Draytek VigorIPPBX 3510 Series User manual

VigorIPPBX 3510 Quick Start Guid
i

VigorIPPBX 3510 Quick Start Guide ii

VigorIPPBX 3510 Quick Start Guid
iii
VigorIPPBX 3510
Quick Start Guide
Version: 2.0
Date: 19/11/2010

VigorIPPBX 3510 Quick Start Guide iv
Copyright Information
Copyright
Declarations
Copyright 2010 All rights reserved. This publication contains information that is
protected by copyright. No part may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language without written
permission from the copyright holders.
Trademarks
The following trademarks are used in this document:
zMicrosoft is a registered trademark of Microsoft Corp.
zWindows, Windows 95, 98, Me, NT, 2000, XP, Vista and Explorer are
trademarks of Microsoft Corp.
zApple and Mac OS are registered trademarks of Apple Inc.
zOther products may be trademarks or registered trademarks of their
respective manufacturers.
Safety Instructions and Approval
Safety
Instructions
zRead the installation guide thoroughly before you set up the router.
zThe router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the router
yourself.
zDo not place the router in a damp or humid place, e.g. a bathroom.
zDo not stack the routers.
zThe router should be used in a sheltered area, within a temperature range
of +5 to +40 Celsius.
zDo not expose the router to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlight or
heat sources.
zDo not deploy the cable for LAN connection outdoor to prevent electronic
shock hazards.
zKeep the package out of reach of children.
zWhen you want to dispose of the router, please follow local regulations on
conservation of the environment.
Warranty
We warrant to the original end user (purchaser) that the router will be free from
any defects in workmanship or materials for a period of two (2) years from the
date of purchase from the dealer. Please keep your purchase receipt in a safe
place as it serves as proof of date of purchase. During the warranty period, and
upon proof of purchase, should the product have indications of failure due to
faulty workmanship and/or materials, we will, at our discretion, repair or replace
the defective products or components, without charge for either parts or labor, to
whatever extent we deem necessary tore-store the product to proper operating
condition. Any replacement will consist of a new or re-manufactured
functionally equivalent product of equal value, and will be offered solely at our
discretion. This warranty will not apply if the product is modified, misused,
tampered with, damaged by an act of God, or subjected to abnormal working
conditions. The warranty does not cover the bundled or licensed software of
other vendors. Defects which do not significantly affect the usability of the
product will not be covered by the warranty. We reserve the right to revise the
manual and online documentation and to make changes from time to time in the
contents hereof without obligation to notify any person of such revision or
changes.
Be a Registered
Owner Web registration is preferred. You can register your Vigor router via
http://www.draytek.com.
Firmware & Tools
Updates Due to the continuous evolution of DrayTek technology, all routers will be
regularly upgraded. Please consult the DrayTek web site for more information on
newest firmware, tools and documents.
http://www.draytek.com

VigorIPPBX 3510 Quick Start Guid
v
European Community Declarations
Manufacturer: DrayTek Corp.
Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu County,
Taiwan 303
Product: VigorIPPBX 3510
DrayTek Corp. declares that VigorIPPBX 3510 is in compliance with the following essential requirements
and other relevant provisions of R&TTE Directive 1999/5/EEC.
The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive
2004/108/EC by complying with the requirements set forth in EN55022/Class A and EN55024/Class A.
The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying
with the requirements set forth in EN60950-1.
Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
zConsult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause undesired
operation.
Please visit http://www.draytek.com/user/AboutRegulatory.php.
This product is designed for POTS network throughout the EC region and Switzerland. Please see the user
manual for the applicable networks on your product.

VigorIPPBX 3510 Quick Start Guide vi

VigorIPPBX 3510 Quick Start Guid
vii
T
Ta ab bl le e o of f C Co on nt te en nt ts s
1. Introduction........................................................................................................... 1
1.1 Panel Explanation ...................................................................................................................... 2
1.2 Package Content........................................................................................................................ 4
2. Installing Your Router........................................................................................... 5
2.1 Hardware Installation.................................................................................................................. 5
2.2 Printer Installation....................................................................................................................... 6
3. Configuring Web Pages ......................................................................................11
4. Trouble Shooting................................................................................................ 17
4.1 Checking If the Hardware Status Is OK or Not......................................................................... 17
4.2 Checking If the Network Connection Settings on Your Computer Is OK or Not ...................... 18
4.3 Pinging the Router from Your Computer.................................................................................. 20
4.4 Checking If the ISP Settings are OK or Not............................................................................. 21
4.5 Backing to Factory Default Setting If Necessary...................................................................... 23
4.6 Contacting Your Dealer ............................................................................................................ 24

VigorIPPBX 3510 Quick Start Guide viii

VigorIPPBX 3510 Quick Start Guide
1
1
1. . I In nt tr ro od du uc ct ti io on n
The VigorIPPBX 3510 is a dual-WAN broadband router with IP PBX function. The 2nd
WAN interface is shared with the 4th LAN port. These two WANs can connect to
DSL/Cable modem or fiber media converter for policy-based load-balance, fail-over and
BoD (Bandwidth on Demand); it also features advanced bandwidth control mechanism
such as IP-layer QoS, NAT Session Limitation, Bandwidth Borrowed, etc., to allow easy,
flexible, reliable access control and bandwidth management.
VigorIPPBX 3510 is an IPPBX device which must connect to a router by WAN port for
accessing into Internet.
The SPI (Stateful Packet Inspection) firewall on VigorIPPBX 3510 uses object-based
design to make settings of firewall policies easy. The CSM (Content Security
Management) feature allows more precise and efficient access control for URL/Web
Content Filtering, IM (Instant Messenger) and P2P (Peer to Peer) applications.
With hardware-based implementation of the VPN protocols, the VigorIPPBX 3510
supports up to 32 VPN tunnels using advanced protocols such as IPSec/PPTP/L2TP with
AES/DES/3DES for encryption and MD5/SHA-1 for authentication.
VigorIPPBX 3510 can provide up to 100 extensions setup to let all IP phones register to
LAN or remote sites around the world to have unlimited free calls through Internet.
Moreover, VigorIPPBX 3510 is able to establish multiple networking architectures
corresponding to your current desire and future needs of growing communication. Its
PSTN compatibility lets you move from simple VoIP solution such as IP phone and
Softphone to integrate with comprehensive networking infrastructure, such as Analog
phone line any time you need.

VigorIPPBX 3510 Quick Start Guide 2
1
1. .1 1 P Pa an ne el l E Ex xp pl la an na at ti io on n
D
De es sc cr ri ip pt ti io on n f fo or r L LE ED D
LED Status Explanation
On The router is powered on.PWR (Power) Off The router is powered off.
Blinking The router is powered on and running normally.ACT (Activity) Off The router is not ready or failed.
On The WAN connection is ready.WAN Blinking It will blink while transmitting data.
On CDR utility has been installed and is recording.CDR Off CDR utility has not been installed and is unable to
record.
On A USB device is connected and active.USB Blinking The data is transmitting.
MSF Blinking
Storage (NAND flash or USB disk) is full.
VPN On The VPN tunnel is active.
CSM On The profiles of CSM (Content Security Management)
for IM/P2P, URL Content Filter, Web Content Filter
application is enabled from Firewall >> General
Setup. (These profile can be established under CSM
menu).
QoS On The QoS function is active.
LED on Connector
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 100Mbps.
LAN 1/2/3/4*
Right LED
(Green) Off The port is connected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Left LED
(Green)
Blinking The data is transmitting.
On The port is connected with 100Mbps.
WAN1/2*
Right LED
(Green) Off The port is connected with 10Mbps.
* LAN 4 and WAN 2 share the same connector.

VigorIPPBX 3510 Quick Start Guide
3
D
De es sc cr ri ip pt ti io on n f fo or r C Co on nn ne ec ct to or rs s
Interface Description
Factory Reset Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and keep for more
than 5 seconds. When you see the ACT LED begins to blink rapidly than usual,
release the button. Then the router will restart with the factory default configuration.
FXS Connecter for telephone set.
FXO Connecter for FXS interface of PABX or PSTN line.
LAN (1-4) Connecters for local networked devices.
WAN Connecter for accessing Internet.
USB Connecter for a USB device (for 3G USB Modem or printer).
PWR Connecter for a power cord.
ON/OFF Power switch.

VigorIPPBX 3510 Quick Start Guide 4
1
1. .2 2 P Pa ac ck ka ag ge e C Co on nt te en nt t
nQuick Start Guide oCD
pRJ-45 Cable (Ethernet) qRack mount kit (brackets)
rFXO (optional) sFXS (optional)
tThe type of the power cord depends on the country that the router will be installed.
UK-type power cord EU-type power cord
USA/Taiwan-type power cord AU/NZ-type power cord
China-type power cord

VigorIPPBX 3510 Quick Start Guide
5
2
2. . I In ns st ta al ll li in ng g Y Yo ou ur r R Ro ou ut te er r
This section will guide you to install the router through hardware connection and
configure the router’s settings through web browser.
2
2. .1 1 H Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
Before starting to configure the router, you have to connect your devices correctly.
1. Connect the cable Modem/DSL Modem/Media Converter to WAN port of router
with Ethernet cable (RJ-45).
2. Connect one end of an Ethernet cable (RJ-45) to one of the LAN ports of the router
and the other end of the cable (RJ-45) into the Ethernet port on your computer.
3. Connect the telephone sets with phone lines (for using PBX function). For the model
without phone ports, skip this step.
4. Connect IP Phone(s) via VigorSwitch to this router.
5. Connect one end of the power adapter to the router’s power port on the rear panel,
and the other side into a wall outlet.
6. Power on the device by pressing down the power switch on the rear panel.
7. The system starts to initiate. After completing the system test, the PWR and ACT
LEDs will light up and start blinking.
(Below we take VigorIPPBX 3510 as an example for hardware installation.)

VigorIPPBX 3510 Quick Start Guide 6
2
2. .2 2 P Pr ri in nt te er r I In ns st ta al ll la at ti io on n
You can install a printer onto the router for sharing printing. All the PCs connected this
router can print documents via the router. The example provided here is made based on
Windows XP/2000/Vista. For Windows 98/SE, please visit www.draytek.com.
Before using it, please follow the steps below to configure settings for connected
computers.
1. Connect the printer with the router through USB/parallel port.
2. Open Start->Settings-> Printer and Faxes.

VigorIPPBX 3510 Quick Start Guide
7
3. Open File->Add a New Computer. A welcome dialog will appear. Please click
Next.
4. Click Local printer attached to this computer and click Next.
5. In this dialog, choose Create a new port Type of port and use the drop down list to
select Standard TCP/IP Port. Click Next.

VigorIPPBX 3510 Quick Start Guide 8
6. In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer
Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next.
7. Click Standard and choose Generic Network Card.
8. Then, in the following dialog, click Finish.

VigorIPPBX 3510 Quick Start Guide
9
9. Now, your system will ask you to choose right name of the printer that you installed
onto the router. Such step can make correct driver loaded onto your PC. When you
finish the selection, click Next.
10. For the final stage, you need to go back to Control Panel-> Printers and edit the
property of the new printer you have added.
11. Select "LPR" on Protocol, type p1 (number 1) as Queue Name. Then click OK.
Next please refer to the red rectangle for choosing the correct protocol and LPR
name.

VigorIPPBX 3510 Quick Start Guide 10
The printer can be used for printing now. Most of the printers with different
manufacturers are compatible with vigor router.
Note 1: Some printers with the fax/scanning or other additional functions are not
supported. If you do not know whether your printer is supported or not, please visit
www.draytek.com to find out the printer list. Open Support >FAQ; find out the link
of Printer Server and click it; then click the What types of printers are
compatible with Vigor router? link.
Note 2: Vigor router supports printing request from computers via LAN ports but not
WAN port.

VigorIPPBX 3510 Quick Start Guide
11
3
3. . C Co on nf fi ig gu ur ri in ng g W We eb b P Pa ag ge es s
To access Internet, please finish basic configuration after completing the hardware
installation.
The Quick Start Wizard is designed for you to easily set up your router for Internet
access. You can directly access the Quick Start Wizard via Web Configurator.
1. Make sure your PC connects to the router correctly.
Notice: You may either simply set up your computer to get IP dynamically
from the router or set up the IP address of the computer to be the same
subnet as the default IP address of Vigor router 192.168.1.1. For the
detailed information, please refer to the later section - Trouble Shooting of
the guide.
2. Open a web browser on your PC and type http://192.168.1.1. A pop-up window will
open to ask for username and password. Please type “admin” as the username and
leave blank for the password on the window. Next click OK for next screen.
Notice: If you fail to access to the web configuration, please go to “Trouble
Shooting” for detecting and solving your problem.
3. Now, the Main Screen will pop up. Click Quick Start Wizard.

VigorIPPBX 3510 Quick Start Guide 12
Note: The home page will change slightly in accordance with the router you have.
4. Enter the login password on the field of New Password and retype it on the field of
Confirm Password. Then click Next to continue.
5. On the next page as shown below, please select the WAN interface (WAN 1 or
WAN2) that you use. If WAN1 interface is used, please choose WAN1; if WAN2
interface is used, please choose WAN2. Choose Auto negotiation as the physical
type for your router. Then click Next for next step.
