Donaldson BOFA AD Nano SST User manual

AD Nano
USER MANUAL
V1 May 15

Contents
01
02
Overview of your extraction system (front)
Overview of your extraction system (back)
1
01
Unpacking and unit placement
3
01
02
Connecting to power supply
Optional interfacing
4
01
Turning extractor on
5
01
02
Important safety notes
Safety labels
2
01
02
Cleaning the unit
Filter replacement
6
01
Consumable spares & filter disposal
7
01
AD Nano specifications
8
03
Overview of the control panel

Overview
Mains Isolation
Switch
Control Panel
Lockable Castors
Door Latches
Combined
Filter
Combined
Filter Lever
Pre Filter
01
1

Overview
Mains Inlet
Signal Cable
Inlet
(Optional)
Exhaust Outlet
Air Outlet
Air Inlet
02
1

Overview
Main Isolation Switch
Company
Branding
Filter Blocked
Filter 75% full
System
Running Clean
03
1

Safety Instructions
Important safety notes
Concerning symbols used on the extraction unit and referred
to within this manual.
Danger
Refers to an immediately impending danger. If the danger is
not avoided, it could result in death or severe (crippling)
injury. Please consult the manual when this symbol is
displayed.
Warning
Refers to a possibly dangerous situation. If not avoided it
could result in death or severe injury. Please consult the
manual when this symbol is displayed.
Caution
Refers to a possibly harmful situation. If not avoided,
damage could be caused to the product or something in its
environment.
Important (Refer to manual)
Refers to handling tip and other particularly useful
information. This does not signify a dangerous or harmful
situation. Refer to manual when this symbol is displayed.
Electrical Safety
The AD Nano has been designed to meet the safety
requirements of the Low Voltage Directive 2006/95/EC
(previously numbered 73/23/EEC)
Warning
When working with the pump/motor housing open, Live
230/115 volt mains components are accessible. Ensure that
the rules and regulations for work on live components are
always observed.
Important
To reduce the risk of fire, electric shock or injury:
1. Always isolate the system from the mains power
supply before removing the pump/motor access
panel.
2. Use only as described in this manual.
3. Connect the system to a properly grounded outlet.
Dangers to eyes, breathing and skin
Once used, the filters within the AD Nano system may
contain a mixture of particulates, some of which may be
sub-micron size. When the used filters are moved it may
agitate some of this particulate, which could get into the
breathing zone and eyes of the operative. Additionally,
depending on the materials being used, the particulate may
be an irritant to the skin.
This unit should not be used on processes with sparks of
flammable materials or with explosive dusts and gases,
without implementation of additional precautions.
Caution: When changing used filters always wear a mask,
safety shoes, goggles and gloves.
Carbon selection
Please note that the media within the filter fitted in the AD
Nano is capable of adsorbing a wide range of organic
compounds. However, it is the responsibility of the user to
ensure it is suitable for the particular application it is being
used on.
BOFA Technical Service
If problems arises with your AD Nano unit or if it displays a
fault code, please contact us:
•Visit our website at www.bofa.co.uk for on-line help.
•Or contact the helpline on [phone],
Mon-Fri, 9am-5pm.
Email: [email protected].uk
Serial Number
For future reference, fill in your system details in the space
provided. The serial number is on the rating label located on
the side/rear of the unit.
Serial Number:
01
2

Safety Instructions
Warning and Information labels
The following listing details labels used on your AD Nano
unit.
Goggles, Gloves & Mask Label
Location: Front face of filter.
Meaning: Goggles, Gloves and Masks should be worn while
handling used filters.
Do Not Cover Label
Location: Rear Exhaust
Meaning: Do not cover any louvers or holes adjacent to the
label.
Electrical Danger
Location: Electrical access panel, top half of unit.
Meaning: Removal of panels with this label attached will
allow access to potentially live components.
Warning Label
Location: Next to release clips.
Meaning: Power should be isolated before the panel with
this label attached is opened/ removed.
Serial Number Label
Location: Next to mains inlet.
Meaning: This label contains a variety
of information about the extraction
unit, including:
•Company name, Address & Contact number
•Extractor model
•Unit serial number
•Operating voltage range
•Maximum current load
•Operating frequency
•Year of Manufacture
•Relevant approval markings/ logos
PLEASE NOTE: If the equipment is used in a manner not
specified by the manufacturer, the protection provided by
the equipment maybe compromised.
Fire Risk Warning
In the very rare event that a burning ember or spark is drawn
into the fume extraction unit, it may be possible that the
filters will ignite.
Whilst any resultant fire would typically be retained within
the fume extraction unit, the damage to the extractor would
be significant.
It is therefore essential to minimise this risk by undertaking
an appropriate assessment to determine:-
a). Whether additional fire protection equipment should be
installed.
b). Appropriate maintenance procedures to prevent the risk
of build-up of debris which could potentially combust.
This unit should not be used on processes where sparks
could occur, with explosive dusts and gases, or with
particulates which can be pyrophoric (can spontaneously
ignite), without implementation of additional precautions.
It is essential that nozzles or other extraction/ fume capture
devices and hoses/pipework are cleaned regularly to prevent
the build-up of potentially ignitable debris.
02
2

Before installation
Inner transit packaging removal & unit placement
Before installation, check the extraction unit for damage.
All packaging must be removed before the unit is connected
to the power supply.
Please read all instructions in this manual before using
this extractor.
1. Move the unit to the location where it is going to be
installed and remove the outer packaging. This unit
should be installed in a well-ventilated area.
2. Open the front door and remove the transit foam
from the centre of the unit.
Caution
Due to the weight of the extractor suitable lifting equipment
should be used and with regard to appropriate safety
precautions. (See Appendix for product weight details)
Ensure that 500 mm space is available around any vented
panels on the extractor to ensure adequate airflow.
3. With the unit in position lock the 2 front castors.
Caution
Do not block or cover the cooling vents on the unit, as this
severely restricts airflow and may cause damage to the unit.
Caution
Under no circumstances should the exhaust
outlet/s be covered as this will restrict the airflow and cause
overheating.
4. Check the filters are located in their correct
position before closing the door and securing the
door latches.
Note: The unit will not operate correctly if the Combined
filter has not been secured in place using the internal
lever. (As detailed below)
01
3

Installation
Specification
Dimensions: Height 797mm Depth 435mm Width 377mm
Weight:
Voltage: 115/230V
Frequency: 60Hz
Full load current: 230V:0.9A 110V: 1.2A
Power: 135ω
Capacity:170m3/h
Connection to Power Supply
Please follow the above specification when selecting the
power supply outlet for the AD Nano system, ensure the
power supply is suitable before connecting the AD Nano
system.
Check the Integrity of the electrical power cable, if the
supply cord is damaged the extraction unit should not be
connected to the mains. The supply cord should only be
replaced by a BOFA engineer as an electrical safety test may
be required after replacement.
The AD Nano MUST be connected to a properly
earthed outlet.
If your AD Nano system was ordered with any optional
extras please read section 4.02 before the
power connection is made as additional
connections may be required before power is connected
to the extractor.
Connect the power cable to an isolated electrical supply.
The mains socket should be installed near the extractor it
should be easily accessible and able to be switched On/ Off.
The cable run should be arranged so as not to create a trip
hazard.
01
4

Installation
Optional added features
The AD Nano can be configured to suit customer
specification. These optional extras would be discussed,
arranged and installed prior to delivery.
(If unsure what features your system is equipped with
please contact the seller with the unit serial number,
(Refer to section 2for location) who will be able to advise
what specification has been supplied.
Remote Stop/Start feature
Enables the extraction unit to be remotely turned On / Off
via an external signal.
Note: Care must be taken to ensure that the system is
correctly wired in order for the extraction unit to function
correctly.
DC Voltage input
This configuration requires the Black & Red cores of the
signal cable (Refer to section 1 for location) to be connected
to a known and tested DC power supply, in order to start the
extractor.
The operating voltage for this signal is between 12 &
24VDC. Only voltages within this range should be
connected. Voltages connected outside of this range may
cause irreversible damage to the internal control PCB.
Red cable = V+
Black cable = V-
When the extractor is provided with the correct DC voltage
the motor will start and maintain the set flow rate (Refer to
section 5for how to set the flow) when the DC voltage is
removed the motor will slow down and come to a stop.
Filter Signal
When the filters become blocked or the system develops a
fault the connection between the Green & White cables will
become “Open”
When the extraction system is running normally the
connection between the Green & White cables will become
“Closed”
Override
Enables the extractor to operate fully with or without either
DC voltage input or the Volt free input.
The override feature can be toggled On / Off by a switch
mounted on the internal motor access panel (see below for
switch location)
Switch in “On” position
In this position the extractor will require a start signal (either
Voltage input or Volt free, depending on the requested
specification) to enable the motor within the extraction unit.
Switch in “Off” position
In this position the extractor motor will run without the
requirement for an external start signal. This feature is
useful for engineers carrying out works/ tests on the
extractor without the need for the laser / auxiliary signal
being present.
02
4

Operation
Turning extraction unit On
Two different main Isolation switches are used on the AD
Nano unit depending on which finish has been used.
Please see the images below to identify the switch your AD
Nano unit uses.
Powder Coated Version
Press the main isolation switch to the “On” position (Refer
to section 1for switch location) by depressing the ‘I’ side of
the switch.
Stainless Steel Version
The unit is turned on by pressing the green side ‘I’ of the
switch and turned off by pressing the red side ‘0’ of the
switch.
01
5

Maintenance
Maintenance UK
It is a legal requirement, under regulation 9 of the COSHH
regulations that all local exhaust ventilation systems are
thoroughly examined and tested at least once every 14
months (typically carried out annually). The approved code
of practice recommends that a visual check should be
carried out at least once a week.
COSHH requires the annual inspection and testing to be
carried out by a competent person and specifies that
documentation results are recorded in a log.
Contact the seller for more information about inspection
and certification.
Maintenance General
User maintenance is limited to cleaning the unit and filter
replacement, only the manufacturers trained maintenance
technicians are authorised to carry out component testing
and replacement. Unauthorised work or the use of
unauthorised replacement filters may result in a potentially
dangerous situation and/or damage to the extractor unit
and will invalidate the manufacturer’s warranty.
Cleaning the unit
The stainless steel units should be cleaned with a
proprietary stainless steel cleaner, in accordance with the
manufacturer’s user instructions.
The powder coat finish can be cleaned with a damp cloth
and non-aggressive detergent, do not use an abrasive
cleaning product as this will damage the finish.
The cooling inlets and outlets should be cleaned once a year
to prevent build-up of dust and overheating of the unit.
Filter Information
A log of filter changes should be maintained by the user.
The filters require attention when the display shows the
configuration shown on the next page or when the extractor
no longer removes fume efficiently.
It is recommended that a spare set of filters are kept on site
to avoid prolonged unit unavailability. Part numbers for
replacement filters can be found on the filters fitted in your
system.
To prevent overheating, units should not be run with a
blocked filter condition, or with dust obstruction of Inlets /
Outlets.
Fire Risk Warning
In the very rare event that a burning ember or spark is drawn
into the fume extraction unit, it may be possible that the
filters will ignite.
Whilst any resultant fire would typically be retained within
the fume extraction unit, the damage to the extractor would
be significant.
It is therefore essential to minimise this risk by undertaking
an appropriate assessment to determine:-
a) Whether additional fire protection equipment should be
installed.
b) Appropriate maintenance procedures to prevent the risk
of build-up of debris which could potentially combust
This unit should not be used on processes where sparks
could occur, with explosive dusts and gases, or with
particulates which can be pyrophoric (can spontaneously
ignite), without implementation of additional precautions.
It is essential that nozzles or other extraction/ fume capture
devices and hoses/pipework are cleaned regularly to prevent
the build-up of potentially ignitable debris
01
6

Maintenance
Filter Replacement
During use, the AD Nano alerts the user when its filter needs
replacing. As the filter becomes 75% full, the orange LED
will glow as well as the green ‘Clean Running’ LED. When
the Filter becomes full and needs to be replaced both the
red LED to the left of the ‘X’ symbol, the 75% orange LED
and the green LED will glow.
The filters now need to be replaced.
Goggles, gloves and masks must be worn when changing
filters.
To remove and replace the pre filter follow the procedure
detailed below.
1. Isolate the electrical supply to the unit.
2. Open the door of the unit.
3. Remove the lower (pre filter) from the base.
4. Vacuum out any dust in the base.
5. Fit new filter.
6. Close door and fasten the latches.
7. Reconnect the power supply.
To remove and replace the combined filter follow the
procedure detailed below.
1. Isolate the electrical supply to the extractor
2. Open the door of the unit.
3. Remove the upper (combined) filter.
4. Fit new filter.
5. Close the door and fasten the latches.
6. Reconnect the power supply.
02
6

Replacement Parts
Consumable Spares
The AD Nano extraction system contains two filters. These
should be replaced when instructed to do so by the AD
Nano system (see section 6for replacing the filters)
To maintain performance it is important that the filters are
replaced with identical BOFA filters. To re-order please refer
to the Filter number printed on the filter installed in your
extraction unit.
Maintenance Protocol
Users can record changes in filter change intervals on the
table below.
Filter disposal
The AD Nano Combined filter is manufactured from non-
toxic materials. Filters are not re-usable, cleaning used
filters is not recommended. The method of disposal of the
used filters depends on the material deposited on them.
For your guidance
Deposit
EWC
Listing*
Comment
Non
Hazardous
15 02 03
Can be disposed of as non-
hazardous waste.
Hazardous
15 02 02M
The type of hazard needs to
be identified and the
associated risks defined.
The thresholds for these
risks can then be compared
with the amount of material
in the filters to see if they
fall into the hazardous
category, if so, the filters
will need to be disposed of
in line with the
local/national regulations.
*European Waste Catalogue
Unit Serial Number:
Pre Filter
Date
Engineer
Unit Serial Number:
Combined Filter
Date
Engineer
01
7

System Specifications
Unit: AD Nano
Capacity: 170m3/h
Weight: 40Kg
Motor: Centrifugal Fan
Output: 135ω
Electrical supply: 115/230V
Hertz: 50/60Hz
Full Load Current: 230V: 0.9A 115V: 1.2A
Noise Level: Below 60dB (A)
(at typical operating speed)
Size:
Metric
(mm)
Imperial
(inches)
Height
797
31.4
Depth
435
17.2
Width
377
14.9
Filters:
Filter
Type
Surface
area/Weight
Efficiency
Pre Filter
6.0 m²
F8
Combined
Filter
6.8kg
99.997 % @
0.5 micron
Gas Filter
6.8kg
Activated
impregnated
carbon.
Environmental operating range:
Temperature: +5oC to + 40oC
Humidity: Max 80% RH up to 31oC
Max 50% RH at 40oC
01
8

Contact Information
BOFA Headquarters
19-20 Balena Close
Creekmoor industrial Estate
Poole
Dorset
BH17 7DU
UK
Phone: [phone]
BOFA Americas
303 S.Madison Street
Staunton
Illnois
62088
USA
Phone: [phone]
BOFA International GmbH
Sudring 62
D-21465
Wentorf bei Hamburg
Germany
Phone: [phone]
