domicet flexSet 25/28 mm User manual

Mounting instructions flexSet 25/28 mm and 36/38 mm
This roller blind is a made to measure product and has been
manufactured especially for you. To ensure that the roller
blind works properly please follow these instructions. The
manufacturer is not responsible for the consumer’s failure to
adhere to the instructions.
Domicet exSet mounting instructions | domicet.

Prepare the brackets
Marking
Please note!
Before installation place the bracket covers on the
brackets.
Keep the brackets in their marked positions and mark the
locations of the screw holes.
Pre-drill the screw holes.
Screw the brackets in place. Use plugs if needed. The
same brackets are suitable both for ceiling and wall
mounting.
Place the brackets to the ends of the roller blind. Measure
the total width of the roller blind including the brackets
and bracket covers. Take the measurement so that the pin
of the end plug is pressed halfway inside. Make sure that
the gap between the chain mechanism and the bracket is
minimal.
Mark the total outer width of the roller blind. Please note
that the brackets must be absolutely level!
The overall dimension
The overall dimension
Pre-drilling
Bracket installation
Checking
Check that the brackets are horizontally level. Adjust of
necessary.
The roller blind must be installed so that it is horizontally
level. If that is not case the fabric may not roll up straight
and may be damaged.
Place the chain mechanism side of the blind onto the bra-
cket with the pin (1). Press the pin of the end plug (2) and
simultaneously place the end plug side of the blind to the
hole of the end plug bracket (3). The end plug pin snaps
into place.
Mount the roller blind
A child safety device needs to be installed to make the
blind child safe. The chain must not hang loose but it also
shouldn’t be so tight that the chain cannot run through it.
Install the child safety device
1
2
3
Chain mechanism bracket
End plug bracket
