DSPPA DSP406II User manual

Speaker unit
4.5"×1
Power rating
10W
Voltage
70V/100V
Sensitivity (1m,1W)
91±2dB
Max. SPL(1m)
99±2dB
Effective Freq. Range
80Hz-18kHz
Product size(L×W×H)
302×115×205mm
Product weight
2.25kg
DSP406II Wall Mount Speaker
Sounds clear and sonorousness;
Top wire adopts integrated design,elegant clever and beautiful;
Enclosure made of high quality fiberboard and birch cold-press leather
manufacturing, eliminate resonant sound box, suitable for indoor;
Input voltage 70V-100V, adapt different public broadcast line
Features
Specification

Installation
W
L
H
The unit: mm
size
Length
Width
Height
Model
DSP406Ⅱ
302
115
205
L
Installation The unit: mm
60mm
6mm
60mm
13mm
4-6mm
Figure 1

Black:70V-100V
Red:Com
Figure 2 Figure 3
① Fit two Ø4mm nail on wall where it is needed to install a speaker system as
shown above；
② Connect audio broadcasting wire to the terminals according to the table below.
Power
Line Voltage
70V
100V
Terminals
Red-Black
5W
10W
③ Position the speaker, then adjust the direction of it and examine whether it
is steady.
