Draytek VigorAP 1062C User manual

i
VigorAP 1062C
802.11ax Ceiling-mount Access
Point
Quick Start Guide
Version: 1.0_(draft)
Firmware Version: V1.4.0
(For future update, please visit DrayTek web site)
Date: July 12, 2022

i
Intellectual Property Rights (IPR) Information
Copyrights
© All rights reserved. This publication contains information that is protected
by copyright. No part may be reproduced, transmitted, transcribed, stored in
a retrieval system, or translated into any language without written permission
from the copyright holders.
Trademarks
The following trademarks are used in this document:
Microsoft is a registered trademark of Microsoft Corp.
Windows, Windows 8, 10, 11 and Explorer are trademarks of Microsoft
Corp.
Apple and Mac OS are registered trademarks of Apple Inc.
Other products may be trademarks or registered trademarks of their
respective manufacturers.
Safety Instructions and Approval
Safety
Instructions
Read the installation guide thoroughly before you set up the device.
The device is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the
device yourself.
Do not place the device in a damp or humid place, e.g. a bathroom.
Do not stack the devices.
The device should be used in a sheltered area, within a temperature
range of 0 to +45 Celsius.
Do not expose the device to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlight
or heat sources.
Do not deploy the cable for LAN connection outdoor to prevent
electronic shock hazards.
Keep the package out of reach of children.
When you want to dispose of the device, please follow local regulations
on conservation of the environment.
Warranty
We warrant to the original end user (purchaser) that the device will be free
from any defects in workmanship or materials for a period of one (1) year from
the date of purchase from the dealer. Please keep your purchase receipt in a
safe place as it serves as proof of date of purchase. During the warranty
period, and upon proof of purchase, should the product have indications of
failure due to faulty workmanship and/or materials, we will, at our discretion,
repair or replace the defective products or components, without charge for
either parts or labor, to whatever extent we deem necessary tore-store the
product to proper operating condition. Any replacement will consist of a new
or re-manufactured functionally equivalent product of equal value, and will
be offered solely at our discretion. This warranty will not apply if the product
is modified, misused, tampered with, damaged by an act of God, or subjected
to abnormal working conditions. The warranty does not cover the bundled or
licensed software of other vendors. Defects which do not significantly affect
the usability of the product will not be covered by the warranty. We reserve
the right to revise the manual and online documentation and to make changes
from time to time in the contents hereof without obligation to notify any
person of such revision or changes.

ii
Declaration of Conformity
Hereby, DrayTek Corporation declares that the radio equipment type VigorAP 1062C is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://fw.draytek.com.tw/VigorAP 1062C/Document/CE/
Manufacturer: DrayTek Corp.
Address: No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan
Product: VigorAP 1062C
Frequency Information for Europe area:
2.4G WLAN
2412MHz - 2472 MHz, max. TX power: 19.95 dBm
5G WLAN
5160MHz - 5340 MHz, max. TX power: 22.84 dBm ;
5480MHz - 5720 MHz, max. TX power: 28.14 dBm
Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/
CY/LV/LI/LT/ LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/ UK/HR.
5150MHz~5350MHz is for indoor use only.
This product is designed for 2.4GHz and 5GHz WLAN network throughout the EC region.
Declaration of Conformity
Hereby, DrayTek Corporation declares that the radio equipment type VigorAP 1062C is in compliance
with Regulation SI 2017 No. 1206.
The full text of the UKCA Declaration of Conformity is available at the following internet address:
https://fw.draytek.com.tw/VigorAP 1062C/Document/UKCA/
Manufacturer: DrayTek Corp.
Address: No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan
Product: VigorAP 1062C
Importer: CMS Distribution Ltd: Bohola Road, Kiltimagh, Co Mayo, Ireland
Frequency Information for UK area:
2.4G WLAN
2412MHz - 2472 MHz, max. TX power: 19.98dBm
5G WLAN
5160MHz - 5340 MHz, max. TX power: 22 dBm
5480MHz - 5720 MHz, max. TX power: 27 dBm
Requirements in UK. 5150MHz~5350MHz is for indoor use only.
This product is designed 2.4GHz and 5GHz WLAN network use in the UK & Ireland.

iii
Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause
undesired operation.
USA Local
Representative
Company name
ABP International Inc.
Address
13988 Diplomat Drive Suite 180 Dallas TX 75234
ZIP Code
75234
E-mail
[email protected]
Contact Person
Mr. Robert Messer
Tel.
19728311600
Caution
Any changes or modifications not expressly approved by the grantee of this device could void the
user's authority to operate the equipment.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

iv
External Power Supply ErP Information
1
2
3
A
Manufacturer
DVE
DVE
AMIGO
B
Address
No.5, Baogao Rd,
Xindian Dist, New
Taipei City (23144),
Taiwan
No.5, Baogao Rd,
Xindian Dist, New
Taipei City (23144),
Taiwan
No.20, Qianyang First
Road, Yun-Mao-Tsun,
San Xing, Zhongshan,
Guangdong, China
C
Model identifier
DSA-12PF09-12 FUK
DSA-18PFR-12 FUK
AMS2000-1202000FV
DSA-12PF09-12 FEU
DSA-18PFR-12 FEU
AMS2000-1202000FB
D
Input voltage
100~240V
100~240V
100~240V
E
Input AC frequency
50/60Hz
50/60Hz
50/60Hz
Output voltage DC
12.0V
12.0V
12V
F
Output current
1.0A
1.5A
2A
G
Output power
12.0W
18.0W
24.0W
H
Average active efficiency
83.3%
85.5%
86.2%
I
Efficiency at low load 10%
80.8%
83.7%
79.1%
J
No-load power consumption
0.06W
0.07W
0.10W
*The external power supply used for each product will be model dependent.
For more update, please visit www.draytek.com.

v
T
Ta ab bl le e o of f C Co on nt te en nt ts s
1. Package Content .................................................................................................. 1
2. Panel Explanation................................................................................................. 2
3. Installation............................................................................................................. 3
3.1 Ceiling-mount Installation (Wooden Ceiling).............................................................................. 3
3.2 Ceiling-mount Installation (Plasterboard Ceiling)....................................................................... 4
3.3 Suspended Ceiling Installation................................................................................................... 5
4. Connection and Configuration............................................................................ 7
4.1 Notifications for Hardware Connection....................................................................................... 7
4.2 Web Configurations.................................................................................................................... 8
5. Customer Service............................................................................................... 10
Be a Registered Owner.................................................................................................................. 10
Firmware & Tools Updates ............................................................................................................. 10

1
1
1. . P Pa ac ck ka ag ge e C Co on nt te en nt t
Take a look at the package content. If there is anything missed or damaged,
please contact DrayTek or dealer immediately.
VigorAP 1062C Main Unit
Quick Start Guide
Kits & Screws
(Used for T-Rail Mounting)
Screws
(Used for Ceiling Mounting)
RJ-45 Cable (Ethernet)
Ceiling Mount Bracket
The type of the power adapter depends on the country that the AP will be
installed:
UK-type Power Adapter
EU-type Power Adapter
USA/Taiwan-type Power Adapter
AU/NZ-type Power Adapter
The maximum power consumption is 23 Watt.

2
2
2. . P Pa an ne el l E Ex xp pl la an na at ti io on n
LED
Status
Explanation
Blue LED
On
The system is in boot-loader mode.
Blinking
The system is in TFTP mode.
Green LED
Blinking
The system is in AP mode and work normally.
Red LED
Blinking
System error.
Off
Off
VigorAP is turned off or not functioning.
Interface
Explanation
Ethernet Port
Connects to LAN or router.
Supports PoE power & Gigabit (2.5G).
Power Jack (DC IN)
Connecter for a power adapter.
Hole
Explanation
Factory Reset
Restores the unit back to factory default settings.
To use, insert a small item such as an unbent
paperclip into the hole. You will feel the button
inside depress gently. Hold it for 5 seconds.
The VigorAP will restart with the factory default
configuration and the LED will blink blue.
LED
Factory
Reset

3
3
3. . I In ns st ta al ll la at ti io on n
VigorAP can be installed under certain locations: wooden ceiling, plasterboard
ceilings, light-weighted steel frame and wall.
3
3. .1 1 C Ce ei il li in ng g- -m mo ou un nt t I In ns st ta al ll la at ti io on n ( (W Wo oo od de en n C Ce ei il li in ng g) )
i. Place the bracket under the wooden ceiling and fasten four screws firmly.
ii. When the bracket is in place, fasten two screws firmly on the bottom of
VigorAP.
iii. Secure the access point firmly in place using the included screw as shown in
step iii.
Bracket

4
3
3. .2 2 C Ce ei il li in ng g- -m mo ou un nt t I In ns st ta al ll la at ti io on n ( (P Pl la as st te er rb bo oa ar rd d C Ce ei il li in ng g) )
i. Drill four holes in your ceiling using the ceiling mount bracket as a guide, and
insert the four included wall plugs/screw anchors (i).
ii. Align the ceiling mount bracket with your wall plugs/screw anchors and use
the four screws to fix it into place (ii).
iii. When the bracket is in place, fasten two screws firmly on the bottom of
VigorAP.
iv. Secure the access point firmly in place using the included screw as shown in
step iv.
Bracket

5
3
3. .3 3 S Su us sp pe en nd de ed d C Ce ei il li in ng g I In ns st ta al ll la at ti io on n
You cannot screw into ceiling tiles as they are weak and not suitable for bearing
loads. Your VigorAP is supplied with mounts (T-Rail brackets) which attach
directly to the metal grid („T-Rail‟) of your suspended ceiling.
1. Choose the correct size T-Rail bracket from the bundled package.
2. Put the T-Rail brackets on the holes of the bottom side of the device. Fasten
them with suitable screws.
3. Secure the access point firmly in place using the included screw as shown in
step iii.
4. Clip the access point onto your T-Rail using the now attached T-Rail bracket.
5. If a larger gap is required between the ceiling and the VigorAP, use the
extension pieces to extend the height of the brackets.
Extension Piece
T-Rail Bracket

6
6. Attach the T-Rail brackets to the ceiling frame.

7
4
4. . C Co on nn ne ec ct ti io on n a an nd d C Co on nf fi ig gu ur ra at ti io on n
4
4. .1 1 N No ot ti if fi ic ca at ti io on ns s f fo or r H Ha ar rd dw wa ar re e C Co on nn ne ec ct ti io on n
Connect VigorAP to Vigor router (via LAN port) with Ethernet cable.
Connect VigorAP to PoE switch (via LAN port) with Ethernet cable. For
connecting with PoE switch, do not connect the power adapter. VigorAP
will get the power from the switch directly.

8
4
4. .2 2 W We eb b C Co on nf fi ig gu ur ra at ti io on ns s
There are two methods to configure VigorAP.
Method 1:
1. First, open a web browser on your PC and type https://192.168.1.2. A
pop-up window will open to ask for username and password.
2. After clicking Login, Quick Start Wizard for configuring wireless settings will
appear.
3. Follow the on-screen steps to finish the network connection.
Note
You may either simply set up your computer to get IP
dynamically from the router or set up the IP address of the
computer to be in the same subnet as the IP address of
VigorAP 1062C.
If there is no DHCP server on the network, then VigorAP
1062C will have an IP address of 192.168.1.2.
If there is DHCP available on the network, then VigorAP
1062C will receive its IP address via the DHCP server.
If you connect to VigorAP by wireless LAN, you could try
to access the web user interface through
http://vigorap.com.

9
Method 2:
(a) Use a mobile phone to scan the QR code named with DrayTek Wireless
App to download DrayTek Wireless APP.
(b) After downloading, run the APP.
(c) Click Quick Start Wizard. Next, scan the QR code named with Connect
SSID. Later, click Connect to access into the APP user interface of
VigorAP 1062C to set the device in AP or Range Extender mode.

10
5
5. . C Cu us st to om me er r S Se er rv vi ic ce e
If the device cannot work correctly after trying many efforts, please contact
your dealer/DrayTek for further help right away. For any questions, please feel
free to send e-mail to “[e-mail]”.
B
Be e a a R Re eg gi is st te er re ed d O Ow wn ne er r
Web registration is preferred. You can register your Vigor router via
https://myvigor.draytek.com..
F
Fi ir rm mw wa ar re e & & T To oo ol ls s U Up pd da at te es s
Due to the continuous evolution of DrayTek technology, all routers will be
regularly upgraded. Please consult the DrayTek web site for more information on
newest firmware, tools and documents.
https://www.draytek.com
GPL Notice
This DrayTek product uses software partially or completely licensed
under the terms of the GNU GENERAL PUBLIC LICENSE. The author of
the software does not provide any warranty. A Limited Warranty is
offered on DrayTek products. This Limited Warranty does not cover
any software applications or programs.
To download source codes please visit:
http://gplsource.draytek.com
GNU GENERAL PUBLIC LICENSE:
https://gnu.org/licenses/gpl-2.0
Version 2, June 1991
For any question, please feel free to contact DrayTek technical
support at suppo[email protected] for further information.
