Dometic RV SOLAR POWER KITS SOLAR EXTREME User manual

RV SOLAR POWER
KITSTM
User Manual
SOLAR EXTREME
SOLAR ELITE
WEEKENDER ISW
OVERLANDER
OVERLANDER-E
RETREAT
RETREAT-E
SLIM-100
SLIM-100E
© 2022 Go Power!
Worldwide Technical Support and Product Information gopowersolar.com
Go Power! | Dometic
201-710 Redbrick Street Victoria, BC, V8T 5J3
Tel: [phone]
56587_MANUAL_GP_RV-KITS-SYSTEMS_RevN
SCAN FOR THE
LATEST MANUAL

gopowersolar.com | [page 3]
2. GENERAL INFORMATION........................................................................................................................4
2.1 HOW DOES A GO POWER! RV SOLAR CHARGING KIT WORK?..........................................................4
2.2 CAUTIONS ......................................................................................................................................6
2.3 DISCLAIMERS..................................................................................................................................7
2.4 KIT PARTS .......................................................................................................................................8
2.4.1 PARTS CHECKLIST ...............................................................................................................8
2.5 REQUIRED TOOLS..........................................................................................................................10
3. PLANNING LOCATIONS .........................................................................................................................11
3.1 PLAN YOUR SOLAR SYSTEM SETUP ...............................................................................................11
3.2 PLACEMENT OF SOLAR PANELS ....................................................................................................11
3.3 GP-PWM-30 SOLAR CHARGE CONTROLLER ...................................................................................12
4. INSTALLATION.........................................................................................................................................13
4.1 MOUNTING FEET ..........................................................................................................................13
4.2 SOLAR PANELS..............................................................................................................................13
4.3 REFRIGERATOR VENT ACCESS 1 ....................................................................................................14
4.4 REFRIGERATOR VENT ACCESS 2 ....................................................................................................14
4.5 CABLE ENTRY PLATE .....................................................................................................................14
4.6 INSTALLING THE GP-PWM-30 SOLAR CHARGE CONTROLLER.........................................................15
4.7 INSTALLING THE 30A FUSE AND FUSE HOLDER .............................................................................15
4.8 CONNECTING GP-PWM-30 TO BATTERY BANK ..............................................................................16
4.9 INITIAL CONNECTION AND OPERATING ........................................................................................16
4.10 BATTERY BANK CONFIGURATIONS ...............................................................................................16
5. MAINTENANCE .......................................................................................................................................17
6. WARRANTY RETURN PROCEDURE......................................................................................................18
7. SYSTEM DIAGRAMS...............................................................................................................................19
CONTENTS

[page 4] | gopowersolar.com
Congratulations on purchasing your Go Power! RV Solar Kit. You have chosen a clean, quiet and sustainable power source. Go Power!
Solar RV Kits allow you to power appliances in your RV, without hooking up to shore power or a noisy generator. Go Power! Solar RV
kits will keep your batteries charged, ensuring you have power when you need it.
This mobile DC power system allows you to enjoy the luxuries that electricity provides, without a campsite hookup. For simple battery
maintenance or full-time live-aboard power, Go Power! RV Solar Power Kits are available in a variety of sizes and can be installed on
RVs, campers, trailers, fth wheels and motor homes. As with any off-grid power systems, the user is required to manage electrical
loads to ensure continual power availability for essential services. Your location and season (hours of sunlight available) play a role in
how much energy can be harnessed from this kit.
This manual will aid in the process of installing the Go Power! Solar RV Kit. Please read and understand this manual and
all included manuals before installing the Go Power! Solar RV Kit. Review all diagrams included in this guide for the easiest
and safest installation. Please retain this manual for future reference.
Note
2.1 HOW DOES A GO POWER! SOLAR CHARGING KIT WORK?
The solar panel converts the sun’s energy into DC electricity and this electricity charges the battery. The battery stores the electricity,
similar to a water tank storing water. This battery power may be used at any time to operate DC powered devices connected to the
battery. To increase the battery service life, a solar controller is used to prevent the solar panels from overcharging the batteries. This
is process is managed by the GP-PWM-30 Solar Charge Controller included in this kit. See Figure 2-A (below) and 2-B (on following
page) for solar system examples.
WARNING: When connecting multiple panels, they will be connected in PARALLEL. Failure to follow this connection pro-
cedure will cause the system to produce large currents which the protection device, DC fuse, is not designed to handle.
RV Console
Area
Solar
Controller
Cable to
Battery
Bank
Battery Bank
Inverter
Transfer Switch
Solar Panel (s)
Cables From
Solar Charge Controller
Internal
View
Inverter
Remote
Converter /
Battery Charger
Refrigerator
Vent Cover
Shore Power /
Generator
Note: Max 30A AC
service for Weekender
FIGURE 2-A: TYPICAL RV INSTALLATION
2. GENERAL INFORMATION
Note

gopowersolar.com | [page 5]
GP DC
BREAKER KIT
SC Connector
Legend
Fuse
Battery Bank
Refrigerator
Vent Cover
or Cable Entry Plate
Inverter
Inverter
Remote
AC
Loads
AC
Panel
Transfer
Switch
Fuse
Converter /
Charger
Shore Power
/ Generator
SC Red Positive
Extension
Cable (25 ft)
"CLICK"
SC Black Negative
Extension Cable (25 ft)
Items Supplied in
Weekender Kit Only
Solar Panel
Note: Max 30A AC
service for Weekender
PWM 30
Solar Charger
Controller
FIGURE 2-B: SOLAR SYSTEM TYPICAL WIRING DIAGRAM
Note: * All fuse sizes dependant on application For Elite and Extreme Kit
GENERAL INFORMATION

[page 6] | gopowersolar.com
2.2 CAUTIONS
Disconnect all power
sources before attempting
installation
Electricity can be very dangerous. Installation should be performed only
by a licensed electrician or qualied personnel.
Solar panel safety
Photovoltaic panels generate DC electricity when exposed to sunlight or
other light sources. Contact with the electrically active parts of the panel,
such as terminals, can result in burns, sparks and lethal shock whether
the panel is connected or disconnected.
When panels are connected in parallel, amperages are additive. Conse-
quently, a system assembled from photovoltaic panels can produce high
amperages, which constitute an increased hazard. Do not touch terminals
while panel is exposed to light. Cover the panel face completely with
opaque material to halt the production of electricity when installing or
working with panels or wiring.
Battery and wiring safety
Observe all safety precautions of the battery manufacturer when handling
or working around batteries. When charging, batteries produce hydrogen
gas, which is highly explosive. Work in a well ventilated area and use
caution when making or removing electrical connections. Ensure wires
are disconnected from their power sources when wiring. Do not expose
battery to open ame, cigarettes or sparks. Shield skin and eyes from
battery acid.
Ensure all connections are tight and secure. Loose connections may gen-
erate sparks, heat and in extreme cases may catch re. Be sure to check
connections one week after installation to ensure they are still tight.
Work safely
Wear protective eye wear and appropriate clothing during installation.
Use extreme caution when working with electricity and when handling
and working around batteries. Use properly insulated tools only.
Observe correct polarity
at all times
Reverse polarity of the battery terminals will cause the controller to give
a warning tone. Reverse connection of the array will not cause an alarm
but the controller will not function. Failure to correct this fault could
damage the controller.
Do not exceed the voltage
and current ratings of the
Solar Controller
The total current of the solar system is the sum of the short circuit current
of the solar panels in parallel, multiplied by a safety factor of 1.25. The
resulting system current is not to exceed the amperage rating of the
controller. The voltage of the array is the rated open circuit voltage of
the solar panels and is not to exceed 28volts.
The current rating of the solar system is the sum of the Maximum Power
Current (Imp) of the solar PV strings in parallel. The resulting system Imp
current is not to exceed 30A. If your solar system exceeds these ratings,
contact your dealer for a suitable controller alternative.
Observe AC service current
requirements of the RV or
boat
The Weekender kit is compatible with max 30A AC service. The Elite and
Extreme kits are compatible with max 50A AC service.
GENERAL INFORMATION

gopowersolar.com | [page 7]
2.3 DISCLAIMERS
IMPORTANT: Please follow installation and wiring instructions exactly as outlined to ensure safety. We recommend installation by an
RV technician or professional electrician to ensure adherence to relevant electrical codes. We have made every reasonable effort to
ensure the accuracy of the instructions in this manual, but Go Power! does not guarantee that the information is error free, nor do we
make any other representation, warranty or guarantee that the information is accurate, correct, reliable or current. The specications
in this manual are for reference purposes only and are subject to change without notice. For additional information please see www.
gopowersolar.com.
DISCLAIMER: Go Power! disclaims liability for any direct, indirect or incidental damages caused by, or in case of, installation not
performed following the instructions and cautions in this manual. Go Power! will refuse requests for exchanges or returns, resulting
from the purchase and installation of items which do not comply with local codes. To avoid such concerns Go Power! recommends
installation by a professional electrician or RV technician. Examples that are shown within this manual are for illustrative purposes only.
GENERAL INFORMATION

[page 8] | gopowersolar.com
2.4 KIT PARTS
Please unpack and make sure all parts shown in the list below are included in the kit. If any parts are missing please contact
the Go Power! customer service team at [e-mail] or 1.866.247.6527.
2.5 PARTS CHECKLIST
SLIM-100 SLIM-100E RETREAT RETREAT E OVERLANDER OVERLANDER-E WEEKENDER ISW SOLAR ELITE SOLAR EXTREME
ITEM # DESCRIPTION
01 Solar panel 1 1 1 1 1 1 1 2 3
02 Solar panel mounting feet 4 4 4 4 4 4 4 8 12
03 1/4” bolt 4 4 4 4 4 4 4 8 12
04 1/4” lock nut 4 4 4 4 4 4 4 8 12
05 1/4” washer 8 8 8 8 8 8 8 16 24
06 #10-16 x 1” screw 8 8 8 8 8 8 8 16 24
07 #6 x 3/4” screw 6 6 6 6 6 18
08 SC Black Negative Wire Extension Cable (25 ft) 1 1 1 1 1 1
09 SC Red Positive Wire Extension Cable (25 ft) 1 1 1 1 1 1
10 Butt Splice, 12-10 AWG 2 2 2 2 2 2
11 Fuse Holder 1 1 1 1 1 1
12 30A Fuse 1 1 1 1 1 1
13 Heat Shrink 2 2 2 2 2 2
14 Tie Wrap 6 6 6 6 6 6
15 Cable Clamp 6 6 6 6 6 6
16 Ring Terminal 2 2 2 2 2 2
17 PWM 30 Amp Solar Charge Controller 1 1 1 1 1 1
18 SC Expansion Connector (1 Male, 2 Female) 1 1 1 1 2
19 SC Expansion Connector (2 Male, 1 Female) 1 1 1 1 2
20 1500 Watt Industrial Pure Sine Inverter 1
21 2000 Watt Pure Sine Inverter Charger (with built-in 100 Amp
Battery Charger and 50 Amp Transfer Switch) 1
22 3000 Watt Pure Sine Inverter Charger (with built-in 125 Amp
Battery Charger and 50 Amp Transfer Switch) 1
23 30 Amp Transfer Switch 1
24 Industrial Pure Sine wave Inverter Remote 1
25 Inverter Charger Remote 1 1
26 GP-DC-Kit 1 1 1
Note
GENERAL INFORMATION

gopowersolar.com | [page 9]
1 2 3 4 5
6, 7 8 9 10 11, 12
13 14 15 16 17
18 19 20 21, 22 23
24 25 26
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
2:1
-
GP-MH-4: SOLAR PANEL
MOUNTING HARDWARE
1 OF 1
74652
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Taylor Townsend
Taylor Townsend
07/31/2015
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
74652
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
2:1
-
GP-MH-4: SOLAR PANEL
MOUNTING HARDWARE
2 OF 2
74652
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Taylor Townsend
Taylor Townsend
07/31/2015
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
74652
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
30
Battery Bank
30A
PWM 30
Solar Charger
Controller
SHORE POWER
UNIT READINGS
INVERTER
ON/OFF
CHARGER
ON/OFF
ENTER / SET BACK
UNIT SETUP
REMOTE SETTINGS
®
GENERAL INFORMATION
G
P
-
D
CKi
t
/G
P-
BREAK
E
R-
K
IT
GP-
D
C-
B
REAKE
R
-KI
T
-2
5
0

[page 10] | gopowersolar.com
2.6 REQUIRED TOOLS
a. Screwdriver (Phillips)
b. Keyhole Saw
c. Pencil or Marker
d. Pliers
e. Wire Strippers and Cutters
f. Butt Splice Crimping Tool
g. Electric Hand Drill
h. 1/16” and 3/8” Drill Bits
i. 5/16” & 7/16” Wrench
j. Heat Gun
k. Caulking Gun
l. Sealant
m. Digital Multimeter (troubleshooting only)
n. Torque Driver (optional)
Design your solar set up here:
GENERAL INFORMATION

gopowersolar.com | [page 11]
3.1 PLAN YOUR SOLAR SYSTEM SETUP
1. Take a few minutes before commencing any installation work to layout your solar system on paper rst. Use the diagrams within
this manual (pages 20-27) to help.
2. Complete a simple block diagram identifying the key components and connections of your Solar charging system: Solar Panels, SC
Positive and Negative Extension Cables, GP-PWM-30 Solar Charge Controller and your Battery Bank as detailed in the diagrams.
3. For the Elite and Extreme Kits include the Inverter, Charger/Converter and Transfer Switch. For detailed installation of these system
components see the specic manuals included with each item.
4. Identify and prepare easy/safe access to possible installation locations in the 3 key installation areas within your RV;
• Roof Solar Panels
• Instrument/Controls Solar Charge Controller and/or Inverter Remote
• Storage Compartments Inverter, Converter/Charger, Transfer Switch
5. Identify on your RV if you have a Cable Entry Plate (CEP) see Fig 3-A pre-installed by the RV Manu-
facturer. The Cable Entry Plate makes the Solar Panel to Solar Charge Controller installation simpler.
(After market purchase of GP-CEP available)
6. If you do not have the Cable Entry Plate pre-installed on your RV, you will be following the ‘Routing
Power Cable through the Refrigerator Vent’ steps.
7. Whilst on the roof of your RV identify the refrigerator vent and investigate the vent-fastening
hardware.
3.2 PLACEMENT OF SOLAR PANELS
1. Remove all solar panels from their boxes. Set aside the boxes as they will be used in the instructions to follow.
2. Using the solar panel boxes, plan the layout of the panels on your RV rooftop. Once you have positioned the boxes
• Placement of the panel(s) should be as close together as possible. Each panel has 3.3’ of cable coming from the junction
box. It may be necessary to use solar panel extension cables. If required, longer extension cables can be purchased.
Please contact customer service at 1.866.247.6527 to purchase.
• Select a location where the mounting surface is at least 1/2” thick and strong enough to support the solar panel
mounting hardware.
• Solar panels should be located a minimum of 3’ from the front of RV to reduce wind load on the panels.
• Avoid internal wiring when selecting the solar panel mounting locations for drilling the mounting holes.
• Ensure xed obstacles, such as air conditioners, will not shade the solar panels. (Shading can greatly reduce the per-
formance of the solar system).
• Ensure there is enough room to access the panels and other xed obstacles for future inspection and maintenance.
3.3 LOCATING THE GP-PWM-30 AMP SOLAR CHARGE CONTROLLER
The GP-PWM-30 is included in all Go Power! RV Solar Kits detailed in this manual except for the expansion kits (Retreat-E, Overlander-E).
The GP-PWM-30 provides the necessary protection for the RV battery system. A condensed version of the installation instructions
appear in this manual. However, please read the full installation manual included with the GP-PWM-30 Solar Charge Controller.
1. Plan where the GP-PWM-30 solar charge controller will mount, see Figure 3-B.
• The GP-PWM-30 is designed to be mounted vertically in an indoor location inside a weatherproof enclosure.
• Ideally the GP-PWM-30 should be located so it can be easily seen for monitoring system operation. Locate at eye level
(the backlit LED affects viewing angle)
• The location will need access to the cable ends from the solar panels and the battery compartment.
WARNING: Failure to secure the GP-PWM-30 could cause it to become dislodged while the RV is in transit and cause severe
damage to the unit and/or the RV.
FIGURE 3-A: CEP
3. PLANNING LOCATIONS
Note
Note

[page 12] | gopowersolar.com
4.1 MOUNTING FEET
1. Assemble 4 mounting feet onto each of the solar panels frame using the 1/4” bolts and nuts. This assembly is easily completed
on the ground before the panels are brought up to the RV roof. (See Figure 4-A)
WARNING:
• The mounting feet must be installed on the 4 outer holes in the panel frame.
• All 4 mounting feet must be used on a solar panel.
• The mounting surface must be at least 1/2” thick and strong enough to support the solar panel mounting hardware.
2. Tighten the nuts securely using a 7/16” wrench.
W
W
AA
SECTION W-W
Screw
Z-Foot
Lock Nut
Bolt
Solar Panel Frame
Exterior RV Roof
Washer
Washer
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL SEE PART MATERIAL
FINISH N/A
FINISH
SPEC
N/A
COLOR N/A
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:12
-
GP-MH-4: SOLAR PANEL
MOUNTING HARDWARE
1 OF 2
74652
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Taylor Townsend
Taylor Townsend
07/31/2015
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
74652
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
FIGURE 4-A: SOLAR PANEL INSTALLATION DETAILS
4. INSTALLATION
4.2 SOLAR PANELS
WARNING: Photovoltaic panels generate DC electricity when exposed to sunlight or other light sources. When exposed to
light, contact with the electricity active parts of the panel, such as terminals, can result in burns, sparks and lethal shock
whether the panel is connected or disconnected.
Do not touch the terminals while the panel is exposed to light. Cover the panel faces completely with an opaque material to
stop the production of electricity when working with panels or wiring – the cardboard shipping boxes are the perfect option
to cover glass surface of the panels.
Panels are not recommended to bend beyond 30° (for 100W Modules, 30° = 2.7”, 69mm Bend)
Site Considerations — Excluded Operating Environments
Certain extreme operating environments are not recommended for Go Power! products and are excluded from the Go Power! limited
warranty. These include (but are not limited to): winds exceeding 45 MPH, ooding or immersion in water or other uids, contact with
liquids or substances with a pH less than 6.5 or greater than 8.5, and contact with re, projectiles, lava ow, volcanic eruptions, or meteors.
Mounting Congurations
Modules installed over a roong system must be mounted over a at, re-resistant roof covering with the appropriate safety rating
for the application. While modules can be mounted at any vertical or horizontal angle, it is recommended that they are installed at a
minimum 10-degree angle to reduce dirt accumulation and soiling.
WARNING: Do not install panels on a surface that is not re resistant or that can be damaged by high temperatures. These
panels are designed to not catch re themselves but can get hot during normal operation and excessively hot in some
failure conditions such as cracked cells or failed protection diodes. Go Power! is not responsible for heat damage such as
discoloration, holes or re due to improper installation.
Note

gopowersolar.com | [page 13]
GP DC
BREAKER KIT
SC Connector
Legend
Fuse
Battery Bank
Refrigerator
Vent Cover
or Cable Entry Plate
Inverter
Inverter
Remote
AC
Loads
AC
Panel
Transfer
Switch
Fuse
Converter /
Charger
Shore Power
/ Generator
SC Red Positive
Extension Cable (25 ft)
"CLICK"
SC Black Negative
Extension Cable (25 ft)
Items Supplied in
Weekender Kit Only
Solar Panel
Note: Max 30A AC
service for Weekender
PWM 30
Solar Charger
Controller
Water entering the junction box could present a safety hazard, and junction boxes should be oriented on the uppermost position of
the panel. The junction box should never be mounted in a depression. Note the junction box manufacturer rates this product with an
ingress protection rating of IP67 for the box.
Modules may be attached using an adhesive on the panel backside or by using the grommet holes as attachment points. Go Power!
does not recommend a preferred attachment method or make any claim as to the safety of the attachment.
Mount modules away from obstructions such as vents, AC Units, etc.
Module Handling
Always use gloves when handling modules. Modules are sensitive to oils and abrasive surfaces — not doing so may lead to scratching
and soiling. Minimize module contact as much as possible, especially with any abrasive surfaces. Do not place anything on the mod-
ules. Do not lift modules by the cables or the junction box under any circumstances. Remove ngerprints from the panels by washing
the panel as described below.
Do not use blunt or sharp force with other hardware (junction boxes, cables and connectors). The resulting damage could render the
module unusable.
1. REMOVE shipping plastic from panel (if applicable)
2. Expose the panel(s) to sunlight and use a voltmeter to test for DC Voltage
3. Locate the solar panels on the RV roof replacing each of the boxes used in the planning step.
4. Locate the Cable Entry Plate / Fridge Vent or Access Point on the roof.
5. Attached the SC Positive and Negative Extension Cables to the solar panel (s).
FIGURE 3-B
INSTALLATION

[page 14] | gopowersolar.com
6. Test that the end solar panel cables can reach the CEP / Fridge Vent Access Point.
7. Use the screws provided in the kit to secure the 4 solar panel mounting feet to the RV.
8. Apply sealant under and around each of the 4 mounting feet to ensure a watertight installation.
WARNING: All 4 mounting feet must be securely fastened to the RV roof. Failure to do so could cause the panels to lift
and separate from the RV while in transit which could cause signicant damage and/or injury.
Use appropriate sealant as recommended by your RV Dealer for your RV roof.
.
Note
INSTALLATION

gopowersolar.com | [page 15]
4.5 CABLE ENTRY PLATE - OPTION 3
1. Remove the rubber sealing caps from the ends of the SC con-
nectors in the CEP.
2. Plug the Positive and Negative SC Connectors from the solar
panels directly into the CEP
3. Locate the positive and negative cables exiting the CEP and
route these to the GP-PWM-30 Solar Charge Controller
FIGURE 4-B
FIGURE 4-C
FIGURE 4-D
RV Roof
Refrigerator
Vent Cover
Solar
Module
Cable Clamps
Caution: The drilled hole may have sharp
edges or burrs - REMOVE
Vent
Screen
RV Roof
Refrigerator
Vent Cover
Solar
Module
Cable Clamps
Caution: The vent screen may have sharp
edges or burrs.
RV Roof
Refrigerator
Vent Cover
Solar
Module
Cable Clamps
Caution: The drilled hole may have sharp
edges or burrs - REMOVE
Vent
Screen
RV Roof
Refrigerator
Vent Cover
Solar
Module
Cable Clamps
Caution: The vent screen may have sharp
edges or burrs.
4.3 REFRIGERATOR VENT ACCESS - OPTION 1
1. Locate the refrigerator vent on the roof of the RV. Remove vent
cover to gain access to the duct opening.
2. Drill a hole through the side of the vent (5/8” hole).
3. Remove any sharp edges from the hole.
4. Insert a rubber grommet (not included) into the hole.
5. Insert the SC Positive and Negative Extension Cables through
the hole and carefully route it to the GP-PWM-30 Solar Charge
Controller. Be certain to leave enough slack to allow cable
routing from module to vent along desired path.
6. Use cable clamps with the #6 self-tapping screw and/or tie
wraps every few feet along RV roof and interior route to the
GP-PWM-30 Solar Charge Controller.
7. Ensure all penetrations into the RV roof are watertight. Use
an appropriate sealant as recommended by your RV Dealer
to seal holes wherever necessary.
8. Replace vent cover.
4.4 REFRIGERATOR VENT ACCESS - OPTION 2
1. Locate the refrigerator vent on the roof of the RV. Remove vent
cover to gain access to the duct opening.
2. Thread SC Positive and Negative Extension Cables carefully
through the screen and into opening.
3. Enlarge screen grid hole if necessary.
4. Remove any sharp edges from the hole.
5. Avoid strapping the power cable to existing wire between the
module and the battery.
Allowing a few inches of space between the power
cable and existing wire will lessen the chance of volt-
age loss through thermal conduction.
6. Use cable clamps with the # 6 self-tapping screw and/or tie
wraps every few feet along RV roof and interior route to the
GP-PWM-30 Solar Charge Controller.
7. Ensure all penetrations into the RV roof are watertight. Use
an appropriate sealant as recommended by your RV Dealer
to seal holes wherever necessary.
8. Replace vent cover.
INSTALLATION
Note

[page 16] | gopowersolar.com
4.6 INSTALLING THE GP-PWM-30 SOLAR CHARGE CONTROLLER
Ensure the Solar Panels are covered. Cover the panel faces completely with an opaque material to stop the production
of electricity when working with panels or wiring – the cardboard shipping boxes are the perfect option to cover glass
surface of the panels.
1. Use the template included in the GP-PWM-30 Manual to mark the four mounting holes and the “cutting line for ush mounting”.
2. Drill the mounting holes
3. Use a keyhole or jig saw to cut along the rectangular outline previously marked
4. Cut the SC extension cables to length, allow some excess for strain relief/exibility
5. Use the leftover cable to connect the controller to the batteries ensuring the 30A Fuse is installed as per 4.7. If extra battery cable
is required to connect to the battery bank, Go Power! recommends using an equivalent cable to that supplied with the kits: 10
Gauge Wire rated to – UL/cUL/USE2.
6. Mount the controller to the wall using the four wood screws provided.
7. Ensure the back of the controller is protected from damage by any object
4.7 INSTALLING THE 30A FUSE AND FUSE HOLDER
1. Locate the positive battery cable from the PWM 30.
2. Plan where you can safely and easily access the fuse holder
& fuse, as close to the battery as possible.
3. Cut the battery positive cable from the PWM 30 to the planned
lengths.
4. Strip the fuse holder cable and positive cable from PWM 30
as shown in Fig 4-F.
5. Thread the red heat-shrink onto the fuse holder cable
6. Insert the fuse holder and PWM 30 stripped cable ends into
the butt splice as shown in Fig 4-G.
7. Crimp the butt splice fully - test the connection by gently
pulling on both cables.
8. Thread the heat-shrink over the butt splice as shown in Fig 4-H.
9. Use the heat gun to shrink the heat shrink over the butt splice
as shown in Fig 4-I.
10. Repeat the process for the other fuse holder cable & battery
bank connection.
11. Do not install the 30A Fuse at this stage.
4.8 CONNECT THE GP-PWM-30 TO BATTERY BANK
It is recommended to connect directly to the battery.
1. Clean all corrosion from the battery terminals before proceeding
2. Crimp ring terminals onto the positive and negative cables to
be attached to the battery
3. Check the ring terminal crimp connection by gently pulling on
the cable and ring terminal
4. Attach the Negative (Black) ring terminal to the battery bank
and tighten according to the battery manufacturers speci-
cation
5. Attach the Positive (Red) ring terminal to the battery bank and tighten according to the battery manufacturers specication
6. Check all electrical connections
7. Apply a protective coating to the battery terminals
INSTALLATION
FIGURE 4-F
FIGURE 4-G
FIGURE 4-H
FIGURE 4-I
FIGURE 4-E
Battery Bank
30A
PWM 30
Solar Charger
Controller
Battery Bank
30A
PWM 30
Solar Charger
Controller
Battery Bank
30A
PWM 30
Solar Charger
Controller
Battery Bank
30A
PWM 30
Solar Charger
Controller
Battery Bank
30A
PWM 30
Solar Charger
Controller
Battery Bank
10A
PWM 10
Solar Charger
Controller

gopowersolar.com | [page 17]
4.9 INITIAL CONNECTION AND OPERATING
1. Check all electrical connections and ensure all cables are securely fastened
2. Install the 30A Fuse into the fuse holder, ensure the fuse holder is securely fastened
3. Remove the opaque material from the solar panels
4. Follow the PWM 30 User Manual and operating steps
BATTERY BANK CONFIGURATIONS
Ring
Terminal
Legend
Ring
Terminal
Cable
Fuse
Fuse
Fuse
Fuse
6V
200A/hr @ 6V
6V
200A/hr @ 6V
Series: 2 x 6V
System Voltage = 12V
System Capacity = 200A/Hr
Series & Parallel: 4 x 6V
System Voltage = 12V
System Capacity = 400A/Hr
6V
200A/hr @ 6V
6V
200A/hr @ 6V
6V
200A/hr @ 6V
6V
200A/hr @ 6V
Parallel: 4 x 12V
System Voltage = 12V
System Capacity = 400A/Hr
Parallel: 2 x 12V
System Voltage = 12V
System Capacity = 200A/Hr
12V
100A/hr @ 12V
12V
100A/hr @ 12V
12V
100A/hr @ 12V
12V
100A/hr @ 12V
12V
100A/hr @ 12V
12V
100A/hr @ 12V
FIGURE 4-J: TYPICAL BATTERY BANK CONFIGURATIONS
INSTALLATION

[page 18] | gopowersolar.com
5.1 INSPECTION
After installing any Go Power! Solar Kit or any other Go Power! products, all modules, electrical and mechanical components and con-
nections should be inspected annually by a trained Go Power! or dealer representative or other qualied personnel for safe electrical
and mechanical connections and to ensure modules are corrosion-free and vehicle mounting has not affected connections.
5.2 CLEANING
Although Go Power! Solar Kits are generally maintenance free, signicant performance gains can be made with clean solar panels
1.
Clean the solar panels monthly. Use water and a soft sponge or cloth. A mild non-abrasive cleanser can be used for more stubborn residue.
Rinse well.
2.
Clean solar panels more frequently during drier months, as they may become covered in dust more quickly. A pressure washer is not recommended.
3. Visual inspection – check the exterior for cracks, missing or broken hardware or other potential problems. Check all roof penetrations and
replace sealant areas as required
5.3 LONG TERM STORAGE - RV
In Cold Climates (temps below 32F)
• Cover your solar panels with a protective material that does not allow light to pass through. We recommend using a dark-coloured
tarp or plywood, with plywood being the best option.
• Label your solar panel wires ‘positive’ and ‘negative’
• Unhook your solar panels from your solar controller
• Fix wire nuts on the positive and negative leads from the solar panels
• Disconnect your batteries and store them inside in a warm, dry place preferably off the oor on something like a wooden pallet.
(AGMs can handle temps lower than 20F)
• Check the batteries monthly and charge them if necessary
In Warm Climates
There is no need to ‘store’ your RV solar system in warm climates unless your RV is parked indoors or in very low sunlight. If that’s the
case, simply follow the cold climate storage directions above.
However, do make sure that all parasitic draws are removed from the batteries i.e. Propane detector, clock radio, etc to make sure the
solar panel(s) can keep the batteries topped up even with reduced sun exposure.
5. MAINTENANCE

gopowersolar.com | [page 19]
The Go Power! warranty is valid against defects in materials and workmanship for the specic product warranty period. It is not valid
against defects resulting from, but not limited to:
• Misuse and/or abuse, neglect or accident
• Exceeding the unit’s design limits
• Improper installation, including, but not limited to, improper environmental protection and improper hook-up
• Acts of God, including lightning, oods, earthquakes, re, and high winds
• Damage in handling, including damage encountered during shipment
A warranty shall be considered void if the warranted product is in any way opened or altered. The warranty will be void if any eyelet,
rivets, or other fasteners used to seal the unit are removed or altered, or if the unit’s serial number is in any way removed, altered,
replaced, defaced, or rendered illegible.
6.1 WARRANTY RETURN PROCEDURE
Before contacting Go Power!’s customer service department, please read the “frequently asked questions” section of our website to
troubleshoot the problem. If trouble persists:
1. Call your Go Power!™ Technical Support team (1-866-247-6527) or
2. Return defective product to place of purchase
Unless approved by Go Power! Management, all product shipped collect to Go Power! will be refused. Test items or items that are not
under warranty, or units that are not defective, will be charged a minimum bench charge of ($50.00 US) plus taxes and shipping. A
15% restocking charge will be applied on goods returned and accepted as “new” stock.
An RMA number (Return Materials Authorization number) from Go Power! Customer Service is required prior to returning any Go Power!
Products. Go Power! reserves the right to refuse any items sent to Go Power! without an associated RMA number. To obtain an RMA
number, please contact [e-mail] Toll Free for US & Canada 1-866-247-6527.
Out of Warranty
Go Power! electronic products are non-repairable, Go Power! does not perform repairs on its products nor does it contract out those
repairs to a third party. Go Power! does not supply schematics or replacement parts for any of its electronic products.
6. WARRANTY

[page 20] | gopowersolar.com
SC Expansion
Connector - Negative
Legend
30A Fuse
Battery Bank
Refrigerator
Vent Cover
or Cable Entry Plate
SC Red Positive
Extension Cable (25 ft)
SC Black Negative
Extension Cable (25 ft)
SC Expansion
Connector - Positive
30A Fuse
Battery Bank
Refrigerator
Vent Cover
or Cable Entry Plate
SC Red Positive
Extension Cable (25
ft)
SC Black Negative
Extension Cable (25 ft)
MC4 Connector
Legend
"CLICK"
r
Solar Panel Solar Panel
Solar Panel
PWM 30
Solar Charger
Controller
PWM 30
Solar Charger
Controller
SLIM-100 SYSTEM DIAGRAM
7. SYSTEM DIAGRAMS
