Dorel DAS002316 User manual

Date of Purchase
DAS002316 (Taupe Velvet), DAS002309 (Navy Velvet),
DAS002310 (Emerald Green Velvet), DAS002312 (Gray Velvet)
Counter Stool
Set of 2
C.W. - 2021/05/14
Lot Number(TAKEN FROM CARTON)
Thank you for purchasing from Dorel !
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
© 2021 Dorel Home Products All Rights Reserved
Weight Limit: 250 Lb / 113 Kg
DO NOT RETURN TO THE STORE !
I f parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
You can also chat with us at www.dhpfurniture.com
B34DAS00231600-260307-ZQ

2
1-800-267-1739
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec H1G 3L1
[e-mail]
is
Limited 1 year Warranty
This warranty does not apply to any product which has been improperly
Visit www.dhpfurniture.com
Contact Us!
Read Before Beginning Assembly
Dorel
Monday to Friday
Saturday
Sunday
9am to 9pm (Eastern Time)
10 am to 6:30 pm (Eastern Time)
11 am to 7 pm (Eastern Time)
Chat
with us! www.dhpfurniture.com
This product is packaged
in 1 carton
15 mins
Do NOT use
powertools

3
PARTS
A
BC
DE
H
F
G
I

4
PART
DAS002316
T807570
T807580
T807590
T807600
T807610
T807620
T807630
T807640
T807650
T807670
T807580
T807590
T807600
T807610
T807620
T807630
T807640
T807650
T807680
T807580
T807590
T807600
T807610
T807620
T807630
T807640
T807650
T807660
T807580
T807590
T807600
T807610
T807620
T807630
T807640
T807650
D
C
B
A
(Taupe Velvet)
DAS002309
(Navy Velvet)
DAS002310
(Emerald Green Velvet)
DAS002312
(Gray Velvet)
S LIST
A
X 2 PCS X 2 PCS
Seat Frame Right Front Le Left Front Legg
X 2 PCS X 2 PCS X 2 PCS X 2 PCS X 2 PCS X 2 PCS
Left Back LegRight Back Leg Right Stretcher Left Stretcher Back Stretcher Front Stretcher
X 2 PCS
BC D E F G H I
Each part has a unique part number. Please reference the appropriate part
number when contacting customer service for replacement parts.
Before throwing any packaging, please verify all contents and make sure you
have received all the parts listed above!
G
H
I
F
E

Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of the
page.
HARDWARE LIST
Hardware Pack
HP#:TDAS002316-00
2
3
2
22
42 5
2
1
ALLEN KEY
1 PC
Ø5/16 " x 2 3/8"
61 PCS
BOLT
Ø5/32" x 1 5/8"
61 PCS
SCREW
Ø12.5 X 1.2mm
16 PCS
SPRING WASHER
Ø22 X 1.8mm
16 PCS
FLAT WASHER
5
(Emerald Green Velvet)
DAS002316(Taupe Velvet)
DAS002309(Navy Velvet)
DAS002310
DAS002312(Gray Velvet)

Attach
A
C
to the seat frameA
right back leg and
B
with flat washers
left back leg
and hex socket head bolts
through the center of the seat frame .
Use Allen key to tighten the bolts.
6
1
3
5
2, spring
washers
X 4X 4
X 4
1
3
2
Note: Do not fully tighten the bolts. Leaving
them slightly loose will facilitate assembly
the
in the following steps.
2
3
15
C
B
A

7
X 4
1
2
X 4X 4
3
2
Attach
A
E
to the seat frameA
right front leg and
D
with flat washers
left front leg
and hex socket head bolts
through the center of the seat frame .
Use Allen key to tighten the bolts.
, spring
washers
Note:Do not fully tighten the bolts.
E
D
A1
3
2
5
1
2
3
5

8
3
Insert front stretcher I, back stretcher H, left
stretcher
F right stretcher G & into seat frame
Aas shown below.
C
BE
I
F
HG
D
A

Attach stretchers F, G, H, Ito legs B, C, D,
E
with screws . Use a Phillips head
screwdriver (not included) to tighten the
screws.
9
4
X8
4
4
C
BE
I
F
HG
D
A
4

10
5
Turn the chair upright. Once leveled,
tighten all bolts previously installed with
Allen key 5and place the fabric lining of
seat frame A back into place.
Note: The front legs are equipped with
adjustable levelers. Before placing this
item in the desired location, make sure
that the chair rests evenly on the floor
by turning the adjustable levelers
clockwise or counterclockwise (as needed).
