Dreamland SCANDI R7606 User manual

Instructions for use
SCANDI
FULL BED SIZE
HEATED
UNDERBLANKET
TYPE R7606
R7612
R7617
R7619
R7621

1
EN
ILLUSTRATIVE GUIDE
DESCRIPTION OF THE APPLIANCE
TECHNICAL DATA
1. Underblanket connector
2. Control connector
3. Mains socket
4. Rating Label
5. Underblanket
6. Timer
7. ON/OFF button
8. Temperature selector
9. Stand-by LED
10. Auto Shut Off Timer LED
11. Temperature LED
Temperature table
6Fast Pre-heat
5-4
Medium Pre-heat
3-1 Continuous or all
night use
[C]
6
7
8
911
10
TYPE R7617
220-240 V 50/60 Hz 2x150 W
TYPE R7621
220-240 V 50/60 Hz 150 W
TYPE R7619
220-240 V 50/60 Hz 2x150 W
TYPE R7606
220-240 V 50/60 Hz 150 W
TYPE R7612
220-240 V 50/60 Hz 2x150 W
[A] [B]
1 2
4
5
3

2
EN
Dear Customer, thank you for choosing our product. We feel certain
you will appreciate its quality and reliability as it was designed and
manufactured with customer satisfaction in mind. These instructions
for use are compliant with the European Standard EN 82079.
INDEX
Illustrative guide page 1
Description of the appliance page 1
Technical data page 1
Symbols page 2
Important instructions page 3
Use page 5
Cleaning and maintenance page 7
Storing the underblanket page 8
Troubleshooting page 9
Disposal page 9
Support and warranty page 10
SYMBOLS
Class II appliance Prohibition
Read the instructions Information
Caution/Warning/Danger NOT to be used by very
young children (0-3 years)
Do not use folded or creased Do not insert pins
Wash at a maximum
temperature of 30 °C on a
delicate cycle
Do not bleach
Dry in a tumble dryer on
a delicate cycle at a low
temperature.
Do not dry clean
Do not iron

3
EN
I MPORTANT INSTRUCTIONS.
RETAIN FOR FUTURE USE.
WARNING! Instructions and warnings for safe use.
Beforeusingthisappliance,carefully readtheinstructions
for use and in particular the safety notes and warnings,
which must be complied with. Keep this manual together
with its illustrative guide for future consultation. Should
you transfer the appliance to another user, make sure
you hand over this documentation as well.
NOTE: Should any part of this manual be difficult to understand or any
doubt arise, contact the company at the address indicated on the last
page before using the appliance.
NOTE: Persons with impaired vision may consult these instructions for
use in digital format at the website www.dreamlanduk.co.uk
• After unpacking, make sure the appliance is intact, complete with all its parts as
shown in the illustrative guide and with no sign of damage. If in any doubt, do not
use the appliance and contact an authorised service centre.
WARNING! Risk of suffocation.
Children shall not play with the packaging. Keep the plastic bag
out of the reach of children.
• This appliance must be used only for the purpose for which it was designed,
namely as an underblanket for home use to heat a bed. Any other use is
considered not compliant with the intended use and therefore dangerous.
• Before connecting the appliance to the mains supply, make sure that the voltage
and frequency indicated on the technical data of the appliance correspond to
those of the mains supply. The rating label is on the appliance or on the power
supply unit, if any (see illustrative guide and technical data).
• This appliance can work automatically at a frequency of 50 Hz or 60 Hz.
• This appliance is only to be used with the types of detachable control unit that
are marked on the appliance.

4
EN
Children under the age of three are not to use this appliance due to
their inability to react to overheating.
• This appliance can be used by children older than 3 years and younger
than 8 years under supervision and with the control always set to minimum
temperature.
• This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance must not be carried
out by children without supervision.
• This appliance must not be used by persons insensitive to heat and other very
vulnerable persons who are unable to react to overheating.
• The cable and control unit of the appliance can give rise to risks of entanglement,
strangulation, tripping or treading if not correctly arranged.The user shall make
sure that electric cords shall be arranged in a safe way.
• Always disconnect the appliance from the mains supply before cleaning or
performing maintenance and when the appliance is not in use.
• Examine the appliance frequently for signs of wear or damage. If the appliance
has been misused or does not work, contact an authorised technical service
centre before switching it on again.
• If the supply cord is damaged, take the whole appliance to an authorised
technical service centre for the replacement of the control unit, so as to prevent
all risks.
• If the appliance is used on an adjustable bed, check that the blanket and cord
do not become trapped or rucked, for example in hinges.
• This appliance is not intended for medical use in hospitals.
• DO NOT use if wet.
DO NOT USE FOLDED OR CREASED.
DO NOT INSERT PINS OR NEEDLES.

5
EN
• When storing the appliance, allow it to cool down before folding.
WARNING! DO NOT crease the appliance by placing items
on top of it during storage.
WARNING! For use, cleaning, maintenance and storage of the
appliance, please follow the instructions specified in the
corresponding chapters.
• DO NOT use the appliance with wet hands or damp feet.
• DO NOT pull the power cable or the appliance itself to remove the plug from
the socket.
• DO NOT pull or lift the appliance by the supply cord.
• DO NOT expose the appliance to humidity, to the effects of weather (rain,
sun, etc.) or to extreme temperatures.
• If the appliance is faulty or malfunctions, switch it off and do not tamper with it.
Contact an authorised technical service centre for any repairs.
• DO NOT use this appliance to warm animals.
• DO NOT tuck in.
• See the external packaging for the characteristics of the appliance.
USE
POSITIONING THE UNDERBLANKET
WARNING! The electric blanket must only be placed between the
mattress and the flat sheet and not on top of persons in bed.
IMPORTANT: The underblanket only works efficiently if it is placed on the bed
and covered with a bed sheet, covers or quilt.
• Place the underblanket (5) directly onto the mattress with the connector side facing
downwards at the top part of the mattress.
• Fit the underblanket to the mattress by securing the elasticated straps over each
corner of the mattress. Make sure the underblanket is always spread out smoothly
and that there are no creases.
• Make the bed, laying the rst sheet on top of the underblanket. Place the second sheet
and the normal blanket or duvet on top.
CONNECTING THE CONTROL UNIT
• Insert the control unit connector (2) in the underblanket connector (1) to connect the
control unit to the underblanket. For the dual control blanket models, repeat this for

6
EN
the other side.
• Run the control unit cable along the oor next to the bed. Do not squash the control
unit cable between the mattress and the bed frame.
• Insert the plug of the control unit cable in the mains socket (3). Every time the plug is
inserted, the control unit automatically performs a self-diagnosis, lighting up all LEDs
(10, 11) in a clockwise sequence for around two seconds.
SWITCHING ON AND SELECTING THE RIGHT TEMPERATURE
The control unit can be set to the following temperature levels:
6: Fast pre-heat temperature
5-4: Medium pre-heat temperature
3-1: Continuous or all-night use
• To switch the underblanket on press the ON/OFF button (7).Every time the appliance is turned
on, the Auto Safety Function automatically runs a full check of your blanket, lighting up all the
LEDs (10, 11) in a clockwise sequence. Following this check, the control unit automatically
sets to temperature 6 and the auto shut o timer to 1 hour.
• For fast pre-heat, use maximum temperature 6. If you like a medium pre-heat temperature,
then you can select 4-5 by pressing the temperature selector button (8) until the LED for
the required temperature lights up (11). The higher the number selected, the higher the
temperature.
IMPORTANT: The temperature of the underblanket must be evaluated by lying in the
bed rather than just feeling it by hand.
CONTINUOUS OR ALL NIGHT USE
For continuous or all night use of the appliance, set the control
unit to temperature settings from 1 to 3 only.
To set the control unit to the continuous use temperature, press the temperature selector button
(8) until LEDs 1, 2 or 3 light up (11).
DO NOT get into bed with the control unit set to a higher
temperature than recommended for continuous use.
If the appliance is slept on with the controls set to a higher
temperature the user may suer skin burns or heat stroke.
WARNING! DO NOT place the control unit under the pillow
or under the sheets when in use.

7
EN
AUTO SHUT OFF TIMER
The underblanket has an automatic shut o timer of 1, 3 or 9 hours. When switched on,
the control unit automatically sets itself to 1 hour on the auto shut o timer and LED
1h lights up in green (10). To set a dierent auto shut o timer, press the timer selector
button (6) and select the desired timer. Each time the auto shut o timer is reset, the
timer starts from zero. When the time has elapsed, the underblanket switches o and
the standby LED (9) lights up in blue.
NOTE: Should the power supply accidentally be interrupted during use, when
the control unit is switched back on it will maintain the temperature and timer
settings in use previously and the timer counter will start from zero.
NOTE: So that the display light does not bother users during the night, the
light intensity reduces around 15 seconds after any button is last pressed.
Similarly, the standby LED becomes less bright 15 seconds after it is activated.
SWITCHING OFF
Switch the underblanket o by pressing the ON/OFF button (7) and remove the plug from the
socket (3) .
CLEANING AND MAINTENANCE
The underblanket is washable. Check the washing symbols on the label to ensure it is
washed correctly.
WARNING! Always disconnect the appliance from the mains
and disconnect the control connector from the underblanket
before cleaning or performing maintenance.
BEFORE WASHING
• Take the plug of the control unit cable out of the mains socket (3).
• Press the grip levers at the sides of the control unit connector (2) to remove the control
unit connector from the underblanket connector (1).
MACHINE WASHING
• The underblanket can be cleaned in the washing machine at 30°C, on a delicate cycle.
• Pre-treat any stains by spot cleaning before placing in the washing machine.
• Use only the delicate cycle for spinning. DO NOT make an additional spinning cycle.
DRYING IN THE TUMBLE DRYER
• The underblanket can be dried in a tumble dryer on a delicate cycle, but at the end of

8
EN
the drying cycle it must be air-dried to allow it to dry completely.
• Remove the underblanket from the tumble dryer at the end of the drying cycle and
reshape it to its original size.
• Allow the underblanket to fully air-dry before using it again.
DRYING IN THE OPEN AIR
• When the underblanket is spread out to dry on a clothes airer, it must be stretched so the
original size is more or less maintained. This is best done while the underblanket is still
damp, working alternately on the opposite corners and pulling one side at a time.You might
have to repeat this procedure several times until the underblanket is completely dry.
WARNING! Spread out the appliance without using clothes
pegs to avoid damaging it, and leave it to fully dry spread out
on a drying rack that is not exposed to the sun.
• Only use the underblanket when it’s thoroughly dry.
• Do not iron the underblanket.
WARNING! Examine the appliance against the light to make sure
the cables are not bent or twisted.
WARNING! Dry the appliance flat without using pegs to avoid damaging
it. Leave it to dry, laid out flat on a clothes airer, not in direct sunlight.
STORING THE UNDERBLANKET
When not in use, store as follows:
• If the underblanket has been washed, wait until it’s completely dry;
• Fold it like a normal blanket;
• You are advised to store the underblanket in the original packaging it was supplied in;
• When storing the appliance, allow it to cool down before folding;
• Put the underblanket away in a dry place
The fabric may turn yellow over time. This does not have any effect at all on the safety and/or
effectiveness of the product itself.
Examine the appliance and its supply cord frequently for signs of wear or damage.
lf there are such signs or in the case of malfunction, contact an authorised technical
service centre.

9
EN
TROUBLESHOOTING
This chapter describes the most common problems that can arise using the appliance. If
the problems cannot be solved with the information below, please contact the Authorised
Service Centre.
Problem Solution
The LEDs on the control unit
do not light up.
Check that the control unit plug is fully inserted in the
socket (3). If the LEDs remain off, remove the control
unit plug from the socket (3) and return the under-
blanket to an authorised technical service centre.
The blue warning light is
flashing.
Turn the control unit off and remove the plug from
the socket (3). Check that the control unit connector
(2) is fully inserted in the underblanket connector (1)
and reinsert the plug in the socket (3). If the standby
LED continues to flash, return the underblanket to
an authorised technical service centre.
Temperature LED 1 (11) is
flashing.
Return the underblanket to an authorised technical
service centre to be checked.
The product has been used
incorrectly or is damaged.
The power cable or another
internal wire is damaged.
The control unit is damaged.
There are holes or tears in the
fabric or stubborn creases that
do not spread out.
DISPOSAL
The packaging of the appliance is made of recyclable materials. Dispose of the packaging in
accordance with the environmental protection regulations.
Pursuant to Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the
crossed bin symbol on the appliance or its packaging indicates that the appliance must be
disposed of separately from other waste at the end of its useful life.
The user must therefore take the appliance to an appropriate recycling centre for electrical and
electronic equipment. Alternatively, instead of handling the disposal, the user can hand over the

10
EN
appliance to the retailer when a new, equivalent one is purchased. The user can hand over electronic
products measuring less than 25 cm to retailers of electronic products having a sales area of at least
400 m2 free of charge and with no obligation to buy. Proper waste sorting prior to sending the equipment
no longer used for recycling, processing and disposal in a manner that respects the environment
contributes towards avoiding negative impacts on the environment and on health and promotes the
reuse and/or recycling of the equipment’s material.
WARRANTY
This product is guaranteed for a period of 3 years from the date of purchase against material, mechanical
and electrical defects. The warranty is binding if it is accompanied by a valid receipt of payment. This
guarantee is only valid if the appliance is used solely for domestic purposes in accordance with the
instructions provided that is not connected to an unsuitable electricity supply, dismantled, interfered
with in any way damaged, through misuse, fair wear and tear. Under this guarantee we undertake to
repair or replace free of charge any parts found to be defective.
PLEASE NOTE, THE COST OF A SAFETY INSPECTION IS NOT COVERED BY THIS
GUARANTEE. A CHARGE WILL BE MADE IN RESPECT OF ANY PRODUCT RETURNED UNDER
THIS GUARANTEE, WHERE NO FAULT IS FOUND.
This guarantee is offered as an extra benefit and does not affect your statutory rights as a consumer.
This guarantee does not confer any rights other than those expressly set out above and in particular
we shall not be liable for any indirect or consequential loss or damage. Nothing in this guarantee or the
instructions relating to the product excludes, restricts or otherwise affects your statutory rights. In line
with our policy of continuous development, we reserve the right to change this product, packaging and
documentation without notice. If a defect appears and after checking that the blanket is being used
properly in accordance with the instructions, return it with a valid proof of purchase, as soon as possible
to the manufacturer’s Service Centre.This guarantee is valid in the UK only.
SERVICE CENTRE
PO Box 166 – Middlewich – Cheshire – CW10 0ZU - Tel: [phone]
E-mail: [email protected]
www.dreamlanduk.co.uk

MI003582
130320
