Dorel Asia WM3669C User manual

UPC CODE:
(TAKEN FROM CARTON)
DOREL ASIA
0-65857-16677-4
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
Model No:
WM3669C
Counter Height Dining Chair
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
_______ / _______ / _______
Lot number:
Date of purchase:
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

* Ensure all parts and components are present before beginning assembly.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first!
You can also order parts by writing to the address listed below. Please include the product model
number, color and a detailed description of the part.
E-MAIL: [email protected]
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
* DO NOT use power tools.
CALL 1-800-295-1980
CARE AND CLEANING
Use a cloth dampened with water or a professional product to clean the fabric. Always test an
inconspicuous area first. Allow upholstery to dry and brush lightly. Keep away from heat to avoid
glazing, melting or scorching.
Canada H1G 3L1
NOTES:
* Assembly and handling may require two people.
* Estimated assembly time is 5 - 8 minutes.
* Assemble on a soft, smooth surface to prevent damage to product finish.
* Phillips head screw driver is not included.
* CAUTION: Adult assembly required.
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to
remedy any such defect. This warranty covers 1 year from the date of original purchase. This
warranty is valid only upon presentation of proof of purchase. This is solely limited to the repair or
replacement of defective furniture components and no assembly labor is included. This warranty does
not apply to any product which has been improperly assembled, subjected to misuse or abuse or which
has been altered or repaired in any way. Any wearing, tearing or fading of the fabric is not covered
under the warranty. This warranty gives you specific legal rights and you may also have other rights
which vary from State to State.
Check bolts/screws periodically and tighten them if necessary.
WARNING: Should this product become damaged, and/or
components are broken or missing, DO NOT USE.
MAINTENANCE
LIMITED WARRANTY
Dust this item regularly with a soft, lint-free cloth to prevent soil build up. Wipe away spills
immediately to prevent staining using a clean cloth dampened with water. Do not use liquid or
abrasive cleaners on the metal frame as this may damage the finish.

1 2 3
Counter Height Dining Chair
HARDWARE LIST
ALLEN KEY
BOLT
WOOD SCREW
WM3669C
1 PC
16 PCS
4 PCS
Ø1/4" X 1/2 "
Ø3/16" X 13/16"

A B C
D E F
G
1 PC
1 PC
1 PC
1 PC
CONNECTING ROD
LEFT BRACE
RIGHT BRACE
1 PC
SEAT CUSHION
2 PCS
Counter Height Dining Chair
PARTS LIST
LEFT LEG
BACK FRAME
RIGHT LEG
WM3669C
1 PC

Counter Height Dining Chair
WM3669C
STEP 1
Attach the right leg (B) and left leg (C) to the two connecting rods (D) with bolts (1). Use Allen
Key (3) to tighten the bolts.
NOTE: Do not fully tighten the bolts. Leaving the bolts loose will facilitate assembly in the
following steps.
1

Counter Height Dining Chair
WM3669C
STEP 2
Attach the left brace (E) and right brace (F) to back frame (A) with the bolts (1). Use Allen Key
(3) to tighten the bolts.
NOTE: Do not fully tighten the bolts. Leaving the bolts loose will facilitate assembly in the
following steps.
1

STEP 3
Attach legs (B & C) to back frane (A) and braces (E & F) with the bolts (1). Use Allen Key
(3) to tighten the bolts.
Tighten all bolts previously installed.
Counter Height Dining Chair
WM3669C
1

STEP 4
Counter Height Dining Chair
WM3669C
Attach the seat cushion (G) to the chair frame with wood screws (2) using a Phillips head
screwdriver (not included).
2

That's it ! You've finished assembling your chair.
