Donco Artesian 9018 User manual

9018 ARTESIAN STAIR BUNK

3
5
4
NO. DESCRIPTION Q'ty NO. DESCRIPTION Q'ty
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK Page 1/11
Princeton Section Assembly Hardware
2pcs
14pcs
1pc
Furniture Screw (Ø1/4x70mm)
Furniture Screw (Ø1/4x50mm)
Allen Key
11
12
Knob
4pcs
Bolt (Ø4x40mm)
4pcs

# A
Chest
1 PC
# B
Outside Princeton Section Panel
1 PC
# C
Inside Princeton Section Panel
1 PC
# D
# E
# M
Small Step
Large Step
Princeton Section Back Panel
1 PC
1 PC
Outside Bunk Bed Section Panel
# G
1 PC
Inside Bunk Bed Section Panel
# H
1 PC
1 PC
ASSEMBLY INSTRUCTIONS
Page 2/11
Box A
Lower Mattress Support Rail
# I
2 PCS
Slat Roll
# L
2 SETS
Upper Bunk Safety Rail
# N
4 PCS
Upper Mattress Support Rail
# J
2 PCS
Box C
Box D
# F
4 PCS
Vertical Support Bar
Box B
# 9018 ARTESIAN STAIR BUNK

ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK Page 3/11
Place the handle in front of the drawer panel and insert the screw into the pre-drilled holes.
Tighten it with screwdriver (not provided).
12
11

Page 4/11
AA
A
AA
B
B
B
1. Open the Chest Box and position the Chest (A) with the Drawer Fronts opening either to the
LEFT (Steps on the Left End of Bunk Bed).
2. Position the Outside Princeton Section Panel (B) so that the opening in the Panel is in Front
of the Chest Drawer Fronts.
5
5
4
5
5
4
5
5
4
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIANSTAIRBUNK
3. Slide the Outside Prince
(A). Align the holes through the Outside Princeton Section Panel (B) with the holes in the edge
of the Chest Top ( Top Step).
4. Insert 2- Furniture Screws (5) from the outside of the Panel (B) and into the Chest Top (A)
and tighten by using the Allen Key (4) provided.

Page 5/11
A
B
5. Position the Inside Princeton Section Panel (C) with the back side of the Chest (A).
C
4
4
4
6. Slide the Inside Princeton Sec ack of the Chest (A).
Align the holes through the Inside Princeton Section Panel (C) with the holes in the edge of the
Chest Top ( Top Step).
7. Insert 2- Furniture Screws (5) from the outside of the Panel (B) and into the Chest Top (A)
and tighten by using the Allen Key (4) provided.
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK

Page 6/11
LEFT ASSEMBLY
M
C
B
D
E
M
B
C
D
E
55
5
5
4
43
3
5
5
4
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK
8. Position the Princeton Section Back Panel (M) in-between the Inside and Outside Princeton
Section End Panels (B&C). Insert 2- Furniture Screws (3) from the outside panel (B) and 2-
furniture screw (5) to the Inside Panels (C) into the Back Panel (M) and tighten by using the
Allen Key (4) provided.
9. Position the Small and Large Steps (D&E) in-between the Inside and Outside Princeton
Section End Panels (B&C) and into the Small and Large Steps (D&E) and tighten by using
the Allen Key (4) provided.
- NOTE: The Large Step (E) is reversible and is notched on one front corner so that it can
if around the Post in both Left and Right Princeton configurations.
10. Princeton Section is now Fully Assembled.

Page 7/11
1
2
7
NO. DESCRIPTION Q'ty NO. DESCRIPTION Q'ty
HARDWARE LIST
1. Insert Wooden Dowels (9) into the ends of all of the Upper Bed safety Rails.
2. Insert Wooden Dowels (9) into the ends of all of the Upper & Lower Support Rails.
3
5
6
8
9
10
N x 4
8pcs
Machine Screw (Ø1/4x75mm)
16pcs
Half Moon (Ø1/4)
4pcs
Furniture Screw (Ø1/4x70mm)
4pcs
Furniture Screw (Ø1/4x50mm)
8pcs
Machine Screw (Ø1/4x60mm)
18pcs
Female Half Moon (Ø1/4x15mm)
18pcs
Machine Screw (Ø1/4x28mm)
16pcs
Wood Dowel (Ø10x40mm)
48pcs
Screw (Ø4x30mm)
9
9
I
J
9
9
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK

Page 8/11
4. Align the Wooden Dowels (9) in the end of the Lower Mattress Support Rails (I) with the
holes in the Outside Bunk Bed End Panel (G) and the Inside Bunk Bed End Panel (H).
5. Insert The Dowel (9) in the Lower Mattress Support Rails (I) into the hole in the inside End
Panel (G & H.)
6. Insert 2-" Half Moon" Nuts into the large holes on the inside of the Lower Mattress Support
Rails (I).
7. Insert 2- Machine Screws (1) into the holes on the outside of the End Panel (G) and into the
Half Moon Nuts (2) in the Lower Mattress Support Rails (I).
8. Tighten by using the Allen Key (4) provided.
10. Repeat these steps for the other Lower Mattress Support Rail (I) with both End Panels
(G&H).
11. Repeat all these steps for the Upper Bunk Mattress Support Rails (J).
3. IMPORTANT: Make sure that the access opening for the upper Bunk Bed on the Inside
Bunk Bed Panel is toward the Back Side/ Wall Side of the Bed, as you would face it when fully
assembled.
H
G
I
I
2
2
2
6
6
6
6
46
6
6
6
6
6
22
2
2
14
1
11
1
1
1
1
1
9
9
I
I
J
J
H
G
9.Insert 2-Machine Screws (6) into the holes on the inside of the End Panel (H) and into
the Half Moon Nuts (2) in the Mattress Support Rails (I).
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK
46
6
2
9
2
2
4
1
9

Page 9/11
17. Repeat all these steps for the three other Bunk Safety Rails (N) with both End Panels
(G&H).
18. Align the 3 - holes in the Vertical Support Bar (F) with the holes in the Upper Bunk Bed
Mattress and Safety Rails (J&N).
19. Insert Machine Screw (7) through the Support Bar and the Bed / Safety Rail and into the
Female Hex Nut (8).
20. Tighten with the Allen Key (4) provided.
21. Repeat all steps with the other Support Bar (F) on the opposite side of the Upper Bunk
Bed.
8
7
7
7
7
8
8
N
NN
NN
9
5
5
5
5
5
3
3
3
3
5
4
F
F
F
F
F
N
8
7
7
7
7
7
7
7
7
7
7
7
8
8
8
8
8
15.Insert 1 - Furniture Screws (5) into the hole on the outside of the End Panel (H) and into
the end of the Safety Rail (N).
16.Tighten using the Allen Wrench provided.
12. Align the Wooden Dowels (9) in the end of the Upper Bunk Safety Rails (N) with the holes
in the Outside Bunk Bed End Panel (G) and the Inside Bunk Bed End Panel (H).
13. Insert the Wooden Dowel (9) in the Upper Bunk Safety Rails (N) into the hole in the inside
End Panel (G & H ).
14. Insert 1-Furniture Screws (3) into the hole on the outside of the End Panel (G) and into the
end of the Safety Rail (N).
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK
8
8
8
8
8
8

Page 10/11
22. Place the Princeton Section in its preferred nal location in the room.
23. Align the Bunk Bed section with the Princeton Section.
24. Slide the Bunk Bed Inner End Panel up to and ush with the Princeton Section.
25. Align the 3-holes vertically along the Rear Inside Panel Corner Posts ( ushed together).
26. Insert Machine Screw (7) through the two posts and into the Female Hex Nut (8).
27. Tighten with the Allen Key (4) provided.
28. Repeat all steps with the holes vertically along the Front Inside Panel Corner Post ( ushed together).
29. Install the Slat Roll (L) in the Upper Bunk Bed by rolling it out into position on the Support Cleat.
30. Align the outside edge of the rst slat with the end of the Support Cleat on the Inside of the Mattress Support Rail (I).
This aligns the rst slat at the proper distance from the Bunk End Panel.
31. The outside edge of the last slat should be ush with the end of the Mattress Rail Support Cleat at the other end of the
Mattress Rail as well.
32. Insert the Wood Screw (10) into the holes in the slats and tighten.
33. Repeat all steps for the Slat Roll (L) in the Lower Bunk Bed.
Back side
7
84
47
84
4
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK

Page 11/11
10
SIDE - RAIL
SLAT ROLL
ASSEMBLY INSTRUCTIONS
# 9018 ARTESIAN STAIR BUNK
