Draytek Vigor2135 Series User manual

i

ii
Vigor2135
Gigabit Broadband Router
Quick Start Guide
Version: 1.0
Firmware Version: V4.2.1.2
(For future update, please visit DrayTek web site)
Date: December 16, 2020

Intellectual Property Rights (IPR) Information
Copyrights © All rights reserved. This publication contains information that is protected
by copyright. No part may be reproduced, transmitted, transcribed, stored in
a retrieval system, or translated into any language without written permission
from the copyright holders.
Trademarks The following trademarks are used in this document:
Microsoft is a registered trademark of Microsoft Corp.
Windows 8, 10 and Explorer are trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Inc.
Other products may be trademarks or registered trademarks of their
respective manufacturers.
Safety Instructions and Approval
Safety
Instructions
Read the installation guide thoroughly before you set up the router.
The router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the
router yourself.
Do not place the router in a damp or humid place, e.g. a bathroom.
Do not stack the routers.
The router should be used in a sheltered area, within a temperature
range of 0 to +45 Celsius.
Do not expose the router to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlight
or heat sources.
Do not deploy the cable for LAN connection outdoor to prevent
electronic shock hazards.
Keep the package out of reach of children.
When you want to dispose of the router, please follow local regulations
on conservation of the environment.
Warranty
We warrant to the original end user (purchaser) that the router will be free
from any defects in workmanship or materials for a period of two (2) years
from the date of purchase from the dealer. Please keep your purchase receipt
in a safe place as it serves as proof of date of purchase. During the warranty
period, and upon proof of purchase, should the product have indications of
failure due to faulty workmanship and/or materials, we will, at our discretion,
repair or replace the defective products or components, without charge for
either parts or labor, to whatever extent we deem necessary tore-store the
product to proper operating condition. Any replacement will consist of a new
or re-manufactured functionally equivalent product of equal value, and will
be offered solely at our discretion. This warranty will not apply if the product
is modified, misused, tampered with, damaged by an act of God, or subjected
to abnormal working conditions. The warranty does not cover the bundled or
licensed software of other vendors. Defects which do not significantly affect
the usability of the product will not be covered by the warranty. We reserve
the right to revise the manual and online documentation and to make changes
from time to time in the contents hereof without obligation to notify any
person of such revision or changes.
iii

iv
EU Declaration of Conformity
We DrayTek Corp. , office at No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 300,
Taiwan, declare under our sole responsibility that the product
Product name: Gigabit Broadband Router
Model number: Vigor2135 Series
Manufacturer: DrayTek Corp.
Address: No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 300,
Taiwan
is in conformity with the relevant Union harmonisation legislation:
EMC Directive 2014/30/EU , Low Voltage Directive 2014/35/EU , ErP 2009/125/EC and RoHS
2011/65/EU with reference to the following standards
Standard Version / Issue date
EN 55032 2012+AC:2013 class B
EN 61000-3-2 2014 Class A
EN 61000-3-3 2013
EN 55024 2010+A1:2015
EN 62368 2014+A11:2017
EC No. 1275/2008 2008
Hsinchu 10th Oct., 2020 Calvin Ma / President
(place) (date) (Legal Signature)

Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
Company name ABP International Inc.
Address 13988 Diplomat Drive Suite 180 Dallas TX 75234
ZIP Code 75234 E-mail [email protected]
USA Local
Representative Contact Person Mr. Robert Messer Tel. [phone]
External Power Supply ErP Information
*The external power supply used for each product will be model dependent.
1 2 3 4 5 6 7 8 9
A Manufacturer CWT CWT CWT CWT CWT APD APD APD APD
B Address No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No. 222, Sec.
2, Nankan Rd.,
Lujhu
Township,
Taoyuan
County 338,
Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
No.5, Lane 83,
Lung-Sou St.,
Taoyuan City
330, Taiwan
2ABB012F UK 2ABB018F UK 2ABL024F UK 2ABL030F UK 2ABN036F UK WA-12M12FG WB-18D12FG WA-24Q12FG WA-36A12FG C Model identifier 2ABB012F EU 2ABB018F EU 2ABL024F EU
2ABL030F EU 2ABN036F EU WA-12M12FK WB-18D12FK WA-24Q12FK WA-36A12FK
D Input voltage 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V
Input AC frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60HzE Output voltage DC 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V
F Output current 1.0A 1.5A 2.0A 2.5A 3.0A 1.0A 1.5A 2.0A 3.0A
G Output power 12.0W 18.0W 24.0W 30.0W 36.0W 12.0W 18.0W 24.0W 36.0W
H Average active
efficiency 84.9% 86.2% 87.6% 87.8% 89.8% 83.7% 85.4% 88.6% 88.2%
I Efficiency at low load
10% 73.6% 78.0% 81.3% 83.3% 83.7% 74.5% 80.5% 86.4% 85.4%
J No-load power
consumption 0.07W 0.07W 0.07W 0.07W 0.07W 0.07W 0.10W 0.07W 0.10W
For more update, please visit www.draytek.com.
v

vi
T
Ta ab bl le e o of f C Co on nt te en nt ts s
1. Package Content .................................................................................................. 1
2. Panel Explanation................................................................................................. 2
3. Hardware Installation ........................................................................................... 4
3.1 Network Connection................................................................................................................... 4
3.2 Wall-Mounted Installation........................................................................................................... 5
4. Software Configuration........................................................................................ 6
5. Customer Service................................................................................................11

1
1. . P Pa ac ck ka ag ge e C Co on nt te en nt t
Take a look at the package content. If there is anything missed or damaged,
please contact DrayTek or dealer immediately.
Vigor Router Quick Start Guide
RJ-45 Cat-5 Ethernet Cable
The type of the power adapter depends on the country that the router will be
installed. * The maximum power consumption is 15 Watts.
UK-type Power Adapter EU-type Power Adapter
USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter
Note
Remove the protective film from the router before use to
ensure ventilation.
1

2
2. . P Pa an ne el l E Ex xp pl la an na at ti io on n
L
LE ED D
LED Status Explanation
Blinking The router is powered on and running normally.
(Activity) Off The router is powered off.
On Internet connection is ready.
Blinking The data is transmitting.
WAN Off Internet connection is not ready.
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
1, 2
(for “V” model) Blinking A phone call comes.
On The LAN port is connected.
Blinking The data is transmitting.
~
LAN1/2/3/4 Off The LAN port is disconnected.
On A USB device is connected and active.
USB Blinking The data is transmitting.
2

C
Co on nn ne ec ct to or rs s
Interface Description
Factory Reset Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the router will
restart with the factory default configuration.
USB1~USB2 Connector for a USB device (USB Modem or printer).
P4~P1 Connectors for local networked devices.
WAN
Connector for remote networked devices (by Ethernet cable).
WAN (F/FV)
Connector for fiber connection for accessing the Internet.
Phone2/Phone1
(for “V” model) Connector of analog phone for VoIP communication.
ON/OFF Power switch.
PWR Connector for a power adapter.
3

3
3. . H Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This section will guide you to install the router through hardware connection and
configure the router’s settings through web browser.
Before starting to configure the router, you have to connect your devices
correctly. Here we take Vigor2135 as an example.
3
3. .1 1 N Ne et tw wo or rk k C Co on nn ne ec ct ti io on n
1. Connect the cable Modem/DSL Modem/Media Converter to any WAN port of
router with Ethernet cable (RJ-45).
2. Connect one port of 4-port switch to your computer with a RJ-45 cable. This
device allows you to connect 4 PCs directly.
3. Connect one end of the power cord to the power port of this device.
Connect the other end to the wall outlet of electricity.
4. Power on the router.
5. Check the ACT and WAN, LAN LEDs to assure network connection.
(For the detailed information of LED status, please refer to section 2. Panel
Explanation)
4

3
3. .2 2 W Wa al ll l- -M Mo ou un nt te ed d I In ns st ta al ll la at ti io on n
Vigor2135 series has keyhole type mounting slots on the underside.
1. A template is provided on the Vigor2135 packaging box to enable you to
space the screws correctly on the wall.
2. Place the template on the wall and drill the holes according to the
recommended instruction.
3. Fit screws into the wall using the appropriate type of wall plug.
Note
The recommended drill diameter shall be 6.5mm (1/4”).
4. When you finished about procedure, the router has been mounted on the
wall firmly.
5

4
4. . S So of ft tw wa ar re e C Co on nf fi ig gu ur ra at ti io on n
To access Internet, please finish basic configuration after completing the
hardware installation.
The Quick Start Wizard is designed for you to easily set up your router for
Internet access. You can directly access the Quick Start Wizard via Web
Configurator.
1. Make sure your PC connects to the router correctly. Here we take Vigor2135
as an example.
Note You may either simply set up your computer to get IP dynamically
from the router or set up the IP address of the computer to be the
same subnet as the default IP address of Vigor router
192.168.1.1. For the detailed information, please refer to the
section - Trouble Shooting in the User’s Guide.
2. Open a web browser on your PC and type http://192.168.1.1. A pop-up
window will open to ask for username and password. Please type
“admin/admin” as the Username/Password and click Login.
6

3. Now, the Main Screen will pop up. Click Wizards>>Quick Start Wizard.
Note The home page will change slightly in accordance with the router
you have.
4. Enter the login password on the field of New Password and retype it on the
field of Confirm Password. Then click Next to continue.
7

5. On the next page as shown below, please select the WAN interface that you
use and click Next. If Ethernet interface is used, please choose WAN1; if 3G
USB modem is used, please choose WAN3. Then click Next for next step.
6. On the following page, please select the appropriate protocol according to
the information from your ISP. For example, you should select PPPoE mode
if the ISP provides you PPPoE interface. Then click Next for next step.
8

PPPoE: If you click PPPoE as the protocol, after clicking Next, you will get
the following web page. Please manually enter the Username/Password
provided by your ISP. Then click Next.
PPTP/L2TP: if you click PPTP/L2TP, you will get the following page. Please
type in all the information originally provided by your ISP. Then click Next
for next step.
Static IP: if you click Static IP, you will get the following page. Please type in
the IP address information originally provided by your ISP. Then click Next
for next step.
9

DHCP: if you click DHCP, you will get the following page. Simply click Next
to continue.
10

11
7. Now you can see the following screen. It indicates that the setup is complete.
Different types of connection modes will have different summary. Click
Finish and then restart the router. Afterward, you will enjoy surfing on the
Internet.
5
5. . C Cu us st to om me er r S Se er rv vi ic ce e
If the router cannot work correctly after trying many efforts, please contact your
dealer/DrayTek for further help right away. For any questions, please feel free
to send e-mail to [email protected].
Be a Registered Owner
Web registration is preferred. You can register your Vigor router via
https://myvigor.draytek.com.
Firmware & Tools Updates
Due to the continuous evolution of DrayTek technology, all routers will be
regularly upgraded. Please consult the DrayTek web site for more information on
newest firmware, tools and documents.
https://www.draytek.com
