1. Introduction
1.1 What is NBSN95 NB-IoT Sensor Node
NBSN95 is a Long Range NB-IoT Sensor Node. It is designed for outdoor data loggingand powered by Li/
SOCl2 battery for long term use and secure data transmission. It is designed to facilitate developers to quickly
deploy industrial level NB-IoT solutions. It helps users to turn the idea into a practical application and make the
Internet of Things a reality. It is easy to program, create and connect your things everywhere.
NarrowBand-Internet of Things (NB-IoT) is a standards-based low power wide area (LPWA) technology
developed to enable a wide range of new IoT devices and services. NB-IoT significantly improves the power
consumption of user devices, system capacity and spectrum efficiency, especially in deep coverage.
NBSN95 uses STM32l0x chip from ST, STML0x is the ultra-low-power STM32L072xx microcontrollers
incorporate the connectivity power of the universal serial bus (USB 2.0 crystal-less) with the high-performance
ARM® Cortex®-M0+ 32-bit RISC core operating at a 32 MHz frequency, a memory protection unit (MPU), high-
speed embedded memories (192 Kbytes of Flash program memory, 6 Kbytes of data EEPROM and 20 Kbytes of
RAM) plus an extensive range of enhanced I/Os and peripherals.
NBSN95 is an open source product, it is based on the STM32Cube HAL drivers and lots of libraries can be found
in ST site for rapid development.

1.2 Features
• STM32L072xxxx MCU
• NB-IoT Bands: B1/B3/B8/B5/B20/B28 @H-FDD
• Pre-load bootloader on USART1/USART2
• MDK-ARM Version 5.24a IDE
• I2C, LPUSART1, USB, SPI2
• 3x12bit ADC, 1x12bit DAC
• 20xDigital I/O
• Open-source hardware / software
• IP66 Waterproof Enclosure
• Ultra-Low Power consumption
• AT Commands to change parameters
• Micro SIM card slot for NB-IoT SIM
• 8500mAh Battery for long term use

1.3 Specification
Micro Controller:
Page 6 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
• MCU: STM32L072xxxx
• Flash: 128KB
• RAM: 20KB
• EEPROM: 6KB
• Clock Speed: 32Mhz
Common DC Characteristics:
• Supply Voltage: 2.1v ~ 3.6v
• Operating Temperature: -40 ~ 85°C
• I/O pins: Refer to STM32L072 datasheet
NB-IoT Spec:
• B1 @H-FDD: 2100MHz
• B3 @H-FDD: 1800MHz
• B8 @H-FDD: 900MHz
• B5 @H-FDD: 850MHz
• B20 @H-FDD: 800MHz
• B28 @H-FDD: 700MHz
Battery:
• Li/SOCI2 un-chargeable battery
• Capacity: 8500mAh
• Self Discharge: <1% / Year @ 25°C
• Max continuously current: 130mA
• Max boost current: 2A, 1 second
Power Consumption
• STOP Mode: 10uA @ 3.3v
• Max transmit power: [email protected]

1.4 Applications
• Smart Buildings & Home Automation
• Logistics and Supply Chain Management
• Smart Metering
• Smart Agriculture
• Smart Cities
• Smart Factory

1.5 Pin Definitions & Switch
Page 7 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
No. Signal Direction Function Remark
1 VCC(2.9V) OUTPUT VCC Directly connect to main power for board
2 PA0 In/Out Directly from STM32 chip Used as ADC in NBSN95 image
3 PA1 In/Out Directly from STM32 chip 
4 PA2 In/Out Directly from STM32 chip, 10k pull up to VCC Used as UART_TXD in NBSN95 image
5 PA3 In/Out Directly from STM32 chip, 10k pull up to VCC Used as UART_RXD in NBSN95 image
6 PB6 In/Out Directly from STM32 chip, 10k pull up to VCC 
7 PB7 In/Out Directly from STM32 chip, 10k pull up to VCC 
8 PB3 In/Out Directly from STM32 chip, 10k pull up to VCC 
9 PB4 In/Out Directly from STM32 chip 
10 PA9 In/Out Directly from STM32 chip, 10k pull up to VCC 
11 PA10 In/Out Directly from STM32 chip, 10k pull up to VCC 
12 GND  Ground 
13 VCC(2.9V) OUTPUT VCC Directly connect to main power for board
14 Jumper  Power on/off jumper 
15 PA4 In/Out Directly from STM32 chip 
16 NRST In Reset MCU 
17 PA12 In/Out Directly from STM32 chip 
18 PA11 In/Out Directly from STM32 chip 
19 PA14 In/Out Directly from STM32 chip 
20 PB13 In/Out Directly from STM32 chip 
21 PB12 In/Out Directly from STM32 chip 
22 PB15 In/Out Directly from STM32 chip 
23 PB14 In/Out Directly from STM32 chip 
24 PA13 In/Out Directly from STM32 chip 
25 PA8 In/Out Directly from STM32 chip Default use to turn on/off LED1 in NBSN95 image
26 GND  Ground 
27 +5V Out 5v output power Controlled by PB5(Low to Enable, High to Disable)
28 LED1  Controlled by PA8 Blink on transmit
29 BOOT MODE  Configure device in working mode or ISP program
mode
Flash: Normal Working mode and send AT
Commands
ISP: UART Program Mode
30 NRST In Reset MCU 
Page 8 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
1.5.1 Jumper JP2
Power on Device when put this jumper.
1.5.2 BOOT MODE / SW1
1) ISP: upgrade mode, device won't have any signal in this mode. but ready for upgrade firmware. LED won't work.
Firmware won't run.
2) Flash: work mode, device starts to work and send out console output for further debug
1.5.3 Reset Button
Press to reboot the device.
1.5.4 LED
It will flash:
1. When boot the device in flash mode
2. Send an uplink packet
1.6 Hole Option
The NBSN95 provides different hole size options for different size sensor cable. The options provided are M12,
M16. The definition is as below:
Page 9 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
Page 10 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
2. Use NBSN95 to communicate with IoT Server
2.1 How it works
The NBSN95 is equipped with a NB-IoT module, the pre-loaded firmware in NBSN95 will get environment data from
sensors and send the value to local NB-IoT network via the NB-IoT module. The NB-IoT network will forward this
value to IoT server via the protocol defined by NBSN95.
The diagram below shows the working flow in default firmware of NBSN95:
Page 11 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
2.2 Configure the NBSN95
2.2.1 Power On NBSN95
Page 12 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
2.2.2 Test Requirement
To use NBSN95 in your city, make sure meet below requirements:
• Your local operator has already distributed a NB-IoT Network there.
• The local NB-IoT network used the band that NBSN95supports.
• Your operator is able to distribute the data received in their NB-IoT network to your IoT server.
Below figure shows our testing structure. Here we have NB-IoT network coverage by China Mobile, the
band they use is B8. TheNBSN95 will use CoAP(120.24.4.116:5683) or raw UDP(120.24.4.116:5601) or
MQTT(120.24.4.116:1883)or TCP(120.24.4.116:5600)protocol to send data to the test server
2.2.3 Insert SIM card
Insert the NB-IoT Card get from your provider.
User need to take out the NB-IoT module and insert the SIM card like below:
Page 13 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
2.2.4 Connect USB – TTL to NBSN95 to configure it
User need to configure NBSN95 via serial port to set the Server Address/ Uplink Topicto define where and how-
to uplink packets. NBSN95 support AT Commands, user can use a USB to TTL adapter to connect to NBSN95 and
use AT Commands to configure it, as below.
In the PC, use below serial tool settings:
• Baud: 9600
• Data bits: 8
• Stop bits: 1
• Parity: None
• Flow Control: None

Make sure the switch is in FLASH position, then power on device by connecting the jumper on NBSN95. NBSN95
will output system info once power on as below, we can enter the password: 12345678 to access AT Command
input.

Page 14 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
Note: the valid AT Commands can be found at:https://www.dropbox.com/sh/jao1xt9kw5r3yq4/
AAAMpJkZzExF2JLbRWxGoQ9Na?dl=0
2.2.5 Use CoAP protocol to uplink data
Note: if you don't have CoAP server, you can refer this link to set up one:http://wiki.dragino.com/xwiki/
bin/view/Main/Set%20up%20CoAP%20Server/
Use below commands:
•AT+PRO=1 // Set to use CoAP protocol to uplink
•AT+SERVADDR=120.24.4.116,5683// to set CoAP server address and port
•AT+URI=5,11,"mqtt",11,"coap",12,"0",15,"c=text1",23,"0" //Set COAP resource path
For parameter description, please refer to AT command set
Page 15 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
After configure the server address and reset the device (via AT+ATZ ), NSE01 will start to uplink sensor values to
CoAP server.
Page 16 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
2.2.6 Use UDP protocol to uplink data(Default protocol)
This feature is supported since firmware version v1.0.1
•AT+PRO=2 // Set to use UDP protocol to uplink
•AT+SERVADDR=120.24.4.116,5601 // to set UDP server address and port
•AT+CFM=1 // If the server does not respond, this command is unnecessary
Page 17 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
Page 18 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
2.2.7 Use MQTT protocol to uplink data
This feature is supported since firmware version v110, it supports only plain MQTT now it doesn't support
TLSandotherrelatedencryption.
•AT+PRO=3 // Set to use MQTT protocol to uplink
•AT+SERVADDR=120.24.4.116,1883 // Set MQTT server address and port
•AT+CLIENT=CLIENT// Set up the CLIENT of MQTT
•AT+UNAME=UNAME// Set the username of MQTT
•AT+PWD=PWD// Set the password of MQTT
•AT+PUBTOPIC=T1_PUB// Set the sending topic of MQTT
•AT+SUBTOPIC=T1_SUB // Set the subscription topic of MQTT
Page 19 / 47 - last modified by Xiaoling on 2023/08/30 14:15

User Manual for LoRaWAN End Nodes - NBSN95_NBSN95A NB-IoT Sensor Node User Manual
To save battery life, NBSN95 will establish a subscription before each uplink and close the subscription 3 seconds
after uplink successful. Any downlink commands from server will only arrive during the subscription period.
Page 20 / 47 - last modified by Xiaoling on 2023/08/30 14:15
