Dranetz Encore Serirs 6100 System User manual

E NCORE S ERIES
®
61000 System
INSTALLATION GUIDE
DRANETZ - BMI
1000 New Durham Road
Edison, New Jersey 08818-4019

ii
WARNING
Death, serious injury, or fire hazard could result from improper connection of this instrument. Read and
understand this manual before connecting this instrument. Follow all installation and operating
instructions while using this instrument.
Connection of this instrument must be performed in compliance with the National Electrical Code (ANSI/
NFPA 70-2008) of USA and any additional safety requirements applicable to your installation.
Installation, operation, and maintenance of this instrument must be performed by qualified personnel
only. The National Electrical Code defines a qualified person as “one who has the skills and knowledge
related to the construction and operation of the electrical equipment and installations, and who has
received safety training on the hazards involved.”
Qualified personnel who work on or near exposed energized electrical conductors must follow applicable
safety related work practices and procedures including appropriate personal protective equipment in
compliance with the Standard for Electrical Safety Requirements for Employee Workplaces (ANSI/NFPA
70E-2004) of USA and any additional workplace safety requirements applicable to your installation.
Published by Dranetz-BMI
1000 New Durham Road
Edison, NJ 08818-4019 USA
Telephone: [phone] or 732-287-3680
Fax: [phone]
Web site: www.dranetz-bmi.com
Copyright ©2008 Dranetz-BMI
All rights reserved.
No part of this book may be reproduced, stored in a
retrieval system, or transcribed in any form or by any
means—electronic, mechanical, photocopying, recording,
or otherwise—without prior written permission from the
publisher, Dranetz-BMI, Edison, NJ 08818-4019.
Printed in the United States of America.
P/N UG-61000 Rev.D

iii
ADVERTENCIA
U na conexión incorrecta de este instrumento puede producir la muerte, lesiones graves y riesgo de incendio. Lea y
entienda este manual antes de conectar. Observe todas las instrucciones de instalación y operación durante el uso de
este instrumento.
La conexión de este instrumento a un sistema eléctrico se debe realizar en conformidad con el Código Eléctrico
Nacional (ANSI/NFPA 70-2008) de los E.E.U.U., además de cualquier otra norma de seguridad correspondiente a su
establecimiento.
La instalación, operación y mantenimiento de este instrumento debe ser realizada por personal calificado solamente.
El Código Eléctrico Nacional define a una persona calificada como "una que esté familiarizada con la construcción y
operación del equipo y con los riesgos involucrados."
El personal cualificado que trabaja encendido o acerca a los conductores eléctricos energizados expuestos debe seguir
prácticas y procedimientos relacionados seguridad aplicable del trabajo incluyendo el equipo protector personal
apropiado en conformidad con el estándar para los requisitos de seguridad eléctricos para los lugares de trabajo del
empleado (ANSI/NFPA 70E-2004) de los E.E.U.U. y cualquier requisito de seguridad adicional del lugar de trabajo
aplicable a su instalación.
AVERTISSEMENT
Si l'instrument est mal connecté, la mort, des blessures graves, ou un danger d'incendie peuvent s'en suivre. Lisez
attentivement ce manuel avant de connecter l'instrument. Lorsque vous utilisez l'instrument, suivez toutes les
instructions d'installation et de service.
Cet instrument doit être connecté conformément au National Electrical Code (ANSI/NFPA 70-2008) des Etats-Unis
et à toutes les exigences de sécurité applicables à votre installation.
Cet instrument doit être installé, utilisé et entretenu uniquement par un personnel qualifié. Selon le National
Electrical Code, une personne est qualifiée si "elle connaît bien la construction et l'utilisation de l'équipement, ainsi
que les dangers que cela implique".
Le personnel qualifié qui travaillent dessus ou s'approchent des conducteurs électriques activés exposés doit suivre
des pratiques en matière et des procédures reliées par sûreté applicable de travail comprenant le matériel de protection
personnel approprié conformément à la norme pour des conditions de sûreté électriques pour les lieux de travail des
employés (ANSI/NFPA 70E-2004) des Etats-Unis et toutes les conditions de sûreté additionnelles de lieu de travail
applicables à votre installation.
WARNUNG
Der falsche Anschluß dieses Gerätes kann Tod, schwere Verletzungen oder Feuer verursachen. Bevor Sie dieses
Instrument anschließen, müssen Sie die Anleitung lesen und verstanden haben. Bei der Verwendung dieses
Instruments müssen alle Installation- und Betriebsanweisungen beachtet werden.
Der Anschluß dieses Instruments muß in Übereinstimmung mit den nationalen Bestimmungen für Elektrizität
(ANSI/NFPA 70-2008) der Vereinigten Staaten, sowie allen weiteren, in Ihrem Fall anwendbaren
Sicherheitsbestimmungen, vorgenommen werden.
Installation, Betrieb und Wartung dieses Instruments dürfen nur von Fachpersonal durchgeführt werden. In dem
nationalen Bestimmungen für Elektrizität wird ein Fachmann als eine Person bezeichnet, welche "mit der Bauweise
und dem Betrieb des Gerätes sowie den dazugehörigen Gefahren vertraut ist."
Qualifiziertes Personal, das an bearbeiten oder herausgestellte angezogene elektrische Leiter sich nähern, muß
anwendbare Sicherheit bezogener Arbeit Praxis und Verfahren einschließlich passende persönliche schützende
Ausrüstung gemäß dem Standard für elektrische Sicherheitsauflagen für Angestellt-Arbeitsplätze (ANSI/NFPA 70E-
2004) der Vereinigten Staaten und alle zusätzlichen Arbeitsplatzsicherheitsauflagen folgen, die auf Ihre Installation
anwendbar sind.

iv
Safety Summary
Definitions WARNING statements inform the user that certain conditions or practices could result
in loss of life or physical harm.
CAUTION statements identify conditions or practices that could harm the 61000, its
data, other equipment, or property.
NOTE statements call attention to specific information.
Symbols The following International Electrotechnical Commission (IEC) symbols are marked
on the top and rear panel in the immediate vicinity of the referenced terminal or device:
Caution, refer to accompanying documents (this manual).
Alternating current (ac) operation of the terminal or device.
Direct current (DC) operation of the terminal or device.
Protective conductor terminal.
Definiciones Las ADVERTENCIAS informan al usuario de ciertas condiciones o prácticas que
podrían producir lesiones mortales o daño físico.
Las PRECAUCIONES identifican condiciones o prácticas que podrían dañar la 61000,
sus datos, otros equipos o propiedad.
Las NOTAS llaman la atención hacia la información específica.
Símbolos Los siguientes símbolos de la Comisión Internacional Electrotécnica (IEC) aparecen
marcados en el panel superior y el posterior inmediatos al terminal o dispositivo en
referencia:
Precaución, consulte los documentos adjuntos (este manual).
OperaciÛn de corriente alterna (ca) del terminal o dispositivo.
Operación de corriente continua (CC) del terminal o dispositivo.
Terminal de proteccion del conductor.
!
!

v
Safety Summary, Continued
Définitions Les messages d’AVERTISSEMENT préviennent l’utilisateur que certaines conditions
ou pratiques pourraient entraîner la mort ou des lésions corporelles.
Les messages de MISE EN GARDE signalent des conditions ou pratiques susceptibles
d’endommager “61000”, ses données, d’autres équipements ou biens matériels.
Les messages NOTA attirent l’attention sur certains renseignements spécifiques.
Symboles Les symboles suivants de la Commission électrotechnique internationale(CEI) figurent
sur le panneau arrière supérieur situé à proximité du terminal ou de l’unité cité:
Mise en garde, consultez les documents d’accompagnement (ce manual).
Fonctionnement du terminal ou du dispositif sur le courant alternatif
(c.a.).
Fonctionnement du terminal ou de l’unité en courant continu (CC).
Borne conductrice de protection.
Definitionen WARNUNGEN informieren den Benutzer darüber, daß bestimmte Bedingungen oder
Vorgehensweisen körperliche oder tödliche Verletzungen zur Folge haben können.
VORSICHTSHINWEISE kennzeichnen Bedingungen oder Vorgehensweisen, die zu
einer Beschädigung von 61000, seiner Daten oder anderer Geräte bzw. von Eigentum
führen können.
Symbole HINWEISE machen auf bestimmte Informationen aufmerksam. Die folgenden
Symbole der Internationalen Elektrotechnischen Kommission (International
Electrotechnical Commission; IEC) befinden sich auf der Abdeck- und Seitenplatte
unmittelbar am betreffenden Terminal oder Gerät.
Vorsichtshinweis, siehe Begleitdokumente (dieses Handbuch).
Wechselstrombetrieb des Terminals bzw. Geräts.
Gleichstrombetrieb im Terminal oder Gerät.
Terminal-Schutzleiter.
!
!

vi
Safety Summary, Continued
Safety
precautions The following safety precautions must be followed whenever any type of voltage or
current connection is being made to the 61000.
• Connect the green safety (earth) ground first, before making any other connections.
• When connecting to electric circuits or pulse initiating equipment, open their related
breakers. DO NOT install any connection of the instrument on live power lines.
• Connections must be made to the instrument first, then connect to the circuit to be
monitored.
• Wear proper personal protective equipment, including safety glasses and insulated
gloves when making connections to power circuits.
• Hands, shoes and floor must be dry when making any connection to a power line.
• Make sure the unit is turned OFF before connecting probes to the rear panel.
• Before each use, inspect all cables for breaks or cracks in the insulation. Replace
immediately if defective.
• Pods should be connected first to the 61000, then connect to the circuit to be
monitored.
• If the equipment is used in a manner not specified in this user’s guide, the protection
provided by the equipment may be impaired.
These safety precautions are repeated where appropriate throughout this manual.

vii
Statements and Notices
Statement of
warranty All products of Dranetz-BMI are warranted to the original purchaser against defective
material and workmanship for a period of one year from the date of delivery. Dranetz-
BMI will repair or replace, at its option, all defective equipment that is returned, freight
prepaid, during the warranty period. There will be no charge for repair provided there is
no evidence that the equipment has been mishandled or abused. This warranty shall not
apply to any defects resulting from improper or inadequate maintenance, buyer-
supplied hardware/software interfacing, unauthorized modification or misuse of the
equipment,operation outside of environmental specifications, or improper site
preparation or maintenance.
Statement of
reliability The information in this manual has been reviewed and is believed to be entirely
reliable, however, no responsibility is assumed for any inaccuracies. All material is for
informational purposes only and is subject to change without prior notice.
Noticeregarding
FCC compliance This device has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his/her own expense.
Noticeregarding
proprietary
rights
This publication contains information proprietary to Dranetz-BMI. By accepting and
using this manual, you agree that the information contained herein will be used solely
for the purpose of operating equipment of Dranetz-BMI.
Continued on next page

viii
Statements and Notices, Continued
Copyright This publication is protected under the Copyright laws of the United States, Title 17 et
seq. No part of this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form, by
any means, electronic, mechanical, magnetic, optical, chemical, manual, or otherwise,
without the prior written consent of Dranetz-BMI, 1000 New Durham Road, Edison,
New Jersey 08818.
Copyright ©2008 Dranetz-BMI
All Rights Reserved. Printed in the United States of America.
Trademarks Encore Series Software, DataNode, Scope Mode, NodeLink and PQView are registered
trademarks of Dranetz-BMI.

ix
Table of Contents
Safety Summary .................................................................................................................... iv
Statements and Notices.......................................................................................................... vii
CHAPTER 1 - Introduction
About the 61000 .................................................................................................................... 1-1
Unpacking the 61000............................................................................................................. 1-3
61000 Accessories................................................................................................................. 1-4
Physical Description.............................................................................................................. 1-5
CHAPTER 2 - Controls, Indicators, and Connectors
External Components ............................................................................................................ 2-1
Connecting to AC Power Source........................................................................................... 2-6
Communications Interface..................................................................................................... 2-9
Input Module Connectors...................................................................................................... 2-11
Connecting Voltage Measurement Cables ............................................................................ 2-21
Connecting Current Probes.................................................................................................... 2-24
Connecting Voltage/Current Input Pods................................................................................ 2-28
Connecting Digital Input Connectors.................................................................................... 2-30
CHAPTER 3 - Circuit Diagrams for Power Monitoring
Connecting Power to the Voltage/Current Connections........................................................ 3-1
Single Phase........................................................................................................................... 3-6
Split Phase ............................................................................................................................. 3-7
3 Phase, Four Wire Wye........................................................................................................ 3-8
3 Phase Delta......................................................................................................................... 3-9
3 Phase 2-Watt Delta............................................................................................................. 3-10
2 1/2 Element without Voltage Channel B............................................................................ 3-11
2 1/2 Element without Voltage Channel C............................................................................ 3-12
CHAPTER 4 - Operational Description
Input Settings......................................................................................................................... 4-1
Data Collection...................................................................................................................... 4-3
Memory Functions................................................................................................................. 4-4
Section A -External Communications Interface .......................................................................... 4-5
Remote Computer Operation................................................................................................. 4-5
Connection Setup via Modem ............................................................................................... 4-6
Configuring the Encore 61000 DataNode for Modem Communication ............................... 4-7
Connection Setup via Com 1 RS232..................................................................................... 4-16
Connection Setup via GPS Antenna...................................................................................... 4-17

x
Table of Contents, Continued
Section B -Local Operation.......................................................................................................... 4-18
Stand Alone Unit................................................................................................................... 4-18
Basic Operation ..................................................................................................................... 4-19
APPENDIX A - Optional Accessories
Introduction ........................................................................................................................... A-1
Hardware Accessories List.................................................................................................... A-2
Enclosure Hardware Options................................................................................................. A-5
Software Accessories............................................................................................................. A-19
APPENDIX B - Technical Specifications
General Specifications........................................................................................................... B-1
Measurement Parameters....................................................................................................... B-4
Enclosure Ingress Protection Ratings.................................................................................... B-10
APPENDIX C - Connecting an External DC Power Supply
Introduction ........................................................................................................................... C-1
Connecting the DC Input Cable............................................................................................. C-2
APPENDIX D - Installing External Ferrite Clamps
Introduction ........................................................................................................................... D-1
Installation Procedure............................................................................................................ D-1

xi
Dranetz-BMI Encore Series
®
61000 System

xii

1-1
C HAPTER 1
Introduction
About the 61000; Unpacking the 61000; 61000 Accessories; Physical Description
About the 61000
61000
description The Encore Series
®
61000 System hereinafter referred to as 61000 encompasses two
world-class data acquisition products developed by Dranetz-BMI - the DataNode
family of products for the Signature System
®
and the PowerXplorer
®
PX5. This
integration of power measurement capabilities coupled with an innovative modular
design set the 61000 apart as a truly revolutionary product. The modular concept
applies to both the hardware configuration and firmware architecture allowing the unit
to be a multi-purpose instrument. 61000 works from being a diagnostic tool to
providing preventive and predictive information as an embedded solution. The
instrument is designed to operate either locally as a stand-alone unit with the optional
LCD panel installed or via remote computer using the Encore Series Software. 61000 is
compliant with IEEE1159, IEC61000-4-30 Class A, EN50160 standards, and more. It
can be installed in a permanent or semi-permanent installation.
Interface to
61000 61000 can operate locally as a stand-alone unit and/or remotely as a data acquisition
module connected to the Encore Series Software:
Local operation with optional user interface
As a stand-alone unit, the 61000 can be outfitted with optional liquid crystal display
(LCD) as user interface. The optional touch screen display is mounted on the front
panel of the instrument (rack mount or switchgear mount). The LCD panel provides
immediate accessibility to monitoring all measurement parameters and instrument
setup and configurations. Refer to the 61000 User Interface Operations Guide for
detailed instructions.
Remote computer operation
The 61000 can operate as a data acquisition module connected to the Encore Series
Software. This software provides a centralized connection point for remote devices,
turning the computer into a self-contained web server. Encore Series Software permits
remote communications with the 61000, with the conventional Internet browser as user
interface. Remote operation includes instrument setup and configurations and
monitoring real-time parameters, disturbance and trend data. Refer to the Encore Series
Software User’s Guide for detailed operating instructions.
Data
communication 61000 can communicate data to the Encore Series Software via Ethernet (wired,
wireless or fiber-optic based), RS485, and land/cellular modem via RS232. The
physical modem is an external option and is not included as part of the standard
product. This extends greater flexibility in the choice of communications interface for
remote operation.
Continued on next page

1-2
About the 61000, continued
Input/Output
modules 61000 provides dedicated digital signal processing power via the separate and
independent connection for each input/output module installed. This modular and
configurable design shatters the traditional 8-channel (4 voltage, 4 current) instrument
format. Choose from the voltage, current, and data acquisition modules to build from
one to four instruments in a single, compact, cost-effective format. The available
modules are:
• AC Voltage Modules - 4 channels using either terminal block, safety jack, or 25-pin
connector to external voltage pods
• AC Current Modules - 4 channels for clamp-on CTs or 25-pin connector to external
CT pod
• Digital Input Modules - 8 channels
NOTE: The Modules are factory-installed. They cannot be installed in the field and are
not user accessible.
See Chapter 2 Controls, Indicators and Connectors for more information on the input
modules. Chapter 3 Circuit Diagrams for Power Monitoring contains wiring diagrams
for when power measurements are to be made.
Virtual analyzer
platform At the heart of the 61000 is the virtual analyzer platform or ‘instruments within an
instrument’ configuration. The virtual analyzer allows the instrument to distinguish
data operations in multiple modules. The user can configure up to four virtual analyzers
per 61000 instrument.
The 61000 firmware architecture is based on the concept of separating the various
stages of acquisition, characterization, communications and visualization with clearly
defined interfaces that decouple one from the other. The instrument can monitor power
quality phenomena for troubleshooting and/or compliance purposes. It can record
inrush conditions, carry out long-term statistical studies to establish performance
baselines, and perform field-basedequipment testing and evaluation for commissioning
and maintenance. The firmware integrates intuitive instrument setup procedures for
each module analyzer to ensure the capture of all relevant data for additional post
process analysis, report writing, and data archiving using other compatible Dranetz-
BMI software applications such as PQView
®
.
This guide This guide is only part of a complete document set designed to provide comprehensive
information about the 61000. It primarily contains instructions on how to set up the
basic 61000 hardware for operation. It describes the input module interface and the
wiring configurations possible for voltage/current connection. It also describes the data
communication ports available in the backplane of the instrument. An overview on how
to set up the 61000 either as a stand-alone unit or as a data acquisition module
connected to the Encore Series Software is included in this guide.
For operational description using the local LCD panel, refer to the 61000 User
Interface Operations Guide (check with Dranetz-BMI for availability).
For operational description using remote communications via Encore Series Software,
refer to the Encore Series Software User’s Guide.

1-3
Chapter 1/ Introduction
Unpacking the 61000
Unpacking For maximum protection against possible shipping damage, the 61000 has been sealed
in a two-piece, plastic suspension pack, enclosed within a durable shipping carton.
After opening the carton, inspect the contents for possible shipping damage and check
the carton inventory.
Unpack the 61000 from the carton as follows:
Shipping
damage
inspection
Visually inspect the 61000 for possible shipping damage. If any damage exists, first
notify and file an insurance claim with your carrier or underwriter or both. Then notify
Dranetz-BMI Customer Service Department of your intentions to return the unit. DO
NOT return the 61000 without prior instructions from Dranetz-BMI Customer Service
Department. Dranetz-BMI Customer Service Department can be reached at (732) 287-
3680 or 1-800-372-6832.
Repacking for
return shipment If the unit must be returned to Dranetz-BMI for service or repair, wrap the unit securely
in heavy packaging material and place in a well padded box or crate to prevent damage.
Do not return the 61000 in an unpadded box. Dranetz-BMI will not be responsible for
damage incurred during transit due to inadequate packing on your part.
Return notice Notify Dranetz-BMI Customer Service of your intention of returning the unit. Do not
return the unit without prior instructions from Dranetz-BMI. Dranetz-BMI Customer
Service Department can be reached at [phone] or 1-800-372-6832.
Step Action
1 Remove any remaining literature inside the top of the carton.
2 Carefully remove the 61000 from its shipping carton.
3 Remove all accessories inside the carton. Check that the standard (see
page 1-4) and optional accessories (see Appendix A) you ordered are
included.

1-4
61000 Accessories
61000 Accessories
Standard
accessories The standard accessory included with the 61000 is the Encore Series 61000 System
Installation Guide, P/N UG-61000.
Optional
accessories Refer to Appendix A for the list of hardware and software optional accessories
available for use with 61000. The unit mainframe can be custom-built with optional
input module connectors, communication port connectors, GPS antenna connector, and
a 12V dc power input jack.
Technical
specifications Specifications for the 61000 measured parameters, computed parameters, voltage
modules, current probes, and pod accessories are listed in Appendix B.
External dc
power source To connect to an external dc power source, refer to Appendix C.
Calibration The recommended calibration interval for this unit is once every 12 months.
We recommend that you return the unit to the factory for calibration. If you decide to
do so, first contact the Dranetz-BMI Customer Service Department to obtain an
Authorization Number.
Telephone: [phone] or 1-800-372-6832
Fax: [phone]
Fill out the Repair/Service Order form enclosed in the shipping carton and ship it along
with the unit to the Dranetz-BMI Repair Department. (If this form is missing, ask the
Dranetz-BMI Customer Service Department for a replacement.)

1-5
Chapter 1/ Introduction
Physical Description
Dimensions The 61000 in the desktop enclosure without the optional LCD panel is a self-contained
instrument weighing 4 pounds and measuring 11.25” width x 3.5” height x 7 3/4”
depth.
When used with the LCD panel installed in 19” rack, the instrument weighs 5 pounds
and has an 8” depth.
When used with the LCD panel installed in switchgear mounting enclosure, the
instrument weighs 10 pounds and measures 7” width x 6.5” height x 8” depth.
Optionaldisplay
panel The optional user interface is a 1/4 VGA LCD panel with touch screen menus for local
operation and configuration.
Connector panel The backplane panel consists of industrial grade, voltage/current/pod connectors,
communication port connectors, dc input power connector, and power switch. See
Chapter 2 Controls, Indicators and Connectors for description.
External dc
power source To connect to an external dc power source, refer to Appendix C.

1-6
This page intentionally left blank.

2-1
C HAPTER 2
Controls, Indicators, and Connectors
External Components; Connecting to AC Power Source; Communications Interface;
Input Module Connectors; Connecting Voltage Measurement Cables; Connecting
Current Probes; Connecting Voltage/Current Input Pods; Connecting Digital Input
Connectors
External Components
Description External components refer to operator related external controls, indicators and
connectors.
Front panel The 61000 front panel display may look different depending on the enclosure options
specified.
Front panel without the local LCD User Interface
See below for description of the 61000 front display without the LCD user interface.
Continued on next page
Part Function
1Status Indicator. LED will light steadily when abnormal condition is detected.
The unit is operating normally when light is off.
2Monitoring On. LED will light if monitoring is on. Monitoring status is off
when light is off.
3Power Indicator. LED will blink when the unit power switch is turned on. The
number of blinks correspond to the number of modules installed.
SF-201

2-2
External Components, continued
Front panel
(continued) Front panel with the optional LCD User Interface in Rack Mount and Switchgear
Mount Display
The front view primarily shows the color touch screen LCD. See below for description
of the 61000 front display with the LCD panel installed.
Part Function
1LCD Rack Mount Protective Enclosure with rack handles
2Liquid Crystal Display (LCD). Provides 3.75 x 4.75 inches display consisting
of 1/4 VGA size screen of text and graphic information. The color LCD is
equipped with touch screen technology, operable using the finger and/or
stylus. Touch screen display permits menu selection, alphanumeric data entry,
and has a compact fluorescent (CCFL) backlighting that is on for low light
level viewing.
The following are some basic care instructions for the LCD monitor:
• Use and store the unit within the specified temperature and humidity range.
The LCD screen may be adversely affected by exposure to high temperature
or humidity. Condensation or moisture produced by sudden temperature
changes may also damage the LCD screen. Clean any moisture from surface
immediately.
• Be careful when cleaning or removing stains on the LCD surface. Gently
wipe the surface with a soft cloth or cotton pad. Isopropyl alcohol may be
used, but make sure that all solvent residue is removed.
• Do not apply excessive force to the LCD surface. The LCD screen contains
sensitive electronic components that may be damaged due to strong impact.
3LCD Switchgear Mount Enclosure
SF-202d
