DR. Heater DR-968 User manual

Infrared Portable Space Heater
• 1500 Watts with
Two Heat Settings
• Automatic Thermostat
• Tip- ver Switch
• Room Temperature
LED Display
• Precision Temperature
Control
• Easy Push-Button Controls
• Remote Control
Owner’s Manual
PLEASE READ AND
SAVE THESE INSTRUCTIONS
Model No.: DR-968

T
C NGRATULATI NS!
he Dr. Infrared Heater ou
have just purchased is a
safe and powerful heater,
designed to heat a room after a few
minutes of operation. The far-infrared
Quartz-PTC heating s stem is an
excellent choice for safel heating
whole rooms, while saving on
heating costs.
Additionall , this heater includes an
overheat protection s stem, and an
inlet air overheat protection s stem
designed to ensure our safet .
This heater does not reduce humidit
or ox gen in our home or office,
promoting a healthier environment!
Before using our Dr. Infrared Heater,
please take a few minutes to read
these instructions, and review the
product’s limited warrant .
Thank ou!
CAUTI N- High temperature! Keep
electrical cords, draper , and other
furnishings at least 3 feet (0.9 m)
from the front and rear of the heater.
IMP RTANT
INSTRUCTI NS
When using this appliance, basic
precautions should alwa s be
followed to reduce the risk of fire,
electric shock and injur to persons.
1. Read all the instructions before
using this heater.
2. This heater is hot when in use. To
avoid burns, do not let bare skin
touch hot surfaces. Keep
combustible materials, such as
furniture, pillows, bedding, papers,
clothes and curtains at least 3 feet
(0.9 m) from the front of the heater
and awa from the sides and rear.
3. Extreme caution is necessar
when an heater is used b or
near children or persons with
ph sical challenges and whenever
the heater is left operating and
unattended.
4. Do not operate the heater with a
damaged cord or plug, or after the
heater malfunctions, has been
dropped, or damaged in an
manner. Return the heater to an
authorized service facilit for
examination, electrical or
mechanical adjustment, or repair.
5. Do not use outdoors.
6. This heater is not intended for use
in bathrooms, laundr areas or
similar locations. Never locate the
unit where it ma fall into a
bathtub or other water container.
WARNING! To reduce the risk of
fire, electric shock, or personal injur ,
read all the instructions before using
this heater. This appliance is
intended for household or personal
use onl as described in this manual.
An other use including but not
limited to commercial, agricultural, or
outdoor use, is not recommended b
the manufacturer and ma cause
fire, electric shock, injur and/or
damages. The use of an
attachments and accessories or
extension cords not recommended
or sold b Dr. Infrared Heater
Products ma cause hazards and
void the warrant .

7. Do not run the cord under
carpeting and do not cover the
cord with throw rugs, runners or
the like. Arrange the cord awa
from traffic areas to avoid a
tripping hazard.
8. To disconnect the heater, turn
controls to OFF, then remove the
plug from outlet.
9. Do not insert or allow foreign
objects to enter an ventilation or
exhaust opening as this ma
cause an electric shock, fire or
damage to the heater.
10. Connect to properl grounded
outlets onl .
11. To prevent a possible fire, do not
block air intakes or exhaust
openings in an manner. Do not
use on soft surfaces, like a bed,
where openings ma become
blocked. Use the heater on flat,
dr surfaces onl .
12. A heater has hot and arcing or
sparking parts inside. Do not use
the heater in areas where
gasoline, paint or flammable
liquids are used or stored.
13. Use this heater onl as described
in this manual. An other use not
recommended b the
manufacturer ma cause fire,
electric shock or injur to
persons.
14. Never clean this heater while it is
plugged in. Do not immerse in
water. To disconnect, turn control
to OFF, then remove the plug
from the outlet b grasping it and
pulling it from the outlet. Never
ank on the cord.
15. This heater includes a visual
alarm to warn that parts of the
heater are getting excessivel hot.
If the alarm flashes, immediatel
turn the heater OFF and inspect
for an objects on or adjacent to
the heater that ma cause high
temperatures. DO NOT
OPERATE THE HEATER WITH
THE ALARM FLASHING. To reset
the heater, turn it OFF, unplug it
from the electrical outlet, and wait
five to ten minutes for the unit to
cool down before plugging it back
in and turning the heater on.
16. Alwa s unplug the heater when it
is not in use.
17. Alwa s plug heater directl into a
wall outlet/receptacle. Never use
with an extension cord or
relocatable power tap
(outlet/power strip).
18. It is normal for the heater’s plug
and cord to feel warm to the
touch. A plug or cord which
becomes hot to the touch or
becomes distorted in shape ma
be a result of a worn electrical
outlet. Worn outlets or
receptacles should be replaced
prior to further use of the heater.
Plugging this heater into a worn
outlet ma result in overheating
of the power cord or fire.
19. Make sure the plug is full
inserted into an appropriate
receptacle. Be mindful that
receptacles also deteriorate due
to aging and continuous use.
Check periodicall for signs of
overheating or deformations of
the plug. If an overheating or
deformation occurs, immediatel

discontinue using the heater and
contact Dr. Infrared Heater
Authorized Service Center.
20. CHECK Y UR HEATER C RD
AND PLUG C NNECTI NS.
Fault wall outlet connections or
loose plugs can cause the outlets
or plug to overheat. During use,
please check frequentl to
determine if our plug outlet or
faceplate is HOT! If it is hot,
discontinue using the heater
and/or make certain a qualified
electrician checks and replaces
the fault outlet(s).
CAUTION: This appliance is not intended
for use b persons (including children)
with reduced ph sical, sensor or mental
capabilities, or lack of experience and
knowledge, unless the have been given
supervision or instruction concerning use
of the appliance b a person responsible
for their safet .
SAVE THESE
INSTRUCTI NS
perating Instructions
1. Plug the power suppl cord into a
grounded wall outlet. (120VAC,
60Hz).
Important: This heater comes with a
grounded (three-prong) plug. The
grounded plug must be used with a
grounded outlet. Do not use an
adapter in a two-slot wall outlet unless
the ground plug of the adapter
properl connects to a building ground.
Using the heater without a properl
grounded outlet or adapter could
result in an electric shock hazard.
The cord has a plug as shown at A in
the following figure. An adapter, as
shown at C, is available for
connecting three-blade
grounding-t pe plugs to two-slot
receptacles. The green grounding lug
extending from the adapter must be
connected to a permanent ground
such as a properl grounded outlet
box. The adapter should not be used
if a three-slot grounded receptacle is
available.
2. TURNING THE HEATER N
To turn the heater ON, press the
POWER button; the power LED
will turn on. Next press the MODE
button; the heat setting will be set
to AUTO. Press the MODE button
again to set to HIGH. Press the
button a third time to set to LOW.
Press the button a fourth time to
turn the heater OFF.
3. TURNING THE HEATER T
STANDBY FF To turn the
heater to Standb OFF, press the
Standb OFF button. The heater
will shut off but the fan will
continue to run until all the heat
has been expelled. The heater will
turn off automaticall and is set to

Standb mode. If ou are not going
to use the heater for a long time,
press the POWER button to full
shut down the heater. The power
LED will turn off.
4. SETTING THE THERM STAT
Press the MODE button, and set to
AUTO mode to engage the
automatic thermostat.
5. SETTING THE TEMPERATURE
To set the desired temperature:
Press the button once
until the numeric temperature starts
flashing.
Press the button again to
increase the temperature or the
button to decrease the
temperature.
After the desired temperature is set,
this will be our ideal setting. The
heater will run on HIGH until the room
temperature reaches the set
temperature. The heater will then
switch to run on LOW for 10 minutes.
The heater will turn off if the room
temperature is equal to or greater
than the set temperature. (The fan
will continue to run a minute until all
of the residual heat has been
expelled).
For example: If our ideal setting is
72°F, the heater will run on HIGH until
it reaches 72°F. The heater then will
switch to run on LOW for 10 minutes.
The unit will turn off if the room
temperature is equal to or greater
than the set temperature.
The default temperature setting is
preset from the factor at 68°F.
Remote Controller
H W T INSERT BATTERIES
N TE: Remove the batteries if the
remote control is not to be used for a
month or more. Batteries left in the
unit ma leak and cause damage.
DO NOT MIX OLD AND NEW
BATTERIES! DO NOT MIX
ALKALINE, STANDARD
(CARBON-ZINC) OR
RECHARGEABLE
(NICKEL-CADMIUM) BATTERIES!
Instructions for the Use of the IR
Remote Control
The buttons of the remote control
function in the same manner as those
on the control panel on the front of
the heater. Set the timer b using the
remote control.
Setting the Timer
1. Press the TIMER button until Set
Time starts flashing. The default
value is 3 hours.
2. Press the “+” button to increase the
set time or the “–” button to
decrease the set time.
The timer can be set from
1 to 12 hours. The timer will set
and execute after the LED displa
stops flashing. The heater will shut
OFF automaticall when the set
time is reached.
3. To turn the timer OFF, follow step 1,
pressing the “–” button to set the
time to 0. The timer feature will
turn off when the LED stops
flashing.

Maintenance
1. Alwa s turn OFF the heater and
disconnect the cord from the
electrical outlet before cleaning
the unit.
2. Light accumulation of dust ma be
removed from the heater with a
soft cloth or vacuum cleaner.
3. Wipe the exterior surfaces of the
heater occasionall with a damp
cloth (not dripping wet), using a
solution of mild detergent and
water. Dr the case thoroughl
before operating the heater.
Caution! Do not allow water to run
into the interior of the heater as
this could create a fire or electric
shock hazard.
4. The fan motor is factor -lubricated
for life and will require no further
lubrication.
5. Store the heater in a clean, dr
place when it is not in use.
Cleaning the electrostatic
filter
The heater has an electrostatic filter
located at the rear. The cleaning of
the filter should be performed once
per month or as needed (when dust is
visible on the filter) to ensure efficient
operation of the heater.
1. Power the heater OFF b pressing
the POWER button located on the
left side of the Control Panel.
2. Unplug the heater’s power cord.
3. Release the filter b pushing the
filter up from below (Figure 1).
4. Remove the filter b pulling down
and out (Figure 2).
5. Clean the filter b vacuuming.
6. Replace the filter b sliding the top
upwards into the spring loaded slot
on the back of the heater (Figure 2).
Then gentl push the bottom of the
filter into place (Figure 1).
Warning: An other servicing
needed must be performed b an
authorized service representative. Do
not attempt to service the unit
ourself.
Product Specifications
Model No.: DR-968
Voltage: 120V, 60Hz
Current: Maximum continuous draw:
12.5 amps
utput: 5200 BTUs
Power: 1500 Watts
Turbo Fan: Multi-blade; Low Noise
Figure 2 Figure 1

G
B
TM
H
Features
A. “Cool-Touch” cabinet E. MODE button
B. POWER button F. LED temperature displa
C. Decrease temperature button G. Standb ON/OFF button
D. Increase temperature button H. Visual alarm LED
I. Power LED
Special Features
LED Displa – When the unit is plugged in, the LED displa will show the
room temperature. At Auto mode, it will displa the set value 2 minutes
after the desired temperature is set.
Overheat Shut-Off Protection S stem –This heater includes a protection
s stem that shuts off the unit if it overheats for an reason.
Inlet Air Overheat Protection S stem – This heater will automaticall shut
off if the inlet air duct becomes obstructed and causes the unit to overheat.
Safet Tip-Over Switch – The Dr. Infrared Heater is designed to shut off
automaticall when tipped in an direction. The alarm will beep and the
LED displa will flash. Place the heater on a flat, smooth, stable surface to
prevent the heater from tipping over again. When returned to a normal
upright position, the heater is read for use again. This is a safet feature
to avoid the possibilit of fire should the unit be tipped accidentall .
Note: There ma be a trace of smoke or odor when the unit is first operated.
Do not be alarmed. This indicates a drop of oil fell on the interior coils during
the manufacturing process. It will quickl evaporate and should not recur.
A
C D
E
F
I

QUESTI NS AND ANSWERS
If the heater cycles N/ FF without heating:
Please note: This is a smart heater that monitors the room temperature and
produces heat only when needed.
You can set the desired room temperature with the heater in either AUTO
HIGH or AUTO LOW mode. (The factor default setting is 68 °F.) For an
example of how the heater works, let’s sa ou set the temperature for 70 °F.
Once the room has reached 70 °F, the heater switches off and the fan stops
(Note: The heater remains on STANDBY as long as ou do not POWER OFF).
As the heater remains on STANDBY, it will read the room temperature ever 5
minutes b running the fan ONLY for 30 seconds. During this process, the fan
also blows out the residual heat from inside the chamber to ensure an
accurate temperature reading of the room. If the room temperature is at 70
°F(or higher), the heater will remain on STANDBY. It will repeat this sensing
cycle, reading the room temperature, ever 5 minutes. However, if the room
temperature drops 2 degrees lower than the set temperature, the heating
function will turn the heater ON and the fan will blow warm air.
If the heater cycles but doesn’t produce heat for hours:
If the temperature is set lower than room temperature, the heater will perform
only the sensing cycle and the heater will not turn on in the heating function.
To have the heater turn on, always set the desired temperature higher (2°+)
than the room temperature, or manuall select High or Low to have instant
heat.
How to turn off the heater:
Switch to STANDBY mode or POWER OFF the heater.

Does the blower cycle use much electricity?
The blower fan will run for 30 seconds ever 5 minutes to clear residual heat
inside the chamber, while at the same time measuring the room temperature.
This uses less than 18 watts of power to operate.
Why does the blower fan keep running after I have pressed the power
FF button?
The blower fan will continue to run until the heat chambers cool down. After a
few minutes the fan will shut off automaticall .
What if the heater’s airflow seems to have diminished?
Please ensure the rear intake is not blocked and that the filter is clean. Please
follow the filter maintenance procedure to clean the filter.
nce the heater is turned on, how long will it take to heat my room?
This heater can heat up to 1,000 square feet. Generall speaking, it takes
minutes to heat a room. Remember that with an t pe of heating process,
there are man variables such as the size of the room, how well the room is
insulated, how man doors and windows there are, the amount of bare
concrete (which acts as a heat sink with an t pe of heating), the opening and
closing of an exterior door, the outside temperature, etc. Please remember
that this is a zone heater and is meant to be used as a supplemental heating
source onl .
Can I use the heater to heat multiple rooms at the same time?
Keep in mind that heating will var based on how open our floor plan is
and the size of the rooms involved. We have heard from customers that
with the help of ceiling fans, the have been able to heat multiple rooms
simultaneousl b placing the unit in a central room. We suggest ou give it
a tr and see what works best for ou.

My home is not well insulated; will this heater help me?
Yes, but it ma take a little longer to heat the room. The outside temperature
will also have an impact on heating time. Once the room has reached the
desired temperature, it will c cle on and off accordingl .
Can the heater be used in a bathroom?
It is not recommended due to a bathroom’s high level of moisture.
Can the heater be used in a basement or garage?
Yes, but keep in mind that rooms with little insulation will not retain the heat as
efficientl . Bare concrete floors, which act as a heat sink with an t pe of
heating, will absorb some of the heat. However, placing the heater a few feet
above the floor will allow for more efficient heating.
Can I use more than one heater at a time?
Yes, but please make sure the heaters are not on the same circuit. Each
heater and appliance should be on its own circuit.
Can I use the heater and another appliance at the same time?
Yes, as long as the are not on the same circuit. This heater is considered to
be an appliance. You should not run more than one large appliance on a single
circuit breaker. Your appliances, such as a freezer, refrigerator, microwave
oven, washing machine, dr er and others, should not share a circuit breaker.
Can I use the heater on a job or construction site?
This heater is not designed to be used in a high dust construction environment.
Using the heater for this purpose will void our warrant .
Can I move the heater around while it is operating?
It is not recommended to move an portable heater while it is operating. We
recommend moving the heater onl once the fan has completel turned off.

What is the life expectancy for the heater?
This heater uses one infrared tube (which is rated for 20,000 hours and up),
and one PTC element (which is rated for 80,000 hours and up).
What is zone heating?
Zone heating focuses heat where people spend the most time. After all, there
is no point in heating multiple rooms to +68 degrees when not in use.
Can I use an extension cord, surge protector, or power strip with my
heater?
No. The DR. INFRARED HEATER is designed to plug directl into a grounded
120V 15 Amp or higher circuit receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
How many kilowatts per hour does the heater use?
The DR. INFRARED HEATER MODEL DR-968 uses approximatel
1.26 kilowatts per hour.
What is the BTU Rating for the heater?
The DR. INFRARED HEATER MODEL DR-968 is approximatel 5200 BTUs.
The power cord feels warm to the touch; should I be concerned?
It is normal for the heater’s plug and cord to feel warm to the touch. A plug or
cord which becomes hot to the touch or becomes distorted in shape ma be a
result of a worn electrical outlet. Worn outlets or receptacles should be
replaced prior to further use of the heater. Plugging this heater into a worn
outlet ma result in overheating of the power cord or even a fire.
I don’t have a grounded outlet; can I use a cord adapter or remove the
grounding plug?

NO. If ou don’t have a grounded outlet, contact a licensed electrician in our
area for advice. Removing or altering an part of the heater is unsafe and will
also void our warrant .
How long is the warranty?
This heater comes with a THREE-YEAR LIMITED COMPONENT WARRANTY.
If our unit does not appear to be working properl , please contact our service
center b calling 1-800-317-1688. Prior to our call, we encourage ou to visit
our service related website www.DrHeaterUSA.com for troubleshooting tips
and service instructions if needed.
Dr Heater USA
239 Harbor Wa
SOUTH SAN FRANCISCO, CA 94080
TEL: [phone]
EMAIL: [e-mail]
