Dorel 7556013COMUK User manual

–Unit can p over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
Storage Tower
7556013COMUK - White
7556815COMUK - Grey
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
Do Not Return This Product!
Contact our customer service team for help rst
Call: 01942 524100
E-mail: cseur[email protected]om
Easy Tough
REFERENCE NO:
Please retain this booklet as you will be asked
to quote this number for any warranty or
product related queries

Contact Us!
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR
2
- Open your item in the area you plan to keep it for less heavy liing
- Idenfy, sort and count the parts before aempng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture
Helpful Hints

Before You Start
Cam Lock Fastening System
3
P
P
P
P
P
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Cauon: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Assembly
1
3
2
4

Board Idencaon
Not actual size
4
x1
T7556013010
TOP PANEL
x1
T7556013020
CENTER SHELF
x4
T7556013030
UPPER LEG (SHORT)
x4
T7556013040
LOWER LEG (LONG)
x3
T7556013050
FIXED SHELF
1
5
2 3
4

5
* raw edges are shaded
Part List
Not Actual Size
5
x20
TUD0042
FLAT WASHER
x1
TUD0062
BALL SHAPE ALLEN KEY
M4
x20
TUD0059
JCBC Screw
M6 X 65
x4
TUD0052
JCBC Screw
M6 X 30
x24
TUD0041
SPRING WASHER
x1 SET
TUD0021
ANTI TIPPING KIT

6
* raw edges are shaded
Step 1
x4
TUD0042
x4
TUD0059
x4
TUD0041
3
3
3
3
5
NOTE : DO NOT FULLY TIGHTEN ALL THE BOLT.
x1
TUD0062

7
* raw edges are shaded
Step 2
x4
TUD0052
3
3
3
3
2
x4
TUD0041
NOTE : DO NOT FULLY TIGHTEN ALL THE BOLT.
x1
TUD0062

8
* raw edges are shaded
Step 3
x4
TUD0042
x4
TUD0059
x4
TUD0041
3 3
3
3
2
1NOTE : FULLY TIGHTEN ALL THE BOLT.
x1
TUD0062

9
* raw edges are shaded
Step 4
x2
TUD0042
x2
TUD0059
x2
TUD0041
4
4
5
x1
TUD0062
NOTE : DO NOT FULLY TIGHTEN ALL THE BOLT.

10
* raw edges are shaded
Step 5
x2
TUD0042
x2
TUD0059
x2
TUD0041
4
4
5
x1
TUD0062
NOTE : DO NOT FULLY TIGHTEN ALL THE BOLT.

11
* raw edges are shaded
Step 6
x2
TUD0042
x2
TUD0059
x2
TUD0041
4
5
5
x1
TUD0062
NOTE : DO NOT FULLY TIGHTEN ALL THE BOLT.

12
* raw edges are shaded
Step 7
x2
TUD0042
x2
TUD0059
x2
TUD0041
45
5
x1
TUD0062
NOTE : DO NOT FULLY TIGHTEN ALL THE BOLT.

13
* raw edges are shaded
Step 8
x4
TUD0042
x4
TUD0059
x4
TUD0041
5
2
1
x1
TUD0062
NOTE : FULLY TIGHTEN ALL THE BOLT.

14
* raw edges are shaded
x1 set
TUD0021
IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER.
FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET
PROVIDED WITH THIS PRODUCT.
WARNING
Serious or fatal crushing injuries


* Install pover restraint provided
* place heaviest items in the lowest
drawers
* Unless specically designed to
accommodate, do not set TVs or
other heavy objects on the top of
this product
* Never allow children to climb or
hang on drawers, door, or shelves
* Never open more than one drawer
at a me

reduce, but not eliminate the risk


Using a stud nder, locate a stud in the wall. Place your unit against the wall, with the safety bracket
aligned in this locaon.
To make driving the screw easier, you can drill a 1/8” diameter pilot hole (3mm) through the safety
bracket into the stud.
Drive the screw through the safety bracket into the wall stud. Tighten the screw that was not fully
ghened in step 5.

Locate your unit where desired against a wall and mark the wall through the safety bracket, then
move your unit aside.
Drill a 3/16” diameter hole (5mm) into the wallboard. Tap the wall anchor into the hole unl it is ush.
Move your unit into locaon and fasten the wall bracket to the wall anchor with the screw.
Tighten the screw that was not fully ghtened in step 5.
For Masonry, Concrete, or other

Consult your local hardware store
for appropriate anchors to securely
aach the safety bracket.

15
Maximum Loads
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
Warning: Risk of serious injury to person - do not place a television on this furniture. This furniture
is not approved for use with a television.
