TWIN TWIN BUNK BED ASSEMBLY:
STEP #1 (SEE #01 ILLUSTRATION)
INSERT DOWELS (PART F) INTO BOTH ENDS OF ALL
SIDE RAILS.
STEP #2 (SEE #02 ILLUSTRATION)
INSERT DOWELS OF SIDE RAIL INTO TALL HEAD
BOARD POSTS, USE BOLT (A) INTO NUT (C) AND
TIGHTEN.
STEP #3 (SEE #03 ILLUSTRATION)
INSTALL ONE SLAT KIT ON THE BED JUST
ASSEMBLED. USE SCREW (PART D) AND SCREW
DOWN FIRST SLAT, LAST SLAT AND THEN THE
MIDDLE SLAT. THE FIRST AND LAST SLAT MUST
START AT THE BEGINNING OF THE SIDE RAIL CLEAT.
MAXIMUM 3.25” AIR SPACE FROM SLAT TO END OF
HEAD BOARDS.
STEP #4 (SEE #04 ILLUSTRATION)
INSERT DOWEL AT END OF THE SIDE RAIL INTO THE
FOOT BOARD POST ATTACH WITH BOLT (A) INTO NUT
(C). ATTACH GUARD RAILS WITH BOLT (A) INTO NUT
(PART C) AND TIGHTEN. WHEN ONE SIDE IS
COMPLETE INSERT ALL DOWELS FROM SIDE RAILS
AND GUARD RAILS INTO THE OTHER FOOT BOARD
SECTION WITH BOLT (A) INTO NUT (C) AND FULLY
TIGHTEN.
STEP #5 (SEE #05 ILLUSTRATION)
INSTALL ONE SLAT KIT ON THE BED JUST
ASSEMBLED. USE SCREW (PART D) AND SCREW
DOWN FIRST SLAT, LAST SLAT AND THEN THE
MIDDLE SLAT. THE FIRST AND LAST SLAT MUST
START AT THE BEGINNING OF THE SIDE RAIL CLEAT.
MAXIMUM 3.25” AIR SPACE FROM SLAT TO END OF
FOOT BOARDS.
STEP #6 (SEE #06 ILLUSTRATION)
PUT THE BIG DOWELS (PART E) IN THE HOLES AT
THE TOP OF THE HEAD BOARD POSTS. WITH TWO
PEOPLE TAKE CARE AND LIFT THE FOOT BOARD
SECTION AND INSERT INTO THE DOWELS ON TOP OF
THE HEAD BOARDS. HEAVY LIFTING, TAKE CAUTION.
STEP #7 (SEE #07, 08 ILLUSTRATION)
ATTACH THE SMALL GUARD RAILA (08) INTO POST
(06) WITH BOLT (G) AND TIGHTEN . IN THE OTHER END
OF THE GUARD RAIL BOARDS INSERT DOWELS (PART
F). NOW INSTALL THE GUARD RAIL INTO THE FOOT
BOARDS BY INSERTING DOWELS INTO HOLES AND
INSERT AND TIGHTEN BOLTS (H). USE SCREW (D) TO
ATTCH GUARD RAIL TO POST. IN THE HOLES ON THE
SIDE OF THE ENTRY USE BOLT (A) INTO NUT (I) AND
TIGHTEN.
SIZE OF MATTRESS
THIS BED IS DESIGNED TO USE A MATTRESS (74” TO
75”) LONG AND (37.5” TO 38.5”) IN WIDTH AND THE
ENCLOSED SLAT KIT SYSTEM. THE TOTAL THICKNESS
OF UPPER OR LOWER MATTRESS AND FOUNDATION
MUST NOT EXCEED 9.25”. NOTE THERE MUST BE AT
LEAST 5” FROM MATTRESS SLEEPING SURFACE TO
TOP EDGE OF GUARDRAIL.
REPLACEMENT PARTS
REPLACEMENT PARTS, INCLUDING ADDITIONAL
GUARD RAILS MAY BE OBTAINED FROM ANY OF OUR
INNOVATIONS DEALERS.
SAFETY WARNINGS
1. FOLLOW THE INFORMATION ON THE WARNINGS
APPEARING ON THE UPPER BUNK END STRUCTURE
AND ON THE CARTON. DO NOT REMOVE WARNING
LABEL FROM BED.
2. ALWAYS USE THE RECOMMENDED SIZE
MATTRESS OR MATTRESS SUPPORT, OR BOTH, TO
HELP PREVENT THE LIKELIHOOD OF ENTRAPMENT
OR FALLS.
3. SURFACE OF MATTRESS MUST BE AT LEAST 5
INCHES BELLOW THE UPPER EDGE OF
GUARDRAILS.
4. DO NOT ALLOW CHILDREN UNDER 6 YEARS OF
AGE TO USE THE UPPER BUNK.
5. PERIODICALLY CHECK AND ENSURE THAT THE
GUARD RAIL, LADDER, AND OTHER COMPONENTS
ARE IN THEIR PROPER POSITION, FREE FROM
DAMAGE, AND THAT ALL CONNECTORS ARE TIGHT.
6. DO NOT ALLOW HORSEPLAY ON OR UNDER THE
BED AND PROHIBIT JUMPING ON THE BED.
7. ALWAYS USE THE LADDER FOR ENTERING OR
LEAVING THE UPPER BUNK.
8. DO NOT USE SUBSTITUTE PARTS. CONTACT
MANUFACTURER OR DEALER FOR REPLACEMENT
PARTS.
9. USE OF A NIGHT LIGHT MAY PROVIDE ADDED
SAFETY PRECAUTION FOR A CHILD USING THE
UPPER BUNK.
10. ALWAYS USE GUARD RAILS ON BOTH LONG
SIDES OF THE UPPER BUNK.
11. IF THE BUNK BED WILL BE PLACED NEXT TO A
WALL, THE GUARD RAIL THAT RUNS THE FULL
LENGTH OF THE BED SHOULD BE PLACED AGAINST
THE WALL TO PREVENT ENTRAPMENT BETWEEN
THE BED AND THE WALL.
12. PROHIBIT MORE THAN ONE PERSON ON THE
UPPER BUNK.
13. THE USE OF WATER OR SLEEP FLOTATION
MATTRESSES IS PROHIBITED.
14. KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
STRANGULATION HAZARD – NEVER ATTACH OR
HANG ITEMS TO ANY PART OF THE BUNK BED THAT
ARE NOT DESIGNED FOR USE WITH THE BED: FOR
EXAMPLE, BUT NOT LIMITED TO HOOKS, BELTS
AND JUMP ROPES.
DONCO TRADING
FORT WORTH, TX
