Draytek Vigor IPPBX 2820 User manual

VigorIPPBX 2820 Series
User’s Guide
Version: 2.7
Based on Firmware Version: V3.5.9
Date: 10/12/2013

VigorIPPBX 2820 Series User’s Guide
ii
Copyright Information
Copyright
Declarations
Copyright 2013 All rights reserved. This publication contains information that is
protected by copyright. No part may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language without written permission from the
copyright holders.
Trademarks
The following trademarks are used in this document:
Microsoft is a registered trademark of Microsoft Corp.
Windows, Windows 95, 98, Me, NT, 2000, XP, Vista and Explorer are
trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Inc.
Other products may be trademarks or registered trademarks of their respective
manufacturers.
Safety Instructions and Approval
Safety
Instructions
Read the installation guide thoroughly before you set up the router.
The router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the router
yourself.
Do not place the router in a damp or humid place, e.g. a bathroom.
The router should be used in a sheltered area, within a temperature range of +5 to
+40 Celsius.
Do not expose the router to direct sunlight or other heat sources. The housing and
electronic components may be damaged by direct sunlight or heat sources.
Do not deploy the cable for LAN connection outdoor to prevent electronic shock
hazards.
Keep the package out of reach of children.
When you want to dispose of the router, please follow local regulations on
conservation of the environment.
Warranty
We warrant to the original end user (purchaser) that the router will be free from any
defects in workmanship or materials for a period of two (2) years from the date of
purchase from the dealer. Please keep your purchase receipt in a safe place as it serves
as proof of date of purchase. During the warranty period, and upon proof of purchase,
should the product have indications of failure due to faulty workmanship and/or
materials, we will, at our discretion, repair or replace the defective products or
components, without charge for either parts or labor, to whatever extent we deem
necessary tore-store the product to proper operating condition. Any replacement will
consist of a new or re-manufactured functionally equivalent product of equal value, and
will be offered solely at our discretion. This warranty will not apply if the product is
modified, misused, tampered with, damaged by an act of God, or subjected to abnormal
working conditions. The warranty does not cover the bundled or licensed software of
other vendors. Defects which do not significantly affect the usability of the product will
not be covered by the warranty. We reserve the right to revise the manual and online
documentation and to make changes from time to time in the contents hereof without
obligation to notify any person of such revision or changes.
Be a Registered
Owner Web registration is preferred. You can register your Vigor router via
http://www.draytek.com.
Firmware & Tools
Updates Due to the continuous evolution of DrayTek technology, all routers will be regularly
upgraded. Please consult the DrayTek web site for more information on newest
firmware, tools and documents.
http://www.draytek.com

VigorIPPBX 2820 Series User’s Guide
iii
European Community Declarations
Manufacturer: DrayTek Corp.
Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu County, Taiwan
303
Product: VigorIPPBX 2820
DrayTek Corp. declares that VigorIPPBX 2820 of routers are in compliance with the following essential
requirements and other relevant provisions of R&TTE Directive 1999/5/EEC.
The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by
complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying with the
requirements set forth in EN60950-1.
Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause undesired operation.
Please visit http://www.draytek.com/user/SupportDLRTTECE.php#.
This product is designed for DSL, ISDN, and POTS network throughout the EC region and Switzerland with
restrictions in France. Please see the user manual for the applicable networks on your product.

VigorIPPBX 2820 Series User’s Guide
iv
T
Ta ab bl le e o of f C Co on nt te en nt ts s
Chapter 1: Introduction.....................................................................................................1
1.1 Web Configuration Buttons Explanation................................................................................. 1
1.2 LED Indicators and Connectors.............................................................................................. 2
1.2.1 For VigorIPPBX 2820 .......................................................................................................3
1.2.2 For VigorIPPBX 2820n ..................................................................................................... 5
1.3 Hardware Installation .............................................................................................................. 7
1.3.1 Installing Vigor Router ...................................................................................................... 7
1.3.2 ISDN Phone Adapter Installation...................................................................................... 8
1.3.3 Printer Installation............................................................................................................. 9
1.4 Web User Interface............................................................................................................... 13
1.4.1 Changing Password........................................................................................................ 13
1.4.2 Online Status.................................................................................................................. 16
1.4.3 Saving Configuration ......................................................................................................19
Chapter 2: Wizards for Easy Configuration...................................................................21
2.1 Quick Start Wizard ................................................................................................................ 21
2.1.1 PPPoE/PPPoA................................................................................................................ 22
2.1.2 1483 Bridged IP.............................................................................................................. 24
2.1.3 1483 Routed IP............................................................................................................... 25
2.2 IPPBX Wizard ....................................................................................................................... 26
2.2.1 Extension & Group Setup............................................................................................... 26
2.2.2 SIP Trunk Setup ............................................................................................................. 28
2.2.3 Office Hours Setup ......................................................................................................... 29
Chapter 3: IP PBX and ISDN Configuration...................................................................31
3.1 Extension for IP PBX............................................................................................................. 31
3.2 Trunks for IP PBX.................................................................................................................. 36
3.2.1 SIP Trunk........................................................................................................................ 37
3.2.2 ISDN Trunk..................................................................................................................... 43
3.2.3 PSTN Trunk.................................................................................................................... 45
3.2.4 Custom Trunk................................................................................................................. 46
3.3 Dial Plan for IP PBX.............................................................................................................. 49
3.3.1 Digit Map......................................................................................................................... 49
3.3.2 Speed Dial...................................................................................................................... 52
3.3.3 Call Barring..................................................................................................................... 53
3.4 PBX System for IP PBX........................................................................................................ 55
3.4.1 SIP Proxy Setting............................................................................................................ 55
3.4.2 PBX Service Number...................................................................................................... 57
3.4.3 Hunt Group..................................................................................................................... 59
3.4.4 Voice Mail /Virtual FAX Configuration ............................................................................ 63
3.4.5 Incoming Fax Rules........................................................................................................67
3.4.6 Office Hours.................................................................................................................... 69
3.4.7 Auto Attendant Wizard.................................................................................................... 70
3.4.8 Auto Attendant Setting....................................................................................................72
3.4.9 Prompt Maintenance....................................................................................................... 73

VigorIPPBX 2820 Series User’s Guide
v
3.4.10 Customer Survey..........................................................................................................77
3.4.11 Phone Setting............................................................................................................... 78
3.4.12 SIP Trunk and Extension Configuration Backup .......................................................... 95
3.5 PBX Status............................................................................................................................ 96
3.5.1 Call Detail Records......................................................................................................... 96
3.5.2 Fax Detail Records......................................................................................................... 97
3.5.3 Extension Monitor........................................................................................................... 97
4.5 General Setup for ISDN........................................................................................................ 97
3.7 ISDN CF Diagnosis............................................................................................................. 102
3.8 Dialing to a Single ISP for ISDN ......................................................................................... 102
3.9 Dialing to Dual ISPs for ISDN ............................................................................................. 104
3.10 Call Control for ISDN......................................................................................................... 106
Chapter 4: Applications and Tutorials..........................................................................108
4.1 Applications......................................................................................................................... 108
4.1.1 The Registration of 50 IP-based Telephone/Extensions.............................................. 108
4.1.2 The IP Registration from Remote Site (through WAN Connection) ............................. 109
4.1.3 The Integration IP Registration with SIP Server........................................................... 110
4.1.4 The Integration VoIP Communications via SIP Server................................................. 111
4.1.5 The Integration with PSTN telephony........................................................................... 112
4.1.6 The Added ISDN Telephony......................................................................................... 113
4.1.7 The Integrated ISDN line.............................................................................................. 114
4.1.8 The 4 B Channels of Two ISDN Lines.......................................................................... 115
4.1.9 The Integration of ISDN PBX with One ISDN Line....................................................... 116
4.1.10 The Integration of ISDN PBX with One ISDN Line-2.................................................. 117
4.1.11 The Deployment of ISDN PBX and PSTN Network ................................................... 118
4.1.12 The Integration of ISDN Telephony and PSTN Network............................................ 119
4.1.13 The Integration of ISDN Telephony, PSTN Network and VoIP Connection............... 120
4.2 Tutorials............................................................................................................................... 121
4.2.1 QoS Setting Example ................................................................................................... 121
4.2.2 LAN – Created by Using NAT....................................................................................... 124
4.2.3 How to achieve DID (Direct Inward Dialing) with SIP Alias?........................................ 126
4.2.4 How to use Call Parking? ............................................................................................. 130
4.2.5 How to set up VigorPhone 350 with VigorIPPBX2820 series by using Auto-Provisioning?
............................................................................................................................................... 132
4.2.6 How to configure Hunt Group?..................................................................................... 137
4.2.7 How to use Auto Attendant?......................................................................................... 141
4.2.8 How to use Voice Mail?................................................................................................ 147
4.2.9 How to configure and use the MWI on VigorIPPBX 2820?.......................................... 153
4.2.10 How to register extensions to VigorIPPBX 2820?...................................................... 156
4.2.11 How to configure and use ISDN-S0 MSN on VigorIPPBX 2820................................ 162
4.2.12 How to use call pickup via IPPBX router.................................................................... 165
4.2.13 How to Configure Hunt Group in VigorIPPBX Series................................................. 167
4.2.14 How to make a phone call for extensions in different IPPBX routers......................... 169
4.2.15 How to enhance the security for extensions' registration........................................... 173
4.2.16 How to Send a FAX via Virtual FAX in VigorIPPBX................................................... 175
4.2.17 How to Configure and Use the Queuing Function in Hunt Group.............................. 183
4.2.18 How to Set the Answering Machine for DrayTek Soft Phone..................................... 187
Chapter 5: Network Configuration ...............................................................................189
5.1 WAN.................................................................................................................................... 189

VigorIPPBX 2820 Series User’s Guide
vi
5.1.1 Basics of Internet Protocol (IP) Network....................................................................... 189
5.1.2 Network Connection by 3G USB Modem..................................................................... 190
5.1.3 General Setup............................................................................................................... 190
5.1.4 Internet Access............................................................................................................. 193
5.1.5 Multi-PVCs.................................................................................................................... 209
5.1.6 Load-Balance Policy..................................................................................................... 214
5.2 LAN ..................................................................................................................................... 216
5.2.1 Basics of LAN............................................................................................................... 216
5.2.2 General Setup............................................................................................................... 218
5.2.3 Static Route.................................................................................................................. 221
5.2.4 VLAN............................................................................................................................. 224
5.2.5 Bind IP to MAC............................................................................................................. 225
5.3 NAT ..................................................................................................................................... 226
5.3.1 Port Redirection............................................................................................................ 227
5.3.2 DMZ Host...................................................................................................................... 230
5.3.3 Open Ports.................................................................................................................... 232
5.3.4 Address Mapping.......................................................................................................... 234
5.3.5 Port Trigger................................................................................................................... 235
Chapter 6: Advanced Configuration.............................................................................239
6.1 Web Filter Activation ........................................................................................................... 239
6.2 Firewall................................................................................................................................ 243
6.3 Objects Settings.................................................................................................................. 257
6.4 CSM .................................................................................................................................... 266
6.5 Bandwidth Management ..................................................................................................... 278
6.6 Applications......................................................................................................................... 287
6.7 VPN and Remote Access.................................................................................................... 296
6.8 Certificate Management...................................................................................................... 315
6.9 Wireless LAN ...................................................................................................................... 318
6.10 USB Application ................................................................................................................ 334
6.11 System Maintenance......................................................................................................... 339
6.12 Diagnostics........................................................................................................................ 353
6.13 External Devices............................................................................................................... 361
Chapter 7: Trouble Shooting.........................................................................................363
7.1 Checking If the Hardware Status Is OK or Not.................................................................... 363
7.2 Checking If the Network Connection Settings on Your Computer Is OK or Not ................. 364
7.3 Pinging the Router from Your Computer............................................................................. 366
7.4 Checking If the ISP Settings are OK or Not........................................................................ 368
7.5 Problems for 3G Network Connection ................................................................................ 368
7.6 Backing to Factory Default Setting If Necessary ................................................................ 369
7.7 Contacting Your Dealer....................................................................................................... 370

VigorIPPBX 2820 Series User’s Guide
1
C
Ch ha ap pt te er r 1 1: : I In nt tr ro od du uc ct ti io on n
VigorIPPBX 2820, an ADSL router with IPPBX feature, provides policy-based load-balance,
fail-over and BOD (Bandwidth on Demand), also it integrates IP layer QoS, NAT
session/bandwidth management to help users control works well with large bandwidth.
By adopting hardware-based VPN platform and hardware encryption of AES/DES/3DS, the
router increases the performance of VPN greatly, and offers several protocols (such as
IPSec/PPTP/L2TP) with up to 32 VPN tunnels.
The object-based design used in SPI (Stateful Packet Inspection) firewall allows users to set
firewall policy with ease. CSM (Content Security Management) provides users control and
management in IM (Instant Messenger) and P2P (Peer to Peer) more efficiency than before.
By the way, DoS/DDoS prevention and URL/Web content filter strengthen the security
outside and control inside.
VigorIPPBX 2820 can provide up to 50 extensions setup to let all registered IP phones in
LAN or remote sites around the world to have unlimited free calls through Internet.
Moreover, VigorIPPBX 2820 is able to establish multiple networking architectures
corresponding to your current desire and future needs of growing communication. Its
ISDN/PSTN compatibility lets you move from simple VoIP solution such as IP phone and
Softphone to integrate with comprehensive networking infrastructure, such as ISDN and
Analog phone line any time you need.
Object-based firewall is flexible and allows your network be safe. In addition, through VoIP
function, the communication fee for you and remote people can be reduced.
1
1. .1 1 W We eb b C Co on nf fi ig gu ur ra at ti io on n B Bu ut tt to on ns s E Ex xp pl la an na at ti io on n
Several main buttons appeared on the web pages are defined as the following:
Save and apply current settings.
Cancel current settings and recover to the previous saved settings.
Clear all the selections and parameters settings, including selection from
drop-down list. All the values must be reset with factory default settings.
Add new settings for specified item.
Edit the settings for the selected item.
Delete the selected item with the corresponding settings.
Note: For the other buttons shown on the web pages, please refer to Chapter 4 for detailed
explanation.

VigorIPPBX 2820 Series User’s Guide
2
1
1. .2 2 L LE ED D I In nd di ic ca at to or rs s a an nd d C Co on nn ne ec ct to or rs s
Before you use the Vigor router, please get acquainted with the LED indicators and
connectors first.
The displays of LED indicators and connectors for the routers are different slightly. The
following sections will introduce them respectively. If the model of router you have does not
support ISDN and/or VoIP function, simply ignore the relational description.
D
De ef fi in ni it ti io on ns s f fo or r I IS SD DN N P Po or rt ts s
Below shows the names that displayed on front panel of the device and the WEB UI of this
device.
Both ISDN1 and ISDN2 port on front panel of the device are configurable for connecting
phone or accessing Internet according to the settings that you adjust on WEB UI.
ISDN1-TE /ISDN2-TE (shown on WEB UI) is a port that used to connect ISDN line.
ISDN1-S0/ISDN2-S0 (shown on WEB UI) is a port that used to connect ISDN phone.
Please refer to IP PBX>>PBX System>>Phone Settings in this User’s Guide for detailed
information.
Warning: When the orange LED lights (means ISDN NT mode), the ISDN
port can be used to connect phone only. Wrong ISDN connection might cause
severe damage on your device.

VigorIPPBX 2820 Series User’s Guide
3
1
1. .2 2. .1 1 F Fo or r V Vi ig go or rI IP PP PB BX X 2 28 82 20 0
LED Status Explanation
Blinking The router is powered on and running normally.ACT (Activity) Off The router is powered off.
On A USB device is connected and active.USB Blinking The data is transmitting.
CSM On The profile of CSM (Content Security Management) for
IM/P2P application is enabled from Firewall >>
General Setup. (Such profile is established under
CSM menu).
VPN On VPN tunnel is up and down.
On The router is ready to access Internet through DSL link.DSL Blinking Slowly: The modem is ready.
Quickly: The connection is training.
On The WAN2 connection is ready.WAN 2 Blinking It will blink while transmitting data.
On A PSTN phone call comes (in and out). However, when
the phone call is disconnected, the LED will be off
about six seconds later.
Line
Off There is no PSTN phone call.
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
Phone
Blinking A phone call comes.
QoS On The QoS function is active.
LED on Connector
On ISDN-S0 (ISDN-NT) mode is active configured from
IP PBX>>PBX System>>Phone Settings and an
ISDN phone adapter is connected.
Blinking ISDN S0 (ISDN-NT) mode configured from IP
PBX>>PBX System>>Phone Settings is active and an
ISDN phone adapter is not connected.
Left LED
(Orange)
Off It means ISDN TE mode is active which is configured
from IP PBX>>PBX System>>Phone Settings.
On A phone adapter with phone set has been connected
(ISDN-S0) or ISDN line has been connected
(ISDN-TE).
Blinking ISDN-S0 (ISDN-NT) mode, it means an ISDN phone is
off-hook or a phone call comes.
In ISDN-TE mode, it means data, fax or voice (phone
call) is transmitting.
ISDN1/2
Right LED
(Green)
Off It will be off if there is nothing connected.
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 1000Mbps.
LAN 1(Giga)
Right LED
(Green) Off The port is connected with 10/100Mbps.

VigorIPPBX 2820 Series User’s Guide
4
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 100Mbps.
LAN 2/3/4
Right LED
(Green) Off The port is connected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 100Mbps.
WAN 2
Right LED
(Green) Off The port is connected with 10Mbps.
Interface Description
Factory Reset Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and keep
for more than 5 seconds. When you see the ACT LED begins to blink rapidly
than usual, release the button. Then the router will restart with the factory
default configuration.
ISDN1/2 Connecter for ISDN line or ISDN phone adapter in particular condition.
Refer to section 2.2 for more details.
Phone Connecter for PSTN phone.
Line Connector for PSTN life line.
LAN (1-4) Connecters for local networked devices.
DSL Connecter for accessing the Internet through ADSL2/2+.
WAN 2 Connecter for remote networked devices.
USB Connecter for a USB device (for 3G USB Modem or printer).
PWR Connecter for a power adapter.
ON/OFF Power Switch.

VigorIPPBX 2820 Series User’s Guide
5
1
1. .2 2. .2 2 F Fo or r V Vi ig go or rI IP PP PB BX X 2 28 82 20 0n n
LED Status Explanation
Blinking The router is powered on and running normally.ACT (Activity) Off The router is powered off.
On A USB device is connected and active.USB Blinking The data is transmitting.
CSM On The profile of CSM (Content Security Management) for
IM/P2P application is enabled from Firewall >>
General Setup. (Such profile is established under
CSM menu).
On Wireless access point is ready.
WLAN Blinking It will blink while wireless traffic goes through.
If ACT and WLAN LEDs blink simultaneously when
WPS is working, and it will return to normal condition
after two minutes. (You need to setup WPS within 2
minutes.)
On The router is ready to access Internet through DSL link.DSL Blinking Slowly: The modem is ready.
Quickly: The connection is training.
On The WAN2 connection is ready.WAN 2 Blinking It will blink while transmitting data.
On A PSTN phone call comes (in and out). However, when
the phone call is disconnected, the LED will be off
about six seconds later.
Line
Off There is no PSTN phone call.
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
Phone
Blinking A phone call comes.
QoS On The QoS function is active.
LED on Connector
On ISDN-S0 (ISDN-NT) mode is active configured from
IP PBX>>PBX System>>Phone Settings and an
ISDN phone adapter is connected.
Blinking ISDN S0 (ISDN-NT) mode configured from IP
PBX>>PBX System>>Phone Settings is active and an
ISDN phone adapter is not connected.
Left LED
(Orange)
Off It means ISDN TE mode is active which is configured
from IP PBX>>PBX System>>Phone Settings.
On A phone adapter with phone set has been connected
(ISDN-S0) or ISDN line has been connected
(ISDN-TE).
ISDN1/2
Right LED
(Green)
Blinking ISDN-S0 (ISDN-NT) mode, it means an ISDN phone is
off-hook or a phone call comes.
In ISDN-TE mode, it means data, fax or voice (phone
call) is transmitting.

VigorIPPBX 2820 Series User’s Guide
6
Off It will be off if there is nothing connected.
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 1000Mbps.
LAN 1(Giga)
Right LED
(Green) Off The port is connected with 10/100Mbps.
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 100Mbps.
LAN 2/3/4
Right LED
(Green) Off The port is connected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 100Mbps.
WAN 2
Right LED
(Green) Off The port is connected with 10Mbps.
Interface Description
Factory Reset Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and keep
for more than 5 seconds. When you see the ACT LED begins to blink rapidly
than usual, release the button. Then the router will restart with the factory
default configuration.
ISDN1/2 Connecter for ISDN line or ISDN phone adapter in particular condition.
Refer to section 2.2 for more details.
Phone Connecter for PSTN phone.
Line Connector for PSTN life line.
LAN (1-4) Connecters for local networked devices.
DSL Connecter for accessing the Internet through ADSL2/2+.
WAN 2 Connecter for remote networked devices.
USB Connecter for a USB device (for 3G USB Modem or printer).
PWR Connecter for a power adapter.
ON/OFF Power Switch.

VigorIPPBX 2820 Series User’s Guide
7
1
1. .3 3 H Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
1
1. .3 3. .1 1 I In ns st ta al ll li in ng g V Vi ig go or r R Ro ou ut te er r
Before starting to configure the router, you have to connect your devices correctly.
1. Connect the ADSL interface to the external ADSL splitter with an ADSL line cable.
Also, connect Line interface to an external ADSL splitter.
For second WAN, connect the cable Modem/DSL Modem/Media Converter to WAN2
port of router with Ethernet cable (RJ-45).
2. Connect one end of an Ethernet cable (RJ-45) to one of the LAN ports of the router and
the other end of the cable (RJ-45) into the Ethernet port on your computer.
Note: It is strongly recommended to connect to Ethernet port on your computer with
a shielding cable provided with the router.
3. Connect the telephone sets with phone lines (for using VoIP function). For the model
without phone ports, skip this step.
4. Connect one end of the power adapter to the router’s power port on the rear panel, and
the other side into a wall outlet.
5. Power on the device by pressing down the power switch on the rear panel.
6. The system starts to initiate. After completing the system test, the ACT LED will light
up and start blinking.
(For the detailed information of LED status, please refer to section 1.2.)

VigorIPPBX 2820 Series User’s Guide
8
Caution: Each of the Phone ports can be connected to an analog phone only. Do not
connect the phone ports to the telephone wall jack. Such connection might damage
your router.
1
1. .3 3. .2 2 I IS SD DN N P Ph ho on ne e A Ad da ap pt te er r I In ns st ta al ll la at ti io on n
ISDN1/2 port is configurable as NT or TE mode. When the user configures ISDN port as NT
mode in IP PBX>>PBX System>>Phone Settings, the orange LED will light on to indicate
ISDN-NT is selected. And by using ISDN phone adapters (coming from the router package),
the user can connect several phones to the router for communication. Refer to the following
figure for reference.
Yet, if the user configures ISDN port as TE Mode in IP PBX>>PBX System>>Phone
Settings, the green LED will light on to indicate ISDN-TE is selected. Then, the port is
specified for ISDN line only. Refer to the following figure for reference.

VigorIPPBX 2820 Series User’s Guide
9
Note: ISDN Phone MUST be connected to ISDN port via an ISDN Phone Adapter. Do not
connect the ISDN phone(s) to the ISDN port of the router directly for it cannot be used
normally.
1
1. .3 3. .3 3 P Pr ri in nt te er r I In ns st ta al ll la at ti io on n
You can install a printer onto the router for sharing printing. All the PCs connected this
router can print documents via the router. The example provided here is made based on
Windows XP/2000. For Windows 98/SE, please visit www.draytek.com.
Before using it, please follow the steps below to configure settings for connected computers
(or wireless clients).
1. Connect the printer with the router through USB/parallel port.
2. Open Start>>Settings>> Printer and Faxes.

VigorIPPBX 2820 Series User’s Guide
10
3. Open File>>Add a New Computer. A welcome dialog will appear. Please click Next.
4. Click Local printer attached to this computer and click Next.
5. In this dialog, choose Create a new port Type of port and use the drop down list to
select Standard TCP/IP Port. Click Next.

VigorIPPBX 2820 Series User’s Guide
11
6. In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer
Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next.
7. Click Standard and choose Generic Network Card.
8. Then, in the following dialog, click Finish.

VigorIPPBX 2820 Series User’s Guide
12
9. Now, your system will ask you to choose right name of the printer that you installed
onto the router. Such step can make correct driver loaded onto your PC. When you
finish the selection, click Next.
10. For the final stage, you need to go back to Control Panel >> Printers and edit the
property of the new printer you have added.
11. Select LPR on Protocol, type p1 (number 1) as Queue Name. Then click OK. Next
please refer to the red rectangle for choosing the correct protocol and LPR name.
The printer can be used for printing now. Most of the printers with different manufacturers are
compatible with vigor router.
