Dometic SKYSCREEN Instruction manual

SKYSCREEN
Assembly, Tensioning & Installation Instructions
Parts Diagram
Roller Surface 2

Page 2 of 8
Unpack SKYSCREEN using suitable implement to avoid damaging contents and lay SKYSCREEN out as shown.
A
BContents:
A. Blind/Fly Cassettes - 2 off
B. Side Rail - 2 off
Lay cassette and side rail face down as shown. Line up and
slot corner radius into side rail.
Continue to slot side rail
onto corner moulding.
Lift crossbar and
continue to slot side rail.
Ensure side rail slots on
inside of corner moulding lip.
Side rail clips into place as
shown, a denite click should
be heard.
Click !!
Repeat steps above for other corners. Test operation of screen.
Assembly instructions

Page 3 of 8
Tensioning the Blind or Fly
With the screen facing you, the tension adjustment is located under the right hand top screw cover
Remove screw cover and
turn the SKYSCREEN over.
SPRING TENSION
Un-clip the tensioner as shown.
CAUTION, this will be under spring tension.
SPRING TENSION
Insert screwdriver in tensioner slot and allow spring to retract
from corner moulding. Spring tension will now be felt in the
two directions shown.
Keeping spring under
tension, clip the tensioner
back in to the corner
moulding.
Turn clockwise to tension or
anti-clockwise to de-tension.
NOTE: No more than 8 full
turns should be required.
To test for sufcient tension, pull blind/y back to the distance
shown and let go. The blind should fully return smoothly
without snapping back into casette.
The SKYSCREEN Is assembled and tested before shipping and does not need tensioning. However if tensioning is lost for any
reason, please follow the steps below.

Page 4 of 8
1
2
1
2
3
4
Open screw covers as shown.
Insert and tighten screws in each corner using
screwdriver, do not use electric screwdriver.
Note:
If the screen is to be tted on to a soft headlining, we
recommend the use of M4 plastic washers (not supplied) to
shim between the screen and headlining. This will help to
avoid distortion of the frame and over compressing the
headlining material.
1
2
1
2
3
4
3
Installing the SKYSCREEN
Turn over and remove protective covers from adhesive
pads in each corner.
Ensuring mounting surfaces are free form dust or grease,
use the adhesive pads to hold the SKYCREEN in position
and drill pilot holes. Ensure that the thickness of the boat
structure at the proposed mounting position is deep enough
to prevent the xing screws from breaking through. Oceanair
recommend No6 x 16mm [5/8”] PANHEAD Screws (not
provided). However if necessary, use shorter xing screws and
use masking tape on the drill bit as a depth guide to avoid
drilling too deep.
x 4
x 4
4
5
Close screw covers.
6
Check operation of SKYSCREEN.
Before installation
• Measure the SKYSCREEN and make sure it is the correct size.
• Make sure the unit is tted to a at surface to avoid forcing the unit out of shape when xing.
• If SKYSCREEN is large; ensure a minimum of two people undertake the installation.
• Ensure that the SKYSCREEN is the correct way up and in the desired orientation.
• Make sure that the SKYSCREEN is not twisted; distortion will damage the blind and affect operation.
