Dometic CFF20 User manual

CFF20, CFF35, CFF45, CFF70DZ
Compressor Cooler
Operating manual
EN
MOBILE COOLING
CFF
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 1 Dienstag, 20. Oktober 2020 4:16 16

© 2020 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 2 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ
3
Please carefully read and follow all instructions, guidelines and warnings included in this product manual in order to ensure that you install,
use and maintain the product properly at all times.
By using the product, you hereby confirm that you have read this disclaimer, all instructions, guidelines and warnings carefully and that you
understand and agree to abide by the terms and conditions as set forth herein.
You agree to use this product only for the intended purpose and application and in accordance with the instructions, guidelines and warnings
as set forth in this product manual as well as in accordance with all applicable laws and regulations.
A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and others,damage to your product
or damage to other property in the vicinity.
Dometic accepts no liability for any loss, damage or injury incurred, directly or indirectly, from the installation, use or maintenance of the
product not in compliance with the instructions and warnings in the product manual.
This product manual, including the instructions, guidelines and warnings, and related documentation may be subject to changes and
updates. For up-to-date product information, please visit: documents.dometic.com, dometic.com.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Function description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
10 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 3 Dienstag, 20. Oktober 2020 4:16 16

EN
Explanation of symbols CFF20, CFF35, CFF45, CFF70DZ
4
1 Explanation of symbols
D
!
!
A
I
2 Safety instructions
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• Do not operate the cooling device if it is visibly damaged.
• If this cooling device's power cable is damaged, it must be replaced
to prevent safety hazards.
• This cooling device may only be repaired by qualified personnel.
Improper repairs can lead to considerable hazards.
Fire hazard
• When positioning the device, ensure the supply cord is not trapped or
damaged.
• Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the device.
DANGER!
Safety instruction: Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 4 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Safety instructions
5
Health hazard
• This device can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the device in a safe way and understand
the hazards involved.
• Children shall not play with the device.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and unload
cooling devices.
Explosion hazard
• Do not store any explosive substances such as spray cans with a
flammable propellant in the cooling device.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Electrocution hazard
• Before starting the cooling device, ensure that the power supply line
and the plug are dry.
• Disconnect the cooling device from the power supply
– before each cleaning and maintenance
– after every use
Health hazard
• Please check if the cooling capacity of the device is suitable for storing
the food or medicine you wish to cool.
• Food may only be stored in its original packaging or in suitable
containers.
• Opening the cooling device for long periods can cause significant
increase of the temperature in the compartments of the device.
• Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
• Store raw meat and fish in suitable containers in the device, so that it is
not in contact with or can drip onto other food.
• If the device is left empty for long periods:
– Switch off the device.
– Defrost the device.
– Clean and dry the device.
– Leave the lid open to prevent mould developing within the device.
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 5 Dienstag, 20. Oktober 2020 4:16 16

EN
Safety instructions CFF20, CFF35, CFF45, CFF70DZ
6
ANOTICE! Damage hazard
• Check that the voltage specification on the type plate corresponds to
that of the energy supply.
• Only connect the cooling device as follows:
– With the DC connection cable to a DC power supply in the vehicle
– Or with the AC connection cable to an AC power supply
• Never pull the plug out of the socket by the cable.
• If the cooling device is connected to a DC outlet: Disconnect the
cooling device and other power consuming devices from the battery
before connecting a quick charging device.
• If the cooling device is connected to a DC outlet: Disconnect the
cooling device or switch it off when you turn off the engine. Otherwise
you may discharge the battery.
• The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
• The insulation of the cooling device contains flammable cyclopentane
and requires special disposal procedures. Deliver the cooling device
at the end of its life-cycle to an appropriate recycling center.
• Do not use electrical devices inside the cooling device unless they are
recommended by the manufacturer for the purpose.
• Do not place the cooling device near naked flames or other heat
sources (heaters, direct sunlight, gas ovens etc.).
•Risk of overheating!
Ensure at all times that there is a minimum of 50 mm ventilation on all
four sides of the cooling device. Keep the ventilation area free of any
objects that could restrict the air flow to the cooling components.
Do not place the cooling device in closed compartments or areas with
none or minimal air flow.
• Ensure that the ventilation openings are not covered.
• Do not fill the inner container with ice or fluids.
• Never immerse the cooling device in water.
• Protect the cooling device and cables against heat and moisture.
• The device shall not to be exposed to rain.
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 6 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Scope of delivery
7
3Scopeofdelivery
CFF20 CFF35, CFF45
CFF70DZ 3x
11
1
23
4
12/24 V DC12/24 V DC 100–240 V AC100–240 V AC
1
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 7 Dienstag, 20. Oktober 2020 4:16 16

EN
Intended use CFF20, CFF35, CFF45, CFF70DZ
8
4 Intended use
The cooling device is suitable for cooling food. The cooling device is also suitable for
use vehicles or on boats.
The cooling device is designed to be operated from a DC on-board power supply of
a vehicle or boat, a DC auxiliary battery or from an AC power supply.
The cooling device is suitable for camping use.
The cooling device is intended to be used in household and similar applications
such as
• staff kitchen areas in shops, offices and other working environments
•farmhouses
• clients in hotels, motels and other residential type environments
• bed and breakfast type environments
• catering and similar non-retail applications
This product is only suitable for the intended purpose and application in accordance
with this instruction. Any other use, deviating from the intended use, is not allowed!
Dometic accepts no liability for any loss, damage or injury incurred, directly or
indirectly due to other as the intended use.
Item Quantity Description
1 1 Cooler
2 1 Connection cable for DC connection
3 1 Connection cable for AC connection
4 2 Carry handle, consisting of:
•2holders
•1handle
• 4 fastening screws
• 1 allen wrench
– 1 Operating manual
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 8 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Function description
9
5 Function description
The cooler can chill products, keep them cool as well as freeze them. A low mainte-
nance refrigerant circuit with compressor provides the cooling. The generous insu-
lation and powerful compressor ensure efficient and fast cooling.
The cooler is portable.
The cooler can withstand a short-term inclination of 30°, for example on boats.
5.1 Scope of functions
• Power supply with priority circuit for connecting to the AC mains
• Three-level battery monitor to protect the vehicle battery
switches off automatically at low battery voltage
• Display with temperature gauge in °C and °F
• Temperature setting: With two buttons in steps of 1 °C (2 °F)
• Display dimming function with 3 brightness levels
• Removable wire basket (CFF35, CFF45, CFF70DZ only)
• Removable carrying handles
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 9 Dienstag, 20. Oktober 2020 4:16 16

EN
Function description CFF20, CFF35, CFF45, CFF70DZ
10
5.2 Operating and display elements
Lid latches
CFF20
CFF70DZ
CFF35, CFF45
2
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 10 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Function description
11
Operating panel
Item Description Explanation
1ON
OFF
Switches the cooler on or off when the button is pressed for
between one and two seconds
2POWER “P”Status indication
LED lights up green: Compressor is on
LED lights up orange: Compressor is off
LED flashes orange: Display switched off automatically due
to low battery voltage
3 ERROR LED flashes red: Device is switched on but not ready
for operation
4 – Display, shows the information
CFF70DZ only: There‘s one display per zone
°
1 2 3 4 5 6 7
°
1 2 3 4 5 6 7
1 2 3 45 6 7
8
CFF20
CFF35, CFF45
CFF70DZ
3
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 11 Dienstag, 20. Oktober 2020 4:16 16

EN
Function description CFF20, CFF35, CFF45, CFF70DZ
12
Connection sockets
5 SET Selects the input mode
– Temperature setting
– Celsius or Fahrenheit display
– Set battery monitor
– Set brightness of display
6 DOWN – Press once to decrease the value
7 UP + Press once to increase the value
8CFF70DZ only: Status indication: LED lights up blue when the
compartment is cooling
Item Description
1 Connection socket AC voltage supply
2 AC fuse holder
3 DC fuse cover
4 Connection socket DC voltage supply
Item Description Explanation
100 - 240V~AC 12 - 24V DC
31 2 4
4
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 12 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Operation
13
6Operation
6.1 Before initial use
I
Mounting the handles
The handles are enclosed unassembled. If you wish to attach the handles, proceed
as follows:
➤Assemble a handle by putting two holders (1) and a handle (2) together.
➤Fasten the holders with the enclosed screws in the holes provided.
NOTE
Before starting your new cooler for the first time, you should clean it
inside and outside with a damp cloth for hygienic reasons (please also
refer to the chapter “Cleaning and maintenance” on page 28).
CFF20 CFF70DZCFF35, CFF45
2x
1
2
1
5
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 13 Dienstag, 20. Oktober 2020 4:16 16

EN
Operation CFF20, CFF35, CFF45, CFF70DZ
14
Reversing the lid opening
➤CFF70DZ: To reverse the lid opening, proceed as shown.
1.
2.
3.
1.
2.
1.
2.
2.
1.
3.
2.
1.
180°
7
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 14 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Operation
15
Opening or removing the lid
2.
1.
1.
A
BA
B
BA
CFF20
CFF70DZ
CFF35, CFF45
2.
1.
1.
2.
8
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 15 Dienstag, 20. Oktober 2020 4:16 16

EN
Operation CFF20, CFF35, CFF45, CFF70DZ
16
➤To open the lid, unlatch (A).
CFF35, CFF45: The lid can be opened from either side.
➤CFF35, CFF45: To remove the lid, unlatch both sides at the same time (B).
CFF20, CFF70DZ: To remove the lid, push the lid beyond the lid stop
position (B).
Lid stop position
The lid has a built-in stop position (A). Do not force the lid past the built-in stop (B).
ANOTICE! DAMAGE HAZARD
CFF35, CFF45: If the lid has been forced too far, follow the steps
described in the chapter “The lid has been forced past the built-in stop
(CFF35, CFF45 only)” on page 31.
CFF35,
CFF45
B
A
9
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 16 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Operation
17
Removing the basket
A
Selecting the temperature units
Temperature display units can be switched between Celsius and Fahrenheit as
follows:
➤Switch on the cooler.
➤CFF20, CFF35, CFF45: Press the “SET” button (fig. 35, page 11) twice.
CFF70DZ: Press the “SET” button (fig. 35, page 11) three times.
➤Use the “UP +” (fig. 37, page 11) or “DOWN –” (fig. 36, page 11) buttons to
select Celsius or Fahrenheit.
✓The selected temperature unit then appears in the display for a few seconds. The
display flashes several times before it returns to the current temperature.
NOTICE! DAMAGE HAZARD!
CFF35, CFF45: Removing the basket with the lid open may scratch the
lid and deform the basket. We recommend to remove the lid (fig. 8)
before removing the basket (fig. 0).
CFF35, CFF45
0
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 17 Dienstag, 20. Oktober 2020 4:16 16

EN
Operation CFF20, CFF35, CFF45, CFF70DZ
18
6.2 Energy saving tips
• Choose a well ventilated location which is protected from direct sunlight.
• Allow warm food to cool down first before placing it in the cooling device to
keep cool.
• Do not open the cooling device more often than necessary.
• Do not leave the cooling device open for longer than necessary.
• Defrost the cooler once a layer of ice forms.
• Avoid unnecessarily low temperatures.
6.3 Connecting the cooler
Connecting to a battery (Vehicle or boat)
The cooler can be operated with 12 V or 24 Vg.
A
For safety reasons the cooler is equipped with an electronic system to prevent
polarity reversal. This protects the cooler against short-circuiting when connecting to
a battery.
Using the fused DC plug
A
➤Plug the DC connection cable (fig. 12, page 7) into the DC voltage socket of
the cooler (fig. 43, page 12).
➤Connect the connection cable to a DC power outlet.
NOTICE! DAMAGE HAZARD
Disconnect the cooler and other consumer units from the battery before
you connect the battery to a quick charging device.
Overvoltage can damage the electronics of the device.
NOTICE! DAMAGE HAZARD
For protection of the device the DC cable supplied includes a fuse inside
the plug. Do not remove the fused DC plug.
Only use the DC cable supplied.
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 18 Dienstag, 20. Oktober 2020 4:16 16

EN
CFF20, CFF35, CFF45, CFF70DZ Operation
19
Connecting to an AC power supply (e.g. in the home or office)
D
The coolers have an integrated multi-voltage power supply with priority circuit for
connecting to an AC voltage source. The priority circuit automatically switches the
cooler to AC operation if the device is connected to an AC power supply, even if the
DC connection cable is still attached.
When switching between the AC power supply and the battery supply, the red LED
may light up briefly.
➤Plug the AC connection cable (fig. 13, page 7) into the AC voltage socket of
the cooler (fig. 41,page 12).
➤Connect the connection cable to an AC power outlet.
DANGER! ELECTROCUTION HAZARD
Failure to obey these warnings will result in death or serious injury.
• Never handle plugs and switches with wet hands or if you are stand-
ing on a wet surface.
• If you are operating your cooler on board a boat from a AC power
supply, you must install a residual current circuit breaker between the
AC power supply and the cooler.
Seek advice from a trained technician.
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 19 Dienstag, 20. Oktober 2020 4:16 16

EN
Operation CFF20, CFF35, CFF45, CFF70DZ
20
6.4 Using the battery monitor
The device is equipped with a multi-level battery monitor that protects your vehicle
battery against excessive discharging when the device is connected to the on-board
DC supply.
If the cooler is operated when the vehicle ignition is switched off, the cooler switches
off automatically as soon as the supply voltage falls below a set level. The cooler will
switch back on once the battery has been recharged to the restart voltage level.
A
In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and
“MED” (see the following table).
The battery monitor mode can be selected as follows:
➤Switch on the cooler.
➤Press the “SET” button (fig. 35, page 11):
–CFF20, CFF35, CFF45: Three times.
–CFF70DZ: Four times.
➤Use the “UP +” (fig. 37, page 11) or “DOWN –” (fig. 36, page 11) buttons to
select the battery monitor mode.
✓Display will be as follows:
Lo (LOW), ΠEd (MED), Hi (HIGH)
✓The selected mode then appears in the display for a few seconds. The display
flashes several times before it returns to the current temperature.
NOTICE! DAMAGE HAZARD
When switched off by the battery monitor, the battery will no longer be
fully charged. Avoid starting repeatedly or operating current consumers
without longer charging phases. Ensure that the battery is recharged.
Battery monitor mode LOW MED HIGH
Switch-off voltage at 12 V 10.1 V 11.2 V 11.8 V
Restart-voltage at 12 V 11.4 V 12.2 V 12.6 V
Switch-off voltage at 24 V 21.5 V 24.1 V 24.6 V
Restart voltage at 24 V 23.0 V 25.3 V 26.2 V
DometicCFF20-35-45-75DZ_OPM_4445103133_APAC(en)_202x-xx-xx.book Seite 20 Dienstag, 20. Oktober 2020 4:16 16
