Dolphin VELOCITY BC 2003BM User manual

BC2002 DOLPHIN HAND DRYER
BC2003BM
DOLPHIN BEHIND MIRROR
HIGH SPEED HAND DRYER
USER MANUAL

Operating Instructions and Parts Manual (Automatic) Surface Mount Hand drierHigh-SpeedBC2003BMITEM CATEGORYOperating VoltageWarm Air Speed OutputMotor TypeMotor Thermal ProtectionHeater ElementHeater Thermal ProtectionDrying TimeCircuit OperationSensor RangeTiming ProtectionDrip proofIsolationNet WeightShipping WeightUnit SizePERFORMANCE DATATECHNICAL SPECIFICATIONS220-240Vac, 50/60Hz, 0.84-1.0kW90m/s, adjustable250-500W, 29000r.p.m., Adjustable; Brush Type, Dual Ball BearingsAuto Resetting Thermostat turns unit off at 95°C {203°F}500W, adjustableAuto Resetting Thermostat turns unit off at 85°C {185°F}Less than 15 seconds Infrared Automatic, self adjustingStandard [170 ± 20mm], Adjustable, The range is [120 - 220mm]60 seconds auto shut offIP14CLASS 14.5kg5.2kg263mm (W) x 170mm(H) x 139mm (D) BC2003BM- Stainless steel; #4 satin finished. (AISI 304 t:1.2 mm)COVER TYPE/ COVER FINISHStand-by PowerLess than 0.5W 263 mm170 mm139 mm
BC2003BM User Manual www.dolphinsolutions.co.uk

BC2003BM User Manual www.dolphinsolutions.co.uk
【Type Y attachment】If the power supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person in order to avoid a hazard. Means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. Circuit DiagramCircuit Board ModuleTransistor Power SwitchMO2HE2NMO1HE1LTransistor Power SwitchVRGNLRed(110-120V)/Brown (208-240~277V)BlackBlackG/Y
BlueBrownMotor With Thermal Switch 2AHeater With Thermo-fuse
FOR SENSORSW.FOR HEATER White(110-120V)/Blue (208-240~277V)Sensor moduleON1VRFOR MOTORGG/YY2 Filter(ONLY 208~240V)
(ONLY 208~240V)
General safety informationNOTE: We do not recommend that this dryer is installed above a basin. If you are installing this dryer above a basin you need to satisfy yourself that reflection won’t occur. Disconnect power at the service breaker beforeinstalling or servicing. Not for household usemay cause burns. This product is intended for installation by a qualified service person. Use 1.2mm² solid conductor for wiring. All units must be supplied with a 3-wire service.The ground wire must be connected to the dryer's backplate. Failure to properly ground unit could result insevere electrical shock and/or death.WARNINGWARNINGDANGERWARNING
Thermostat
Operating Instructions and Parts Manual Hand drier

BC2003BM User Manual www.dolphinsolutions.co.uk
1. Make sure power supply breaker is switched off. Installation must be carried out in accordance with the current edition of the local wiring regulations code having jurisdiction. Installation should be performed only by a qualified electrician.2. Place template against wall at desired height (see mounting height recommendations) and mark locations of 4 mounting holes and wire service entry at knockout (KO) location. Note: For two or more dryers, dryers should be no closer than 24 inches (610mm) on center. Remove and retain 2 cover screws and cover.K.O holeBackBackK.O holeOperating Instructions and Parts Manual Hand drierConnect the wire into terminal as below: Connections: A. Connect the live wire (colored red or black or brown) to the terminal block marked "L". B. Connect the neutral wire (colored white or blue) to the terminal block marked "N". C. Connect the ground wire (colored green or green and yellow) to the terminal block marked " ". Installation14Fix the part to the wall with 4 screws of1/4 x 1-3/4 dimension."2Insert the power cord into the suitable K.O. hole.5Put the front cover back and screw it with L key.3

BC2003BM User Manual www.dolphinsolutions.co.uk
Periodic cleaning of the unit is recommended to ensure optimum performance.Cleaning and MaintenanceDisconnect the electrical supply.Remove the two cover-mounting screws.Remove the cover.Clean all dust lint from the interior of the dryer.Replace the cover. Do not over tighten the screws.Wipe the cover with a damp cloth and mild cleaning solution. Do not Soak. Never use abrasives to clean the cover.OperationNo-touch operation.Shake excess water from hands.Place hands under the outlet to start operation.Rub hands lightly and rapidly.Stops automatically after hands are removed.Operating Instructions and Parts Manual Hand drierOperation

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drierOperationC. Sensor range adjustment
VR.FOR SENSOR
1.The recommended unit sensor range is 150mm. This can be adjusted from 120mm to 220mm.2.Clockwise: Increases the sensing range(+) .3.Counterclockwise: Decreases the sensing range(-) .4.DO NOT OVERTURN!
SW.FOR HEATER
Use phillips screw to adjust air speed.Install the cover once adjustment is completed.Clockwise: Increases the air speed(+) .Counterclockwise: Decreases the air speed(-) .A. Warm air speed adjustment B. Heater Element Switch ON/OFF 1.Switch off the power, loosen the cover screws and remove the cover.2.Adjust the heater switch on the PCB with a small plastic or wood flat blade probe.2-1. Heater ON: Slide the switch to "ON".2-2. Heater OFF:Slide the switch to "1".
VR.FOR AIR SPEED
Settıng Adjustmenet

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drierTimer replacement1. Pull off the four wires and remove the fixing screws of the timer.2 . Ensure that the two flanges on the timer to be wedged in the two holes are on the base plate.3. Fix the timer to the blower and connect the four wires to the timer as the photos of procedure 1. Surface-mounted high speed hand drier

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drierSurface-mounted high speed hand drier Sensor replacement1. Pull off the wires that connect timer and remove the fixing screws of the timer.2. Fix the sensor on the sensor bracket as in the photos of procedure 1, and plug the wires on the timer.

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drierMotor replacement1. Remove the wires that connect motor to the timer.2. Loosen the fixing screws of the blower and remove the blower housing.

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drier3. To replace the motor, install the motor rubber (large/small) on the motor, and place the motor under the fan blower.The wire set must be fixed to the ditch in the lower housing of the blower.

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drierHeater replacement1. Remove the wires that connect heater to the timer.2. Loosen the fixing screws of the blower and remove the blower housing.

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drier3. To replace the heater, the wire set must be fixed to the ditch in the lower housing of the blower.

BC2003BM User Manual www.dolphinsolutions.co.uk
Operating Instructions and Parts Manual Hand drierToolsPhilips ScrewdriverSlotted ScrewdriverWire CutterModular Crimping Cuts ToolImportant InformationThis Product falls within the scope of the Waste Electrical &Electronic Equipment Directive 2002/96 EC. (WEEE)NOTE:This Product should not be disposedof with household wastePlease recycle where facilities exist.Check with your local authority forrecycling advice.

BC2003BM User Manual www.dolphinsolutions.co.uk
LIMITED THREE-YEAR WARRANTYWarrantyPlease see our website by following this link: http://www.dolphinsolutions.co.uk/or contact our customer service team on 01424 202224 for more details.Operating Instructions and Parts Manual Hand drierDiagnostics and RemediesIf the dryer will not runThe dryer cycles by itselfor runs constantlyThe dryer runs but airstream is low pressureand/or low velocityEnsure that there is no obstruction on or in front of the IR sensor. Cleanany dirt or debris off the sensor lens. If problem persists, replace sensor.First ensure that the breaker supplying the dryer is operational. If it is,disconnect the power and remove the dryer cover. Taking suitableprecautions to avoid shock hazard, reconnect the power and check forVoltage at the terminal block. Verify that connections are made correctly.Ensure that the supply Voltage is correct. Dryer will run weakly if theinput Voltage is too low. Verify Voltage requirement on unit rating labeland correct supply as required.The dryer makes a loudnoise and does not runfor a complete cycleEnsure that the supply Voltage is correct. Dryer will make a loud hummingnoise if the input Voltage is too high. Verify Voltage requirement on unitrating label and correct supply as required. If CBM has been damaged,replace CBM, IR sensor module and VR component and cable.Symptom Corrective Actions for Initial Installation FailuresSymptom Corrective Actions for In-Service FailuresIf the dryer will not runThe IR sensor only seesclose range objects""The dryer only blows coldair during a full cycleFirst ensure that the breaker supplying the dryer is operational. If it is,disconnect the power and remove the dryer cover. Replace the CBMand IR sensor module. Taking suitable precautions to avoid shock hazard, reconnect the power and check for voltage at the terminal block.Disconnect the power. Remove the dryer cover and disassemble the blower-motor/fan housing. Test the thermostat for open circuit. Check the heater element for signs of burning or breakage. Damaged element must be replaced.The heater gets hot butno air stream is producedor the air stream is lowpressure and velocity Disconnect the power. Remove the dryer cover and disassemble the blower-motor/fan housing. Replace the fan motor.Ensure that there is no obstruction on or in front of the IR sensor. Cleanany dirt or debris off the sensor lens. Check VR for sensor range setting, If problem persists, disconnect the power and remove the dryer cover and replace CBM, IR sensor module.

BC2003BM User Manual www.dolphinsolutions.co.uk
12891011121314151617181934567202122 1 2 3 4 5 6 7 8 91011Key1213141516171819202122Enclosure (Casing)Security hex screw (2 reqd.)Blower housing - UpperBlower housing - BelowMotorMotor rubber - Motor rubber - Heater assemblyCircuit Board ModuleBase plateNylon hole bushingSmallLargeDescriptionInsulation MylarTerminal blockBlower mounting bracketSensor bracketSensorCable clampCable ProtectorGrounding ScrewLeft box bracketRight box bracketBoxKeyDescriptionOperating Instructions and Parts Manual Hand drierDiagramRepair parts list
