Dorel Asia Project 62 Sofa DA7857SF-BL User manual

style # DA7857SF-BL
DA7857SF-GR
dpci # 249-08-5484
249-08-5486
>>>assembly instructions
project 62
sofa

DA7857C-BL
249-08-5485
Tools needed (not included)
2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck-though we’re confident you won’t need it.
Before you begin
1. Check for damaged or missing parts. Please call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.

introduction 2
hardware 4
parts list 5
assembly 6~12
3
table of contents
QUESTIONS?
Just call 1-855-MYTGTHOME (855-698-4846). For faster service, have the style number and DPCI number ready when calling.

hardware
H2 x 8 H3 x 4 H4 x 20
hex socket head bolt hex socket head bolt flat washer
Ø1/4" x 60MM Ø5/16" x 20MM Ø22 x 1.8MM
H6 x 20 H7 x 8 H8 x 2
spring washer spring washer screw
Ø12.5 x 1.2MM Ø10.5 x 1MM M4 x 60MM
H10 x 1
allen key
M4 x 55MM
4
flat washer
Ø16 x 1.5MM
H1 x 16
hex socket head bolt
Ø5/16" x 65MM
H5 x 10
H9 x 1
allen key
M5 x 65MM

ITEM DESCRIPTION QUANTITY
A 1
B 1
C 1
D 1
E 2
F 2
5
seat frame
leg
stretcher
sofa back
right arm
left arm

step 1.
6
1. Attach right arm (B) to sofa back (A) by inserting the metal
bracket on sofa back (A) into the metal glide on right arm
(B). Push the sofa back (A) with a downward force to
secure it into place.
2. Repeat this step to attach the left arm (C) to sofa back (A).

step 2.
7
1. Place the seat frame (D) to the sofa back (A)
and the arms (C and B) as shown.
Note: Push the seat frame (D) with a downward force to secure it into place.

step 3.
8
H1x 16
hex socket head bolt
Ø5/16" x 65MM
H4 x 16
flat washer
Ø22 x 1.8MM
H6 x 16
spring washer
Ø12.5 x 1.2MM
H9 x 1
allen key
M5 x 65MM
1. With the help of another person, gently place the unit on sofa back (A) and
pull back the fabric lining underneath seat frame (D) and sofa back (A).
2. Secure seat frame (D) to sofa back (A) with flat washers (H4), spring washers
(H6) and hex socket head bolts (H1). Use Allen key (H9) to tighten all bolts.
3. Secure sofa back (A) to arms (B & C) with flat washers (H4), spring washers (H6) and
hex socket head bolts (H1). Use Allen key (H9) to tighten all bolts.
4. Secure seat frame (D) to arms (B & C) with flat washers (H4), spring washers (H6)
and hex socket head bolts (H1). Use Allen key (H9) to tighten all bolts.
5. Place the fabric lining back into place.
Note: Periodically check bolts and screws and retighten as necessary. Keep Allen
key (H9) for future use.

step 4.
9
H10 x 1
allen key
M4 x 55MM
H2 x 4
hex socket head bolt
Ø1/4" x 60MM
H5 x 4
flat washer
Ø16 x 1.5MM
H7 x 4
spring washer
Ø10.5 x 1MM
1. With the help of another person, gently turn the unit upside down.
2. Attach the leg (E) to the assembled unit with hex socket head bolts (H2),
spring washers (H7) and flat washers (H5). Use Allen Key (H10)to
tighten all bolts.
Note: Do not fully tighten the bolts.

step 5.
10
H9 x 1
allen key
M5 x 65MM
H3 x 2
hex socket head bolt
Ø5/16" x 20MM
H4 x 2
flat washer
Ø22 x 1.8MM
H6 x 2
spring washer
Ø12.5 x 1.2MM
1. Insert the leg (E) into the stretchers (F).
2. Secure the leg (E) to the stretchers (F) with hex socket head bolts (H3),
spring washers (H6) and flat washers (H4). Use Allen key (H9) to tighten all bolts.

step 6.
11
1. Attach the assembled leg (done in step 5) to the leg (E).

step 7.
12
H2 x 4
hex socket head bolt
Ø1/4" x 60MM
H5 x 6
flat washer
Ø16 x 1.5MM
H7 x 4
spring washer
Ø10.5 x 1MM
H10 x 1
allen key
M4 x 55MM
H3 x 2
hex socket head bolt
Ø5/16" x 20MM
H9 x 1
allen key
M5 x 65MM
H8 x 2
screw
M4 x 60MM
H4 x 2
flat washer
Ø22 x 1.8MM
H6 x 2
spring washer
Ø12.5 x 1.2MM
1. Secure the legs (E) to the assembled sofa body with flat washers (H5), spring washers (H7)
and hex socket head bolts (H2). Use Allen key (H10) to tighten the bolts.
2. Secure the stretchers (F) to the assembled sofa body with flat washers (H4), spring
washers (H6) and hex socket head bolts (H3). Use Allen key (H9) to tighten the bolts.
3. Use Allen key (H9 & H10) to tighten all bolts assembled in the prior steps..
4. Secure the stretchers (F) to the assembled sofa body with flat washers (H5) and screws (H8).
Use a Phillips head screwdriver (not included) to tighten screws.
5. Turn the assembled sofa upright.
