Dometic MO0911 User manual

www.dometic.com
SAFETY ALERT SYMBOLS
COOKTOPS & COMBINATION UNITS
Instruction Book
FOR YOUR SAFETY
Safety Symbols alerting you to potential personal safety hazards. Obey all safety messages following these symbols.
MO0911 - MO8302 - MO8322 - MO8801D - MO8801S - MO8821D - MO8821S - MO9523RSUS - PI8002 - PI8022
PI8022A - PI8003 PI8023 - PI8621A - PI8621R - PI8621S - PI8802D - PI8802S - PI8822D - PI8822S - PI8842D - PI8842S
PI8862D - PI8862S
WARNING: if the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal ijury or death.
- Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your recreational vehicle.
• Clear the recreational vehicle of all occupants.
• Turn off the gas supply tank valve(s) or main gas supply.
• Immediately call your gas supplier for instructions.
• If you cannot reach your gas supplier, call the fire
department.
- Have the gas system checked and leakage source
corrected by a qualified installer, service agency,
manufacturer or dealer or the gas supplier.
WARNING
Avoid possible injury
or death.
CAUTION
Avoid possible injury and/or
property damage.
FOR YOUR SAFETY READ ALL INSTRUCTIONS BEFORE OPERATING APPLIANCE
INSTALLER: PROVIDE THESE INSTRUCTIONS TO THE CONSUMER.
CONSUMER: KEEP DOCUMENTS FOR FUTURE REFERENCE.

ENGLISH
2
CONTENTS
INSTALLATION 3
WARNING 3
HOLE 3
CONNECTING TO GAS SUPPLY 4
CONNECTING TO ELECTRICITY SUPPLY 4
FIXING 5
USE 6
SAFETY WARNINGS 6
CONTROLS 6
BURNERS 7
SELECTING BURNER 8
ELECTRONIC IGNITION COOKTOP 8
MANUAL IGNITION COOKTOP 8
COOKTOP FLAME REGULATION 8
VISUAL FLAME CONTROL 8
MAINTENANCE 9
INJECTOR 9
TEST PRESSURE POINT 9
CLEANING 9
WARRANTY 9
TECHNICAL PLAN 21-31
CARBON MONOXIDE POISONING
• NEVER USE THIS APPLIANCE AS A SPACE HEATER TO HEAT OR WARM THE ROOM.
DOING SO MAY RESULT IN CARBON MONOXIDE POISONING AND OVERHEATING
OF THE APPLIANCE.
• CARBON MONOXIDE (CO) POISONING PRODUCES FLU-LIKE SYMPTOMS, WATERY
EYES, HEADACHES, DIZZINESS, FATIGUE AND POSSIBLY DEATH. YOU CAN’T SEE
IT AND YOU CAN’T SMELL IT. IT’S AN INVISIBLE KILLER. IF THESE SYMPTOMS ARE
PRESENT DURING OPERATION OF THIS PRODUCT GET FRESH AIR IMMEDIATELY!
FOR YOUR SAFETY

USE
MAINTENANCE INSTALLATION ENGLISH
3
WARNING
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH REGULATIONS IN
FORCE AND ONLY USED IN A WELL VENTILATED SPACE. READ THE INSTRUCTIONS
BEFORE INSTALLING OR USING THIS APPLIANCE.THE APPLIANCE MUST BE
INSTALLED BY SPECIALIST TECHNICIANS.
Installation must conform with local codes or in the absence of local codes, with the American National Standard
for Recreational Vehicles, ANSI/A119.2 and the National Electrical Code, ANSI/NFPA 70. In Canada, installation
must conform with CSA Z240.4.2-M.
This appliance is designed to cook foods only. Any other use is considered incorrect and dangerous.
Any storage cabinet placed directly above the appliance should not be used when one or more of the appliance
burners are on. The manufacturer is not responsible for any damage to persons or parts due to incorrect
installation, improper, incorrect, or irresponsible use.
For proper operation of your cooking appliance:
THE CABINET MUST BE
• properly constructed.
• squared to the countertop and cabinet face
THE OPENING IN CABINET MUST BE
• level from side to side and front to rear
The cabinet opening must be constructed so that no combustible material can be placed next to the cooktop sides.
The maximum depth of cabinets installed above the cooking top must be 13’’.
INFLAMMABLE MATERIALS MUST BE KEPT AT A SAFE DISTANCE FROM THE
APPLIANCE.
HOLE
Clearances are measured to combustible materials.
Make a hole in the furniture as indicated in FIG. 2 - PAG. 22
The cabinet must be suitably constructed and horizontally and vertically aligned.
The cabinet aperture must be perfectly squared and aligned.
If there are apertures for cabinet ventilation, avoid that any flammable material can enter these.
MINIMUM CLEARANCES FROM THE EXTERNAL COMBUSTIBLE SURFACES (FIG. 4 - PAG. 31):
SIDE CLEARANCE FROM THE EDGE OF THE
APPLIANCE TO ANY VERTICAL WALL
OVERHEAD CLEARANCE FROM THE
APPLIANCE COOKTOP TO A
RANGE-HOOD OR SHELVES
FROM THE LOWER PART OF THE APPLIANCE
TO THE WALL UNDERNEATH
0 mm - 0”
762 mm - 30”
THE CLEARANCE MAY BE 495 mm - 19 1/2”
ONLY WHEN A VENT HOOD IS INSTALLED IN
ACCORDANCE WITH ANSI/NFPA 1192 ET CSA Z240
25 mm - 1”
THE APPLIANCE IS NOT TO BE USED AS A SPACE HEATER.

USE INSTALLATION
MAINTENANCE ENGLISH
4
DURING INSTALLATION AND CONNECTION, THE APPLIANCE GAS PIPE MUST
NOT BE TWISTED, STRETCHED OR DEFORMED IN ANY OTHER WAY CAUSING A
HAZARD TO THE USER.
THE APPLIANCE AND ITS INDIVIDUAL SHUTOFF VALVE MUST BE DISCONNECTED
FROM THE GAS SUPPLY PIPING SYSTEM DURING ANY PRESSURE TESTING.
LEAK TEST IN EXCESS OF 1/2 PSI (3,5 kPa) OF AIR PRESSURE WILL INVALIDATE
WARRANTY.
Do not over tighten connections to the gas regulator, as this may crack the regulator and cause a gas leak. Do not
allow the regulator to turn on the pipe when tightening fittings.
The connection of the gas supply pipe to the appliance must be gastight. Make sure that the gas supply pipe does
not touch any metal parts which get hot during operation of the appliance. It must also be installed so that there is
no contact with moving parts (e.g. drawers etc.) and must not pass through spaces where it can be deformed.
PRESSURE GAS
INPUT
INLET MAX INLET MIN. MANIFOLD
propane
14 IN. W.C.
(1/2 PSI)
11 IN. W.C.
(1/2 PSI)
10 IN. W.C.
(1/2 PSI)
TOTAL FLOW RATE DEPENDS ON THE MODEL AND NUMBER OF BURNERS. FOR FURTHER DETAILS ON
TOTAL FLOW RATE FOR THE MODEL PURCHASED, REFER TO THE “ BURNER” SECTION.
CONNECTING TO ELECTRICITY SUPPLY
CONNECT THE UNIT TO 12 V DIRECT CURRENT ONLY
DO NOT CONNECT TO HIGHER VOLTAGE
CONNECT ONLY TO PROTECTED CIRCUIT FUSED FOR NOT MORE THAN 3 Amps.
This chapter provides details on wiring for the following models: MO8322 - MO9523RSUS - PI8022A - PI8023.
The above models must be wired as illustrated in the “WIRING DIAGRAM”. Voltage supply must be between 9
and 13 V
This appliance operate with the following gas and corresponding supply pressure. The gas category of the appliance is
given on the specifications label affixed to the appliance.
CONNECTING TO GAS SUPPLY
THE USE OF A TYPE OF GAS AND/OR OF A PRESSURE DIFFERENT FROM THOSE
PRESCRIBED BY DOMETIC, MAY CAUSE IRREGULAR OPERATING CONDITIONS
OF THE APPLIANCE; FOR THIS REASON, DOMETIC DECLINES ANY
RESPONSIBILITY ORIGINATING FROM INCORRECT USE OF THE APPLIANCE
ITSELF.
Check all connections for gas leaks using a non-corrosive leak detection fluid. Do not use a soap and water
solution. Never use a naked flame.
LEAK TESTING OF THE APPLIANCE SHALL BE CONDUCTED ACCORDING TO THE
MANUFACTURER’S INSTRUCTIONS.

USE INSTALLATION
MAINTENANCE ENGLISH
5
FIXING
The appliance must be secured by means of the fastening screws (FIG. 3 - PAG. 29):
1) insert the appliance in the unit;
2) tighten the screws.
ALWAYS DISCONNECT THE ELECTRIC SUPPLY BEFORE ANY TYPE OF
INTERVENTION ON THE UNIT
LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS.
WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION.
VERIFY PROPER OPERATION AFTER SERVICING.
If polarity is incorrect electronic igniter will not function.
R = RED Wire
G = GREEN WITH YELLOW STRIPES Wire
(only for three burner models)
W = WHITE Wire
BK = BLACK Wire
= WIRE Connection
= Wired by Installer
= only for three burner models
SCHEMATIC DIAGRAM
CONNECTION DIAGRAM
WWW
TOP BURNERS
+
+
-
-
BKW BK
SWITCH
RBK
12 VOLT
BATTERY
IGNITION
MODULE
GCONNECTORS
WWW
TOP BURNERS
+
+
-
-
BKW BK
SWITCH
RBK
IGNITION
MODULE
G
SPARK ELECTRODES
12 V
WIRING DIAGRAM:

USE INSTALLATION
MAINTENANCE ENGLISH
6
SAFETY WARNINGS
THIS APPLIANCE MUST ONLY BE USED BY RESPONSIBLE ADULTS. DURING AND
IMMEDIATELY AFTER USE ACCESSIBLE PARTS MAY BE HOT; DO NOT TOUCH THEM
AND KEEP CHILDREN AWAY. ONCE COOKING IS COMPLETED, ENSURE THAT ALL
GAS CONTROL KNOBS ARE TURNED TO THE OFF POSITION. AFTER USE TURN OFF
THE GAS AT THE MAIN SUPPLY.
USE THE APPLIANCE ONLY IN A WELL VENTILATED SPACE. THE USE OF A GAS
COOKING APPLIANCE RESULTS IN THE PRODUCTION OF HEAT AND MOISTURE
IN THE ROOM IN WHICH IT IS INSTALLED. ENSURE THAT THE KITCHEN IS WELL
VENTILATED: KEEP NATURAL VENTILATION APERTURE OPEN OR INSTALL
A MECHANICAL VENTILATION DEVICE (MECHANICAL EXTRACTOR HOOD).
PROLONGED INTENSIVE USE OF THE APPLIANCE MAY REQUIRE ADDITIONAL
VENTILATION, FOR EXAMPLE OPENING OF A WINDOW, OR MORE EFFECTIVE
VENTILATION, FOR EXAMPLE INCREASING THE LEVEL OF THE MECHANICAL
VENTILATION WHERE PRESENT. COOKING FACILITIES MUST NOT BE USED
TO HEAT THE INSIDE OF THE VEHICLE. USE OVEN GLOVES OR POT HOLDERS
WHEN HANDLING HOT ELEMENTS. NEVER LAY PYREX LIDS OR OTHER ITEMS ON
THE BURNERS. KEEP APPLIANCE AREA CLEAR AND FREE FROM COMBUSTIBLE
MATERIALS, GASOLINE AND OTHER FLAMMABLE VAPORS AND LIQUIDS. DO NOT
OBSTRUCT THE FLOW OF COMBUSTION OR VENTILATION AIR.
CONTROLS
GLASS COOKTOP COVERS MAY SHATTER WHEN HEATED.
TOP COVER MUST BE OPEN WHEN ANY BURNER (COOKTOP, OVEN AND BROILER)
IS IN OPERATION AND TURN OFF ALL BURNERS (COOKTOP, OVEN AND BROILER)
BEFORE LOWERING THE COOKTOP GLASS COVER.
The following symbols indicate the burner corresponding to the control knob.
NOTE: different models may have different knobs and different symbols.
THIS SYMBOL IS PLACED NEXT TO THE COOKTOP BURNER KNOBS.
FULL DOT REFERS TO THE CORRESPONDING COOKTOP BURNER.
GRILL
LIGHT
OFF
OFF
LIGHT
250-350-450
WITH THE EXCEPTION OF MODEL CU402 WHEN USING THE Broiler THE DOOR MUST
BE KEPT OPEN AND WITH THE HEAT GUARD FULLY EXTRACTED. (FIG. xx - PG. xx)
EXCEPTE POUR LE MODELE CU402, PENDANT LE FONCTIONNEMENT DU GRIL, LA
PORTE DOIT RESTER COMPLETEMENT OUVERTE ET LA PLAQUE DE PROTECTION
CONTRE LA CHALEUR COMPLETEMENT SORTIE. (FIG. XX - PAGE XX)
GRILL
LIGHT
OFF
OFF
LIGHT
250-350-450
WITH THE EXCEPTION OF MODEL CU402 WHEN USING THE Broiler THE DOOR MUST
BE KEPT OPEN AND WITH THE HEAT GUARD FULLY EXTRACTED. (FIG. xx - PG. xx)
EXCEPTE POUR LE MODELE CU402, PENDANT LE FONCTIONNEMENT DU GRIL, LA
PORTE DOIT RESTER COMPLETEMENT OUVERTE ET LA PLAQUE DE PROTECTION
CONTRE LA CHALEUR COMPLETEMENT SORTIE. (FIG. XX - PAGE XX)
GAS OFF
HIGH FLAME
MINIMUM FLAME
IGNITE POSITION
The following symbols indicate the burner regulation corresponding to the knob position.
NOTE: different models may have different knobs and different symbols.

USE INSTALLATION
MAINTENANCE ENGLISH
7
OTHER SYMBOLS
PUSH BUTTON ELECTRONIC IGNITION
BURNERS
Technical specifications for burners referring to appliance model:
MODEL BURNERS TOTAL FLOW RATE
AUXILIARY SEMIRAPID RAPID
Ø 47 mm
Ø 1 27/32” Ø 62 mm Ø 2 7/16” Ø 77 mm Ø 3”
nr. (BTU/HR) nr. (BTU/HR) nr. (BTU/HR) BTU/HR
MO0911 1 (3700) 1 (5900) 9600
MO8302 1 (3700) 1 (5900) 9600
MO8322 1 (3700) 1 (5900) 9600
MO8801D 1 (3700) 3700
MO8801S 1 (3700) 3700
MO8821D 1 (3700) 3700
MO8821S 1 (3700) 3700
MO9523RSUS 1 (3700) 1 (5900) 1 (7200) 16800
PI8002 1 (3700) 1 (5900) 9600
PI8022 1 (3700) 1 (5900) 9600
PI8022A 1 (3700) 1 (5900) 9600
PI8003 1 (3700) 2 (5900) 15500
PI8023 1 (3700) 2 (5900) 15500
PI8621A 1 (3700) 3700
PI8621R 1 (7200) 7200
PI8621S 1 (5900) 5900
PI8802D 1 (3700) 1 (7200) 10900
PI8802S 1 (3700) 1 (7200) 10900
PI8822D 1 (3700) 1 (7200) 10900
PI8822S 1 (3700) 1 (7200) 10900
PI8842D 1 (3700) 1 (7200) 10900
PI8842S 1 (3700) 1 (7200) 10900
PI8862D 1 (3700) 1 (7200) 10900
PI8862S 1 (3700) 1 (7200) 10900

USE INSTALLATION
MAINTENANCE ENGLISH
8
VISUAL FLAME CONTROL
Propane: The flames internal tongue should be blue and the outline well defined.
6 - 16 cm
2 3/8” - 6 5/16”
16 - 22 cm
6 5/16” - 8 21/32”
AUXILIARY
Ø 47 mm - 1 27/32”
SEMIRAPID
Ø 62 mm - 2 7/16”
BURNER PAN DIAMETER
16 - 22 cm
6 5/16” - 8 21/32”
RAPID
Ø 77 mm - 3”
To ignite burner, gently push-in and turn the control knob to IGNITE POSITION and maintaining the knob pushed at
the same time press the electronic ignition pushbutton. Once the burner is alight maintain the knob in this position
for few seconds to the ensure the flame remains alight.
MANUAL IGNITION COOKTOP
THE FLAME MUST NEVER EXTEND BEYOND THE EDGE OF THE PAN. CENTER THE
PAN OVER THE BURNER ENSURING STABILITY ON THE PAN SUPPORT.
SELECTING BURNER
ELECTRONIC IGNITION COOKTOP (DEPENDING ON MODEL)
Manual ignition when the appliance is not fitted with the electronic ignition feature or in the event of failure in the
electronic ignition.
MAKE SURE THERE ARE NO PANS OR OTHER ANY OBJECTS ON THE BURNERS
WHEN IGNITING.
IF THE BURNER DOES NOT IGNITE IMMEDIATELY REPEAT IGNITION AFTER
HAVING FOLLOWED EACH STEP BELOW:
• TURN THE KNOB TO “MINIMUM FLAME”
• PROCEED WITH MANUAL IGNITION
• CHECK THERE IS SUFFICIENT GAS IN THE GAS BOTTLE.
IF THE APPLIANCE STILL DOES NOT IGNITE SHUT OFF THE GAS SUPPLY AT THE
MAIN GAS TAP AND CONTACT YOUR LOCAL DEALER.
MAKE SURE THERE ARE NO PANS OR OTHER ANY OBJECTS ON THE BURNERS
WHEN IGNITING.
To ignite burner, gently push-in and turn the control knob to IGNITE POSITION and maintaining the knob pushed at
the same time light the burner with a match or gas lighter. Once the burner is alight maintain the knob in this position
for few seconds to the ensure the flame remains alight.
IF THE BURNER DOES NOT IGNITE IMMEDIATELY CHECK THERE IS SUFFICIENT
GAS IN THE GAS BOTTLE.
IF THE APPLIANCE STILL DOES NOT IGNITE SHUT OFF THE GAS SUPPLY AT THE
MAIN GAS TAP AND CONTACT YOUR LOCAL DEALER.
COOKTOP FLAME REGULATION
To regulate flame turn the knob to the desired cooking flame.

USE INSTALLATION
MAINTENANCE
INJECTOR
CLEANING AND/OR REPLACEMENT OF BURNER INJECTORS (FIG. 1 - PAG. 21)
When removing or installing an injector, the holder must be held with a suitable tool.
THE OPERATIONS MUST BE CARRIED OUT BY AUTHORIZED PERSONNEL.
DOMETIC DECLINES ANY RESPONSIBILITY RELATED TO SAID INTERVENTION.
BURNERS HOBBED
NUMBER
AUXILIARY
Ø 47 mm - 1 27/32”
SEMIRAPID
Ø 62 mm - 2 7/16”
RAPID
Ø 77 mm - 3”
57
72
80
0,57
0,72
0,80
ENGLISH
9
TURN OFF THE APPLIANCE AND ALLOW TO COOL BEFORE CLEANING.
COLD WATER OR A DAMP CLOTH MAY DAMAGE HOT SURFACES.
CLEANING
TEST PRESSURE POINT
THE OPERATIONS MUST BE CARRIED OUT BY AUTHORIZED PERSONNEL.
DOMETIC DECLINES ANY RESPONSIBILITY RELATED TO SAID INTERVENTION.
The test pressure point is located on the pressure regulator.
WARRANTY
In case of warranty claim or any repair or replacement which becomes necessary, the vehicle or part dealer who sold
the product should be contacted. Give model and serial number on all repair part orders and correspondence.
DO NOT USE ABRASIVE, CORROSIVE, CHLORIDE-BASED PRODUCTS OR STEEL OR
OTHER SCOURING PADS. DO NOT LEAVE ACIDIC SUBSTANCES E.G. VINEGAR, SALT,
LEMON JUICE ETC. ON THE APPLIANCE SURFACES. STAINLESS STEEL SURFACES
AND ENAMELED PARTS SHOULD ONLY BE WASHED WITH SOAPY WATER OR
NEUTRAL DETERGENT, RINSED AND DRIED. ONLY USE CLEAN SPONGES OR
CLOTHS.

NOTE
10
