Dormakaba LA GARD ComboGard Pro 39E Manual

Keypad Only
Setup Instructions
LA GARD
ComboGard Pro
39E Electronic
Combination Lock
P/N 735.028
Rev. N - 05/18

2 P/N 735.028 Rev N • 05/18 ©copyright 2006-2018
dormakaba
ComboGard Pro locks can either be configured using the ComboGard Pro
Setup software or through a series of keypad commands. This document will
cover configuring the lock using the keypad commands ONLY.
The ComboGard Pro Lock has three states of operation: Factory Default,
Manual Setup, and Active. ComboGard Pro locks are shipped from LA GARD
in Factory Default state without Users or features enabled.
Factory Default: The Lock must be in the Factory Default state to be
programmed by the PC software.
Factory mode functions as follows:
• 1 key – When pressed, will open the Lock.
• 0 key – When pressed, prompts the ComboGard Pro Setup software to
send the configuration settings to the Lock.
OR if pressed and held, places the Lock into Manual Setup.
• All other keys perform no function.
Manual Setup: The Lock can be configured using the keypad only.
Active: To activate the Lock and freeze the configuration, the Manager
combination MUST be changed.
WARNING: Add all required Users and complete Setup Configuration before
changing the Manager’s default combination from 5-5-5-5-5-5. Once the
combination is changed, NO ADDITIONAL USERS can be added.
PROGRAMMABLE LOCK FEATURES
MODES (Multiple Modes may be selected.)
• Silent Alarm (Alarm Box Required)
If enabled, this option will send a signal to an outside alarm system through
the LA GARD Alarm Box.
• Dual Mode
If enabled during keypad set up (not using the software setup), two
combinations are required to open the lock. All other manager functions can
be performed using the Manager combination alone.
NOTE: If the user prefers that two combinations shall be required
to perform ALL lock functions, set up must be performed using
ComboGardPro Set Up Software v. 5.2.0.116 or higher. This is only
available on locks with 39E code level .669 or higher. See instruction
731.018 for detailed software setup instructions.
• Time Delay Override
If enabled, User 9 can override delay period.
User 9 must be active.

P/N 735.028 Rev N • 05/18 ©copyright 2006-2018 3
EXTERNAL SIGNALS (Alarm Box Required - P/N 2789NC. Only one External
Signal type may be selected.)
An external input signal to the Alarm Box will either disable the Lock from
opening, override the time delay, or enable the remote override depending on
the selection programmed for External Signals.
• External Signal disables Lock opening with valid combination.
NOTE: When configuring the ComboGard Pro Lock using the keypad only, the
Disable Opening option is enabled by default and cannot be changed.
OR External Signal overrides Time Delay. (This option is ONLY available if
enabled using Setup software.)
OR External Signal enables the Remote Override. (This option is ONLY
available if enabled using Setup software, and with Lock code level 39E v1.09
or higher.)
TIME DELAY
• Delay Period 1 - 99 minutes
• Open Period 1 - 19 minutes
COMBINATION LENGTH
A combination length from six (6) to nine (9) digits may be selected.
NOTE: To maintain the VdS Class 2 and EN 1300 Class B certification when
the duress alarm feature is used, a combination length of 7 digits or longer
must be selected.
LOCK USERS
Manager
• Open Lock
• Change Combination
• Enable/Disable Users
• Delete Users
• Set Time Delay Values
• Audit Lock
Up to 9 Users
• Open Lock
• Change Combination
STANDARD LOCK FEATURES
Wrong Try Penalty
• Entry of four (4) consecutive invalid combinations initiates a five (5) minute
delay penalty.
Lock responses during the penalty period are as follows:
- The LED will flash every ten (10) seconds.
- If any key is pressed, the Lock will flash the LED and beep three times.
• Once the penalty period has ended, two (2) consecutive invalid combinations
will initiate another five (5) minute penalty period.

4 P/N 735.028 Rev N • 05/18 ©copyright 2006-2018
dormakaba
Low Battery Warning
• Repeated audio/visual signals (LED flashes/beeps) during Lock opening
indicate the battery is low and should be replaced immediately.
• If the battery level becomes too low to safely operate the Lock, pressing any
key will initiate the low battery warning. The battery must be replaced
before the Lock will operate.
Audit Records
• Lock records the last 63 events in non-volatile memory.
• Audit file cannot be deleted from the Lock.
• Only the Manager can audit the Lock.
• ComboGard Pro auditing software and an Interface Adapter are required to
retrieve a Lock audit.
LOCK OPERATING CONVENTIONS
• If a mistake is made while entering keystrokes, wait thirty (30) seconds and
repeat operation.
• To access lock commands, enter combination and hold down the last digit
until Lock double signals and the LED stays on.
• In Dual Mode, two combinations are required to open the lock. Manager
Commands 1,2,3,7 and 9 can be performed using the Manager combination
alone.
• In Dual Mode and [User + Manager] to access Manager Menu, two
combinations are required for all lock functions except to Change
Combination. A valid User combination must be entered first, followed by
the Manager combination to access Manager Commands 1,2,3,7 and 9.
• Lock must be opened within 4 seconds once a valid combination has been
entered.
• To open a container with a Swing Bolt Lock, turn the container handle to the
open position and open the door.
• To open a container with a Dead or Spring Bolt Lock, turn the keypad or dial
to retract the bolt and open the door.
• When closing a container, verify that it has been secured.
LOCK RESPONSES
Standard Operations
Entry Devices with LEDs respond with both LED flashes and beeps.
• Single signal - one (1) LED flash and one (1) beep indicate the operation is
complete.
• Double signal - two (2) LED flashes and two (2) beeps indicate entry is valid
or accepted.
• Triple signal - three (3) LED flashes and three (3) beeps indicate invalid or
not accepted.
NOTE: The 8130 Entry Device (no LED) responds with beeps only.

P/N 735.028 Rev N • 05/18 ©copyright 2006-2018 5
Additional Operations
• Delay Period – The LED will flash once every second.
• Open Period – The LED will flash twice a second, and the Entry Device will
beep every 10 seconds.
• If any key is pressed, the Lock will flash the LED and beep three times.
• Penalty Period - The LED will flash every ten (10) seconds.
• Low Battery Warning - During a Lock opening, the LED will flash and Entry
Device will beep repeatedly.
SUPER MASTER RESET
SMR will reset the lock back to factory state, but the SM code remains
unchanged. The default code of 5-5-5-5-5-5-5-5 must be changed before the
Manager default code is changed or the Super Master Reset function will be
permanently lost.
Process is as follows:
• Action - Press and hold [0] key for 3 seconds
• Result – Lock beeps twice and the LED remains ON throughout the entire
process.
• Action – Enter default code of 5-5-5-5-5-5-5-5. Press and hold last digit until
the unit gives a double beep.
• Result – Command Menu access is granted.
SMR has only 2 Command options available:
• If press [0] = Change Code, (1 time use)
• Enter current default Super Master code of 5-5-5-5-5-5-5-5
• Enter new Super Master code (ex. 8-8-8-8-8-8-8-8) then double beep.
• Enter new Super Master code again to confirm (ex. 8-8-8-8-8-8-8-8) then
double beep the SMR code is set.
NOTE: Once the default code is changed to a new code the code can never be
changed. A reset box must be used to reset.
• If press [8] = Reset the Lock
• Lock will signal a long beep to indicate it was reset
• If any other key is pressed then the lock beeps 3 times and the operation is
ended.
PROGRAM THE LOCK
EXIT FACTORY STATE
CAUTION: Always perform this operation with the door open!
1. Press and hold the 0 key until lock double signals.
2. Enter the default Manager combination, 5-5-5-5-5-5.
The lock will open. Lock is now in Manual Setup.

6 P/N 735.028 Rev N • 05/18 ©copyright 2006-2018
dormakaba
SET COMBINATION LENGTH
1. Enter the default Manager combination (5-5-5-5-5-5) and hold down last
digit of combination until lock double signals twice release and the LED
stays on.
2. PRESS 8.
3. Enter combination length (6, 7, 8, or 9).
4. Press 0.
5. Enter combination length a second time and press 0 to confirm.
Example setting a combination length to seven digits:
Enter 5-5-5-5-5-5 (hold down the last number) 8 - 7-0-7-0.
6. To test, enter default Manager combination 5-5-5-5-5-5-5 (all fives to length
of combination). Lock will signal twice and lock will open.
NOTE: If combination length is changed after Users are enrolled, all Users will
be deleted and must be re-enrolled.
CAUTION: To maintain the VdS Class 2 and EN 1300 Class B certification
when the Silent alarm feature is used, a combination length of 7 digits or
longer must be selected.
CONFIGURE LOCK MODES
1. Enter default Manager combination (all fives to length of combination) and
hold down last digit of combination until lock double signals twice release
and the LED stays on.
2. PRESS 8.
3. Enter 0(this maintains current combination length value).
4. Enter desired Lock Mode configuration from the chart below.
5. Enter 0and re-enter the desired Lock Mode configuration to confirm.
NOTE: Dual Mode cannot be selected if at least one additional User has
not been enrolled. User 9 must be enrolled to use the Time Delay Override
function.
MODE TIME DELAY OVERRIDE DUAL MODE DURESS ALARM
0
1P
2P
3P P
4P
5P P
6P P
7PPP

P/N 735.028 Rev N • 05/18 ©copyright 2006-2018 7
ACTIVATE USERS
1. Enter Default Manager combination (all 5’s to length of combination) and
hold down last digit of combination until lock double signals twice release and
the LED stays on.
2. PRESS 1.
3. Enter User number (1 - 9.)
4. Enter the NEW User combination
5. Re-enter the User combination to confirm.
6. Repeat steps 1- 5 for each User to be added.
NOTE: If a User is not enrolled during setup, the User is blocked and cannot
be added later. New combinations are rejected when less than 2 digits are
different from existing combinations.
Set Time Delay Values:
The Delay and Open Periods may be set up at this time or later by the
Manager. To set the Time Delay Periods follow the instructions below or refer
to Manager Instructions 732.018.
1. Enter Manager combination and hold down last digit of combination until
lock double signals release and the LED stays on.
2. PRESS 9.
3. Enter two-digit Delay Period value (00 to 99 minutes) followed by the
two-digit Open Period value (00 to 19 minutes).
4. Re-enter the Delay and Open Period values to confirm.
ACTIVATE THE LOCK
To complete the activation of the lock and freeze the configuration, the
Manager combination MUST be changed
To change the Manager combination, follow the steps below:
WARNING: Add all required Users and complete Setup Configuration before
changing the Manager’s default combination from 5-5-5-5-5-5. Once the
combination is changed, NO ADDITIONAL USERS can be added.
CAUTION: Always perform this operation with the door open!
1. Enter the default Manager combination and hold down the last digit until
unit double signals twice release and the LED stays on.
2. PRESS 0.
3. Enter your NEW combination,
4. Re-enter your NEW combination to confirm.
5. The lock is now active and the configuration is frozen.
6. Test lock operation several times before closing the door.
NOTE: If default combinations are used, it is recommended that they be
changed. New combination will not be accepted if it varies from the current
combination by only one digit (+/-). When selecting a combination, do not
use a birthday or other predictable information that could give correlation
between the user and the combination.

dormakaba
RESET THE LOCK
(Reset Box [P/N 6066] required.)
To change the lock settings after the configuration is frozen, you must reset
the lock.
1. Remove battery.
2. Hold down the 0 key for at least 10 seconds to discharge all internal
capacitors.
3. Connect Reset Box to BAT port on Lock.
4. PRESS 1.
If the lock opens, the factory reset is complete. If the lock does not open,
disconnect the Reset Box and repeat steps 2 and 3.
5. Disconnect Reset Box.
The Lock is now in Factory mode, and is ready to be configured by the PC
Software or through the keypad.
dormakaba USA Inc.
749 W. Short St.
Lexington KY 40508
T: 859 253 4744
F: 859 255 2655
Toll-free: 877 522 2627
www.dormakaba.us P/N 735.028 Rev. N 05_2018
