Dorel DA6794 User manual

5-PC WOOD & METAL DINING SET
(TAKEN FROM CARTON)
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
_______ / _______ / _______
Lot number:
Date of purchase:
NOTE:
THIS INSTRUCTION BOOKLET
Model No:
DA6794
INSTRUCTION MANUAL
UPC CODE:
0-65857-16888-4
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

* Ensure all parts and components are present before beginning assembly.
Dust this item regularly with a soft, lint-free cloth to prevent soil build up. Wipe away spills
immediately to prevent staining using a clean cloth dampened with water. Do not use liquid or abrasive
cleaners on the metal frame as this may damage the finish.
LIMITED WARRANTY
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to
remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is
valid only upon presentation of proof of purchase. This is solely limited to the repair or replacement of
defective furniture components and no assembly labor is included. This warranty does not apply to any
product which has been improperly assembled, subjected to misuse or abuse or which has been altered
or repaired in any way. Any wearing, tearing, fading or splitting of the leather is not covered under the
warranty. This warranty gives you specific legal rights and you may also have other rights which vary
from State to State.
Check bolts/screws periodically and tighten them if necessary.
Dust the upholstery regularly with a clean, dry cloth to avoid soil build-up. A damp cloth may be used
occasionally to clean surface. Buff dry. Keep leather soft and supple by applying a leather care product
occasionally. Avoid contact with oil, furniture polish and varnish.
WARNING: Should this product become damaged, and/or
components are broken or missing, DO NOT USE.
NOTES:
* Assembly and handling may require two people.
* Estimated assembly time is 45 - 60 minutes.
* Assemble on a soft, smooth surface to prevent damage to product finish.
MAINTENANCE
* DO NOT use power tools.
* Phillips head screw driver is not included.
* CAUTION: Adult assembly required.
CARE AND CLEANING
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first!
You can also order parts by writing to the address listed below. Please include the product model
number, color and a detailed description of the part.
E-MAIL: [email protected]
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada H1G 3L1
CALL 1-800-295-1980

1 2 3
4
BOLT
Ø1/4" X 1/2"
Ø1/4" X 1-3/8"
Ø3/16" X 5/8"
HARDWARE LIST
5-PC WOOD & METAL DINING SET
DA6794
48 PCS
BOLT
8 PCS
WOOD SCREW
16 PCS
ALLEN KEY
1 PC

A B C
D E F
G H I
5-PC WOOD & METAL DINING SET
DA6794
PARTS LIST
BACK FRAME
RIGHT CHAIR LEG
LEFT CHAIR LEG
4 PCS
CHAIR FRONT RAIL
CHAIR MIDDLE RAIL
SEAT CUSHION
4 PCS
4 PCS
4 PCS
4 PCS
4 PCS
TABLE TOP
TABLE STRETCHER
TABLE LEG
1 PC
1 PC
4 PCS

5-PC WOOD & METAL DINING SET
DA6794
STEP 1
Attach the right and left chair legs (B & C) to back frame (A) with bolts (1) and Allen key (4).
Attach the chair middle rail (E) to chair legs (B & C) with bolts (1) and Allen key (4).
NOTE: Do not fully tighten the bolts. Loose bolts will facilitate assembly in the following
steps.
A
B
C
1
11
11

STEP 2
5-PC WOOD & METAL DINING SET
DA6794
Attach the chair front rail (D) to the chair legs (B & C) with bolts (2).
Ensure that the chair front rail (D) goes smoothly into the two chair legs before tightening the
bolts (2).
Tighten all bolts previously installed.
2

STEP 3
5-PC WOOD & METAL DINING SET
DA6794
Attach the seat cushion (F) to the chair frame with wood screws (3) as shown. Use a Phillips
head screw driver (not included) to tighten the screws.
NOTE- Seat cushion (F) does not have pre-drilled holes. Wood screws (3) will make their
own holes in seat cushion (F).
Repeat steps 1- 4 to assemble the other chairs.
3

STEP 4
5-PC WOOD & METAL DINING SET
DA6794
Attach the metal legs (I) to the table top (G) with bolts (1). Leave bolt (1) loose.
Attach the stretcher (H) to the table legs (I) with bolts (1).
Use Allen key (4) to tighten all bolts installed in this step.
Turn the table upright.
A
B
C
1
11
11

That's it ! You've finished assembling your dining set.
CAUTION: This unit is intended for use only with the products
and/or maximum weights indicated. Use with other products and/or
products heavier than the maximum weights indicated may result in
instability or cause possible injury.
5-PC WOOD & METAL DINING SET
DA6794
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
100 lbs
Product Maximum Weight
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

MODEL #: DA6794
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Customer Service Fax Number 514-353-7819
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity: (Please be sure to list model number or SKN number)
Customer Service Representative Mailing Address:
Customer Service
Customer Service Phone Number 1-800-295-1980
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Email: [email protected]
