Supreme™Instructions
For PVC Reclining Bath Chair
Model Numbers:
BCCS-8510S (up to 100 lb. weight capacity)
BCCS-8610M (up to 130 lb. weight capacity)
BCCS-8710L (up to 180 lb. weight capacity)
These products covered by U.S. Patents:
D606,387; D606,388; D606,389; D592,492; 3,795,218

2January 2017
ATTENTION
Your Supreme Bath Chair has been built to the highest standards of
quality to ensure years of superior service. Please take the time to read
the informative instruction guide and pay particular attention to the safety
information provided.
Here are some precautions you should take to reduce the risk of injury:
1. Read and understand ALL instructions.
2. Determine, with a physician or therapist, the suitability of this product
for the intended user.
3. To reduce the risk of injury or drowning, NEVER leave the user
unsupervised or unattended while using this product.
4. Check regularly that all tubing, bolts, buckles, and other parts are
tight at ALL times.
5. Check regularly that all PVC tubing and connectors are free
from cracks or distortion. At the fi rst sign of cracks or distortion,
discontinue use immediately.
6. SAVE THESE INSTRUCTIONS.
Thank you for choosing Inspired by Drive.
Before You Begin
The following are assembly instructions for each of the sizes of Inspired
by Drive Supreme PVC bath chairs. Follow ONLY the instructions that
are specifi c to your particular model.

3Supreme Reclining Bath Chair
ASSEMBLY INSTRUCTIONS
Models BCCS-8510S - Supreme Bath Chairs (Small)
The small Supreme bath chairs are shipped with the frame and seat
unattached.
1. Reach inside the seat cover by opening the top fl ap of the mesh
cover.
2. From the inside of the seat, insert the bolts through the pre-drilled
holes in the plastic tubing, the through the holes in the plastic
frame. The cap nuts should then be screwed to the bolt ends
protruding on the outside of the frame.
3. Insert the tube at the rear of the seat back into the frame’s larger
tube by pressing the metal release button.
4. Additionally, insert the tube under the seat front into the frame’s
larger tube by pressing the metal release button.
Models BCCS-8610M - Supreme Bath Chairs (Medium)
The medium Supreme bath chairs are shipped with the seat already
attached to the frame.
1. Insert the tube at the rear of the seat into the frame’s larger tube
by pressing the metal release button.
2. Additionally, insert the tube under the seat front into the frame’s
larger tube by pressing the metal release button.
Models BCCS-8710L - Supreme Bath Chairs (Large)
The large Supreme bath chair is shipped with the seat already bolted
to the frame. Simply insert the tube at rear of the seat into the frame’s
larger tube by pressing on the metal release button.
Setting the Angle of Recline
1. Push the release button on the upright post. Slide the inner post
up or down, until the bottom locks into the desired position.
Setting the Seat Angle
1. Push the release button on the post under the seat. Slide the inner
post up or down until the button locks into the desired position
(please note that large chair has two posts).

Every Inspired by Drive product comes with our one year manufacturer’s warranty. This
warranty ensures that when you receive our products, they will arrive free of defects
in material and workmanship. We will repair or replace any part or entire product at
our discretion for a period of up to one year from the date of delivery to the original
purchaser. This warranty does not include cost of inconvenience, shipping, property
damage, misuse, abuse, accident, or similar incidents. The warranty will not apply if
the product has been modified, tampered with, repaired by unauthorized individuals or
assembled incorrectly. Custom orders are non-refundable and non-returnable.
January 2017 (Rev D) C0000-10-53
© 2015 Columbia Medical, LLC dba Inspired by Drive
