client and work related site safety
procedures as well as reference to local/regional and
National legislation.
▪Be aware of possible dangers regarding explosions
or fire.
▪Ensure that the scaffolders are trained and fully
instructed to erect Ringlock system scaffolding.
▪Check the safety and function of all the tools that are
used during erection.
98179-200-01
