Dorel Asia PARSONS WM3738-DF User manual

Model No:
WM3738-DF
UPC CODE:
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
________________
DOREL ASIA
PARSONS CHAIR
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [e-mail]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]
0-65857-16528-9

*
*
*
*
*
*
Montreal, Quebec
Canada H1G 3L1
E-MAIL: [email protected]
Assemble on a soft, smooth surface to prevent damage to product finish.
DO NOT use power tools.
CAUTION: Adult assembly required.
Check bolts/screws periodically and tighten them if necessary.
LIMITED WARRANTY
WARNING: Should this product become
damaged, and/or components are broken or missing,
DO NOT USE.
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees
to remedy any such defect. This warranty covers 1 year from the date of original purchase. This
warranty is valid only upon presentation of proof of purchase. This is solely limited to the repair
or replacement of defective furniture components and no assembly labor is included. This
warranty does not apply to any product which has been improperly assembled, subjected to
misuse or abuse or which has been altered or repaired in any way. Any wearing, tearing, fading
or splitting of the fabric is not covered under the warranty. This warranty gives you specific
legal rights and you may also have other rights which vary from State to State.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first! CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the product model
number, color and a detailed description of the part.
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
CARE AND CLEANING
Dust regularly with a clean, dry cloth to avoid soil build-up. Wipe away spills immediately to
prevent staining. Use a cloth dampened with water or professional product to clean the fabric.
MAINTENANCE
NOTES
Ensure all parts and components are present before beginning assembly.
Estimated assembly time: 15 minutes.
Assembly and handling will require two people.
Always test an inconspicuous area first. Allow upholstery to dry and brush lightly. Keep away
from heat to avoid glazing, melting or scorching.

HARDWARE LIST
1 2 3
4 5
PARTS LIST
A B C
ALLEN KEY
1 PC
FLAT WASHER SPRING WASHER
10 PCS 10 PCS
HEX SOCKET HEAD BOLT
4 PCS
PARSONS CHAIR
WM3738-DF
Ø5/16" X 60mm Ø22 X 1.8mm Ø12.5 X 1.2mm
HEX SOCKET HEAD BOLT
6 PCS
Ø5/16" X 90mm
SEAT FRAME FRONT LEG
1 PC 2 PCS
BACK FRAME
1 PC

PARSONS CHAIR
WM3738-DF
STEP 1:
Place back frame (A) on a clean, smooth surface.
Remove the fabric lining underneath seat frame (B).
Attach the seat frame (B) to back frame (A) with flat washers (2), spring washers
(3) and hex socket head bolts (1) through the center of the seat frame (B).
Use Allen key (5) to tighten the bolts.
NOTE: Do not fully tighten bolts.
A
B
1
2
3
5
①②③

PARSONS CHAIR
WM3738-DF
5
4
3
2
A
B
STEP 2:
Secure seat frame (B) to back frame (A) with flat washers (2), spring washers (3)
and hex socket head bolts (4).
Use Allen Key (5) to tighten the bolts.
NOTE: Do not fully tighten bolts.
④②③

PARSONS CHAIR
WM3738-DF
STEP 3:
Attach front legs (C) to seat frame (B) with flat washers (2), spring washers (3)
and hex socket head bolts (1). Use Allen key (5) to tighten the bolts.
Tighten all bolts previously installed.
Place the fabric lining back into place.
①②③
1
2
3
5
C
C
B
A

PARSONS CHAIR
WM3738-DF
STEP 4:
Turn the chair upright.
Note: Legs are equipped with adjustable levelers. Before placing
this item in the desired location, make sure that the chair rests
evenly on the floor by turning the adjustable levelers clockwise
or counterclockwise (as needed).

PARSONS DINING CHAIRS
WM3738-DF
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with other
products and/or products heavier than the maximum weights
indicated may result in instability or cause possible injury.
That's it ! You've finished assembling your chairs.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [e-mail]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]
Dust regularly with a
soft, dry cloth to prevent
soil build-up. Wipe
away spills immediately
to prevent staining. Use a
cloth dampened with
water or a professional
product to clean the
fabric. Always test an
inconspicuous area first.
Allow upholstery to dry
and brush lightly. Keep
away from heat to avoid
glazing, melting or
scorching.

MODEL #: WM3738-DF
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity (Please be sure to list model number or SKN number):
Email: [email protected]
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Customer Service
Customer Service Phone Number 1-800-295-1980
Customer Service Fax Number 514-353-7819
Customer Service Representative Mailing Address:
