Dover Wayne Select S1 Guide

Installation / Operation
Wayne Select™ S1 Compact Electronic Dispensers
3/G7100 Series
W2940305
Rev 07

For the purpose of this manual: the product designated on the front cover will be defined herein after
as the “Product;” and Dover Fueling Solutions (“DFS”), will reference different entities based on the
point of origin for which the Product is manufactured. For Products from North America, DFS
references Wayne Fueling Systems LLC located in Austin, Texas. For Products from Brazil, DFS
references Wayne Industria e Comercio Ltda. located in Rio de Janeiro, Brazil. For Products from the
United Kingdom, DFS references Dover Fueling Solutions UK Ltd. located in Dundee, Scotland. For
Products from China, DFS references Tokheim Hengshan Technologies Company, Ltd. located in
Guangzhou, China. For Products from India, DFS references Dover Fueling Solutions India Private
Limited.
READ THIS MANUAL BEFORE YOU BEGIN
Dispensers have both electricity and a hazardous, flammable, and potentially explosive liquid. Failure
to follow the below precautions and the Warning and Caution instructions in this manual may result in
serious injury or death. Read every tag attached to the dispenser before commencing installation.
Follow all rules, codes, and laws that apply to your area and installation.
SAFETY PRECAUTIONS - INSTALLATION AND MAINTENANCE
Always make sure ALL power to the dispenser (motors and electronic head) is turned OFF before you
open the dispenser cabinet for maintenance. Physically lock, restrict access to, or tag the circuit
breakers you turn off when servicing the dispenser. If applicable, be sure to trip (close) and test the
emergency valve(s) under the dispenser BEFORE beginning maintenance.
Make sure that you know how to turn OFF power to the dispenser and submersible pumps in an
emergency. Have all leaks or defects repaired immediately.
EQUIPMENT PRECAUTIONS
Be sure to bleed all air from the product lines of remote dispensers and prime suction pumps before
dispensing product, otherwise, damage to the equipment may occur. Always use the approved
method for lifting the dispenser. Never lift by the nozzle boot, sheet metal, etc., otherwise equipment
damage or personal injury may occur.
USE ONLY GENUINE PARTS
For product liability to be valid, no changes may be made to the equipment without the written
consent of Dover Fueling Solutions.
REGISTRATION OF SITE AND HOW TO CONTACT DFS
The equipment used at this site must be registered prior to contacting for warranty service. Sites can
be pre-registered prior to installation by a DFS Authorized Service Organization (ASO) via the on-line
registration system OR through completing the Section 1 portion of the form, at the end of this
manual, and sending it to DFS (for non-ASOs). Pre-registration of a site helps to expedite warranty
service in case it is needed. Please allow 2-3 days after receipt of the information for pre-registration.
Final registration, which requires all of the information pertaining to the site including Start-Up date
and equipment serial numbers, must be completed within 7 days of the completion of the Start-Up
using the same aforementioned methods.
Trouble with the installation of this product should be referred to your DFS ASO. An ASO with a
technician number can receive assistance by calling the DFS Support Center at:
1-800-926-3737
Customers, Installers or Distributors who are not an ASO, needing help with the operation or
installation of this product, should contact the DFS Support Center at:
1-800-289-2963 OR [email protected]
DANGER

INDICATORS AND NOTATIONS
Danger indicates a hazard or unsafe practice which, if not avoided, will result in severe injury or
possibly death.
Warning indicates a hazard or unsafe practice which, if not avoided, may result in severe injury
or possibly death.
Caution indicates a hazard or unsafe practice which, if not avoided, may result in minor injury.
Important information to consider, otherwise, improper installation and/or damage to
components may occur.
DEF DISPENSER CONSIDERATIONS
Human Exposure: Avoid contact with eyes, skin, and clothing. Refer to Material Safety Data Sheet
(MSDS) for detailed safety information. In case of contact with eyes, immediately flush with water for
at least 15 minutes, occasionally lifting the upper and lower eyelids. In case of skin contact,
immediately flush skin with plenty of water for at least 15 minutes while removing any contaminated
clothing and shoes. Wash clothing and clean shoes before reuse. In both cases, get medical
attention if symptoms occur.
Temperature: DEF freezes at approximately 12ºF. This dispenser provides no heating for
protecting the DEF on against cold temperatures. While allowing DEF to freeze does not damage
the DEF, it can damage the fluid containing components of the dispenser. This dispenser should not
be used in areas where the ambient temperature will go below 12ºF to prevent the DEF from freezing.
If the DEF in the dispenser is allowed to freeze, components in the dispenser must be inspected for
damage before the dispenser is placed back into service. Additives may not be used in DEF to lower
the DEF freezing point. Prolonged storage above 77ºF can impair the quality of DEF and reduce its
shelf life.
Compatibility: DEF can cause corrosion of components that are made from incompatible materials.
Using incompatible materials can also contaminate the DEF which can potentially damage the
vehicle’s Selective Catalytic Reduction (SCR) system. Use only materials in the installation that are
known to be compatible with DEF.
Prover Cans: Prover cans designed and/or used for motor fuels must not be used for measuring
DEF nor should DEF Provers be used for measuring motor fuels. Contaminating the DEF with motor
fuel can potentially damage the vehicle’s SCR system.
Disposal: During testing and calibration, DEF is dispensed into containers or the prover can. This
DEF must be properly handled to prevent contamination of the DEF (if it is to be reused) and any
potential ground water contamination (if it is to be disposed of). See PEI Recommended Practices for
the Storage and Dispensing of DEF (RP100-10).
Sealant: When making connections on NPT pipes, it is important to use the correct sealant to reduce
the possibility for leaks. Loctite 567 is recommended to be used as a sealant along with Loctite
activator 7649. Apply the activator onto both surfaces and allow it to dry before applying the sealing
compound. Follow the manufacturer’s instructions for use of these materials. Do not use Teflon
tape. Do not use any sealing compound on BSPP fittings. These fittings are provided with an o-ring
which forms the proper seal.
Recommended Practices: Refer to PEI publications RP1100 Recommended Practices for Storage
and Dispensing of Diesel Exhaust Fluid (DEF) for additional information and guidelines for working
with a DEF installation.
NOTE:
DANGER
WARNING
CAUTION
CAUTION

This page intentionally left blank

W2940305 Rev 07 8/2019 Dover Fueling Solutions 1
Table of Contents
1Introduction ......................................................................................................................5
1.1Dispensers Covered..................................................................................................5
1.2Model Description......................................................................................................6
1.3Model Designation Format ........................................................................................7
1.4Technical Information ................................................................................................8
2Site Design & Preparation.............................................................................................11
2.1Local, State, and Federal Codes.............................................................................11
2.2Safety Precautions...................................................................................................12
2.3Ethanol and Bio-Diesel Installations........................................................................13
2.4DEF Installations......................................................................................................13
2.5Existing Installations................................................................................................13
2.6Island Construction, Dispenser Anchoring, Piping, and Bollards............................14
3Installation ......................................................................................................................15
3.1Equipment Inspection..............................................................................................15
3.2Typical Site Layout ..................................................................................................15
3.3Electrical Wiring.......................................................................................................16
3.3.1General................................................................................................................16
3.3.2Electrical Termination Descriptions - All Dispensers...........................................16
3.3.3Electrical Termination Descriptions – Pulse Output Interface Option .................17
3.3.4Circuit Breakers & Emergency Electrical Disconnect..........................................19
3.3.5Grounding............................................................................................................19
3.3.6Wire Type ............................................................................................................20
3.3.7Conduit ................................................................................................................20
3.4Gasoline & Diesel Hose and Accessories Installation.............................................21
3.4.1General................................................................................................................21
3.4.2Vapor Recovery Nozzles.....................................................................................22
3.5DEF Hose and Accessories Installation ..................................................................22
3.5.1Nozzle..................................................................................................................22
3.5.2Breakaway/Swivel................................................................................................22
3.5.3Hose ....................................................................................................................22
3.5.4Sealant.................................................................................................................22
4Start-Up ...........................................................................................................................23
4.1Initial Checkout........................................................................................................23
4.2Configuring the Dispenser Software........................................................................24
4.2.1General................................................................................................................24
4.2.2Making Configuration Changes...........................................................................24
4.2.3Configuration Start-Up (Units without Price Displays).........................................25
4.2.4Configuration Start-Up (Units with Price Displays)..............................................26
4.2.5Set the Pulse Output Resolution (Pulse output interface option only) ................30
4.3Operating Units w/ Pulse Output I/F Option Before Control System is Operational32
4.4Bleeding Product Lines............................................................................................33
4.5Initial Delivery ..........................................................................................................33
4.6Meter Check (Calibration)........................................................................................34
4.6.1General................................................................................................................34
4.6.2Accuracy Verification...........................................................................................34
4.6.3Calibration Procedure..........................................................................................35
4.7Voltage Test.............................................................................................................36
4.8Complete Installation...............................................................................................36
4.9Complete Warranty Registration .............................................................................36
5Operation.........................................................................................................................37
5.1Safety Items You Should Know...............................................................................37
5.1.1Portable Tanks and Containers...........................................................................38

2 Dover Fueling Solutions W2940305 Rev 07 8/2019
5.1.2Health Note..........................................................................................................38
5.2Dispenser Operation................................................................................................38
5.3Displays...................................................................................................................39
5.4Electromechanical Totalizer ....................................................................................40
5.5Restarting After Power Failure or Shutdown...........................................................40
5.6Cycling Power to Clear Faults.................................................................................40
5.7Dispenser Statistics & Diagnostics..........................................................................41
5.7.1General................................................................................................................41
5.7.2Password Protection............................................................................................42
5.7.3Changing Your Passwords..................................................................................42
5.7.4Viewing the Electronic Totalizers.........................................................................44
6Maintenance....................................................................................................................47
6.1Preventive Maintenance..........................................................................................47
6.2Strainer/Filter – Gasoline & Diesel Dispensers.......................................................47
6.3Strainer/Filter – DEF Dispensers.............................................................................48
6.4Cleaning and Corrosion Prevention Instructions.....................................................48
6.5Meter Maintenance Issue ........................................................................................48
6.6How to Get Service on Your Pump..........................................................................48
Appendix A: Dimensions & Base Layouts..........................................................................49
Appendix B: Electrical Ratings & Wiring Diagram.............................................................57
B.1Electrical Ratings.....................................................................................................57
B.2Wiring Diagram: All Models ....................................................................................58
Appendix C: Pulse Output Interface....................................................................................58
C.1Pulse Output Interface Wiring Diagram...................................................................59
C.2Pulse Output Interface Board Layout ......................................................................60
Appendix C: Dispenser Current Loop & T7 Payment Terminal Connections................61
C.1 General..........................................................................................................................61
C.2 General Notes...............................................................................................................61
C.3 Site Layouts...................................................................................................................62
Site Layout A....................................................................................................................62
Site Layout B....................................................................................................................63
Site Layout C....................................................................................................................64
Site Layout D....................................................................................................................65
Site Layout E....................................................................................................................66
C.4Point-to-Point Dispenser to Fusion Forecourt Controller Wiring.............................67
C.5Point-to-Point Dispenser to Fusion UDB Replacement Wiring ...............................68
C.6Point-to-Point Dispenser to Data Distribution Cabinet Wiring.................................69
C.7Wiring Using One Data Distribution Cabinet (Up to 16 dispensers)........................70
C.8Wiring Using Two Data Distribution Cabinets (Up to 24 dispensers)......................71
C.9Payment Terminal RS485 Wiring............................................................................72
C.10Ethernet Connection................................................................................................73
Appendix E: Dispenser Software Configuration, Statistics & Diagnostics.....................75
E.1General....................................................................................................................75
E.2Entering Functions and Statistics............................................................................75
E.3IRC Commands.......................................................................................................76
E.4Changing Subfunction Values.................................................................................77
E.5Resetting Totals.......................................................................................................77
E.6Exiting Functions .....................................................................................................78
E.7Exiting Statistics.......................................................................................................78
E.8Quick Exit from Functions or Statistics....................................................................78
E.9Pulse Output Interface Option Settings...................................................................79
E.10List of Statistics........................................................................................................80
E.11Meter Number Assignments....................................................................................81
E.12Configuration Functions...........................................................................................82

W2940305 Rev 07 8/2019 Dover Fueling Solutions 3
Appendix F: Local Authorize / Standalone Operation.......................................................95
F.1General....................................................................................................................95
F.2Place Dispenser into Standalone Operation from Pulse Output.............................96
F.3Place Dispenser into Standalone Operation from Serial Mode...............................97
Appendix G: Weights & Measures Mode ............................................................................99
G.1General Information.................................................................................................99
G.2Upper Level Menu ...................................................................................................99
G.3Unit of Measure Menu...........................................................................................101
G.4Pulse Output Menu................................................................................................102
G.5Automatic Temperature Compensation (ATC) Menu............................................103
G.6Product Pressurization Menu ................................................................................104
G.7Program Change Menu .........................................................................................105
G.8Meter Totals...........................................................................................................106
G.9Metrological Settings Menu...................................................................................107
G.10Metrological Configuration Parameter Definitions.................................................108
G.11Automatic Temperature Compensation (ATC) Testing.........................................109
Appendix H: iX Fleet Fuel Control System .......................................................................111
H.1General..................................................................................................................111
H.2Power Requirements.............................................................................................111
H.3Ethernet Connection..............................................................................................111
H.4iX Fleet Board Setup .............................................................................................115
Appendix J: Bezel Security ................................................................................................117
J.1General..................................................................................................................117
J.2Secure Access Modes...........................................................................................117
J.2.1One-Shot Control...............................................................................................117
J.2.2Local Passcode Control.....................................................................................117
J.3Servterm Loading ..................................................................................................117
J.4Function Settings...................................................................................................117
J.5Enabling Security Mode.........................................................................................118
J.6Clearing a Breach..................................................................................................119
J.6.1One-Shot Control Breach Clear.........................................................................119
J.6.2Localized Control Breach Clear.........................................................................119
J.7Maintenance/Service.............................................................................................120
J.7.1Maintenance with One-Shot Control..................................................................120
J.7.2Maintenance with Localized Control..................................................................120
J.8Testing the Switches .............................................................................................121
Appendix K: T7 Receipt Printer..........................................................................................123
K.1General..................................................................................................................123
K.2Description of Indicator Lights & Control Button....................................................124
K.3Replace Paper.......................................................................................................125
K.4Paper Jams............................................................................................................128
Appendix L: Error Codes....................................................................................................131
Appendix M: Internal Wiring & Connections....................................................................135
M.1Internal Wiring........................................................................................................135
M.2Internal Wiring – iXFleet & Connectors .................................................................136
Appendix N: Warranty Registration...................................................................................137
N.1Warranty Registration Instructions ........................................................................137

4 Dover Fueling Solutions W2940305 Rev 07 8/2019
This page intentionally left blank

W2940305 Rev 07 8/2019 Dover Fueling Solutions 5
1 Introduction
1.1 Dispensers Covered
This manual describes the installation and operation of Wayne SelectTM S1 Compact
Electronic Dispensers. Select S1 Compact Electronic dispensers are designated by the
3/G7100 model number series. Model descriptions are shown in Section 1.2. The model
number suffix designations are defined in Section 1.3. Technical information can be found in
Section 1.4.
Select S1 Compact Electronic dispensers use the iGEMTM computer powered by DFS to
control the iMeterTM fuel meter powered by DFS and Intelligent Pulser (WIP). There is one
iGEM computer and one iMeter fuel meter module in each dispenser. There is one WIP
pulser for each iMeter fuel meter.
The iGEM computer uses software that is uploaded by a laptop. Computer function settings
necessary for dispenser startup are included in this manual. If additional information on
function settings and statistics is required, refer to the iGEM Computer Service manual, part
number 920525. Note: When making updates to the iGEM computer using a laptop, ensure
that it is done in an unclassified location.
Select S1 Compact Electronic dispensers may be installed and operated as a stand-alone
unit, may be controlled through an internal control system, or may be controlled by a third
party fuel control system. This manual provides installation and operation information for
these dispensers operating as stand-alone units and with an internal control system. General
information is provided for connecting to third party fuel control systems. It is also necessary
to consult the applicable third party fuel control system documentation for installation and
operation information and any necessary safeguards and warnings.
Trouble with the installation of this product should be referred to your DFS ASO. An ASO
with a technician number can receive assistance by calling the DFS Support Center at:
1-800-926-3737
Customers, Installers or Distributors who are not an ASO, needing help with the operation or
installation of this product, should contact the DFS Support Center at:
1-800-289-2963 OR [email protected]
NOTE: Terminology Used in This Manual
Dispenser(s): Generic term used to refer to any model in the Select dispenser
series.
Remote Dispenser(s): Models utilizing a submersible pump in the tank to provide fuel
to the dispenser.
Enhanced Capacity: Remote dispenser models with one iMeter fuel meter measuring
chamber per hose.
Super-High Capacity (SHC): Remote dispenser models with two iMeter fuel meter measuring
chambers per hose for increased flow performance.

6 Dover Fueling Solutions W2940305 Rev 07 8/2019
Single-Sided Display, Lane-Oriented
3/G7107D/R - Enhanced Capacity
3/G7127D/R - Super High Capacity
E3/G7107D/R - E85 Enhanced Capacity
D3/G7107D/R - DEF Enhanced Capacity
Dual-Sided Display, Island-Oriented
D3/G7101D - DEF Enhanced Capacity
Hose Outlet
Display
Nozzle Boot
Inlet
Meter, Filter
& Valve
Note:
Adding iX Fleet or T7 option makes unit
taller but has no impact on basic model
information.
1.2 Model Description

W2940305 Rev 07 8/2019 Dover Fueling Solutions 7
3iGEM
E3 iGEM&E85
D3 iGEM&DEF
/
A
GGlobal
B7SelectElectronicFleet
CModelStyle 1 CompactCabinet
0EnhancedCapacity
2Super‐HighCapacity
1OneHose,OneProduct,Island‐OrientedNozzle
7OneHose,OneProduct,Lane‐OrientedNozzle
F HydraulicSystem D RemoteDispenser
/
AdditionalMode l Designators R Single‐SidedLane‐OrientedMode l
2EnhancedCapacity(1"Discharge)
G InternalFilter
KHoseHanger
UiMeter2
1PriceDisplays
9E25andB20Compatible
CAutomaticTemperatureCompensation
HPulseOutputInterface
NEthernetSwitch
XxFlometer(usedforE85hydraulictrees)
Z240VACOperation
/
D1 iXFleet,RFTags,1‐Sided
D3 iXFleet,MagCards,1‐Sided
D5 iXFleet,Keypad,1‐Sided
D7 iXFleet,HID‐ProxCards,1‐Sided
D9 iXFleet,HID‐IndalaCards,1‐Sided
JHoseMast
LHeater
RPumpDirectDriveRelay
SAllStainlessSteel
S1 StainlessSidePanels,Top,BaseHalvesw/PaintedDoors
S2 StainlessSteelDoorsOnly
T1 T7Baseassembly
T2 T7Contactless
T3 T7Scanner
T4 T7Contactless&Scanner
V4 BezelSecurity(ixFleet&T7optiononly)
Prefix X
Electronic&Hydraulic
Configuration
Main Body
ModelSeries
DFlowRateCapacity
EHoses,Products,Nozzle
Configurations
Second
Suffix Y Options
First
Suffix Z
Options
Standard
1.3 Model Designation Format
Prefix / Main Body / First Suffix / Second Suffix
X / ABCDEF / ZZZZZZZZ / YYYYYYYYYY

8 Dover Fueling Solutions W2940305 Rev 07 8/2019
1.4 Technical Information
Application: For dispensing low viscosity petroleum fuels - diesel, including biodiesel blends
up to 20%; kerosene; gasoline, including standard oxygenated blends; AvGas;
and Jet Fuel (check with fuel supplier for any metal flow path restrictions for
AvGas and Jet Fuel, you must install the appropriate filters, water separators,
etc. needed for the fuel type being used.) - from aboveground or underground
storage tanks in applications. Dispensers with the “E” Prefix utilize nickel-
plating, hard anodizing, stainless steel, special elastomers and a special fuel
filter. While standard dispensers are Listed to handle Ethanol products up to
an E10 blend, “E” prefix dispensers are Listed for use with products up to E85.
Dispensers with a first suffix “9” are equipped to handle up to E25 and B20
products. Dispensers with a “D” prefix are rated for use with DEF. Use
hanging hardware rated for the available fuel type dispensed. Note: Dispenser
not Listed by a nationally recognized testing laboratory (NRTL) for Biodiesel (over
20%), AvGas, or Jet Fuel.
Performance: Enhanced Capacity: Up to 22 GPM (83 LPM) maximum test rate at discharge
outlet.
Super-High Capacity (SHC): Up to 30 GPM (114 LPM) maximum test rate at
discharge outlet.
Important: Actual flow rates will depend upon the installation conditions, product
dispensed, dispenser accessories, and for remote dispensers, the size of the
pump.
Electronic Head: iGEM electronics platform. Controls dispenser operation. Provides user
operating messages, transaction limit controls, error monitoring, enhanced
diagnostics. Allows software uploads/downloads via a PC. Infrared remote
control allows configuring settings, reading totalizers, and accessing diagnostic
tools. 120/240VAC 50/60 Hz operation.
Liquid Crystal
Displays: Backlit displays, 1.5” (3.8 cm) seven-digit upper display, 1” (2.5 cm) six-digit middle display, and ½” (1.3 cm) four-character lower display. Display function
varies according to options. One display assembly for lane-oriented models.
Two display assemblies for island-oriented model. Configurable 0-4 digits to
right of decimal. Programmable gallons or liters. In event of power loss, remain
visible for approximately 15 minutes.
Totalizers: 7-digit electromechanical non-resettable totalizer per product. One non-
resettable and one resettable electronic 6-digit totalizer. Electronic totalizers
display on volume display by using infrared remote control.
Light: LED light in electronic head provides lighting of bezel.
Fuel Control
System Interfaces: Wayne dispenser US Current Loop protocol. Optional pulse output interface.
Meter: Enhanced Capacity and Super-High Capacity Models: 2-piston, positive
displacement iMeter fuel meter with integral intelligent pulser. E85 models
utilize XfloTM fuel meter powered by DFS. Electronic calibration.
Filter: Enhanced Capacity Models comes with 10 micron internal filter. Super-High
Capacity comes with 30-micron hydrosorb internal filter. DEF units come
standard with a strainer and cap. A 5 micron filter kit is optional.
(Note: User should make sure the filter element meets the application and replace with
the appropriate element as necessary.)
Flow Control Valve: Enhanced Capacity and Super-High Capacity Models: Proportional 7/8”
(2.2cm) 24V valve. Super-High Capacity Models use 2 valves.
Inlet: All models: 1 ½” female NPT.
Outlet: All models: 1” female NPT. ¾” (1.9cm) reducing bushing supplied for ¾” hose
assemblies on non-SHC models.
Cabinet: Galvanealed metal. Removable front and rear doors. Optional SS.
Finish: Silver powder coat finish with blue powder coated doors. Optional black, green,
red, silver, white, or yellow powder-coated doors.

W2940305 Rev 07 8/2019 Dover Fueling Solutions 9
Nozzle Boot and
Hook: Fits standard U.L. interchangeable automatic nozzles. Balance vapor recovery nozzles: Emco Wheaton A4015 short spout and Husky
V short spout. DEF nozzle
Options: Pulse output interface, price display, register heater, 240VAC 50/60 HZ
operation of the electronic head, stainless steel, iX Fleet, T7, Pump Direct Drive
Relay.
Zone Rating Rated for location in a Class I, Division 2 hazardous location.
Approvals: Underwriter’s Laboratories UL Listed: UL File MH1821
CARB: G-70-52-AM – Balanced Vapor Recovery
National Conference of W & M: C of C #99-122
FCC certified Note: Dispensers that are UL Certified bear the UL Listing mark.
Dispensers listed for both the US and Canadian market carry a cULus label.

10 Dover Fueling Solutions W2940305 Rev 07 8/2019
This page intentionally left blank

W2940305 Rev 07 8/2019 Dover Fueling Solutions 11
2 Site Design & Preparation
2.1 Local, State, and Federal Codes
Select S1 Compact Electronic dispensers are only part of a fuel dispensing system. A fuel
dispensing system typically comprises equipment and safety devices from a variety of
manufacturers. It is the responsibility of the dispenser owner to have a qualified installer
ensure that all of the necessary equipment and accessories are included to meet the
requirements of the application and all tanks (both underground and aboveground), piping
and fittings, check valves, leak detection and corrosion protection devices, wiring, venting
systems, filtration devices, safety valves, submersible pumps, etc. are installed in accordance
with the manufacturer’s instructions and in compliance with local and regional building codes
and requirements pertaining to private fueling facilities (or other locations where the
dispenser may be installed).
These requirements may include references to the National Electrical Code (NFPA 70); Code
for Motor Fuel Dispensing Facilities and Repair Garages (NFPA 30A); Flammable and
Combustible Liquids Code (NFPA 30); Code of Federal Regulations, Title 40, Section 280 (40
CFR 280); United States Environmental Protection Agency (U.S. EPA) Technical Regulations
of 9-23-88 and U.S. EPA Financial Responsibility Regulations of 10-26-1988.
Where local requirements do not specify applicable codes, Wayne recommends using the
codes listed above. These codes are comprehensive and detailed, often requiring
interpretation to cover unusual situations, and, therefore, the associated handbooks (where
applicable) should also be consulted. (The handbooks are also available from the same
sources.)
Due to the variety of locations encountered, further information on installation cannot
be dealt with in this document except as the codes relate directly to the installation of
the dispenser. Therefore, it is strongly recommended that a qualified engineer or
contractor familiar with local regulations and practices be consulted before starting
installation.
Pertinent information and codes are available from the following sources:
Association for Composite Tanks (ACT)
North State Street
Suite 720
Chicago, IL 60602
[phone] (for information requests)
American Petroleum Institute (API)
1220 L Street, N.W.
Washington, DC 20005
[phone]
Fiberglass Petroleum Tank and Pipe Institute
One SeaGate, Suite 1001
Toledo, OH 43604
[phone]
National Assoc. Corrosion Engineers
(NACE)
Box 218340
Houston, TX 77218
[phone]
National Fire Protection Association (NFPA)
One Batterymarch Park
Quincy, MA 02269-9101
[phone]
National Leak Prevention Association
(NLPA)
685 Fields Ertel Road
Cincinnati, OH 45241
[phone] or 1-[phone]
Petroleum Equipment Institute (PEI)
Box 2380
Tulsa, OK 74101
[phone]
Steel Tank Institute
P. O. Box 4020
Northbrook, IL 60065
[phone]
(continued on next page)

12 Dover Fueling Solutions W2940305 Rev 07 8/2019
Underwriters Laboratories Inc.
333 Pfingsten Road
Northbrook, IL 60062
[phone]
Underwriters Laboratories of Canada
7 Crouse Road
Scarsborough, Ontario, Canada N1R3A9
[phone]
United States Environmental Protection
Agency
Office of Underground Storage Tanks
401 M St., SW (05-400WF)
Washington, DC 20640
[phone] (Underground Storage Tanks)
U. S. Department of Labor,
Occupational Safety and Health Administration
(OSHA) Washington, DC 20402
• Call OSHA at [phone] to determine
specific needs; OSHA rules are covered by Title
29 of the Code of Federal Regulations (29 CFR.)
• Order OSHA publications from:
Government Printing Office (GPO)
Washington, DC 22304
[phone]
Western Fire Chiefs Association
5360 South Workman Mill Road
Whittier, CA 90601
[phone]
NOTE: Other regulatory codes may apply. Consult your local and regional code requirements
to determine which codes are applicable for your location.
2.2 Safety Precautions
NFPA 30A states that:
“When maintenance to Class I dispensing devices becomes necessary and such
maintenance is capable of causing the accidental release or ignition of liquid, the following
precautions shall be taken before such maintenance is begun:
Only persons knowledgeable in performing the required maintenance shall perform the
work.
All electrical power to the dispensing devices, to the pump serving the dispensing
devices, and to all of associated control circuits shall be shut off at the main electrical
disconnect panel.
The emergency shutoff valve at the dispenser, if installed, shall be closed.
All vehicular traffic and unauthorized persons shall be prevented from coming within 20 ft.
(6 m) of the dispensing device.”1
Electric shock hazard! More than one disconnect switch may be required to de-energize the
pump for maintenance and servicing. Use a voltmeter to make sure ALL circuits in the pump
are de-energized. Failure to do so may result in serious injury.
Lockout/Tagout requirements of the U. S. Dept. of Labor, Occupational Safety and Health
Administration (OSHA) may also apply. Refer to Title 29, Part 1910 of the Code of Federal
Regulations (29CFR1910), Control of Hazardous Energy Source (Lockout/Tagout).
1. Reprinted with permission from NFPA 30A, Code for Motor Fuel Dispensing Facilities and Repair
Garages 2000 Edition, Copyright ©2000, National Fire Protection Association, Quincy MA 02269.
This reprinted material is not the complete and official position of the National Fire Protection
Association on the referenced subject, which is represented only by the standard in its entirety.
WARNING

W2940305 Rev 07 8/2019 Dover Fueling Solutions 13
2.3 Ethanol and Bio-Diesel Installations
All Wayne dispensers (except DEF models) are rated and Listed for use with Ethanol blends
up to and including E10. For blends that exceed E10, the dispenser must be supplied with a
first suffix option of “9” for blends up to E25 and B20 or an “E” prefix option for blends up to
E85. “E” prefix dispensers are Listed for use up to and including E85 blends. The “9” suffix
is available for all enhanced capacity remote dispensers. The “E” prefix is only available on
remote dispenser model E3/G7107D/R. When considering an installation, all fluid handling
components must be rated for the type of fuel that will be dispensed. Piping connections for
above E10 must use UL Classified Saf-T-Lok Teflon pipe sealant.
Some alternative fuels and additives can degrade the dispenser performance and integrity if the
dispenser is not designed for that product. In addition, converting between fuel types
(especially between an alternative fuel to a standard fuel) can degrade the dispenser
performance and integrity. Before changing fuel types, always make sure that the dispenser is
designed for use with the new product. In addition, the dispenser should be closely monitored
for any sign of degradation or leaks after the conversion. This monitoring should take place in
the days, weeks and even a month after the conversion takes place. Leaks can result related to
the conversion which can create an environmental hazard.
DEF models should only dispense DEF.
2.4 DEF Installations
While DEF is not a combustible liquid, the electrical requirements as well as the proximity of
the DEF dispenser to dispensers that handle combustible liquids could dictate that various
requirements of NFPA codes be followed for a hazardous area. Wayne recommends that
DEF dispensers be installed using the same techniques and requirements that would be
applied to a dispenser dispensing flammable liquids. NPT piping connections for DEF should
use Loctite 567 sealant and Loctite accelerator 7649. Use the accelerator on both sets of
threads and allow it to dry before applying the sealant. Put the sealant on the male threads
only, being careful not to get excess inside the pipe or fittings. Do not use Teflon tape. Do
not apply sealant or Teflon tape to BSP fittings. DEF dispensers using internal DEF filter kit
require additional clearance under the base of the dispenser for the DEF filter. See the “Base
Layout” for details.
DEF models should only dispense DEF.
2.5 Existing Installations
If the dispenser is to be installed on an existing installation, it is still the responsibility of the
installer to read and follow this installation manual in its entirety and make sure the existing
installation meets the requirements and satisfies local, state, and federal codes.
WARNING
WARNING

14 Dover Fueling Solutions W2940305 Rev 07 8/2019
2.6 Island Construction, Dispenser Anchoring, Piping, and Bollards
This dispenser is designed to be shelf-mounted. The base of the dispenser contains four
bolt slots that measure 7/16” x 1-7/16” for anchoring the dispenser to the shelf. Allow for
the proper dispenser containment box if required by local, state, or federal regulations.
Reference Appendix A, Dimensions & Base Layouts, for dispenser and shelf dimensions.
Vertical supply risers and electrical conduits must be located per the Installation Drawing
for the appropriate model. Proper height must be maintained to avoid undue stress on the
dispenser. See Section 3.3 for wiring and conduit requirements. Reference Appendix B
for Wiring Diagrams.
Supply piping should be selected and installed based on the product dispensed and in
accordance with local, state, and federal regulations. The piping manufacturer’s
instructions should be followed for the proper trenching, connection, sealing, corrosion
prevention, pressure relief, leak detection, containment, and testing.
DEF dispensers using the internal DEF filter kit require additional clearance under the
base of the dispenser for the DEF filter. See the base layout for details
This dispenser should only be mounted to a UL Listed tank that already has a suitable
means to mount the dispenser to the tank. No modification to the tank is allowed for the
installation of the dispenser.
Bollards must be installed around the dispenser to prevent
vehicles from coming into contact with the dispenser.
Wayne dispensers are specified to work at a maximum normal operating pressure of 50 PSI.
Normal operation can create pressure spikes which may exceed 50 PSI. These normal
spikes are easily handled by the dispenser. Wayne dispensers are designed and tested to
withstand pressures up to 250 PSI, for short durations, without rupture or permanent
distortion. Certain extreme conditions, such as installations with above-ground tanks and
very long runs of pipe, can create pressure spikes that may damage the dispenser and its
accessories. If these conditions exist, measures must be taken to reduce or dampen these
pressure spikes to prevent damage to the equipment.
To maximize flow, position the remote dispenser and tank as close together as possible
and minimize the number of turns in the piping. Consult the submersible pump
manufacturer for the proper sizing of the submersible pump, any necessary leak
detection equipment, and installation details.
Product piping must avoid the creation of vapor in the lines and deliver a minimum
pressure of 25 psi at the remote dispenser inlet when all dispensers connected to the
same submersible pump are operating. The dispenser’s maximum operating pressure is
50 psi.
A listed, rigidly anchored emergency shutoff valve must be installed, in accordance with the
manufacturer’s instructions. Failure to install the proper emergency shutoff valve will
present a hazardous condition that could result in serious injury and/or environmental
damage.
NOTE: On E85 dispenser models, use shear valve part number 10P-0152E85 manufactured
by OPW.
“Listed” means published on a list by a nationally recognized testing laboratory (NRTL) which is
responsible for product evaluation and is acceptable to the authority having jurisdiction. Underwriters
Laboratories, Inc. is one example of a Nationally Recognized Testing Laboratory. For more information
on NRTL’s, see Title 29, Parts 1907 and 1910 of the Code of Federal Regulations, Safety Testing or
Certification of Certain Workplace Equipment and Materials.
WARNING
WARNING
WARNING

W2940305 Rev 07 8/2019 Dover Fueling Solutions 15
Solenoid Valve
(Anti-Siphon)
Gate Valve
(Block Valve)
Submersible
Pump
Expansion
Relief Valve
1-1/2" Emergency
Double-Poppet
Shear Valve
Electrical
Conduit
Shelf
Bracket
(If Solenoid Valve
has pressure relief,
separate relief
valve is not needed.)
1-1/2" Supply
Line
Cutaway
View
Select S1
Conduit
Seal-off
Bollards
3 Installation
3.1 Equipment Inspection
Examine the shipment immediately upon arrival to make certain there has been no
damage or loss in transit. Make sure that all the component parts are accounted for,
including keys and any optional equipment.
Check and save the Packing Slip, Bill of Lading, Invoice, and all other documents
included in the shipment.
Damaged or lost equipment must be reported to the carrier. Any damage or loss that may
occur in transit is not covered under the DFS Warranty.
3.2 Typical Site Layout

16 Dover Fueling Solutions W2940305 Rev 07 8/2019
3.3 Electrical Wiring
3.3.1 General
DFS recommends employing a qualified licensed electrician for all wiring.
A primary requirement in dispenser installation wiring is to provide a means for
disconnecting all power connections, including the neutral, as well as the communication
lines to the dispensers for a safe shutdown and servicing of the units. All wiring to the
dispenser must be broken for the Emergency Electrical Disconnect.
A hazardous liquid is being handled, so it is extremely important to ensure that all wiring
and conduit are in accordance with all local, state and federal regulations, including, but
not limited to, the National Electrical Code (NFPA 70), NFPA 30, and NFPA 30A.
NOTE: NFPA 70 requires that all electrical connections to the dispenser be made with
threaded, rigid conduit and properly sealed conductors. All dispensers and electrical
connection boxes must be grounded per NFPA 70.
3.3.2 Electrical Termination Descriptions - All Dispensers
The chart to the right describes the
standard electrical inputs and outputs
utilized in the Wayne Select S1 Series
and can provide assistance in
interpreting the Wiring Diagrams in
Appendix B. These connections are
found on the standard terminal block
located in the head of the dispenser.
3.3.2.1 Control Power (Hot)
The control power (hot) is a 120VAC [international (int’l) - 240VAC] input for supplying power
to the electronic register. The control power must have a dedicated breaker and must remain
on all the time. For sites with multiple dispensers, if it is not practical to use separate
breakers for each dispenser, the number of dispensers that can be included on one breaker
is determined by analyzing the power requirements of each dispenser to determine the total
load required for the group of dispensers. The breaker and wire must be sized accordingly
for that load and the length of the wire run.
NOTE: When the dispenser is connected to a fuel control and/or tank monitoring system, they
should be powered from the same circuit breaker panel so that they share a common
neutral.
3.3.2.2 Control Power (Neutral)
The control power (neutral) is an AC return line from the electronic register to the breaker
panel.
3.3.2.3 Ground
A good ground ensures proper operation of the equipment and provides the necessary safety
factors. A ground wire must be connected between the unit’s ground connection on the
terminal strip and the main electrical service panel. One (1) earth ground connection is
required per unit. Make sure that a ground rod is properly installed and wired to the ground
bus strip of the main electrical service panel in accordance with the National Electrical Code.
Do not rely on electrical conduits as the grounding connection.
TB# Signal Function
1 AC Hot Control Power (Hot)
2 Pump Hot In Pump DirectDrive Relay(Optional)
3 Subm Subm RelayControl X
4 Pump Hot Out Pump DirectDrive Relay(Optional)
5N/A
6N/A
7 AC Neut AC Neutral for electronics
8 Gnd Ground for dispenser
9 Current Loop + Dispenser comm +
10 Current Loop - Dispenser comm -
11 CAT+ Paymentterminal +
12 CAT- Payment terminal -
