Dormakaba YD30 Series Manual

Installation & Operating Instructions
YD30D
Double Sideload Lock

2
Table of Contents
1. Document Information 3
1.1 Contents and Purpose 3
1.2 Target Group 3
2. Safety and Compliance 4
2.1 Safety Information 4
2.2 Regulatory Compliance Information 5
3. Product Information 7
3.1 Product Description 7
3.2 Package Contents 8
3.3 Technical Data 9
4. Product Dimensions 10
4.1 Lock Dimensions 10
4.2 Strike Dimensions 11
4.3 Housing Dimensions (Available Separately) 12
4.4 Dress Plate Dimensions (Available Separately) 12
4.5 Fitting Tab Dimensions (Available Separately) 13
5. Pre-Installation Assessment 14
5.1 Mounting Assessment 14
5.2 Wiring Assessment 15
5.3 Operating Mode Assessment 15
6. Mounting 16
6.1 Mortise Installation (Solid Wood) 16
6.2 Mortise Installation (Metal Extrusion) 17
6.3 Surface Mounting Installation (Solid Wood) 18
6.4 Surface Mounting Installation (Glass) 19
7. Wiring 20
7.1 Wiring Guide 20
7.2 Fail Safe Connection 20
7.3 Fail Secure Connection 20
8. Operating Mode 21
8.1 Fail Safe Operation 21
8.2 Fail Secure Operation 21
9. Maintenance 22
9.1 Maintenance and Cleaning 22
9.2 End of Service Life 22

3
1.1 Contents and Purpose
This document describes installation, connection, operation, and maintenance of the lock SL30DBL. Read the
document carefully and observe the instructions it contains. They contain important information for reliable
installation and trouble-free operation.
1.2 Target Group
Target group of these instructions are:
• Installer
• Service Technician
Installers and service technicians are skilled personnel who have the specialist knowledge required for instal-
lation, commissioning, and maintenance.

4
1. Safety and Compliance
1.1 Safety Information
WARNINGS
• Live parts inside.
• The handling and installation of this device is recommended for a professional.
• Use of an unsuitable power supply unit may cause product failure or injury.
• Do not remove the cover plates or face plate.
• Ensure installation does not expose sharp edges of the product to users.
UL REQUIREMENTS
• If the unit is installed on a fire exit door the product installation shall be allowed only if
accepted by a local AHJ authority having jurisdiction and comply with NFPA 101.
• The unit is to be connected and controlled via a UL 294 or FWAX7 listed Access Control Unit.
• That the unit shall be installed in accordance to NFPA 70 along with any additional
requirements imposed by the local authority of jurisdiction.
• Do not connect the unit to a receptacle controller by a switch.
• If the unit is installed in conjunction with panic hardware the lock shall be installed in a
manner to not impair panic device operations.
• The unit shall be powered by a UL 294 or UL 2610 listed power supply with a Class 2 power
limited output.
• All factory tested grades were not evaluated by UL.
• UL1034 rating only applies when product is installed in a mortised application.
• UL10C rating only applies when product is installed in vertical position

5
1.1 Regulatory Compliance Information
This product is in compliance with the CE Directives including Electomagnetic Compatibility (EMC) Directive,
Restriction of the use of certain hazardous substances (RoHS) Directive, and Registration, Evaluation,
Authorisation and Restriction of Chemicals (REACH) Regulation.
This product is in compliance with the United Kingdom (UK) Legislation including the Electromagnetic
Compatibility Regulation 2016, and the Restriction of the Use of Certain Hazardous Substances in Electrical
and Electronic Equipment Regulations 2012.
CE and UKCA Declaration of Conformity is available at www.dormakaba.com.
EN14846:2008
1 2 3 4 5 6 7 8 9
3 X 9 0* / G 2 1 1
*Grade 0 for classification 4 ‘Suitability for use on fire/smoke doors’ applies only to the product when used
as a primary latching device for a fire/smoke door. The product is suitable for use on a fire/smoke door when
installed as an auxiliary locking device alongside a primary latching device with appropriate test evidence.
This appliance is labelled in accordance with European Directive 2012/19/EU concerning
used electrical and electronic appliances (waste electrical and electronic equipment
- WEEE). The guideline determines the framework for the return and recycling of used
appliances as applicable throughout the EU.
In Countries Outside the European Union and EEA (Norway, Iceland, and Liechtenstein): If
you wish to dispose of this product please contact your local authorities and ask for the
correct way of disposal.
This product is in compiance with the Regulatory Complaince Mark (RCM) for Australia and
New Zealand.

6
This product is regulated by the UL/CSA and bears UL/C-UL certification.
Certifications: UL294, UL1034, ULC-S533-15
UL File Number: BP7604, R22400
UL Catagories: CVXY, ALVY, FWAX7, GWXT
UL294
Line Security Level I
Standby Power Level I
Attack Level I
Endurance Level IV
UL1034
Static Strength: 1,500 lbf (6,673N)
Dynamic Strength: 70 ft·lbf (95J)
Endurance: 250,000 cycles
UL10C For use in vertical orientation with any UL swinging type
fire door frame rated up to and including 3 hours.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
residential, commercial, or industrial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
Modifications: Any modifications made to this device that are not approved by the
manufacturer may void the authority granted to the user by the FCC to operate this
equipment.
Innovation, Science and Economic Development Canada ICES-003:
CAN ICES-3(B)/NMB-3(B)

7
1.1 Product Description
The SL30DBL is a motor driven low voltage electric lock designed to secure commercial and residential swing-
through (180°) doors. The lock has been designed to address the two biggest issues in concealed electric
locking today;
1. The ability to ‘pull’ a door into alignment even if the door has not closed in a central position.
2. The ability to release when requested even if there is excessive load on the door.
The design of the SL30DBL is unique as it has two motors which independently operate two bolt pins. The bolt
pins operate on a cam action which enables each bolt pin to pull a door into place. In practice as the door
closes it may come to rest in a position that is not fully closed. The SL30DBL senses when the door is within
8mm (5/16 inch) of being fully closed in either direction and activates the bolt pin. This is an effective 16mm
(10/16 inch) alignment window. The bolt pin then rotates out and pulls the door from its resting position to
the closed and secured position.
With the door secured and locked the SL30DBL can be given an unlock signal and it will instantly unlock. If
the door is loaded (pre-load) when the unlock signal is given the SL30DBL will still unlock, even with loads
in excess of 100kg on the door from either side. Critically the ability of the SL30DBL to instantly release with
excessive pre-load on the door even occurs in the event of a power failure if the lock is configured as fail safe.
Additional features of the SL30DBL are;
• Multi-voltage input (12 - 24VDC)
• Very low current consumption
• Door position and bolt position monitors
• High physical strength
• Fail-safe / Fail-secure on-site conversion with the re-positioning of a single switch

1.1 Package Contents
1x Lock 1x Strike Plate
4x 10G self-tapping screws 1x 300mm 7-way wire loom
8

1.1 Technical Data
Materials
Bolt Stainless Steel 17-4PH
Lock / Strike Plate Stainless Steel 304
Mechanical
Bolt Extension 13mm
Door Gap max. 6mm (¼ inch)
Misalignment Correction max. 8mm (5/16 inch)
Cycle Life 1,000,000 cycles
Holding Force 10,000N (2,250 lbf) (factory tested only)
Side Load Release 6,000N (1,350 lbf) (factory tested only)
Locking Time 1.0 seconds (typical)
Unlocking Time 0.3 seconds (typical)
Environmental
Operating Temperature -10°C to +55°C
Electrical
Power Requirements 12-24 VDC ±15%
Initial Power Up Time 11 seconds
Initial Current Draw 750mA@12VDC, 400mA@24VDC
Standby Current 40mA@12VDC, 25mA@24VDC
Signal Contacts Bolt Position (NO) 30VDC max., 100mA max.
Door Position (NO)
Compliance
CE, UKCA, UL, FCC, IC, RCM, RoHS 2
9

10
1. Product Dimensions
1.1 Lock Dimensions
The dimensions shown are approximate and subject to change without prior notice.
183mm
7.205in
47mm
1.854in
3mm
0.118in
255mm
10.039in
10mm
0.394in
235mm
9.252in
10mm
0.394in
30mm
1.181in

11
1.1 Strike Dimensions
The dimensions shown are approximate and subject to change without prior notice.
255mm
10.039in
100mm
3.937in
55mm
2.165in
14mm
0.551in
3mm
0.118in
10mm
0.394in
235mm
9.252in
10mm
0.394in
30mm
1.181in

12
1.1 Housing Dimensions (Available Separately)
The dimensions shown are approximate and subject to change without prior notice.
259mm
10.205in
56mm
2.189in
220mm
8.661in
20mm
0.787in
34mm
1.346in
1.2 Dress Plate Dimensions (Available Separately)
260mm
10.236in
58mm
2.283in

13
1.1 Fitting Tab Dimensions (Available Separately)
The dimensions shown are approximate and subject to change without prior notice.
38mm
1.476in
24mm
0.945in
20mm
0.787in
M5x0.8 Thread
4mm
0.157in

14
1. Pre-Installation Assessment
1.1 Mounting Assessment
The first decision regarding installation is whether the SL30DBL will be mortised or surface mounted. Mortise
installation ensures a discrete solution as the lock and strike plate can be embedded into the door leaf and
frame, however in some instances this is not possible. Glass doors for example require surface mounting
which is done with the aid of the SL30DBL housing and dress plate (available separately).
The lock and strike plate can be installed mortised (1), surface mounted (2), or a combination of the two (3).
Regardless of the installation method it is vital that the lock face plate and strike plate are aligned vertically
to each other and that the gap between them does not exceed 6mm (¼ inch) when the door is closed.
When the door is closed, the resting position of the door leaf can be misaligned up to 8mm (5/16 inch) in
either direction and the SL30DBL will pull the door into alignment with ease. This misalignment could be
caused by an automatic door closer not aligning the door or natural distortions in the door assembly.
The SL30DBL can be installed vertically or horizontally but is not designed to be mounted in a floor cavity
firing upwards or in a wet environment. Must be installed vertically for UL10C applications.

15
1.1 Wiring Assessment
Before installation begins, consideration must be made for where to run the wires and decide on what
feedback is required from the lock. There are a total of seven available connections; three are compulsory
power/control connections whilst the remaining four provide optional door and bolt position feedback. These
optional connections can be integrated into access control or alarm systems to provide full monitoring.
The correct gauge of wire needs to be chosen as voltage drop across the power/control wires can limit the
locks operation. For all the remaining connections, a lower gauge wire can be used as these are only signal
wires. The following table shows the maximum distance that the wire runs can be between the power supply
and the lock, assuming the power supply outputs 12VDC or 24VDC.
Conductor Cross Sectional Area Maximum Distance
#AWG (mm²) at 12VDC at 24VDC
24 0.20 10m (33ft) 30m (98ft)
22 0.33 16m (52ft) 48m (157ft)
20 0.52 26m (85ft) 77m (253ft)
18 0.82 41m (135ft) 122m (400ft)
16 1.31 65m (213ft) 195m (640ft)
14 2.08 103m (338ft) 310m (1017ft)
1.2 Operating Mode Assessment
The SL30DBL can be set to one of two operating modes before installation, Fail Safe or Fail Secure.
When the operating mode is set to Fail Safe, supply voltage is applied to the control input to lock the door,
and the SL30DBL will unlock in the event of power loss.
When the operating mode is set to Fail Secure, supply voltage is applied to the control input to unlock the
door, and the SL30DBL will lock or remain locked in the event of power loss.
The failure mode of the SL30DBL is factory set as Fail Safe. Before the lock is installed this can be changed to
Fail Secure by repositioning the switch located at the end of the product.

16
1. Mounting
1.1 Mortise Installation (Solid Wood)
1. Cutting the mortise
Referring to the product dimension drawings, a mortise is cut into
the door frame to fit the lock and a mortise is cut into the door
leaf to fit the strike. Wooden doors and frames require full mortises
with space made behind the lock body to accommodate the wire
connections.
It is crucial to ensure that the mortises in the door leaf and frame
are aligned vertically and horizontally when the door is closed as
this aligns the bolt pin to the strike opening and also the strike
magnet to the locks internal door position sensor.
Ensure that the final gap between the lock face plate and strike
plate once it is installed will be no more than 6mm (¼ inch).
2. Wiring the lock
A hole needs to be drilled in the back of the mortise to bring the
wires out and a connection can be made to the supplied wire loom
which in turn plugs into the lock.
Refer to the Wiring section of this document for detailed
instructions on wiring.
3. Setting the operating mode
Ensure the operating mode switch is positioned to the required state, Fail
Safe or Fail Secure.
Refer to the Operating Mode section of this document for detailed
instructions on wiring.
4. Fitting the lock and strike plate
The lock can be slid back into the door frame mortise, ensuring that the
wiring integrity is maintained, and then secured in place with the supplied
10G self-tapping screws. Please ensure the lock is the correct orientation
as to pull the door into the door jamb.
The strike is then placed into the door leaf mortise and the remaining
10G self-tapping screws are used to secure it in place. Ensure the strike is
oriented so that the bolt hole aligns with the lock bolt.

17
1.1 Mortise Installation (Metal Extrusion)
1.
Referring to the product dimension drawings, a mortise is cut into the
door frame to fit the lock and a mortise is cut into the door leaf to fit
the strike. Metal doors and frames, being hollow, often only require a
single rectangle cut-out to accommodate the lock face plate or strike
plate. For these installations lock and strike can be installed flush using
fitting tabs (available separately).
It is crucial to ensure that the mortises in the door leaf and frame
are aligned vertically and horizontally when the door is closed as this
aligns the bolt pin to the strike opening and also the strike magnet to
the locks internal door position sensor.
Ensure that the final gap between the lock face plate and strike plate
once it is installed will be no more than 6mm
(¼ inch).
2.
Feed the wires out of the hollow chamber of the frame and a
connection can be made to the supplied wire loom which in turn plugs
into the lock.
Refer to the Wiring section of this document for detailed
instructions on wiring.
3.
Ensure the operating mode switch is positioned to the required state, Fail
Safe or Fail Secure.
Refer to the Operating Mode section of this document for detailed
instructions on wiring.
4.
The lock can be placed into the door frame cutout, ensuring that the wiring
integrity is maintained, and then secured in place with M5 machine screws
(included with fitting tabs). Please ensure the lock is the correct orientation
as to pull the door into the door jamb.
The strike is then placed into the door leaf cutout and then M5 machine
screws (included with fitting tabs) are used to secure it in place. Ensure the
strike is oriented so that the bolt hole aligns with the lock bolt.

18
1.1 Surface Mounting Installation (Solid Wood)
1.
Install two 10Gx1” self-tapping screws (included with housing) in the mounting
surface, as per the product dimension drawings they should be 220mm apart,
20mm from the surface edge.
2.
An 8mm hole should be drilled through the housing wall at the position chosen
by the installer for the wiring to enter. The wiring can be guided to the housing
through surface mount conduit, or through a hole in the mounting surface
material. Push a rubber grommet (included with housing) over the drilled hole
to protect the wires from any sharp edges.
3.
Position the keyhole cutouts of the housing over the screw heads and slide
into position flush with the surface edge, and then tighten screws in place to
secure the housing.
4.
Feed the wires through the 8mm hole in the housing and a connection can be
made to the supplied wire loom which in turn plugs into the lock.
Refer to the Wiring section of this document for detailed
instructions on wiring.
5.
Ensure the operating mode switch is positioned to the required state,
Fail Safe or Fail Secure.
Refer to the Operating Mode section of this document for detailed
instructions on wiring.
6.
The lock can be placed into the housing, ensuring that the wiring
integrity is maintained, and then secured in place with M5 machine
screws (included with housing). Please ensure the lock is the correct
orientation as to pull the door into the door jamb.

19
1.1 Surface Mounting Installation (Glass)
1. Fitting the housing
Clean the glass surface with isopropyl alcohol and peel the
protective layer from the double sided tape of the housing.
Position the housing flush with the edge of the glass, and press
down to adhere tape to surface.
2. Fitting the dress plate
Clean the glass surface with isopropyl alcohol and peel the
protective layer from the double sided tape of the dress plate.
Position the dress plate flush with the edge of the glass and
centered on the housing location, and press down to adhere
tape to surface.
3. Fitting the strike plate
The strike is then placed into the housing and then secured in
place with M5 machine screws (included with housing). Ensure
the strike is oriented so that the bolt hole aligns with the lock
bolt.

20
1.1 Wiring Guide
The SL30DBL is supplied with a 7-way wire loom that plugs directly into the lock. The wires are colour coded
as per table below, with the power and control wires being essential connections and the four monitor
connections being optional.
Wire Colour Meaning Description
RED Power Supply
(12 - 24VDC)
Positive connection to DC power supply, “”
BLACK Negative connection to DC power supply, “”
BLUE Control Switched positive control input
VIOLET Bolt Position
Monitor
Normally open contact (NO), closed when the bolt
pin is extended (optional)
VIOLET
WHITE Door Position Monitor Normally open contact (NO), closed when the
strike is aligned with the lock (optional)
WHITE
1.2 Fail Safe Connection
When in Fail Safe configuration, applying positive voltage to the control wire triggers the SL30DBL to lock
(active-high locking signal). In the event of a power cut, the SL30DBL will unlock.
1.3 Fail Secure Connection
When in Fail Secure configuration, applying positive voltage to the control wire triggers the SL30DBL to unlock
(active-low locking signal). In the event of a power cut, the SL30DBL will remain locked.
