Dorel Asia DA6788W User manual

UPC CODE:
KEEP FOR FUTURE REFERENCE.
Date of purchase:
DOREL ASIA
DA6788W (WHITE)
Model No:
DA6788E (ESPRESSO)
CRIB CHANGER COMBO
2 IN 1 CRIB
ESPRESSO: 0-65857-16658-3
Lot number:
NOTE:
WHITE: 0-65857-16659-0
_______ / _______ / _______
THIS INSTRUCTION BOOKLET
_____________________________________
(TAKEN FROM CARTON)
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

Convertible Crib
*Failure to follow these warnings and assembly instructions could result in serious injury or death.
*Read all instructions before assembling crib. KEEP INSTRUCTIONS FOR FUTURE USE.
*
*
*Stop using crib when child begins to climb out or reaches the height of 35 inches (89 cm).
*To reduce the risk of SIDS, pediatricians recommend healthy infants be placed on their backs to sleep,
unless otherwise advised by your physician.
* DO NOT place crib near window where cords from blinds or drapes may strangle a child.
*Strings can cause strangulation! DO NOT place items with a string around a child's neck, such as hood
strings or pacifier cords. DO NOT suspend strings over a crib or attach strings to toys.
*To help prevent strangulation tighten all fasteners. A child can trap parts of the body or clothing on loose
fasteners.
*If refinishing, use a non-toxic finish specified for children's products.
*When child is able to pull to standing position, set mattress to lowest position and remove bumper pads,
large toys and other objects that could serve as steps for climbing out.
*
Never use plastic shipping bags or other plastic film as mattress covers because they can cause suffocation.
*Replace teething rail if damaged or loose (if teething rail is provided for this model).
*Follow warnings on all products in a crib.
* CAUTION: ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY
51-5/8 INCHES (69CM BY 131CM) WITH A MINIMUM THICKNESS OF 4 INCHES (10CM)
BUT NOT EXCEEDING 6 INCHES (15CM).
*Infants can suffocate in gaps between crib sides and a mattress that is too small.
*The TODDLER BED or DAY BED is not intended for children under 15 months of age or over 50 pounds
(22.7kgs)
*If guardrails are used as the mattress containment means, guardrail(s) provided must be used to avoid the
formation of a gap between the mattress and the bed that could cause an entrapment (when product is
used as a TODDLER BED or DAY BED).
*
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first!
CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the product model
number, color and a detailed description of the part.
Montreal, Quebec
Canada, H1G 3L1
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Check this product for damaged hardware, loose joints, loose bolts or other fasteners, missing parts or
sharp edges before assembly and frequently during use. Securely tighten loose bolts and other fasteners.
DO NOT use crib if any parts are missing, damaged or broken. Contact a customer service representative
at 1-800-295-1980 for replacement parts and instructional literature if needed. DO NOT substitute parts.
Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding
under an infant.
The mattress intended for use on the bed shall be a full-size crib mattress having minimum dimensions of
51-5/8 in. (1310 mm) in length and 27-1/4 in. (690 mm) in width with a minimum thickness of 4 in. (100 mm)
and not exceeding 6 in. (150 mm).
E-MAIL: [email protected]
WARNING

*
*
*
*
*
*
*
*
*Ensure all parts and components are present before beginning assembly.
* Assemble on a soft, smooth surface to prevent damage to product finish.
*
DO NOT use power tools.
*CAUTION: Adult assembly required.
* Assembly will require two people.
* Estimated assembly time: 60 minutes.
Check bolts/screws periodically and tighten them if necessary.
Read all instructions before use of the changing table. KEEP INSTRUCTIONS FOR FUTURE USE.
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to
remedy any such defect. This warranty covers 1 year from the date of original purchase. This
warranty is valid only upon presentation of proof of purchase. This is solely limited to the repair or
replacement of defective furniture components and no assembly labor is included. This warranty
does not apply to any product which has been improperly assembled, subjected to misuse or abuse
or which has been altered or repaired in any way. This warranty gives you specific legal rights and
you may also have other rights which vary from State to State.
Always secure the child to the changing pad using safety straps attached to changing pad.
The maximum recommended weight of the child is 30 lbs (13.60 kgs).
The changing table is to be used with a changing pad measuring 16 inches X 32 inches and not
exceeding 2 inches in thickness (excluding the height of any contoured edges).
DO NOT use the changing table if it is damaged or broken.
When used as a changing table, this unit must be used with a changing pad (not provided) equipped
with safety straps that secure the child to the changing pad as well as straps that secure the pad to
the changing table.
WARNING
Changing Table
FALL HAZARD - To prevent death or serious injury, always keep child within arm's reach.
Avoid serious injury. Never leave child unattended.
WARNING: Should this product become damaged,
and/or components are broken or missing, DO NOT USE.
NOTES
CARE AND CLEANING
Dust regularly with a soft, lint-free cloth to prevent soil build-up. A damp cloth may be used
occasionally to clean surface. Dry immediately. Do not use any abrasives that may damage finish.
Excessive exposure to sunlight and extreme changes in temperature and moisture can damage
wood furniture.
MAINTENANCE
LIMITED WARRANTY

HARDWARE LIST
1 2
3 4
5 6
7
Ø1/4" X 13mm X Ø10mm
ALLEN KEY
1 PC
Ø1/4" X 13mm X 75mm
Ø1/4" X 13mm X 60mm
Ø1/4" X 13mm X 50mm
Ø8mm X 30mm
CRIB CHANGER COMBO
DA6788W / DA6788E
BOLT
17 PCS
BOLT
2 PCS
BOLT
12 PCS
MATTRESS SUPPORT BOLT
16 PCS
BARREL NUT
12 PCS
20 PCS
Ø1/4" X 13mm X 15mm

PARTS LIST
A B C
D E F
G H
MATTRESS SUPPORT
1 PC
LEFT SIDE PANEL
1 PC
RIGHT SIDE PANEL
1 PC
FRONT PANEL
1 PC
FRONT RAIL
1 PC
CRIB CHANGER COMBO
DA6788W / DA6788E
BACK POST
2 PCS
BACK PANEL
1 PC
FRONT POST
2 PCS

PARTS LIST
I J K
L M N
O P Q
R S
CRIB CHANGER COMBO
DA6788W / DA6788E
CHANGER TOP BACK RAIL
1 PC
MIDDLE BACK RAIL
1 PC
RIGHT SIDE FRAME
1 PC
BOTTOM FRONT RAIL
1 PC
MIDDLE FRONT RAIL
1 PC
TOP PANEL
1 PC
BOTTOM BACK RAIL
1 PC
TOP FRONT BAR
1 PC
TOP FRONT RAIL
1 PC
MIDDLE PANEL
1 PC
BOTTOM PANEL
1 PC

NOTE: When inserting bolts, turn clockwise until tight. Then loosen
1/2 - 3/4 of a turn. After crib is completely assembled, return to each
bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
CRIB CHANGER COMBO
DA6788W / DA6788E
CRIB ASSEMBLY INSTRUCTION

STEP 1
Attach posts (B1 & B2) to back panel (C) with bolts (1).
Use Allen Key (7) to tighten all bolts (1).
CRIB CHANGER COMBO
DA6788W / DA6788E
Insert wood dowels (4) and barrel buts (6) into back panel ( C) as shown.
14
6

STEP 2
Insert barrel nuts (6) into side panels (D & E) as shown.
Use Allen Key (7) to tighten all bolts.
CRIB CHANGER COMBO
DA6788W / DA6788E
Attach left front post (A1) to left side panel (D) with bolts (1) .
Attach right front post (A2) to right side panel (E) with bolts (1 & 3) as shown.
Insert wood dowel (4) to right front post (A2).
16
3
4

STEP 3
Insert barrel nuts (6) into side panels (D & E) as shown.
Insert wood dowel (4) into right back post (B2).
Attach right side panel (E) to back panel (C ) with bolts (1 & 3) as shown.
Attach left side panel (D) to back panel (C) to the with bolts (1).
Use Allen Key (7) to tighten all bolts.
CRIB CHANGER COMBO
DA6788W / DA6788E
6
1
NOTE:
The lower rails of side panels (D & E)
are labeled "INSIDE." To ensure
proper assembly, the side panels
must be attached so that the INSIDE
label face inside the crib.
4
3

STEP 4
Insert barrel nuts (6) into front rail (G).
Attach front rail (G) to left front post (A1) and right front post (A2) with bolts (1).
Use Allen Key (7) to tighten all bolts (1).
CRIB CHANGER COMBO
DA6788W / DA6788E
16

STEP 5
Attach mattress support (H) to the posts with mattress support bolts (5).
Use Allen Key (7) to tighten the mattress support bolts (5).
CRIB CHANGER COMBO
DA6788W / DA6788E
INCORRECT-
Raised edge
should face
down -this photo
shows mattress
support is
upside down.
INCORRECT-
Tabs on corners
of mattress
support should
point up.
CORRECT
*Tabs to point UP.
*Flat surface of mattress
support to face up - mattress
must sit on flat surface.

NOTE: The above photos and drawings showing how to properly attach the
mattress support are for reference only. Crib styles and colors will vary.
5

STEP 6
Attach front panel (F) to left front post (A1) and right front post (A2) with bolts (3).
Secure front panel (F) to front rail (G) with bolts (2).
Use Allen Key (7) to tighten the bolts (2 & 3).
CRIB CHANGER COMBO
DA6788W / DA6788E
32

STEP 7
Attach bottom front rail (P) to right front post (A2) with bolt (3).
CRIB CHANGER COMBO
DA6788W / DA6788E
Attach middle back rail (K) to right back post (B2) with wood dowels (4).
Attach bottom back rail (L) to right back post (B2) with bolt (3).
Insert wood dowel (4) into changer top back rail (J).
Attach changer top back rail (J) to right back post (B2) with bolts (3).
Insert wood dowels (4) into top front bar (M), top front rail (N) and middle front rail (O) as shown.
Attach top front bar (M), top front rail (N) and middle front rail (O) to right front post (A2).
Secure top front bar (M) to right front post (A2) with bolt (3).
Tighten all bolts using Allen key (7)
34

STEP 8
CRIB CHANGER COMBO
DA6788W / DA6788E
Slide top panel (Q) into the grooves of rails (J & N).
Slide middle panel (R) into the grooves of rails (K & O).
Slide bottom panel (S) into the grooves of rails (L & P).
Make sure panels (Q,R & S) rest inside the grooves of right side panel (E).

STEP 9
CRIB CHANGER COMBO
DA6788W / DA6788E
Insert wood dowels (4) into changer top back rail (J), middle back rail (K), top front bar (M), top
front rail (N), middle front rail (O), and bottom front rail (P).
Attach right side frame (I) to the assembled unit with bolts (3).
Use Allen Key (5) to tighten all bolts.
34

STEP 1: Follow steps step 9 to 7 backwards to remove the change table.
STEP 2: Unscrew bolts (2) underneath the crib front rail (G) with Allen Key (7).
STEP 3: Unscrew bolts (3) on front post (A1 & A2) with Allen Key (7).
STEP 4: Detach the front panel (F) from the posts (A1 & A2).
STEP 5: If mattress support (H) is not in the lowest position, unscrew bolts (5) from left & right
posts (A1, A2, B1 & B2) and move to the lowest position.
STEP 6: Ensure all bolts are tightly secured.
WARNINGS:
*ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY
51-5/8 INCHES (69CM BY 131CM) WITH A MINIMUM THICKNESS OF 4 INCHES
(10CM) BUT NOT EXCEEDING 6 INCHES (15CM).
*The day bed is not intended for children under 15 months of age or over 50 lbs (22.7 kgs).
CRIB CHANGER COMBO
DA6788W / DA6788E
DAY BED ASSEMBLY INSTRUCTION: STARTING FROM CRIB

That's it ! You've finished assembling your crib changer combo!
CRIB CHANGER COMBO
DA6788W / DA6788E
CAUTION: This unit is intended for use only with the products
and/or maximum weights indicated. Use with other products and/or
products heavier than the maximum weights indicated may result
in instability or cause possible injury.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]
NOTE:
DO NOT throw away this
instruction manual. Use the
crib pouch attached to the
mattress support to store this
manual for future use.
The maximum
recommended weight of the
child is 30 lbs (13.60 kgs).
Stop using crib when
child begins to climb out
or reaches the height of
35 inches (89 cm).
Maximum weight not to
exceed 50 pounds when
used as a crib.
Maximum weight
per shelf is 10
lbs.

MODEL #: DA6788W / DA6788E
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity: (Please be sure to list model number or SKN number)
Customer Service Representative Mailing Address:
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Customer Service
Customer Service Phone Number 1-800-295-1980
Email: [email protected]
Customer Service Fax Number 514-353-7819
