Operation Manual for the
Drummond Pipet-Aid®XL
NEW Smooth r,
Qui t r Pump
Made in USA
by
Drummond Scientific Co.
500 Parkway
Broomall, PA 19008
800/523-7480 • 610/353-0200
www.pipet-aid. om
Catalog Number 4-000-105
4-000-205
4-000-205-A
4-000-205-E
LISTED
(LABORATORY EQUIPMENT)
34 HB
DOMINIQUE DUTSCHER SAS

2
Op rating Instructions for th Drummond
Stat m nt of Purpos
All Pipet-Aid models are designed to transfer liquids with the use of serologi al,
volumetri and/or blow-out pipets in either glass, plasti or something similar.
Rul s for Saf Op ration
• For indoor use only.
• Do not attempt to use the harger/power supply with any other produ t.
DO NOT ATTEMPT TO CHARGE THIS UNIT WITH ANY OTHER CHARGERS.
• This produ t in ludes re hargeable Ni-MH batteries. Do not in inerate batteries as
they may explode at high temperatures.
• Never operate unit in an explosive atmosphere.
• Expelling liquid from a pipet generates aerosols. The faster the liquid is expelled,
the more aerosols are generated. Understand the nature of the liquid being
pipetted and take appropriate pre autions.
• Do not operate unit with a damaged ord.
• Use harger only in a standard ele tri al outlet.
• Do not handle power supply with wet hands.
• Do not put unit or harger in water or other liquid.
• Pipetting a ids or strong alkalis will damage unit.
• When servi ing, use only identi al Drummond repla ement parts.
• Save these instru tions.
If the equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment may be impaired. Always use
the charger or power supply that is supplied with the unit.
Conn ctions to Pow r Supply:
Che k the power supply to see that the line voltage orresponds to the voltage
indi ated on the mains adapter.
If the mains adapter supply and the line voltage are not ompatible, the ele tri al
omponents of the Pipet-Aid may be damaged or destroyed.
Before ea h use, onfirm that the mains adapter able is not damaged, worn or
severely bu kled and there are no breaks in the insulating surfa e. If any damage is
noted, do not use the Pipet-Aid until the damaged mains is repla ed.
Sp cifications for Usag
This quipm nt is for indoor us only.
Temperature Range 10°C–35°C, Maximum Humidity 60%
For us with pip ts from 1 mL to 100 mL
FAILURE TO USE THE EQUIPMENT IN ACCORDANCE WITH INSTRUCTIONS
OR MODIFYING THE EQUIPMENT WILL VOID WARRANTIES.
CAUTION: CAREFULLY READ THROUGH THIS ENTIRE MANUAL BEFORE USING
YOUR NEW PIPET-AID XL. PAY CLOSE ATTENTION TO THE RULES FOR
SAFE OPERATION WARNINGS AND CAUTIONS.
DOMINIQUE DUTSCHER SAS

3
Pip tting Instructions
Insert a pipet into the nosepie e by twisting the pipet while pushing. Exer ise
extreme aution when using glass pipets as breakage is an ever present danger.
Depressing the top button fills the pipet, depressing the bottom button empties it.
The flow rate is proportional to the amount the button is depressed.
Sp d Controls
Ea h button has three speeds: “F” fast, “M” medium, and “S” slow. The speed is
sele ted by rotating the button on its axis until a detent is felt; the speed hosen is
visible when the handle is held in the right hand. The “M” orresponds to the speed
of previous Pipet-Aids. Fast is to be used for rapid filling of large pipets or breaking
up ell lumps. Slow speed should be used for small pipets or where pre ise
delivery is required. Please note that ea h button an be set independently. For
example, one ould fill a large pipet on “F” and deliver small amounts on “S”.
CAUTION: SPEED CONTROL BUTTONS MUST BE POSITIONED ON “F”, “M”,
OR “S”. INTERMEDIATE SETTING WILL CAUSE LEAKAGE. ALSO, DO NOT
CHANGE SPEED CONTROL BUTTONS WITH FLUID IN THE PIPET. THIS WILL
ALSO CAUSE THE UNIT TO LEAK.
Filt r
The XL in orporates a new EZ Grip, tissue ulture nosepie e (2), whi h features a
unique filter element. The self-lo king TC filter (4-000-051) will ease to pass air in
either dire tion when it be omes wet, alerting the user to possible ontamination of
the rubber insert.
NOTE: IF THE PUMP PULSES WHEN THE FILL BUTTON IS DEPRESSED, THE FILTER
HAS BEEN COMPROMISED AND MUST BE REPLACED. REPLACE WITH FILTER
NUMBER 4-000-051. St ril filt rs ar availabl (4-000-051-S).
To remove the filter (4), push in the nosepie e release (7), turn the EZ Grip nosepie e
(2) 1/4 turn ounter lo kwise and pull down. Repla e the filter, making sure both
TC gaskets (5) are pla ed on the new filter and making sure the rubber insert (3)
(4-000-002) is lean and dry and does not ontain any otton plugs.
F atur s
The Pipet-Aid®XL in orporates several new features. The new lightweight ergonomi
handle is designed to redu e ne k, shoulder, and arm fatigue when pipetting under
a hood. A new powerful pump improves fluid movement and redu es noise level.
Individual speed ontrols are provided for both aspirate and dispense modes. A
green LED indi ates battery is harging and the unit an be harged while in use.
The new EZ Grip nosepie e makes filter repla ement easy and the new nosepie e
lo k will prevent a idental removal. An adjustable sliding hand rest is provided along
with a removable stand and a wall mount holster.
The Drummond Pipet-Aid®XL is overed under the following U.S. Patents, and other
foreign and US patents pending. #5,294,405, #5,214,968, #5,616,871
Pip t-Aid®XL
DOMINIQUE DUTSCHER SAS

4
Batt ry
The XL is powered by a 3.6V, ni kel-metal hydride (Ni-MH), re hargeable battery (14)
( atalog number: 4-000-036). It is not the same battery used in our other
Portable Pipet-Aids®.
Battery repla ement is a user fun tion. Although the batteries are re hargeable,
they have a limited life span of generally 2-3 years or 1000 y les. To repla e the
battery, remove the nosepie e, remove the hand rest by prying off, uns rew the
4 Phillips s rews, lay the unit down on the ben h with the s rew holes up, open up
the unit arefully, unplug the old battery, and repla e with a new battery. Batteries
are available from your lo al lab equipment supplier or dire t from Drummond
S ientifi Company.*
Charging th Batt ry
IMPORTANT: BATTERY SHOULD BE CHARGED FOR A MINIMUM
OF SIX HOURS BEFORE INITIAL USE.
When not in use, plug in the harger/power supply and let harge overnight.
The GREEN LED will light up when harging.
The green LED will remain on as long as the harger is plugged into the unit.
An internal ir uit will prevent over harging.
NOTE: DO NOT USE ANY CHARGER OTHER THAN THE ONE SUPPLIED (4-000-065).
THIS UNIT IS NOT COMPATIBLE WITH OTHER DRUMMOND CHARGERS.
ALTHOUGH MANY OTHER CHARGERS WILL FIT INTO THE UNIT, CHARGING WILL NOT
OCCUR OR DAMAGE TO THE BATTERY WILL RESULT.
While using the unit and the battery harge be omes insuffi ient to operate the unit,
plug in the harger and ontinue using the unit. Charging will take pla e while in use.
The harger also fun tions as a power supply.
All re hargeable batteries have a limited life span. Generally ea h battery will last
approximately 1000 y les ( harges) and then must be repla ed. Repla ement is a
user fun tion and will require a Phillips head s rewdriver, a new battery (4-000-036),
and about two minutes of your time. (See above)
*Use only re ommended battery for repla ement (DSC #4-000-036). Do not repla e the battery with a
non-re hargeable battery. Explosion or fire hazard an o ur if in orre t battery repla ement is used.
Instructions for Cl aning
Wiping the unit with a soft loth or wipe with isopropyl al ohol is suffi ient to lean the
unit. Avoid the use of a etone and other organi solvents whi h will damage the handle.
All omponents inside the nosepie e may be auto laved with the ex eption of the
Drummond Self-lo king Filter. Repla e the filter when ompromised.
Always dis onne t the harger/power supply from the unit when leaning.
DOMINIQUE DUTSCHER SAS

5
NOSE-
PIECE
RELEASE
ASPIRATE
DISPENSE
CHARGING
INDICATOR LED
SLIDING
HAND REST
Qu stions,
Comm nts,
Sugg stions,
or S rvic :
CALL OUR HOTLINE
AT 1-800-523-7480
Ord ring Information
Catalog No. D scription
4-000-105 Pipet-Aid®XL 110V
4-000-065 Power Supply/Charger, Input: 120V, 60Hz, 55mA
Output: 6VDC, 200mA
4-000-205 Pipet-Aid®XL 230V, International
4-000-066 European Power Supply/Charger, Input: 230V, 50Hz, 55mA
Output: DC6V, 200mA
4-000-205-E Pipet-Aid®XL 240V, UK
4-000-066-E UK Power Supply/Charger, Input: 240V, 50Hz, 55mA
Output: DC6V, 200mA
4-000-205-A Pipet-Aid®XL 240V, Australia
4-000-066-A Australian Power Supply/Charger, Input: 240V, 50Hz, 55mA
Output: 6VDC, 300mA
Sp cifications
Size 10˝
Weight 8 oz.
Capa ity A epts 1 to 100 mL pipets
Battery Ni-MH (3.6V/750 mAh)
POWER SUPPLY
DOMINIQUE DUTSCHER SAS

6
1
8
2
3
5
4
5
6
7 14
11
Catalog No. Parts D scription
[1] 4-000-067 XL Handle Shell
[2] 4-000-079 EZ Grip Nosepie e
[3] 4-000-002 Rubber Insert (2/pk)
[4] 4-000-051 Self-lo king Filter (5/pk)
4-000-051-S Self-lo king Filter, Sterile (5/pk)
[5] 4-000-057 TC Gasket Pair
[6] 4-000-063 Handle Conne tor XL
[7] 4-000-064 Nosepie e Release XL
[8] 4-000-072 Swit h Operator XP/XL
[9] 4-000-073 Valve Body XP/XL
( omplete w/buttons and springs)
[10] Valve Body Slide (yellow) in luded with [9]
[11] 4-000-070 Button Assembly XP/XL in ludes springs
[12] 4-000-061 Pump, board, wire harness
Parts:
Commonly used parts (e.g., rubber
inserts, TC gaskets, batteries, filters)
are available from your lo al dealer
or Drummond S ientifi Company.
Call us at 1-800-523-7480.
DOMINIQUE DUTSCHER SAS

7
Catalog No. Parts D scription
[13] Pump/Valve body onne ting
tubing in luded w/pump
[14] 4-000-036 Battery Pa k (XL only)
[15] 4-000-062 Hand Rest
[16] 4-000-068 XL Stand, removable
[Not Shown] 4-000-065 Power Supply/Charger, Input: 120V, 60Hz, 55mA
Output: 6VDC, 200mA
4-000-066 European Power Supply/Charger, Input: 230V, 50Hz, 55mA
Output: DC6V, 200mA
4-000-066-A Australian Power Supply/Charger, Input: 240V, 50Hz,
Output: 6VDC, 300mA
4-000-066-E UK Power Supply/Charger, Input: 240V, 50Hz, 55mA
Output: DC6V, 200mA
[Not Shown] 4-000-087 TC Nosepie e Kit with 4 Filters
[Not Shown] 4-000-089 Pipet-Aid®Holster-Type Wall Bra ket
15
10
9
16
13
12
DOMINIQUE DUTSCHER SAS

©Copyright Drummond S ientifi Company, 2014, Rev. 3/14 Printed in USA
Pipet-Aid®is a registered trademark of Drummond S ientifi Company
500 Parkway, Box 700
Broomall, PA 19008
800/523-7480 • FAX: [phone]
Website: www.drummonds i. om
For Te hni al Assistan e, all
1-800-523-7480 or e-mail
[e-mail]
Maint nanc and S rvicing
Keep your Pipet-Aid lean and harged at all times. When not in use, it is appropriate
to keep the unit plugged into the harger. No damage will o ur if you are using the
harger supplied.
Drummond S lf-locking Filt rs ar provid d with all mod ls that us filt rs.
R plac m nt part numb rs ar :
4-000-051 5 pk 4-000-051-S 5 pk, sterile
4-000-052 50 pk 4-000-052-S 50 pk, sterile
These filters must be repla ed if over-pipetting o urs. They prote t the handle
omponents as well as minimize ross ontamination of samples and ontain two
membrane layers.
On some models, (XP2and XL) if the battery harge be omes insuffi ient to operate
the unit, plug in the harger and ontinue using the unit. Charging will take pla e while
in use. The harger supplied with these two units fun tion as a power supply.
All re hargeable batteries have a limited life span; generally ea h battery will last
1,000 y les ( harges) and then must be repla ed. Battery repla ement is a user
fun tion and will not require any spe ial tools; a Phillips s rewdriver is all you will need.
Batt ry Sp cifications – Pip t-Aid®XL
Cat. No. Rating
4-000-036 3.6V/750mA Ni-MH
