DSPPA DSP406 User manual

70V
100V
Wall Mount Speaker System DSP406
OWNER’S MANUAL
Thanks for purchasing PA speaker system of DSPPA series. All of DSPPA series
products have been tested strictly before shipping. DSPPA series PA speaker system is
widely used in hotel, trade building, supermarket, school, entertainment, etc. It’s the most
ideal choice of you! In order to facilitate installing, modulating and running please read this
manual carefully before setup.
FEATURES:
Made of high beaverboard, hard to vibrate, sounds clear and
sonorousness;
Weight 2 kg, equipped with hanging holes for mounting convenient;
70/100V, 5-10W, suited for different field;
Effective Freq. Range 80Hz-18kHz, high sensitivity (91±2dB), Max.
Sound Pressure Level 101±2dB.
FREQ. RESPONSE DISTORTION
(dB SPL、1W、1m) (THD< 1.5% 1W、1m、100Hz-10kHz)
HANGING HOLE NAIL FOR MOUNTING
4.5mm
10mm
31.5cm
4mm-6mm
6cm
6cm
20.5cm
INSTALLATION
1. Fit two Ø4mm nail on wall where it is needed to install a speaker system as
shown above.
2. Connect audio broadcasting wire to the terminals according to the table
below.
Red-Black
5W
10W
3. Position the speaker, then adjust the direction of it and examine whether it is
steady.
Guangzhou DSPPA Audio Co., Ltd.
Line Voltage
Terminals
Power
50050
80
70
100 300200
90
100
1K 2K 3K 5K 20K10K 20020 5030 100
1.000
500 1K 2K 3K 10K
5K
0.010
0.032
0.100
0.316
3.162
10.000
300 Hz
D istortion / %
Public Address System
