Doogee PS10UA050K2000EU User manual

X97
Series

02

03

04

WEEE
Special precautions must be taken to safely dispose of
this product. This marking indicates that this product
may not be discarded with other household waste in the
EU.
To prevent harm to the environment or human health from inappropriate
waste disposal, and to promote sustainable reuse of material
resources, please recycle responsibly.
To safely recycle your device, please use return and collection systems
or contact the retailer where the device was originally purchased.
To view our Environmental Declaration, please refer to the following
link: www.doogee.cc/page/environment.html
CAUTION
RISK OF EXPLOSION IF BATTERYIS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO INSTRUCTIONS.
To prevent possible hearing damage. do not listen
at high volume levels for long periods.
Important Safety Information
Read all safety information below before using your device:
. Use of unauthorized cables, power adapters, or batteries can cause
fire, explosion, or pose other risks.
. Use only authorized accessories which are compatible with your
device.
. This device's operating temperature range is -20°C to 45°C. Using this
device in an environment outside of this temperature range may
damage the device.
· If your device is provided with a built-in battery, to avoid damaging the
battery or the device. do not attempt to replace the battery yourself.
· Charge this device only with the included or authorized cable and
power adapter. Using other adapters may cause fire, electric shock, and
damage the device and the adapter.
· After charging is complete, disconnect the adapter from both the
device and the power outlet. Do not charge the device for more than 12
hours.
05

· The battery must be recycled or disposed of separately from
household waste. Mishandling the battery may cause fire or explosion.
Dispose of or recycle the device, its battery, and accessories according
to your local regulations.
· Do not disassemble, hit, crush,or burn the battery. If the battery
appears deformed or damaged. stop using it immediately.
- Do not short circuit the battery, as this may cause overheating. burns,
or other injury.
-Do not place the battery in a high-temperature environment.
-Overheating may cause explosion.
-Do not disassemble, hit, or crusn the battery, as this may cause the
battery to leak, overheat, or explode.
- Do not burn the battery, as this may cause fire or explosion.
-If the battery appears deformed or damaged, stop using it immediately.
· User shall not remove or alter the battery. Removal or repair of the
battery shall only be done by an authorized repair center of the
manufacturer.
· Keep your device dry.
· Do not try to repair the device yourself. If any part of the device does
no twork properly, contact DOOGEE customer support or bring your
device to an authorized repair center.
· Connect other devices according to their instruction manuals. Do not
connect incompatible devices to this device.
· For AC/DC adapters, the socket-outlet shall be installed near the
equipment and shall be easily accessible.
Safety Precautions
.Observe all applicable laws and rules restricting use of mobile phones
inspecific situations and environments.
.Do not use your phone at petrol stations or in any explosive
atmosphere or potentially explosive environment, including fueling
areas, below decks on boats, fuel or chemical transfer or storage
facilities, or areas where the air may contain chemicals or particles such
as grain, dust, or metal powders.
Obey all posted signs to turn off wireless devices such as your phone or
other radio equipment. Turn off your mobile phone or wireless device
when in a blasting area or in areas requiring "two-way radios" or
"electronic devices" to be turned off to prevent potential hazards.
06

Security Statement
Please update your phone's operating system using the built-in
software update feature, or visit any of our authorized service outlets.
Updating software through other means may damage the device or
result in data loss, security issues, and other risks.
Do not use your phone in hospital operating rooms, emergency rooms,
or intensive care units. Always comply with all rules and regulations of
hospitals and health centers. If you have a medical device, please
consult your doctor and the device manufacturer to determine whether
your phone may interfere with the device's operation. To avoid potential
interference with a pacemaker, always maintain a minimum distance of
15 cm between your mobile phone and the pacemaker. This can be
done by using your phone on the ear opposite to your pacemaker and
not carrying your phone in a breast pocket. To avoid interference with
medical equipment, do not use your phone near hearing aids, cochlear
implants, or other similar devices.
. Observe all aircraft safety regulations and turn off your phone on board
aircraft when required.
·When driving a vehicle, use your phone in accordance with relevant
traffic laws and regulations.
To avoid being struck by lightning, do not use your phone outdoors
during thunderstorms.
- Do not use your phone to make calls while it is charging.
·Do not use your phone in places with high humidity, such as
bathrooms. Doing so may result in electric shock, injury, fire, and
charger damage.
EU Regulations
07

RED Declaration of Conformity
Shenzhen DOOGEE Hengtong Technology CO.,LTD hereby declares
that this GSM /GPRS/WCDMA/LTE Digital Mobile Phone with Bluetooth
and Wi-Fi M2101K7AG is in compliance with the essential requirements
and other relevant provisions of the RE Directive 2014/53/EU. The full
text of the EU declaration of conformity is available at the following
internet address: www.doogee.cc/page/certification.html
RF Exposure Information (SAR)
This device is in compliance with Specific Absorption Rate (SAR) limits
for general population/uncontrolled exposure (Localized 10-gram SAR
for head and trunk, limit: 2.0W/kg) specified in Council Recommenda-
tion 1999/519/EC, ICNIRP Guidelines,and RED (Directive
2014/53/EU).
During SAR testing, this device was set to transmit at its highest
certifiedpower level in all tested frequency bands and placed in
positions that simulate RF exposure during use against the head with
no separation and near the body with a separation of 5 mm.
SAR compliance for body operation is based on a separation distance
of 5 mm between the unit and the human body. This device should be
carried at least 5 mm away from the body to ensure RF exposure level
is compliant or lower than the reported level. When attaching the
device near the body, a belt clip or holster should be used which does
not contain metallic components and allows a separation of at least 5
mm to be maintained between the device and the body. RF exposure
compliance was not tested or certified with any accessory containing
metal worn on the body, and use of such an accessory should be
avoided.
Certification Information
(Highest SAR)
SAR 10g limit: 2.0 W/Kg,
SAR Value:Head: 1.36W/Kg,Body: 0.959W/Kg(5 mm distance).
08

Disclaimer
This user guide is published by DOOGEE or its local affiliated company.
Improvements and changes to this user guide necessitated by
typographical errors, inaccuracies of current information, or improvements
to programs and/or equipment, may be made by DOOGEE at any time
and without notice. Such changes will, however, be incorporated into new
online editions of the user guide ( please see details at
www.doogee.cc/page/manual.html ). All illustrations are for illustration
purposes only and may not accurately depict the actual device.
09

RF Specification:
Function
Operation Frequency
Max RF output
power:
Limit
BLE
2402MHz–2480MHz
-5.72dBm
20 dBm.
BT(BR+EDR)
2402MHz–2480MHz
9.69dBm
20 dBm.
WIFI 802.11b/g/
n(HT20,HT40)
802.11b/g/n(20MHz): 2412~2472MHz;
802.11n(40MHz):2422~2462MHz
15.26dBm
20 dBm.
Wi-Fi
5.2G(802.11a/n20/n4
0/ac20/ac40/ac80)
802.11a/ n20/ac20:5180MHz~5240MHz
802.11 n40/ac40:5190MHz~5230MHz
802.11ac80:5210MHz
9.41dBm
23 dBm.
Wi-Fi
5.8G(802.11a/n20/n4
0/ac20/ac40/ac80)
802.11a/ n20/ac20:5745MHz~5825MHz
802.11 n40/ac40:5755MHz~5795MHz
802.11ac80: 5775MHz
9.89dBm
13.98 dBm.
GSM/GPRS/EGPRS
900
TX(Uplink):880M‐915MHZ;
RX(Downlink):925M‐960MHZ
32.68dBm
class 4 (33±3dBm)
GSM/GPRS/EGPRS
1800
TX(Uplink):1710M‐1785MHZ;
RX(Downlink):1805M‐1880MHZ
29.41dBm
class 1 (30±3dBm)
WCDMA B1
TX(Uplink):1920-1980MHz;
RX(Downlink):2110-2170MHz
22.95dBm
24 (dBm) +1,7/-3,7 (dB)
WCDMA B8
TX(Uplink): 880-915MHz;
RX(Downlink):925-960MHz
23.00dBm
24 (dBm) +1,7/-3,7 (dB)
LTE FDD B1
TX(Uplink):1920-1980MHz;
RX(Downlink):2110-2170MHz
23.24dBm
23(dBm) ±2,7(dB)
LTE FDD B3
TX(Uplink) :1710-1785MHz;
RX(Downlink):1805-1880MHz
23.26dBm
23(dBm) ±2,7(dB)
LTE FDD B7
TX(Uplink) :2500-2570MHz;
RX(Downlink):2620-2690MHz
23.48dBm
23(dBm) ±2,7(dB)
LTE FDD B8
TX(Uplink): 880MHz to 915 MHz
RX(Downlink): 925 MHz to 960 MHz
23.13dBm
23(dBm) ±2,7(dB)
LTE FDD B20
TX(Uplink): 832MHz~862MHz;
RX(Downlink): 791MHz~821MHz
23.03dBm
23(dBm) ±2,7(dB)
LTE FDD B28
TX(Uplink): 703 MHz to 748MHz
RX(Downlink): 758 MHz to 803 MHz
23.64dBm
23(dBm) ±2,7(dB)
LTE TDD B38
TX(Uplink): 2570 MHz to 2620 MHz
RX(Downlink): 2570 MHz to 2620 MHz
23.83dBm
23(dBm) ±2,7(dB)
LTE TDD B40
TX(Uplink): 2300 MHz to 2400MHz
RX(Downlink): 2300 MHz to 2400MHz
23.03dBm
23(dBm) ±2,7(dB)
NFC
13.56MHz
-5.33dBuA/m@10
m
60 dBuA/m@10m
FM
Rx(Downlink): 87.5MHz~108MHz
--
--
GPS
Rx(Downlink): 1.57542GHz
--
--

Warning:
1.Use careful with the earphone maybe possible excessive sound pressure from earphones and headphones can
cause hearing loss.
2. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BYAN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDINGTO THE INSTRUCTIONS.
3. The product shall only be connected to a USB interface of version USB2.0.
4. Adapter shall be installed near the equipment and shall be easily accessible.
5. Operation temperature:-10~40℃
6. The plug considered as disconnect device of adapter.
7. SAR: The device complies with RF specifications when the device used at 0.5cm from your body (SAR limit 2.0
W/Kg). The device is in compliance with the requirements.
8. Accessories information:
Adapter
Model: PS10UA050K2000EU
Input: 100-240V~50/60Hz 0.35A Max
Output: 5.0V 2.0A 10.0W
Battery: DC 3.87V, 4000mAh, 15.5Wh
This information has to be presented in such a way that the user can readily understand it. Typically, this will
necessitate translation into every local language (required by national consumer laws) of the markets where the
equipment is intended to be sold. Illustrations, pictograms and using international abbreviations for country
names may help reduce the need for translation.
EU Declaration of Conformity
We,
Shenzhen DOOGEE Hengtong Technology CO.,LTD (B, 2/F, Building A4, Silicon Valley Power Digital Industrial Park, No.
22, Dafu Industrial Zone, Guanlan Aobei Community, Guanlan Street, Longhua New District, Shenzhen, Guangdong
China) hereby declares that this Smart Phone is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
According to Article 10(2) of Directive 2014/53/EU, the Smartphone 3.5 can be used in Europe without restriction.
The full text of the EU declaration DOC is available at the following: Visit the Web site http: www.doogee.cc
Restrictions in the 5 GHz band:
According to Article 10 (10) of Directive 2014/53/EU, the packaging showsthat this radio equipment will be subject
to some restrictions when placed on the market in Belgium (BE), Bulgaria (BG), the Czech Republic (CZ),Denmark
(DK), Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain(ES), France (FR), Croatia (HR), Italy (IT), Cyprus
(CY), Latvia (LV), Lithuania(LT), Luxembourg (LU), Hungary (HU), Malta (MT), Netherlands (NL), Austria(AT), Poland
(PL), Portugal (PT), Romania (RO), Slovenia (SI), Slovakia (SK),Finland (FI), Sweden (SE), the Turkey (TR),
Norway(NO), Switzerland (CH), Iceland (IS), and Liechtenstein (LI).
The WLAN function for this device is restricted to indoor use only when operating in the 5150 to 5250 MHz
frequency range.
ES
LU
RO
CZ
FR
HU
SI
DK
HR
BE
BG
DE
EE
IE
EL
IT
Cy
LV
LT
SK
MT
NL
AT
PL
PT
FI
SE
LI
TR
NO
CH
IS
