Dolphin Velocity BC 2011 User manual

BC 2011 Dolphin Velocity Hand Dryer
User Manual
Please read carefully before use

Features:
·Apply high-speed brushless DC motor that produces 65m/s jet airflow
·Dry hands in 6-12 seconds
·Long service life brushless DC motor
·Intelligentized,simple operation and a big LCD display screen
·Unique design,energy-saving, economical and durable
Components:
ķLCD screen
ĸupper sensor
Ĺlower sensor
ĺpower switch
Ļfront cover
ļwater tank
Installation: Figure1
·Electrical connection must be made to the fixed wiring of the property using a double ploe
isolating switch,with a break contact distance of at least 3mm.
·This product must be grounded.
1. Please pull out the three screws which indicated by “----- >on the back of the hand dryer before
installation
2. Take off the plugs(14)and the screws(13)from both sides of the hand dryer,and take off the
hanger board (17).(Figure 3)
3. Put the hanger board on the suitable position on the wall, drill 5 holes that diameters are 8mm
(0.3Ͳ),and then remove the hanger board.( Figure 2)
4. Put the plugs(16)into the holes, and fix the hanger board on the wall with the screw.( Figure 3)
5. Hang the hand dryer to the hanger board.( Figure 3)
6. Keep the hand dryer by the screws on both side, and cover the screws by the screw
caps.(Figure 3)
7. Plug in the hand dryer,and switch on to use it.(Figure 1)
BC 2011 User Manual www.dolphindispensers.co.uk
Thank you for purchasing the BC 2011 Dolphin Velocity Hand Dryer.
This product adopts CPU control,wide LCD display screen, and is durable and ergonomic. It
applies high-speed brushless DC motor to produce jet airflow that dries your hands in 6-12
seconds. It has high efficiency that can save your time,and it takes only 1/3 of the power that
general hand dryers use to achieve same effect.It is energy-saving, environmental friendly,
economical and durable.This product is especially suitable for hotel, office, store and other public
places.

Installation for internal circuit lining:
1. Take out the water tank from the bottom ņ;(Figure 3)
2. Remove the screwsŋby using the screw driver, and then remove the front cover;(Figure 3)
3. Remove the screwsň, open the cover of the wire boxʼn,remove the power line, put the
prepared power down-lead through the middle hole, and connect to the terminalŇ.Please note
that do not misconnect L, N and ground;(Figure 3)
4. Put back the cover of wire box,front cover and the water tank.
Use direction:
1. Put hands into the notch, LCD screen lights up,the drying direction(19)reminds you to insert
hands to the bottom of the notch.
2. The hand dryer starts working when hands inserted, fan blip(18)runs, and timer(20)counts
down from 18 seconds.
3. Dry hands in 6-12 seconds.
4. Automatically stop working when done counting down;follow the direction again to make it
rework.
Maintenance:
1. Must unplug the hand dryer before clean;wring out the wet cloth before cleaning. Do not clean
the product with chemical or abrasive substances,e.g. retinol and alcohol,and do not use the
nylon brush. These may damage the paint finish.
2. Before use chemical cloth, please read its direction carefully.
3. Do not drench the product directly with any disinfectors.
BC 2011 User Manual www.dolphindispensers.co.uk
Cable
entry
point

4. Please clean up the water in the water tank before reach the full-line; clean up the water at
least 1 time every week when seldom use the hand dryer.
5. To prevent the drain from being blocked, pour out about 200ml water to the drain, and clean up
the water in the water tank.
6. Please clean the air filter every week.
7. Before fix back, make sure the air filter is dry after wash.
Specifications:
Notes:
1. The hand dryer must be installed away from the place for shower bath;
2. Do not install the product near the bathtub, washbowl or other vessels that contain water;
3. Avoid spattering the product with water;
4. Do not cover the air inlet and outlet;
5. Do not shake the hand dryer;
6. When the hand dryer is out of order during use, please cut off the power immediately, stop
using it, and contact our company or find a qualified electrician to fix it;
7. This product is not intended to use by persons (include children) who are disabled, or lack of
experience and knowledge, unless they are given instruction concerning about the use of
the product and supervised by a person who is responsible for their safety;
8. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
a qualified electrician in order to avoid a hazard.
The meaning of crossed-out wheel bin symbol:e.g.“ This symbol indicating separate
collection for electrical and electronic equipment. ”
Indoor use only.
Package:
One set of hand dryer
One copy of user manual
One copy of installation template
One pack of ST5 self-threading screws 5pcs and Ø8mm plugs 5pcs
BC 2011 User Manual www.dolphindispensers.co.uk
Bell-Chem Products Company, Haywood Way, Hastings, TN35 4PL
