DSPPA DSP406 User manual

Model
DSP406
Freq. Resp
80Hz-18kHz
Sensitivity
91±2dB
Max SPL
101±2dB
Weight
2 kg
DSP406 5W-10W Beaverboard Wall Mount Speaker
70/100V, 5-10W
Max SPL: 101±2dB
High sensitivity: 91±2dB
Effective Freq:80Hz-18kHz
Made of high beaverboard
Easy and fast hook wall mount installation
Features
DSP406 Wall mount speaker built in 70/100V transformer, the multiple power tapes5-10W are
helpful for different applications varies from room size and ambient noise surroundings.Max sound
pressure level is 101±2dB. Effective Freq range is 80Hz-18kHz. High sensitivity is 91±2dB. Made
of high beaverboard, hard to vibrate, clear and sonorous sound.Easy and secure wall mount
installation through the supplied mounting hook. It is ideal choice for industrial and commercial
applications in hotel, school, office and factory where background music and paging is needed.
Description
Specification

70V
100V
Installation
1. Fit two Ø4mm nails on wall where it is needed to install a speaker system as shown
above.
2. Connect audio broadcasting wire to the terminals according to the table below.
3. Position the speaker, then adjust the direction of it and examine whether it is steady.
Freq. Response Distortion
(dB SPL、1W、1m) (THD< 1.5% 1W、1m、100Hz-10kHz)
Hanging Hole Nail for Mounting
4.5mm
10mm
31.5cm
4mm-6mm
6cm
6cm
20.5cm
Red-Black
5W
10W
50050
80
70
100 300200
90
100
1K 2K 3K 5K 20K10K 20020 5030 100
1.000
500 1K 2K 3K 10K
5K
0.010
0.032
0.100
0.316
3.162
10.000
300 Hz
D is tortio n /%
Line
Voltage
Terminals
Power
