DPVIDEO DZ1109 User manual

Before operating the monitor, please read this manual thoroughly
and retain it for future reference .
Please contact an authorized installer for professional installation.
User’s Manual
DZ1109

Specifications
Power DC12V
Current Consumption 25W Max
Screen Format 16:9
Resolution
1280*RGB*768 pixel
System NTSC/PAL
Video Input 1EA
Video Output
Audio Input
Audio Output
Disc Format
1EA
2EA
2EA
MP3/VCD/DVD/CD/CD-R
CD-RW/DVD-R/DVD-RW
IR Transmitter Yes
FM Transmitter Yes
Yes
Yes
Dome Light
Remote Control
Dimensions(mm)
Yes
Yes
(W)326*(D)275*(H)60
17
Contents
Caution.......................................
Check Point....................................
Name and Function of Each Part
Unit...........................................
Remote Control.................................
Remote Control.................................
Picture Control
Picture Selections...............................
Playing a Disc
Play DVD Player.................................
Basic Operation
FM Channel.....................................
DVD Setup
System Setting..................................
Language Setting...............................
DVD Function
Playback Function...............................
Advanced Function...............................
USB/SD card Function..........................
Installation.....................................
Connection Diagram.............................
Disc Information................................
Game Function
Cautions of Use................................
Trouble Shooting...............................
Specifications..................................
26
Trouble Shooting ..........................27
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 28
.................................
1
2
3
4
5
6
6
6
7
8-9
10-11
12
12
13
13
14
14
15
16
17
SD CARD PLAYER
USB PLAYER

Caution
Be careful with any liquids in your car. If you or your child spills any liquid on
these products, park your vehicle at the roadside, turn the key off to disconnect
the power and then wipe the products with a towel.Do not operate the equipment
until all liquids have evaporated or you have had the monitor inspected by a
qualified Technician. Severe harm or death can occur!
Do not mount the product where it will obstruct the deployment of the airbag or
in an area where it would affect the vehicular control. Also be careful to avoid
mounting the product where it can become hazardous during sudden stops
or in the event of an accident.
Make sure to keep products away from heater ducts or vents and out of direct
sunlight. Do not mount forward of the driver's shoulders.
WARNING
The two kinds of alarm symbols are as folIows:
Please read and observe all warnings and instructions in this owner's manual
and those marked on the unit.Retain this booklet for future reference.
The driver should never operate these products while the vehicle is in motion!
Be careful not to overload your cigarette lighter plug by adding more than one
device at a time.
Installation of all TV monitors must be out of the driver's field of vision!
Do not try and service these products yourself, seek only a qualified service center
or factory service center.
Just use a wet cloth to clean the screen, only use purified water on the cloth,
wring out all excess water before wiping the screen. Do not use any
cleaners or chemicals to clean the screen. In most cases a dry cloth will do!
Be careful not to drop or apply undue pressure to the front panel of your video
monitor. If the screen cracks due to misuse your warranty will be void!
1
WARNING
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of
“dangerous voltage"within the product's enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to
persons.
CAUTION
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing ) instructions in the literature
accompanying the product.
Trouble Shooting
Check point
When a disc is brought from a cold environment to a warm one,there may be
moisture on the disc,or condensation will appear on the pickup lens.It will
affect the disc playback.
1.Remove the disc from the DVD player.
2.Turn on the power and leave it on for an hour to vaporize the condensation.
3.You can now operate the DVD player without any problem.
The remote control doesn t work
properly
'
"DISK ERROR" is displayed on
the screen
Distorted sound
No color
The playback picture is poor
Stopped picture
No picture
No power
Remove any obstacles between the
remote control unit and the remote control
sensor.Operate the remote control
at a shorter distance.
Set the power button to OFF and then
back to ON alternatively,Turn off the
power,disconnect the power plug,and
then reconnect it.
Adjust the video system by pressing
the TV system button.(PAL,NTSC)
The color system of this unit does
not match the color system of the monitor.
Check the color system of the unit.
Clean the disc
Make sure that the equipment is
connected properly.Check and see if
the connected monitor is turned on
Check and see if the power cable
is connected properly.
Check and see if the video cable is
connected, if the monitor is turned on.
TROUBLE ACTION
16

1 The operating temperature of this product is limited to -4 F + 176 F.
Your vehicle can reach temperatures up to 212 F in the summertime.
2 If your vehicle is extremely hot or cold you must allow time for your air
conditioner or heater to cool or heat the vehicle until operating
temperatures have returned to the normal operating ranges.
3 Optimum picture quality will be achieved when viewed from directly in front
of the monitor ( +/-30 degrees).
4 Do not open the housing and attempt to make any repair yourself. Refer
servicing to qualified personnel.
5 DVD Players use an invisible laser beam which can cause hazardous radiation
exposure. Be sure to operate the unit correctly as instructed.
6 Do not cut the car power supply off while a disc is playing. It can cause
damage to the DVD Player.
°~°
°
2
Quality installations are performed by qualified and certified installers.
Watching the monitor for an extended period of time without the engine running
may deplete the vehicle's battery charge.
This product is designed for operation with a 12 Volt DC, negative ground vehicle.
It is not suitable for operation under other conditions or voltages.
Caution
Check Point
Cautions on Use
Handing
. Do not use damaged ( cracked or warped ) discs.
. Do not scratch the signal surface or let it become
dirty.
. Do not stick a label or a glue-based note on
either side of the disc.
. Do not use discs that have glue or a damaged
label with exposed adhesive residue, it might
result in damage to your DVD player.
Do not put discs in the sunshine.
Park your car in the shade
Storing discs
Always put discs in their place and store
them vertically.
Do not put discs in a hot or humid place,
places exposed to direct sunlight and places
in which the temperature is extremely low or
high.
. Read any cautions included with the disc
carefully
Cleaning discs
Fingerprints or dust on discs may
reduce sound or picture quality.
remove them by wiping the disc with
a soft cloth from the center toward the
edges gently.
For tough dirt, wipe softly with a wet cloth and then
with a dry one.
Do not use any type of solvent such as thinner,
benzene.
Do not use antistatic spray.
Irregularly shaped dies
Irregularly shaped dics( heart-shaped discs,
hexagonal discs, etc. ) cannot be played on
this player.
May cause damage to the player.
Only use round discs.
15
When holding with both hands

3
Name and function of each part
UNIT
14
Copyright protection.
This product incorporates copyright protection technology that is protected by methods
claims of certain U.S. patents and other intellectual property rights owned by the
Macrovision Corporation and other rights. Owner's use of this copyright protection
technology must be authorized by the Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise authorized by the
Macrovision Corportation.
Disc Information
DVD features
DVD discs provide high-resolution images with high- quality sound and surround
sound effects. This DVD player can play not only DVD discs of various versions,
but also S-VCD ,VCD , audio CD and MP3 discs.
Each disc only plays the information saved in it, and some functions cannot be
utilized.
Discs that cannot be played
DVD-RW, DVD-REM, CD-ROM, CD-EXTRA discs cannot be played on this unit. Also,
a CD or a CD-RW which was recorded on special software cannot be played.
Region code
Your DVD player is designed and manufactured to region management information
that is recorded on a DVD disc. The region number of this DVD Player is 1. This DVD
player plays free code also.
Caution
Wipe softly with a wet cloth and then with a dry one.
Before playback, wipe the disc outward from the center with a clean cloth.
Do not use any type of solvent such as thinner, benzene, coommercially - available
cleaners or antistatic spray.
To avoid damaging your DVD player, don't use a scratched disc.
How to handle the disc
Don't touch the shiny side of the disc (the side with the embedded information).
Don't stick a label or a glue - based note on either side of the disc. Don't use discs
that have glue or a damaged gluey label- it might result in damage to your DVD player,
Don't put discs in the sunshine. Park your car in the shade.
1.
3.Power button
5.Menu button
7.AV/DVD button
9.SD card/USB button
11.Monitor release button
13.NEXT button
Remote control 2.Power LED
4.Down button
6.Up button
8.IR transmitter/Dome light
10.Play/Pause button
12.PREV button
THE BACK PANEL
14. 15.Eject 16.
17.USB port 18.SD card slot
Dome light switch Disc case cover
1234567
88
910
11
12 13
14
15
16
17
18
GAME FUNCTION
The player is equipped with a game function, it will let you enjoy the
wonderful game in your spare time.
playing the game disc
1.Load the game disc in the loading cabin, the game main menu
will be displayed in seconds.
2.Press / / / on the remote control or game controller to select the games
then press ENTER on the remote control or press START on the game controller to
enter the game.
Operation of
In game mode,the remote control will be effected as follows:
1. CURSOR / , / move button
In the game mode, use these buttons to control the direction of unit.
2.ENTER button
3.RETURN
.
Notice: In order to operate the game well, please use the wireless game controller.
You can download the games onto a USB or memory card from the internet.
Download the Native Games from this website: http://www.native32.com.
You may apply more kinds of games.
To confirm the choice, to confirm to use the function of the item in the game.
Return to the top or return to the directory menu

Name and function of each part
Remote Control Unit
4
Connection Diagram
Installation(Professional installation recommended)
1.
contents.Disassemble the
metal support bracket from
the unit as shown in the
illustration,by unscrewing
the six screws on the unit
body.
Unpack and check the
2.Tighten the metal support bracket
to the ceilling support beam(s),
using the supplied screws.Take
extra care to not penetrate the
roof of your car.
3.Connect the wiring harness,
according to the diagram under
"Connection Diagram"on the following
diagram to the wires located in the
dome light of your vehicle.
4.Flip the monitor screen down and
tighten the monitor to the support
bracket, using the supplied screws.
13
--
12V
BATTERY
Video2 input(yellow)
Video output(yellow)
CAR AUDIO(DVD OR VCD)
Audio left input (white)
Audio left output (white)
Audio right input (red)
Audio right output (red)
++
IR/FM wireless headphone(optional)
4. REV/FWD-Scan buttons
Use these buttons to scan forward and
backward through pictures or audio.
8. ANGLE button
Press it to choose to switch the picture's angle if available.
2. EJECT button
Press this button to return to opening picture.
3. NUMBER buttons
Press these buttons to input numbers.
5. TITLE button
Press this button to display the DVD's title.
7. ZOOM button
Zoom in or zoom out the picture on screen.
9. SLOW button
Press this button to slow playback at 1/2,1/4,1/6,1/8 speed.
10. Program button
Use this button to program individually.
1. MENU button
Press this button to display the
LCD’s menu screen.
12.RETURN button
Press this button to return to the previous item.
14. Play/Pause button
Use this button to play picture or
sound or stop temporarily.
15. STOP button
Press this button to stop playback of the picture or sound
16.10+ button
Press this button to select a program of
which the sequence number on the disc is more than 10.
17 . MODE button
Press this button to switch DVD/AV mode.
6.MENU/
Press this button to display the DVD's
menu on screen. Playback control.
PBC button
11. VOL+ button
Press this button to increase volume.
13. POWER button
The power turns on and off when
this button is pressed.
29
1
2
3
4
5
6
7
89
10
11
12
14
13
15
16
17
18
19 20
21
22
23
24
25
26
27
28
30
(optional)

5
12
Advanced Functions
. Selecting the DVD's angle ( multi-angle)
Press the ANGLE button while playing back a scene recorded with multiple angles.
If your DVD disc is not recorded with multiple angles, the ANGLE button has no function.
Repeat play DVDs, Video CDs, and CDs
. Repeat a TITLE, CHAPTER, or TRACK
Press the REPEAT button.
Select the title, chapter, or track you want to repeat.
. Repeat a section between Point A and B.
During playback, press the A-B button on the remote control at the starting point of the
Section you want to repeat. ( Point A)
Press A-B button again at the ending point of the section you want to repeat. ( Point B )
Press A-B button a third time to cancel the A-B repeat function.
.Switch Music/picture/video play
Press [ / ] on the remote control to move the cursor left/right to select
music, picture or video. Red shows that it has been selected, press the [ENTER] button
to confirm selection.
Press [ / ] on the remote control to select upwards/downwards music or folder to play.
Red shows that it has been selected, press [ENTER] to confirm selection.
.Previous/Next
Press [ ]/[ ] on the remote control to play the previous/next music
.Fast Forward/Fast Back
Press [ ]/[ ] on the remote control to realize x2,x4,x8,x20 fast forward/fast back play.
.Pause/Play
Press [ ] on the remote control to play or pause play.
.Stop
Press [ ] on the remote control to stop play.
SD card & USB play
While in DVD source, Insert an MMC/SD/MS card or connect to USB, Press the(SD/USB)
(Unit or Remote control) button
hen MMC/SD/MS or USB is found, It can select multimedia and play.
Note: please do not use a removable hard disk. This will lead to abnormal working.
to bring up the on-screen DISC/CARD/USB picture
control menu, press the / (unit) or / (remote control) button to choose the
mode you need, then press (unit) or ENTER(remote control) button to confirm
playback.
W
.SD card & USB play interface
01.MP3
02.VIDEO
01._______~1
01._______~1
[MP 3 ] - IOVE
01._______~1
1
2
3
4
567
1.Music display window
2.Display music played currently
3.Display folder played currently
4.Folder window
5.Music
6.Picture
7.Video
Viewing DVDs and Video CDs in slow motion
Press the SLOW button during playback, the playback speed becomes 1/2,1/4, 1/6, or
1/8 of the normal speed each time you press the SLOW button.
18. SD CARD&USB button
Press the button to select disc/SD card/USB
input.
20. PRE/ NEXT buttons
Use these buttons to return to the beginning
of the previous/next tracks or chapters.
21. ENTER button
Press it to confirm setting.
22. SUBTITLE button
Press it to switch the DVD's
subtitle languages.
23. SETUP button
Press it to enter or quit the SETUP
Menu.
24. REPEAT button
For DVDs use it to play title or chapters repeatedly.
For CDs, use it to play tracks or the entire disc repeatedly.
25.GOTO button
Press this button , Select time or chapter to go to and play when disc is playing.
26 . AUDIO button
Press it to switch the audio Lanuages.
27. DISPLAY button
Press it to display the disc
information.
28. VOL-. button
Press this button to decrease volume.
19. CURSOR / , / [LCD menu
adjustment button
Use these buttons when selecting setting items to
move the cursor up,down, left and right. Press
up , and down buttons to change TV channels.
29.MUTE button(optional)
Press the button during playback to stop the audio output.
Press it again to resume.
29
1
2
3
4
5
6
7
89
10
11
12
14
13
15
16
17
18
19 20
21
22
23
24
25
26
27
28
30
30.A-B repeat button
Press it during playback to set repeat playback between A and B.
(optional)
press the
Press
the
Press the

6
Picture control
use the unit to achieve the desired settings.
MENU button on n picture cont
2.Select the desired menu by pressing AV/DVD button on the unit to change
COLOR,OSD,FUNCTION,SOUND. Press +/- button to enter picture control menu.
3.Adjust the current settings with the AV/DVD button on the unit, then press + or -
on the unit to achieve the desired settings.
In the menu controlled process, press the MENU button to return to the upper
level of menus.
1.Press the the unit to bring up the on-scree rol
menu.
use the remote control to achieve the desired settings.
MENU button on
2.Select the desired menu by pressing the unit / button to change COLOR,
OSD,FUNCTION,SOUND.Press the / button to enter picture control menu.
3.Adjust the current settings with the unit / button, then press / on the
unit to achieve the desired settings.
In the menu controlled process, press the TFT MENU button to return to the upper
level of menus.
1.Press theTFT the remote control to bring up the on-screen
picture control menu.
11
Note:
For CDs or one-sided DVDs, do not worry about touching the label ( printed) side
or the disc with you finger. But for two-sided DVDs, with signals recorded on both
sides, be careful not to scratch them when removing them from the player.
Stopping the disc
Press the STOP button.
Resume function (DVDs and Video CDs)
Playback will be stopped when the STOP button is pressed, when the play button is
pressed playback starts from the position at which it was stopped. When the disc is
removed or the STOP button is pressed again, the resume function is cancelled.
Hint:
For some discs, playback may not start from the position at which it was stopped.
Press the STOP button then press the previous button, playback starts from the
beginning of the title.
. Pausing the disc
Press the play/pause button.
Press the button again to resume playback.
. Scanning forward and backward
During playback, press the previous or next button.
Reverse direction
Forward direction
Returning to the previous chapter or track DVDs ,Video CDs and CDs
Press the previous button during playback.
When pressed, playback returns to the beginning of the previous chapter or track.
.
. Moving ahead to the next chapter or track DVDs, Video CDs and Cds
Press the next button during playback.
When pressed once, playback moves forward to the next chapter or track.
. Removing discs
1.Press the STOP button.
2.Press the EJECT button to open the disc.
3.Remove the disc.
Playback Functions
Playing a disc
Playing DVD player
1.Press the POWER(Unit,Remote)
buttons.
2.Load a disc in the disc loading
cabin with the lable on the top side.
Put a disc in the loading cabin, and
close the cover, then it will be played
automatically.
Picture selections:
FM channel:
Basic operation
This unit has multiple frequencies
Search for a specific scene
1.Press the SEARCH button.
2.Press the number button to select specific
time or title chapter.
3.Press the ENTER button and playback starts
from the selected chapter.
Unit control
press the unit, press the AV/DVD button, then press +/- to select
the SOUND CONTROL item. press AV/DVD button, select the press +/- to display the
FM menu, press unit AV/DVD button, then press +/- to select the FM channel.
menu button on the
In the menu controlled process, press the MENU button to return to the upper
level of menus.
Remote control
press the remote control, press the / button, then press /
to select the SOUND CONTROL item. press the / button, then press / to
display the FM menu, press / button, then press / to select the FM channel.
menu button on the
In the menu controlled process, press the TFT MENU button to return to the upper
level of menus.
Use

7
DVD Setup
10
Playing disc
1. Loading the disc
. One of the following messages appears on the LCD: DVD, VCD, or CD.
. For some discs, playback starts automatically when the disc is loaded.
. But for some discs on which program memories are set, playback starts
automatically in the order.
2. Press the PLAY/PAUSE button
. Playback starts.
For some discs, a menu screen appears. For video CDs, playing the disc according
to the instructions on the disc's menu screens called PBC ( playback control)
playback.
3.Hint:
. For video CDs, it is also possible to play a disc without displaying the menu screen.
For example, to play from track 1 , press the 1 number button while in the stop mode.
*When playing CD discs or MP3 discs, you are recommended to turn off the TFT LCD
screen to save power. ( Please make reference of "TFT ON/ OFF Function" on Page
10 and Page 12.)
1 POP
2 JAZZ
3 COUNTRY
4 R&B
5 CLASSICAL
Video CD
Press the number button on the remote control unit to select item.
To display the menu screen
The way in which the menu screen is displayed differs from disc to disc. Press the MENU,
TITLE button during playback of DVDs, the RETURN button during PBC playback of video
CDs. For details, refer to documentation included with the disc.
TITLE MENU
1 POP
2 JAZZ
3 COUNTRY
4 R&B
5 CLASSICAL
If a menu screen appears
For DVDs with a menu screen or video CDs with playback control ( PBC), a menu
screen appears.
DVD
Use the cursor buttons to select the item, then press the ENTER button.
Press the number button on the remote control unit to select an item.
Example: For DVDs with menu screen.
DVD Functions
Playback Functions
You can easily modify setup information on the setup menu.
How To Setup Menu
System Setting
TV SYSTEM
AUDIO PLAY
PASSWORD
TV TYPE
RATING
DEFAULT
SYSTEM SETUP
Please press the setup button, then
press to select [SYSTEM] items.
Still Mode Setting
PASSWORD
RATING
DEFAULT
SYSTEM SETUP
TV SYSTEM
AUDIO PLAY
PAL
NTSC
AUTO
1. STILL MODE
To setup the display mode of
still pictures. There are
three options[AUTO]
[FIELD] and [FRAME].
DEFAULT
SYSTEM SETUP
TV SYSTEM
AUTO PLAY
PASSWORD
RATING
ON
OFF
DEFAULT
SYSTEM SETUP
TV SYSTEM
AUTO PLAY
PASSWORD
RATING
4:3PS
4:3LB
16:9
Auto Play Setting
Auto Play Setting
2. AUTO PLAY
To setup DISC auto play
mode.
3. TV TYPE(no function)
To setup the proper TV aspect ratio.
/
TV TYPE
TV TYPE
TV TYPE

8
DVD Setup
9
DVD Setup
MENUS Language Setting
OSD Language Setting
LANGUAGE
To setup OSD languages
OSD LANGUAGE
SUBTITLE LANG
MENU LANG
LANGUAGE SETUP
SPANISH
GERMAN
ENGLISH
PORTUGUESE
CHINESE
RUSSIAN
AUDIO LANG
Audio Language Setting
1. AUDIO
To setup disc output languages.
Subtitle Language Setting
OSD LANGUAGE
LANGUAGE SETUP
SPANISH
ENGLISH
PORTUGUESE
GERMAN
CHINESE
RUSSIAN
AUDIO LANG
MENU LANG
SUBTITLE LANG
2. SUBTITLE
To setup disc subtitle Ianguages.
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
LANGUAGE SETUP
SPANISH
ENGLISH
PORTUGUESE
GERMAN
CHINESE
RUSSIAN
MENU LANG
3. MENUS
To setup DISC MENU
languages
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG
LANGUAGE SETUP
4. PASSWORD
Setup parental lock
password. It is acceptable
to input a new password
with 4 numerals to re-setup
the parental lock.
(The original password is 8888)
Parental Lock Password Setting
TV SYSTEM
AUDIO PLAY
SYSTEM SETUP
PASSWORD
RATING
DEFAULT
5. RATINGS
According to different grade,
setup the parental lock.
Hint:
Normally, the grade is set as
[0 LOCK ALL]
Parental Lock Setting
TV SYSTEM
AUDIO PLAY
SYSTEM SETUP
PASSWORD
RATING
DEFAULT
1 KID SAFE
2 G
3 PG
4 PG 13
5 PG-R
6 R
7 NC-17
8 ADULT
DEFAULTS Setting
6. DEFAULTS
Setup all menus to the
initial setting of the factory.
TV SYSTEM
AUDIO PLAY
PASSWORD
SYSTEM SETUP
RATING
DEFAULT RESTORE
Language Setting
Please press the setup button, then
press to select [LANGUAGE]
items. press to select language
menu.
/
/
TV TYPE
TV TYPE
TV TYPE
AUDIO LANG
SUBTITLE LANG
MENU LANG
LANGUAGE SETUP
FRENCH
SPANISH
GERMAN
ENGLISH
PORTUGUESE
RUSSIAN
OSD LANGUAGE
CHINESE
