Notes on using the manual CC09, CCK09, CC11
4
Please read this manual carefully before installation and starting up the
device. Keep it in a safe place for future reference. If the device is hand-
ed over to another person, this manual is to be handed over along with
it.
Contents
1 Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6 Installing the hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 Connecting the electrical power to the hob . . . . . . . . . . . . . . . . . . . 13
8 Using the hob. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10 Cleaning the hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11 Cleaning and maintaining the hob . . . . . . . . . . . . . . . . . . . . . . . . . . 18
12 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1 Notes on using the manual
!WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
!CAUTION!
Safety instruction: Failure to observe this instruction can lead to
injury.
_CC09_CCK09_CC11.book Seite 4 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 General safety instructions
5
ANOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
INOTE
Supplementary information for operating the product.
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
Please observe the following safety instructions.
2 General safety instructions
The manufacturer will not be held liable for claims for damage resulting from
the following:
Damage to the product resulting from mechanical influences
Alterations to the product without express permission from the manu-
facturer
Use for purposes other than those described in the operating manual
Note the following basic safety information when using electrical devices to
protect against:
Electric shock
Fire hazards
Injury
_CC09_CCK09_CC11.book Seite 5 Donnerstag, 12. Mai 2011 12:59 12

EN
General safety instructions CC09, CCK09, CC11
6
2.1 General safety
!Only use liquid gas (butane, propane) in the I3B/P, I3+, I3catego-
ries. Do not use any other fuel sources.
Keep a suitable fire extinguisher in the immediate vicinity.
Ensure that the fire extinguisher is regularly checked by a spe-
cialist.
Persons whose physical, sensory or mental capabilities prevent
them from using the device safely should only use it under the
supervision of a responsible adult.
Do not touch the cooking zones or the area near them.
The surface of the cooking zones could be hot even if they are
still dark. The areas near the cooking zones can be hot enough
to cause burns.
If the surface of the cooking zone is cracked, cleaning agents
and spilt liquids could penetrate the device, which could cause
an electric shock. In this case, switch off the device straight
away.
Always disconnect the power supply when working on the de-
vice.
Maintenance and repair work may only be carried out by quali-
fied personnel who are familiar with the risks involved and the
relevant regulations.
AOnly use the device with the approval of qualified personnel.
Do not perform any modifications to the device.
Switch off the device when it is not in use.
Do not use the device if it is damaged or parts of it are faulty.
_CC09_CCK09_CC11.book Seite 6 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 General safety instructions
7
2.2 Safety precautions when handling liquid gas
!Keep combustible materials away from heating or cooking de-
vices and other light or heat sources.
Danger of suffocation!
Ensure that the surrounding area is sufficiently ventilated before
switching on the device. During operation, air vents with a
cross-section of at least 50 cm2must be present in the installa-
tion space. These vents can be closed, but must be kept open
when the device is in use (see sign located above the hob).
Compare the pressure information on the type plate with the in-
formation on the pressure regulator.
Never store liquid gas bottles in unventilated areas.
Keep liquid gas cylinders away from direct sunlight. The temper-
ature may not exceed 50 °C.
If you smell gas:
– Open all windows and leave the room.
– Do not touch any electrical devices or switches and do not
use naked flames (risk of gas ignition).
– Close the valve on the gas cylinder and keep it closed until
the error is rectified.
– Never attempt to find a gas leak with a naked flame.
The hob must not be used in garages, on ferries or when refu-
elling.
2.3 Operating the device safely
!Wear suitable clothing when using the hob.
Do not wear loose hanging clothing which might catch fire.
Leave the hob to cool down properly before you touch it with
bare hands.
Keep the area around the hob free from fat, alcoholic substanc-
es, plastic and flammable materials (e.g. curtains, cloths or
kitchen materials).
Do not hang up hand towels, curtains or any other flammable
materials near the hob and do not place them on it.
Proceed with caution when heating oil or fat, as they can ignite
under excessive heat.
Do not attempt to put out burning fat with water.
_CC09_CCK09_CC11.book Seite 7 Donnerstag, 12. Mai 2011 12:59 12

EN
Scope of delivery CC09, CCK09, CC11
8
Only use dry oven cloths and wooden spoons to avoid steam
build-up. Wet or damp oven cloths on hot surfaces can cause
burns from steam.
Only use the hob when you or another person can attend to it.
Pots which boil over can cause smoke and fires.
Switch off the cooking zone before you remove the pot.
Turn the handles inwards, to prevent the risk of burns, flamma-
ble material from igniting and spillage from occurring due to ac-
cidently knocking the pots. Make sure that they do not protrude
onto the adjacent cooking zone.
ADo not use the hob to heat the room.
Using the hob at a high temperature without putting any pots on
it can damage the hob.
Do not place any plastic objects, such as salt and pepper hold-
ers, packets etc. while the hob is on.
Make sure that there are no oven cloths on or near the cooking
zones.
Use pots, pans and other equipment which are designed for ce-
ramic surfaces and the rated power of the hob.
Only certain types of glass, glass ceramic, crockery or other
glazed cookware can withstand the rapid changes in tempera-
tures and are suitable for ovens.
Use pots and pans that are the right size.
3 Scope of delivery
Gas glass ceramic hob
Operating manual
4 Intended use
Dometic CC09, CCK09 and CC11 are glass ceramic hobs operated with liq-
uid gas. They are intended for installing in fitted kitchens at home, in mo-
torhomes, caravans or boats.
_CC09_CCK09_CC11.book Seite 8 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 Technical description
9
5 Technical description
The hob is available in different versions.
CC09 (item no. 9103303386): two cooking zones
CCK09 (item no. 9103303387): one cooking zone
CC11 (item no. 9103303390/9103303391): two cooking zones
You can find out your device type by checking the item number shown on the
type plate.
The cooking zones are all heated with a gas burner.
Behind the cooking zone (fig. 11, page 2) is a simmer cooking zone
(fig. 12), which is heated by the flue gas of the burner under the cooking
zone. Here the temperature is not as hot as the cooking zone. The simmer
cooking zone can be used as an additional cooking zone, which needs a low-
er temperature.
Only CC09, CC11: The smaller cooking zone on the right has a lower heating
power.
The glass ceramic hob is resistant to heat and cold. It can withstand heavy
pots. Prevent impact caused by pointed items, such as falling objects. This
can cause damage.
_CC09_CCK09_CC11.book Seite 9 Donnerstag, 12. Mai 2011 12:59 12

EN
Installing the hob CC09, CCK09, CC11
10
Control elements
Only CC09, CC11: The front control knob corresponds to the cooking zone
on the right and the rear control knob to the cooking zone on the left.
6 Installing the hob
The hob can be installed in your kitchen worktop.
6.1 Selecting the installation location
When selecting the installation location, observe the following instructions:
Select a well-ventilated location for the device.
Select a covered place to prevent water or any other liquids splashing di-
rectly onto the hob.
Observe the minimum distance according to fig. 2, page 2.
Underneath the hob, air vents must have a cross-section of at least
50 cm² for the combustion air supply and heat discharge.
Die Lüftungsöffnungen müssen mindestens 5 mm breit sein.
No. in fig. 1,
page 2 Description
1 Cooking zone
2 Simmer cooking zone
3 Warning LED “Hot surface”
This LED lights up when the cooking zone is switched on.
It stays lit until the surface has cooled down and can be safely
touched again (this takes about 12 minutes once the cooking
zone has been switched off).
4 Control LED
This LED lights up green when the cooking zone is switched
on.
5 Control knob with three settings (neutral position, large flame
and small flame)
Press and turn clockwise or anti-clockwise to set the required
temperature.
Turn the knob anti-clockwise to open the gas cock.
Turn the knob clockwise up to the stop to close the gas cock.
_CC09_CCK09_CC11.book Seite 10 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 Installing the hob
11
Ensure that there are no draughts in the installation location.
If the hob is installed in an open cockpit or another exposed location, then
also install a wind guard.
Do not operate the device in rooms that are potentially explosive.
6.2 Installing the hob
ANOTICE! Beware of damage
Before drilling any holes, make sure that no electrical cables or
other parts of the vehicle can be damaged by drilling, sawing
and filing.
Do not use the gas pipe, tap or burner parts to attach the hob.
➤Saw a rectangular opening in the worktop (for dimensions, see fig. 3,
page 2).
➤Place the hob in the middle of the cut-out section.
➤Attach the hob (2) with the four attachment elements (3) and screws (4)
to the worktop (1), see fig. 4, page 3.
➤Keep a class B-1 fire extinguisher in the immediate vicinity.
6.3 Connecting the hob to the gas supply
!WARNING! Beware of injury
Only use propane or butane gas cylinders with an approved
pressure regulator and a suitable connector.
Compare the pressure information on the type plate with the in-
formation on the pressure regulator.
The device may only be connected to the gas supply by quali-
fied personnel.
Observe the following instructions during connection:
Use gas pipes made from steel ∅8 x 1 mm (welded, seamless or stain-
less steel), which are flush-mounted with a cutting ring screw assembly.
Fasten the pipes on the side or rear wall of the surrounding furniture parts
so that no loads are exerted on the actuators.
The connection must only be able to be released using tools. Observe the
technical regulations on DVGW worksheets G607 and G608.
The entire pipe system must be free of stress.
_CC09_CCK09_CC11.book Seite 11 Donnerstag, 12. Mai 2011 12:59 12

EN
Installing the hob CC09, CCK09, CC11
12
Keep the hose connection between the gas appliance and the liquid gas
supply system as short as possible, and no longer than 750 mm.
The entire hose connection must be accessible for inspection purposes.
During operation, air vents must have a cross-section of at least 50 cm2
in the installation space. These vents can be closed, but must be kept
open when the device is in use.
➤Connect the hob to the gas supply.
➤Attach a sign above the hob with the following text:
“WARNING!
When cooking, provide additional ventilation e.g. by opening windows
near the grill, hob or oven.
This equipment must not be used for heating the room.”
➤Make sure that the hose line:
– is not crushed or kinked
– is a safe distance from the burner
➤Open the valve on the gas cylinder.
!WARNING! Beware of injury
Never check for leaks with a naked flame or near sources of igni-
tion.
➤Check all connections with leak spray.
There are no leaks if no bubbles form.
_CC09_CCK09_CC11.book Seite 12 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 Connecting the electrical power to the hob
13
7 Connecting the electrical power to the
hob
!WARNING! Beware of injury
Connecting the hob may only be carried out by a qualified techni-
cian.
The following information is intended for technicians who are famil-
iar with the guidelines and safety precautions.
Observe the following safety instructions for the electrical connections:
ANOTICE!
If you need to feed cables through metal walls or any other walls
with sharp edges, use ducts or tubes.
Do not lay cables which are loose or bent next to electrically
conductive material (metal).
Fasten the cables securely.
Do not pull on the cables.
Lay the cables so that they cannot be tripped over or damaged.
➤Make sure that the operating voltage of the device corresponds to the on-
board electricity supply by referring to the type plate on the hob.
➤Connect the device according to fig. 5, page 3 to the 12 Vgon-board
electronics.
Use a two-wire cable with flat sockets 6.3 x 0.8 mm (1).
The power circuit must be protected with a 5 A fuse (not included in
delivery scope).
➤Secure the cable with a clip.
_CC09_CCK09_CC11.book Seite 13 Donnerstag, 12. Mai 2011 12:59 12

EN
Using the hob CC09, CCK09, CC11
14
8 Using the hob
!CAUTION! Beware of injury
The hob remains hot for some time even after it is switched off. The
warning LED indicates this.
Do not place any items on the hob which could get damaged or be-
come hot until the surface has cooled down.
ANOTICE!
Make sure that there are no flammable materials on the hob before
you switch it on.
Tips on handling the hob
To prevent the glass ceramic surface from damage, observe the following:
Do not use the hob for resting things on.
The base of the pots and pans may have edges and ridges which leave
scratches when moved, particularly for cast iron cookware.
Scratches can occur for instance, if grains of sand left over from cleaning
vegetables are dragged over the surface of the hob.
Prevent the following from coming into contact with the hot surface:
– Plastic
– Aluminium foil
– Sugar or substances with a high sugar content.
Prevent food residues from burning on repeatedly.
To achieve the best results with the hob, observe the following basic rules
when cooking and preparing meals:
The cooking zones heat up very quickly, but cool down slowly. Turn the
control knob to the required position straight away.
Use high quality pots and pans with even bases to ensure full contact with
the cooking zone.
The better the contact between the cooking zone and the pot or pan, the
better the efficiency.
Pots and pans made from stainless steel and cast iron are the most suit-
able. Aluminium pans are not recommended for the maximum tempera-
ture setting.
Make sure that the pot or pan is the same size as the cooking zone or
slightly larger.
_CC09_CCK09_CC11.book Seite 14 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 Using the hob
15
If you use a pot or pan that is too small, part of the cooking zone is
exposed, which could result in your clothing catching fire.
Make sure that the base of the pot or pan is dry.
Turn the handles inwards, to prevent the risk of burns, flammable material
from igniting and spillage from occurring due to accidently knocking the
pot or pan. Make sure that it does not protrude onto the adjacent cooking
zone.
Checking before switching on
Check the following before you switch on the hob:
Is the correct type of gas connected? The device is only permitted for liq-
uid gas.
Are the air inlet and outlets unobstructed in the room or on the outside of
the vehicle? The openings ensure a supply of fresh air and that the flue
gas is discharged.
Is the hob surface clean? Dirt could catch fire and damage or blemish the
surface.
Is the shut-off valve for the gas cylinder open?
_CC09_CCK09_CC11.book Seite 15 Donnerstag, 12. Mai 2011 12:59 12

EN
Using the hob CC09, CCK09, CC11
16
Switching on the cooking zone
➤Put the control knob to the neutral position.
➤Press the control knob in, hold it down and turn it anti-clockwise to the
“large flame” position.
➤Keep the control knob pressed down for not more than 15 seconds until it
is ignited and the thermoelectric safety pilot has responded.
➤Release the control knob.
✓The burner is on.
✓The status LED lights up.
✓The warning LED lights up.
➤If the burner goes out after releasing the control knob,
wait at least 60 seconds before you ignite it again.
INOTE
When using for the first time or after changing a gas cylinder, the
burner might not ignite after 15 seconds due to a lack of air in the
gas pipe.
In this case, ignite it again.
Adjusting the temperature
➤Adjust the temperature with the control knob to between the “large flame”
and “small flame”.
Switching off the cooking zone
➤Turn the control knob to the neutral position.
✓The status LED is off.
✓The warning LED stays lit.
The warning LED switches off when the surface has cooled down and can
be safely touched again (this takes about 12 minutes once the cooking
zone has been switched off).
➤Close the shut-off valve on the gas cylinder if it will be out of operation for
a long time.
_CC09_CCK09_CC11.book Seite 16 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 Troubleshooting
17
8.1 Replacing the gas cylinder
!WARNING! Beware of injury
Only change the gas cylinder in well-ventilated areas.
Make sure that there are no ignition sources in the vicinity.
Only change the gas cylinder when the device is switched off.
➤Switch off the hob by turning the control knob clockwise to the neutral po-
sition.
➤Completely close the valve on the gas cylinder.
➤Unscrew the pressure regulator from the gas cylinder.
➤Check the condition of the hose line.
Replace the hose line if the material is brittle or porous.
➤Screw the pressure regulator firmly onto the new gas cylinder by hand.
9 Troubleshooting
Repairs to the gas supply parts on the device may only be carried out by a
qualified technician.
➤Shut off the gas supply immediately if a fault occurs.
➤Check again for any damage to the device.
➤Replace the damaged parts.
➤Only use the device again once all the faults have been rectified.
Before you contact customer services about problems with the hob, check:
The connection to the on-board supply is OK.
The controller is switched on and the temperature setting is correct.
The base of the pot or pan and the hob surface are all clean and dry.
The pot or pan is the correct size and positioned on the cooking zone
properly.
The base of the pot or pan is level and even.
_CC09_CCK09_CC11.book Seite 17 Donnerstag, 12. Mai 2011 12:59 12

EN
Cleaning the hob CC09, CCK09, CC11
18
10 Cleaning the hob
For safety reasons, it is necessary to have the device inspected before using
for the first time and then every two years by a specialist to check it functions
properly and to correct any faults.
➤While checking the device every year, pay particular attention to the fol-
lowing:
–Gasleaks
– Burning and flame stability
– Fresh air supply
– Safety and regulating devices (burner taps, pressure regulator)
➤Check that the installation location conforms to local regulations.
11 Cleaning and maintaining the hob
!CAUTION! Beware of injury
Make sure that the surface has cooled down and the warning
LED is off.
Be careful when removing any spilt cooking residues with a wet
sponge or cloth, to avoid scalding from steam.
ANOTICE!
Do not use scouring agents for cleaning the hob's glass ceramic
surface.
Only use special cleaning agents for glass ceramic hobs. Any
other cleaning agents will damage the surface or in some cir-
cumstances create poisonous fumes if they are applied to a hot
surface.
Do not use a steam cleaner.
➤Before using for the first time, clean the glass ceramic surface thoroughly
(see the following chapter).
_CC09_CCK09_CC11.book Seite 18 Donnerstag, 12. Mai 2011 12:59 12

EN
CC09, CCK09, CC11 Cleaning and maintaining the hob
19
11.1 Regular cleaning
➤Put a small amount of cleaning agent into the middle of the surface to be
cleaned.
➤Dampen a paper towel and rub the cleaning agent into the surface.
➤Wipe the surface with a clean, dry paper towel.
✓Now there is a protective film on the surface which is resistant to water
and dirt.
11.2 Removing spilt cooking residues
➤If cooking residues get spilt while cooking, switch off the cooking zone and
wipe the area around it with a dry paper towel.
Treat spilt cooking residues on the cooking zones in the same way as for
burnt on cooking residues (see chapter “Burned on, spilt cooking resi-
due” on page 19).
Removing melted substances or spilt cooking residues with high
sugar content (jam, ketchup, tomato sauce etc.)
➤Remove the spilt substance straight away using a scraper while the sur-
face is still hot: Move the spilt or melted substance to a cool part of the
hob surface.
➤Switch off the cooking zones.
➤Leave the hob to cool down (warning LED must be off).
➤Clean the surfaces according to chapter “Regular cleaning” on page 19.
11.3 Burned on, spilt cooking residue
➤Remove the burnt substance with a scraper. Keep the scraper at an angle
of approx. 30° to the surface and scrape off the substance.
➤Finish cleaning, see chapter “Regular cleaning” on page 19.
_CC09_CCK09_CC11.book Seite 19 Donnerstag, 12. Mai 2011 12:59 12

EN
Warranty CC09, CCK09, CC11
20
11.4 Removing metal traces
Metal traces might appear on the hob surface, especially if you use light-
weight pots and pans. These traces appear more often than scratches.
➤Remove the metal traces according to chapter “Removing spilt cooking
residues” on page 19.
➤For stubborn traces, use a cleaning agent with the scraper.
12 Warranty
The statutory warranty period applies. If the product is defective, please
contact the manufacturer's branch in your country (see the back of the
instruction manual for the addresses) or your retailer.
For repair and guarantee processing, please include the following docu-
ments when you send in the device:
A copy of the receipt with purchasing date
A reason for the claim or description of the fault
13 Disposal
➤Place the packaging material in the appropriate recycling waste bins
wherever possible.
MIf you wish to finally dispose of the product, ask your local recycling
centre or specialist dealer for details about how to do this in
accordance with the applicable disposal regulations.
_CC09_CCK09_CC11.book Seite 20 Donnerstag, 12. Mai 2011 12:59 12
