Dorel Asia DA6439-2G User manual

GRANITE TOP KITCHEN CART Model No:
DA6439-2G
(TAKEN FROM CARTON)
Date of purchase:
NOTE:
DOREL ASIA
UPC CODE:
0-65857-16521-0
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
_____________________________________
Lot number:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

* Ensure that all parts and components are located before beginning assembly.
* Assemble on a soft surface to prevent damage to the product finish.
* DO NOT use the unit if it is damaged or broken.
* DO NOT use power tools.
* Caution: Adult assembly required.
* Assembly will require 2 people.
* Estimated assembly time: 30 minutes.
* Phillips head screwdriver (not provided) is required for assembly.
* DO NOT use the kitchen cart as a seating surface.
* DO NOT place any type of electrical appliance on the unit.
* DO NOT place any pots or pans containing hot liquids on the unit.
* DO NOT place any item on the top panel weighing more than 30 lbs.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service representative first!
CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the product model number, color
and a detailed description of the part.
12345 Albert-Hudon Boulevard, Suite 100
E-MAIL: [email protected]
NOTE
Customer Service Department No. 413
* After placing the kitchen cart in the desired location, lock the caster wheels to prevent movement.
Montreal, Quebec
Canada H1G 3L1
WARNING
* Before moving the kitchen cart remove all products off the top panel and make sure the caster wheels are in
the unlocked position.
* To prevent damage to the caster wheels, gently lift the kitchen cart when sliding it over raised edges on the floor.
* DO NOT place any item on the kitchen cart with dimensions exceeding those of the top panel.
WARNING: Should this product become damaged,
and/or components are broken or missing, DO NOT USE.
LIMITED WARRANTY
CARE AND CLEANING
Dust regularly with a soft, lint-free cloth to prevent soil build-up. A damp cloth may be used occasionally to clean
surface. Dry immediately. Do not use any abrasives that may damage finish. Excessive exposure to sunlight and
extreme changes in temperature and moisture can damage wood furniture.
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any
such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon
presentation of proof of purchase. This is solely limited to the repair or replacement of defective furniture
components and no assembly labor is included. This warranty does not apply to any product which has been
improperly assembled, subjected to misuse or abuse or which has been altered or repaired in any way. This
warranty gives you specific legal rights and you may also have other rights which vary from State to State.
MAINTENANCE
Check bolts/screws periodically and tighten them if necessary.

HARDWARE LIST
1 2
3 4
5 6
7 8
9 10
GRANITE TOP KITCHEN CART
BARREL NUT
12 PCS
HEX SOCKET HEAD BOLT
12 PCS
PLASTIC DRAWER STOPPER
1 PC
Ø6 x 50mm
Ø10 x 13mm
DA6439-2G
Ø5.8 x 30mm
Ø6 x 20mm
SCREW
8 PCS
BOLT
2 PCS
ALLEN KEY
1 PC
HANDLE
1 PC
Ø4 x 20mm
HEX SOCKET HEAD BOLT
3 PCS
WOOD DOWEL
8 PCS
Ø4 x 25mm
SCREW
1 PC
Ø4 x 12mm
END PANEL
RIGHT END PANEL (A-R) 1 PC
MATTRESS SUPPORT 1PC END PANEL
LEFT END PANEL (A-L) 1 PC
ACEGI7

PARTS LIST
A B C
D E F
G H I
J K L
M N O
LEFT FRAME
1 PC
WINE RACK
1 PC
GRANITE TOP KITCHEN CART
LOCK CASTER
2 PCS
DRAWER FRONT PANEL
1 PC
DRAWER SIDE PANEL
2 PCS
DA6439-2G
BOTTOM PANEL
1 PC
DRAWER BOTTOM PANEL
1 PC
CASTER
2 PCS
GRANITE TOP PANEL
1 PC
RIGHT FRAME
1 PC
TOP FRONT RAIL
1 PC
BOTTOM RAIL
2 PCS
DRAWER BACK PANEL
1 PC
TOP BACK RAIL
1 PC
BACK PANEL
1 PC

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 1
Attach plastic drawer stopper (6) to top front rail (F) with screw (7) using a Phillips screwdriver (not
included). Attach top front rail (F) and top back rail (G) to the left frame (B) with hex socket head bolts (1) and
barrel nuts (2). Use Allen key (10) to tighten bolts. Attach wine rack (D) to the left frame (B) with hex socket head bolts (1) and barrel nuts (2). Use
Allen key (10) to tighten bolts. Insert wood dowels (3) into the holes of bottom rails (I). Attach bottom rails (I) to the left frame (B)
with hex socket head bolts (1) and barrel nuts (2). Use Allen key (10) to tighten the bolts. Insert the wood dowels (3) into the back panel (H) and then attach the back panel (H) to the left frame
(B). NOTE：DO NOT fully tighten the bolts.
①
②
③ ⑦ ⑥
F
F
H
G
D
B
I
I
1
1
1
1
1
2
2
2
2
3
3
3
3
2
2
7
6
10
1

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 2
Repeat Step 1 to attach the top front rail (F), top back rail (G), wine rack (D), back panel (H) and
bottom rails (I) to the right frame (C) with hex socket head bolts (1), barrel nuts (2) and wood dowels
(3). Use Allen key (10) to tighten the bolts. NOTE：DO NOT fully tighten the bolts.
F
G
H
D
I
I
B
C
1
1
1
1
1
1
2
2
2
2
2
2
3
3
3
3
10
① ② ③

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 3
Place the unit upside down on a clean, smooth surface. Attach casters (N) and lock casters (O) to the left frame (B) and the right frame (C) as shown.
B
C
N
N
O
O

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 4
Place the granite top panel (A) on a clean, smooth surface. Attach the unit to the granite top panel (A) with hex socket head bolts (4). Use Allen Key (10) to
tighten the bolts (4).
4
4
4
A
front
F
G
B
C
④

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 5
Attach the drawer side panels (K) to drawer front panel (J) with screws (5). Attach the handle (8) to drawer front panel (J) with screws (9). Use a Phillips head screwdriver (not included) to tighten them. NOTE: Do not fully tighten the bolts.
J
K
K
8
9
9
5
5
⑧ ⑨ ⑤

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 6
Slide the drawer bottom panel (M) into the groovesof the drawer frame. Attach drawer back panel (L) to the drawer side panels (K) with screws (5). Use a Phillips screwdriver
(not included) to tighten them. NOTE: Fully tighten all bolts and screws previously installed.
K
K
M
K
K
L
5
5
⑤
J
J

GRANITE TOP KITCHEN CART
DA6439-2G
STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10 STEP 11
STEP 7
Turn the kitchen cart upright. Insert the assembled drawer. Place the bottom panel (E) as shown.
E

That's it ! You've finished assembling your kitchen cart.
GRANITE TOP KITCHEN CART
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with other
products and/or products heavier than the maximum weights
indicated may result in instability or cause possible injury.
DA6439-2G
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]
Top Panel:
30 LBS
Product
Maximum
Weight
Bottom Panel:
15 LBS
Wine Rack:
15 LBS
Drawer: 10
LBS

MODEL #: DA6439-2G
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity (Please be sure to list model number or SKN number):
Email: [e-mail]
Customer Service Phone Number 1-800-295-1980
Customer Service Fax Number 514-353-7819
Customer Service Representative Mailing Address:
Customer Service
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
