Draper StormForce PT141KSF User manual

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.
GENERAL INFORMATION
These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.
INSTRUCTIONS FOR
135W 230V
Rotary Multi-Tool Kit
Stock No.83651 Part No.PT141KSF
STORM

1. TITLE PAGE
1.1 INTRODUCTION:
USER MANUAL FOR:
135W 230V ROTARY MULTI-TOOL KIT
Stock no. 83651
Part no. PT141KSF
1.2 REVISIONS:
As our user manuals are continually updated, users should make sure that they use the very
latest version.
Downloads are available from: http://www.drapertools.com/manuals
DRAPER TOOLS LIMITED WEBSITE: drapertools.com
HURSLEY ROAD PRODUCT HELP LINE: [phone]
CHANDLER’S FORD GENERAL FAX: [phone]
EASTLEIGH
HAMPSHIRE
SO53 1YF
UK
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! Information that draws attention to the risk of injury or death.
CAUTION! Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other
form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
Date first published March 2016

2. CONTENTS
3
2.1 CONTENTS
PAGE CONTENT PAGE
1 TITLE PAGE
1.1 INTRODUCTION ....................................................................................................2
1.2 REVISION HISTORY................................................................................................2
1.3 UNDERSTANDING THIS MANUAL .......................................................................2
1.4 COPYRIGHT NOTICE .............................................................................................2
2 CONTENTS
2.1 CONTENTS .............................................................................................................3
3 GUARANTEE
3.1 GUARANTEE ..........................................................................................................4
4 INTRODUCTION
4.1 SCOPE ...................................................................................................................5
4.2 SPECIFICATION ......................................................................................................5
4.3 HANDLING & STORAGE ........................................................................................5
5 HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS ........................................................................6 - 7
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR MULTI-TOOL USE ............................7 - 8
5.3 CONNECTION TO THE POWER SUPPLY................................................................8
6 TECHNICAL DESCRIPTION
6.1 IDENTIFICATION ....................................................................................................9
7 UNPACKING & CHECKING
7.1 PACKAGING ..........................................................................................................10
7.2 WHAT´S IN THE BOX? ...........................................................................................10
8 BASIC MULTI-TOOL OPERATIONS
8.1 SWITCHING ON AND OFF .....................................................................................11
8.2 APPLICATIONS.......................................................................................................11
8.3 HOLDING THE TOOL .............................................................................................11
8.4 CHANGING BITS ....................................................................................................11
8.5 FITTING A CUTTING/SANDING DISC .....................................................................12
8.6 FITTING THE SANDING DRUMS ............................................................................12
9 MAINTENANCE
9.1 MAINTENANCE & PARTS REPLACEMENT ............................................................13
10 OPTIONAL ACCESSORIES .........................................................................................................14
11 EXPLANATION OF SYMBOLS
11.1 EXPLANATION OF SYMBOLS ................................................................................15
12 DISPOSAL
12.1 DISPOSAL ..............................................................................................................15
DECLARATION OF CONFORMITY ..........................................................................................ENCLOSED

4
3. GUARANTEE
3.1 GUARANTEE
Draper tools have been carefully tested and inspected before shipment and are guaranteed to
be free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor or
contact Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: [phone] or Product Help Line [phone].
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee period covering
parts/labour is 12 months from the date of purchase except where tools are hired out when the
guarantee period is 90 days from the date of purchase. The guarantee is extended to 24 months
for parts only. This guarantee does not apply to normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges
will be quoted and made accordingly.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the guarantee period.
Please note that this guarantee is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.

5
4. INTRODUCTION
4.1 SCOPE
For drilling, milling, grinding, engraving, cutting, polishing, sharpening, buffing and
removing rust, etc. This tool is intended for domestic and light commercial use only. Any
other application is considered as misuse..
4.2 SPECIFICATION
Stock no. .. .......................................................................................................................... 83651
FSK141TP...........................................................................................................................ontraP
Rated voltage .............................................................................................................230V~50Hz
Rated input..........................................................................................................................135W
nim000,83-000,01........................................
.....................................................)daolon(deepS -1
Collet capacity...........................................................................5 (1.6, 2.0, 2.4, 3.0, and 3.2mm)
Sound pressure level ... ................................................................................................... 77dB(A)
Sound power level ... ...................................................................................................... 88dB(A)
Vibration level.................................................................................................................. 2.3m/s2
Weight (Excluding Accessories)........................................................................................... 700g
Collet nut..................................................................................................................................M7
Maximum diameter.................................................................................................................ø35
4.3 HANDLING & STORAGE
Although this machine is small in size, care must still be taken when handling.
This machine is not a toy and must be respected.
The environment will have a negative result on its operation if you are not careful. If the air
is damp, components will rust. If the machine is unprotected from dust and debris;
components will become clogged: And if not cleaned and maintained correctly or regularly
the machine will not perform at its best.

6
5. HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS
General Power Tools Safety Warnings
WARNING: Read all instructions. Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains operated (corded) power tool or
battery operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electrical shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal Safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, nonskid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.

7
5. HEALTH & SAFETY INFORMATION
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust
related hazards.
4) Power Tool Use And Care
a) Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool
accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tools operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from intended could result
in a hazardous situation.
5) Service
a. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR MULTI-TOOL USE
Sander Safety Warning
1) Personal Safety
a) Wear dust protection with sanders. Exposure to dust can be detrimental to health.
b) Connect dust extraction equipment. If the tool is provided for the connection of dust
extraction and collecting equipment, ensure these are connected and properly used.
Working hints for your tool.
- If your power tool becomes too hot, especially when used at low speed, set the speed to
maximum and run it with no load for 2-3minutes to cool the motor. Avoid prolonged
usage at very low speeds. Always keep the blade sharp.
- Always ensure the workpiece is firmly held or clamped to prevent movement.
- Any movement of the material may effect the quality of the cutting or sanding finish.
- Start your tool before working and turn it off only after you stop working.
- Do not start sanding without having the sandpaper fitted.
- Do not allow the sandpaper to wear away, it will damage the sanding pad. The
guarantee does not cover sanding pad wear and tear.
- Use coarse grit paper to sand rough surfaces, medium grit for smooth surfaces and fine
grit for the finishing surfaces. If necessary, first make a test run on scrap material.
- Excessive force will reduce the working efficiency and cause motor overload. Replacing
the accessory regularly will maintain optimum working efficiency.
Maintain tool with care

8
5. HEALTH & SAFETY INFORMATION
- NOTE: Remove plug from the socket before carrying out any adjustment, servicing or
maintenance.
- Your power tool requires no additional lubrication or maintenance. There are no user
serviceable parts in your power tool. Never use water or chemical cleaners to clean your
power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place.
Keep the motor ventilation slots clean. Keep all working controls free of dust.
Occasionally you may see sparks through the ventilation slots, this is normal and will not
damage your power tool.
If the supply cord is damaged, it must be replaced by the manufacturer, it's service agent
or similarly qualified persons in order to avid a hazard.
- This tool is designed for single or double handed operation (do not overload – let the
tool do the work).
Adopt a stable stance and make sure that the mains cable is prevented from coming into
contact with the machine or getting caught up on other objects preventing completion
of the task being done.
- Ensure that you have removed all foreign objects such as nails and screws from the work
piece before commencing sanding.
- For dry sanding only (not to be used for wet sanding).
- Avoid cutting into hidden electrical wiring, pipes or the power lead to this tool. Any
cutting of this type may result in electric shock, escape of water and possibly serious
injury – always use a residual current device (available separately).
- Contact with a “live” wire will make exposed metal parts of the tool "live" and create an
electrical shock risk to the operator.
- Only use accessories that are in good condition. Do not use if they are torn or worn.
- Do not touch any accessory whilst it is still moving.
- Do not treat the surface to be worked with solvent-containing fluids. Materials being
heated by the sanding friction can cause toxic vapours to develop.
- Keep your hands away from the cutting area. Do not reach under the material being cut.
- NOTE: Instruction that the maximum recommended diameter of mounted wheels,
threaded cones and plugs shall not exceed 35mm and that the maximum recommended
diameter of sanding accessories shall not exceed 15mm.
- WARNING: Do not touch the tip of the accessory after use, it will be very hot and may
create a burn risk.
- NOTE: The length range of accessories metal pole is 20-25mm.
When the metal pole is completely inserted into collet the maximum allowable overhang
length of the metal pole is 25mm.
5.3 CONNECTION TO THE POWER SUPPLY
Make sure the power supply information on the machine’s rating plate are compatible with
the power supply you intend to connect it to.
This product comes supplied with a UK standard 3 pin plug fitted. It is designed for
connection to a domestic power supply rated at 230V AC.
This appliance is Class II† and is designed for connection to a power supply matching that
detailed on the rating label and compatible with the plug fitted.
If an extension lead is required, use an approved and compatible lead rated for this
appliance. Follow all the instruction supplied with the extension lead.
†Double insulated : This product requires no earth connection as supplementary insulation
is applied to the basic insulation to protect against electric shock in the event of failure of the
basic insulation.
Apart from replacing the fuse in the plug, no other electrical work is recommended on this
machine.

9







6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION
 Hook
 On/Off Switch
 Spindle Lock
 Collar
 Collet nut
 Variable Speed Dial
 Plug and Cable

10


 
7.1 PACKAGING
Carefully remove the multi-tool from the packaging and examine it for any sign of damage
that may have happened during shipping. Lay the contents out and check them against the
parts shown below. If any part is damaged or missing; please contact the Draper Help Line
(the telephone number appears on the Title page) and do not attempt to use the multi-tool.
The packaging material should be retained at least during the guarantee period: in case the
machine needs to be returned for repair.
Warning! Some of the packaging materials used may be harmful to children. Do not leave
any of these materials in the reach of children.
If any of the packaging is to be thrown away, make sure they are disposed of correctly;
according to local regulations.
7.2 WHAT´S IN THE BOX?
As well as the multi-tool; there are several parts not fitted or attached to it.
NOTE: To ensure safe use do not use the following accessories faster than 10,000rpm (speed 1): Grinding
Stones, Sanding Discs, Cutting Discs, Soft ‘Bristle’ Brushes and Wire Brushes.
When you purchase additional accessories check the safe working speed is compatible with the tool.
 HSS drill bits x3
 Aluminium oxide grinding points x5
 Diamond grinding points x5
 Holder for cutting/sanding/grinding
discs
 Holder for felt polishing wheel
 Milling point x2
 Wire brush
 Nylon brush
 Holder for sanding drum (Large)
 Cloth polishing wheel
 Brass wheel
 Bristle wheel
 Sanding drums (large) x10
 Collets x5
 Grinding wheel x2
 Felt polishing wheels (large) x5
 Cutting disc 0.64mm x10
 Collet spanner/plain slot screwdriver
   
     
7. UNPACKING & CHECKING

11
8.1 SWITCHING ON AND OFF - FIG. 1
Press switch  into the 'I' position. This will start the
machine. Press switch to the 'O' position - this will stop
the machine.
Using the variable speed dial  will enable you to alter
the speed of the collet chuck:
Position 1 - SLOW
Position 3 - MEDIUM
Position 6 - FAST
Select the correct speed for the work and type of bit you
are using.
8.2 APPLICATIONS
Your multi-tool can be used for drilling, grinding,
polishing, milling and brushing. Other jobs like
engraving, cutting and removing rust are also possible. It
can be used on most wood, metal, glass and ceramics.
It is a good idea to practice on a scrap piece of material.
Best results are achieved by an even speed and pressure
(not too hard). Use lower speeds for larger tools and
higher speeds for smaller tools.
WARNING: Excessive force on this machine will cause the
motor to overheat and fail. This is not covered by the
guarantee.
8.3 HOLDING THE TOOL - FIGS. 2 - 3
For jobs such as milling or engraving where precision is
required, hold the multi-tool like a pen.
Care should be taken not to fully cover exhaust vents.
Covering the vents will cause the machine to overheat
and fail.
For heavier work like cutting or grinding hold the
multi-tool in the palm of your hand.
8.4 CHANGING BITS - FIG. 4
NOTE: Remove the plug from the socket before carrying
out adjustment, servicing or maintenance.
Choose from the five collets provided, the appropriate
size for the bit shank. If the size is not known, insert the
bit into the collet. The collet which offers a machine fit to
the bit is the correct one to use. Do not force the bit into
a collet.
Press spindle locking button  to stop the spindle from
rotating. Using the spanner , loosen the collet nut
.
Place the collet into the spindle and loosely replace the
nut.
NOTE: Do not over tighten the collet nut .




FIG.1
FIG.2
FIG.3
FIG.4
8. BASIC MULTI-TOOL OPERATIONS

12
8.5 FITTING A CUTTING/SANDING DISC -
FIG. 5
With the disc holder  in the chuck, remove the screw
using the plain slot screwdriver (incorporated in the
spanner handle tip). Leave one fibre washer on the
screw, place the cutting disc on the screw and fit the
second fibre washer, refit to the disc holder spindle.
(Do not over tighten).
8.6 FITTING THE SANDING DRUMS - FIG. 6
To fit a drum , firstly loosen the small screw in the
top of the holder . This will allow the rubber to
relax. Slide the sanding drum onto the holder. To secure
simply tighten the screw and the rubber drum will swell,
gripping the drum. (Do not over tighten).
WARNING: Excessive force on this machine will cause
the motor to overheat and fail. This is not covered by
the guarantee.
FIG.5
FIG.6



8. BASIC MULTI-TOOL OPERATIONS

13
9. MAINTENANCE
9 .1 MAINTENANCE & PARTS REPLACEMENT
Regular inspection and cleaning reduces the necessity for maintenance operations and will
keep your tool in good working condition.
The motor must be correctly ventilated during tool operation. For this reason avoid blocking
the air inlets. After use disconnect the tool from the power supply and vacuum the
ventilation slots.
If the replacement of the supply cord is necessary, this has to be done by the manufacturer or
his agent in order to avoid a safety hazard.

14
Stock No. Part No. Description Packed Qty
44479 APT41A Wire Brush 1
44480 APT42A Nylon Brush 1
44460 APT43A Holder for Cutting/Sanding/Grinding Disc 1
44473 APT44A Holder for Felt Wheels 1
44475 APT46A Milling Point 1
44476 APT47A Milling Point 1
44467 APT48A Diamond Grinding Point 1
44471 APT49A Diamond Grinding Point 1
44469 APT50A Diamond Grinding Point 1
44466 APT51A Diamond Grinding Point 1
44470 APT52A Diamond Grinding Point 1
63073 APT57 HSS Drill Bit 2.0mm 1
44465 APT59A Grinding Point 80 Grit 1
44461 APT60A Grinding Point 80 Grit 1
44462 APT61A Grinding Point 80 Grit 1
44463 APT62A Grinding Point 80 Grit 1
44464 APT63A Grinding Point 80 Grit 1
44456 APT66A Cutting Disc 120 Grit 0.64mm 30
44472 APT67A Felt Polishing Wheel 24mmØ 3
44475 APT68A Cloth Polishing Wheel 1
44454 APT69A Grinding Wheel 80 Grit 6
44477 APT71A Brass Wheel 1
44478 APT72A Bristle Wheel 1
86847 APT94 Sanding Drum 80 Grit (Large) 6
87366 APT102 Sanding Drum 150 Grit (Large) 6
86850 APT95 Holder for Sanding Drums (Large) 1
86851 APT96 1.6mm Collet 1
86852 APT97 2.0mm Collet 1
86853 APT98 2.4mm Collet 1
86854 APT99 3.0mm Collet 1
86855 APT100 3.2mm Collet 1
86856 APT101 Spanner/Plain Slot screwdriver 1
10. OPTIONAL ACCESSORIES

15
12. DISPOSAL
12.1 DISPOSAL
- At the end of the machine’s working life, or when it can no longer be repaired, ensure
that it is disposed of according to national regulations.
- Contact your local authority for details of collection schemes in your area.
In all circumstances:
• Do not dispose of power tools with domestic waste.
• Do not incinerate.
• Do not abandon in the environment.
• Do not dispose of WEEE*
as unsorted municipal waste.
* Waste Electrical & Electronic Equipment.
11. EXPLANATION OF SYMBOLS
11.1 EXPLANATION OF SYMBOLS
Warning!
Wear dust mask.
Warning!
Read the instruction manual
Warning!
Wear ear defenders.
WEEE
Do not dispose of Waste Electrical
& Electronic Equipment in with
domestic rubbish
Class II construction
(Double insulated).
Warning!
Wear suitable eye/face
protection.
Reference to
‘Welding’
removed from
eye/face
protection icon
wording.
05/08/16 CH

CONTACTS
- DRAPER TOOLS LIMITED,
Hursley Road, Chandler's Ford,
Eastleigh, Hampshire. SO53 1YF. U.K.
- Help Line: [phone]
- Sales Desk: [phone]
- General Enquiries: [phone]
- Service/Warranty Repair Agent
For aftersales servicing or warranty repairs, please
contact the Draper Tools Help Line for details of an
agent in your local area.
YOUR DRAPER STOCKIST
RDCH0816
drapertools.com
