# 316 Bunk bed

BUNK BED ASSEMBLY MANUAL
#316
1

BUNK BED ASSEMBLY MANUAL
#316
A
A
B
C
E
H
F
F
G
GI
K
J
L
L
M
N
R
R
S
S
T
T
AB
PARTS LIST
C
DEF
TOP POST
2 PCS
BOTTOM POST
2 PCS UPPER HEADBOARD TOP CAP 2 PCS
TOP POST
1PC TOP POST 1PC
BOTTOM POST
2 PCS
2

BUNK BED ASSEMBLY MANUAL
#316
G
LOWER HEADBOARD TOP CAP
2 PCS SHORT GUARDRAIL POST 1 PC TOP FRONT SIDE RAIL
1 PC
BOTTOM SIDE RAIL
2PCSSLAT 26 PCS
LONG GUARDRAIL
2 PCS SHORT GUARDRAIL 2 PCS LEFT LADDER END
1 PC
RIGHT LADDER END
1 PC LADDER STEP
4 PCS GUARDRAIL LEG
2 PCS
TOP HEADBOARD ASSEMBLY
2 PCS
TOP BACK SIDE RAIL
1 PC
BOTTOM HEADBOARD ASSEMBLY
2 PCS SPACE BLOCK 3 1/4 2 PCS
3

Insert wood dowels (7) into the large holes of the bottom headboard assembly (T), Attach lower headboard top
cap (G) to bottom headboard assembly (T) using wood joint connectors (2) as shown. Tighten the wood joint
connectors (2) with the hex key (8).
BUNK BED ASSEMBLY MANUAL
#316
Insert wood dowels (7) into the large holes of the top headboard assembly (S), Attach upper headboard top cap
(F) to top headboard assembly (S) using wood joint connectors (2) as shown. Tighten the wood joint
connectors (2) with the hex key (8).
STEP 1
2
8
7
7
ST
G
2
2 PCS 2 PCS
212 PCS 78 PCS
4

One of the top headboard assembly (S) has a warning label on it, do not use it in this step.
BUNK BED ASSEMBLY MANUAL
#316
Insert wood dowels (7) into the end holes of the top headboard assembly (S). Attach top posts (A) and (B) to
the top headboard assembly (S) using wood joint connectors (3) as shown. Tighten the wood joint connectors
(3) with the hex key (8).
STEP 2
A
3
3
8
7
5

STEP 3
BUNK BED ASSEMBLY MANUAL
#316
Repeat the previous step to assemble the remaining three sets of headboards. Be sure to pair the bottom
posts (D) and (E) for one pair; (E) and (D) for another; and the top posts (C) and (A) for the last pair.
NOTE: Be sure to use top headboard assembly (S) with warning label attached to it between top posts (A)
and (C). See illustration for label orientation.
A
3
3
8
7
3
Warning label
2 PCS
6

Note: This is the lower bunk.
BUNK BED ASSEMBLY MANUAL
#316
Attach the two headboards with bottom posts (D and E) to bottom side rails (K) using joint connectors (1)
and barrel nuts (9) as shown. Tighten the joint connectors (1) with the hex key (8).
STEP 4
9
9
9
9
1
1
1
8
K
K
D
D
E
E
18 PCS 98 PCS
7

STEP 5
BUNK BED ASSEMBLY MANUAL
#316
Insert a wood dowel (7) into each end of the long guardrails (M). Attach two long guardrails (M) and
two top side rails (I and J) to top posts (A and B) & (A and C) as shown. Fasten top side rails (I and
J) with joint connectors (1) and barrel nuts (9). Fasten long guardrails (M) with wood joint
connectors (3) .Tighten the joint connectors (1) and wood joint connectors (3) with the hex key (8).
3
3
3
3
7
7
J
A
C
8

STEP 6
Fasten two short guardrails (N) to top post (A) with wood joint connectors (3). Fasten the short
guardrail post (H) to top front side rail (I) with joint connectors (10) and hex cap (11) as shown.
BUNK BED ASSEMBLY MANUAL
#316
Insert wood dowel (7) into each end of the short guardrails (N). Attach two short guardrails (N) to
short guardrail post (H) with wood joint connectors (3) as shown.
8
7
7
7
H
N
N
H
N
I
A
8
C
10
11
11
10
9

STEP 7
Attach a slat (L) onto bottom side rails (K) of the bottom bunk with flat head screws (4). Make sure the slat
touches the corner posts (as close to the headboard as possible). Attach the other slats (L) onto the bottom
side rails (K) with flat head screws (4). Use space block (U) to space them out evenly. Use Phillips
screwdriver (not included) to tighten flat head screws.
BUNK BED ASSEMBLY MANUAL
#316
NOTE: If you notice that any of the slats (L) are not perfectly flat, be sure to assemble them so that the slats
(L) curves up in the middle and down on the ends.
Repeat this process for the top bunk.
I
I
J
H1
Headb
Footboard
Headboar
SIDE RAIL
WOOD SCREWS
SLAT
NOTE:
DIAGRAM 1
DIAGRAM 2
A
IMPORTANT:
Install slats in upper bunk before stacking on lower bunk
Bed rails may bow outwards slightly after installation
To compensate, attach one end of the center slat to the left bed rail
Make sure that slat flush to the inside of rail where attached
Walk to other side of bed, stand near the bed rail and use your leg to push
slightly against the outside of the bed rail so that slat ends flush against inside
of the bed rail
Insert screw through slat and attach while keeping the gap flush with your leg
PHILLIPS
SCREWDRIVER
L
K
K
D
4 52 PCS
4
4
4
4
10

STEP 8
BUNK BED ASSEMBLY MANUAL
#316
Place four metal dowels (5) into the holes in the lower headboard top cap (G). Stack the top bunk onto the
bottom bunk with the help of another person.
I
I
J
H1
Headb
Footboard
Headboar
SIDE RAIL
WOOD SCREWS
SLAT
NOTE:
DIAGRAM 1
DIAGRAM 2
A
A
G
11

STEP 9
BUNK BED ASSEMBLY MANUAL
#316
To assemble the ladder, insert wood dowels (7) into the end of the ladder steps (Q). Attach left ladder end (O)
and right ladder end (P) to ladder steps (Q) with wood joint connectors (2). Tighten the wood joint connectors
(2) with the hex key (8).
I
I
J
H1
Headboard
Footboard
Headboard
SIDE RAIL
WOOD SCREWS
SLAT
NOTE:
DIAGRAM 1
DIAGRAM 2
A
7
7
7
7
Q
O
8
28 PCS 78 PCS
2
2
2
2
12

STEP 10
BUNK BED ASSEMBLY MANUAL
#316
Attach the guardrail leg (R) to the short guardrails (N) and top front side rail (I) with flat head screws (6).
Attach another guardrail leg (R) (on the other side of the bed) to long guardrails (M) and top back side rail (J)
with flat head screws (6) as shown. Use Phillips screwdriver (not included) to tighten flat head screws.
Attach the ladder to the top front side rail (I) with flat head screw (12) as shown.
I
I
J
H1
Headb
Footboard
Headboar
SIDE RAIL
WOOD SCREWS
SLAT
NOTE:
DIAGRAM 1
DIAGRAM 2
A
612
R
R
M
N
I
J
O
P
12
12
I
N
P
Cback view
12
6
6
6
6
13

With the help of another person, remove the top bunk from the lower bunk.
Instructions for Converting the bunk bed into two single beds
Note: Switching the headboards will allow the two single beds to be identical (the headboards will have
taller posts and the footboards will have the shorter posts).
#316
Remove the ladder and all the guardrails.
Disassemble the side rails from all headboards (top and lower bunks).
Re-assemble the headboards (with tall posts) and footboards (with short posts) to side rails.
