Dormakaba Confidant RFID User manual

Confidant RFID
Exit Device Operators
Installation instructions
PK3664-T - 2017 - 04
EN

2 Confidant RFID Exit Device Operators PK3664-T 04-17
CAUTION
WARNING
IMPORTANT
Wear Safety glasses before starting the installation process.
1. Tools 3
2. Inventory 4
3. Introduction and disclaimers 5
4. Install spindle 5
5. Attach and clamp spindle clip to spindle 6
6. Install outside lever 7
7. Prepare the door for the appropriate exit device. 8
8. Install mortise (if applicable) 8
9. Install lock on door 8
10. Install lock on door (Bluetooth and/or Messenger Version) 9
11. Plug battery holder 11
12. Test lock functionality 11
13. Program lock - with jack cable 11
14. Install battery door 12
Annex A 13
Install outside housing with gasket 13
Annex B 13
Remove battery holder 13
Drilling templates are in the center of the installation guide
Lever handle and card reader for fire exit hardware
Clasified by Underwriters Laboratories Inc.®
Intended for installation on mortise, rim or vertical rod type devices.
Model: Confidant RFID
IC: 4652A-CRFID
FCCID: Q8SCONFIDANT-RFID
Regulatory Compliance: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Any changes or modifications of this product, not approved by manufacturer will void the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Made in Canada
©2017 Kaba Ilco Inc. All trademarks and registered trademarks are the property of their respective owners.
Installation steps

Confidant RFID Exit Device Operators PK3664-T 04-17 3
A - Screw Driver Small Flat
B - Screw Driver Phillips #2
C - Screw Driver Torx T-20
D - Hexagonal Key 3 mm
E - 5/16" / 7/16" / 1" Drill Bit
F - Needle Nose Pliers
A B C D
E F
1- Tools

4 Confidant RFID Exit Device Operators PK3664-T 04-17
11/16
[17,5]
4-13/16
[122,3]
3-5/8
[92,1]
3-15/32
[88,5]
3-5/8
[92,1]
5-3/32
[129,8]
BACK SET
SEE NOTE #3
HOLE
ID
DIM
INCH/[mm] INCH/[mm] COMMENTS
A5/16
[7.9]
3/4
[19.1] SEE NOTE #4
B7/16
[11.1] * -
C1
[25.4] * SEE NOTE #2
D1
[25.4] * SEE NOTE #6
* UNLESS OTHERWISE NOTED, DRILL HALF DOOR
THICKNESS ON BOTH SIDES.
LHR
RHR
EXIT DEVICE OPERATOR
DRILLING TEMPLATE
AND CORBIN RUSSWIN ED5200/5400
YALE RIM AND SURFACE MOUNT ROD 7100/7170
CONFIDANT RFID LOCK SERIES
www.kabalodgingsupport.com
SHEET
1 OF 2
DATE
18NO2016
UNE VERSION FRANCAISE DE CE DOCUMENT
EST DISPONIBLE SUR DEMANDE.
ECN
16023 DT-514902 REV-4
NOTES:
1- FOR DIMENSIONS AND TOLERANCES REFER TO:
DOOR PREPARATION DRAWING CORRESPONDING IP #.
2- FOR EXIT DEVICE AND MORTISE LOCK CUT-OUT
REFER TO EXIT DEVICE MANUFACTURER
INSTALLATION INSTRUCTIONS.
3- BACKSET SHOWN FOR REFERENCE ONLY,
ADJUST BACKSET TO EXIT DEVICE
MANUFACTURER INSTALLATION INSTRUCTIONS.
4- HOLES A: FROM THE INSIDE OF THE DOOR,
DRILL HOLES (SEE TABLE)
5- SYMBOLS: - DEEP
- CENTER LINE OF DOOR
- DIAMETER
- NOT TO SCALE
6- HOLE D: ONLY LOCK WITH MESSENGER OR
BLUETOOTH. FOR COMPLETE HOLE PATTERN REFER
TO DRAWING DT-514911/IP-514911 FOR RIM AND
MORTISE LOCKS OR DT-515144/IP-515144 FOR
SURFACE MOUNT LOCKS.
7- ALL DIMS INCHES [mm]
DOOR
INSIDE
DOOR
OUTSIDE
LHR LOCK
B
A
C
BCB
B
A
D
D
DOOR
BOTTOM
DOOR
TOP
DO NOT REPRODUCE
CONTACT CUSTOMER SUPPORT
ILCO 1-877-468-3555
SAFLOK 1-800-999-6213
2- Inventory
Hardware Bag
Confidant RFID with battery holder
Exit Device Operator
Double Enclosure
Drilling Template

Confidant RFID Exit Device Operators PK3664-T 04-17 5
3- Introduction and disclaimers
CAUTION
WARNING
IMPORTANT
These instructions are designed for use by maintenance professionals or lock installers who are familiar
with common safety practices and competent to perform the steps described. dormakaba is not
responsible for damage or malfunction due to incorrect installation, that may arise.
CAUTION
WARNING
IMPORTANT
Carefully inspect windows, doorframe, door, etc. to ensure that the recommended procedures will not
cause damage. dormakaba’s standard warranty does not cover damages caused by installation.
CAUTION
WARNING
IMPORTANT
Wear safety glasses when making the holes.
4- Install spindle
From hardware bag, choose the required spindle for the door thickness. Choose a spindle that engages by
1/8" minimum in the exit device chassis and that it is not too long to bottom-out against the exit device
mechanism to jam the lock assembly, once it is tightened down.
For the spindle position see the table in the document named "spindle position"
Insert Spindle

6 Confidant RFID Exit Device Operators PK3664-T 04-17
Ensure legs are firmly clamped
against the spindle
5- Attach and clamp spindle clip to spindle
as shown
For the spindle position, see the table in the document named "spindle position"

Confidant RFID Exit Device Operators PK3664-T 04-17 7
Left Hand
1
1
2
2
Right Hand
6- Install outside lever
CAUTION
WARNING
IMPORTANT
Hold down the outside lever against the outside housing while tightening the lever set screw.

8 Confidant RFID Exit Device Operators PK3664-T 04-17
BACKSET
DRILLING
T
EMPLATE
7- Prepare the door for the appropriate exit
device
8- Install the mortise (If applicable)
9- Install lock on door
For mortise exit devices, install the mortise according to the manufacturer's instructions.

Confidant RFID Exit Device Operators PK3664-T 04-17 9
10- Install lock on door (Bluetooth and/or
Messenger Version)
H1
H2
W
I
G
H3
S-BASE
S-COVER
A
B
CD
F
S1
S-SCREW
E
W1
A Pass wires (W) through the hole (H1). For the hollow doors, the wires shall pass inside the door to come
out from the hole (H2).
B Place the outside housing (I) on the door.
C Attach adaptor plate (G) to the lock (I) using 2 flat head screw (D) (12-24unc) (for solid doors, make sur
that the wires are in the groove (S1).
D Attach the Exit Device chassis (F) to the Adaptor Plate (G) using 2 screws or 4 screws (B) depending on
the Exit Device. For Detex only, use 2 or 4 Flat washers (C).
E Make sure the lock and the Exit Device are well aligned and then tighten screws.
F Connect wires (W) to (W1) and put the excess cables and connectors in the hole (H2) on the door.
G Attach the base (S-base) to the adpator plate (G) with the two screws. Put the cover (S-cover) as shown,
and put the screw (S-screw).
H Follow the manufacturer’s instructions to complete the installation of the exit device and the appropriate
strike

10 Confidant RFID Exit Device Operators PK3664-T 04-17
10- Install lock on door
(Bluetooth and/or Messenger Version) (Suite)
EXIT DEVICE
SURFACE MOUN
T
VERTICALE ROD
ANTENNA
MODULE
MESSENGER
ANTENNA POSITION
BLE ANTENNA
POSITION
ANTENNA
MODULE
EXIT DEVICE
RIM, MORTISE,
CONCEALED ROD
MESSENGER
ANTENNA POSITION
BLE ANTENNA
POSITION

Confidant RFID Exit Device Operators PK3664-T 04-17 11
✗
✓
12-Test lock functionality
Make Sure Room Door is Open
A - Present Test Keycard
B - Check Green & Red Lights Flash
C - Rotate Outside Lever to Check Bolt or Rod Retraction
D - Release Outside Lever, Should Move Freely
E - Activate Panic Bar to Check Bolt or Rod Retraction
13-Program lock - With Jack Cable
11- Plug battery holder

12 Confidant RFID Exit Device Operators PK3664-T 04-17
14- Install battery door
A
C
B
D
CAUTION
WARNING
IMPORTANT
For security reasons, lock must be programmed BEFORE installing the battery door. Every time the
battery door is removed pass an emergency card or connect lock to a dormakaba Programming Unit to
reset the tamper alarm. Audit information is not affected.
* WARNING

Confidant RFID Exit Device Operators PK3664-T 04-17 13
Annex A • Install outside housing with gasket
(Exterior and ocean front versions)
Annex B • Remove battery holder
A
C
B
D
Unscrew
Unclip Battery Holder
Remove Door
Remove Battery Holder

PK3664-T 17-04
Subject to change without notice
www.dormakaba.com
dormakaba
Customer Services & Support
Ilco: 1.877.468.3555 / + 1.514.340.9025
Saflok: 1.800.999.6213 / + 1.248.837.3700
General information:
www.kabalodging.com
Online consumable orders:
www.ilcostore.com
www.saflokstore.com
To access all of our easy steps, please
visit our support website:
www.kabalodgingsupport.com
