DSP8063B 30W Wall Mount Speaker with Power Tap
Input 70V/100V/4-16Ω
Wide Freq.Resp.:80Hz-20KHz
Max SPL:105±2dB
High sensitivity:90±2dB
Wall mount type loudspeaker
Metal grille and ABS enclosure of black color
Equipped with hanging holes for mounting convenient
Features
The DSP8063 is a wall mount speaker built-in 70v/100v transformer. The 70v/100v transmission is
realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel
connection of multiple loudspeakers possible.
Metal grille and ABS enclosure of black color, long-term durability, never out of shape and fading; high
sensitivity, clear and sonorous sound. Easy and secure wall mount installation by hanging holes.
It is ideal choice for industrial and commercial applications in hotel, school, office and factory where
background music and paging is needed.
Description
Specification
Model
DSP8063
Speaker Unit
5"×1, 1"×1
Rated Power
30W
Input
Constant voltage
70/100V
Constant resistance
8Ω
Sensitivity(1M,1W)
90±2dB
Max SPL(1M)
105±2dB
Freq. Resp
80Hz-20kHz
Weight
3.2 kg
Dimension(H×W×D)
280×194×185mm

1. Fit two Ø4mm nails on wall where it is needed to install a speaker system.
2. Connect audio broadcasting wire to the speaker according to the table below.
Constant voltage
Constant
resistance
70V
100V
8Ω
Red--White
30W
-
30W
15W
30W
8W
15W
5W
8W
2.5W
5W
Note:
When the audio line is the constant voltage, prohibit the knob to the 8Ω.
Prohibit to adjust to“—” under state at 100V cause speaker damage!
3. Position the speaker, then adjust the direction of it and examine whether it is steady.
Installation
Hanging hole Nail For Mounting
Input Voltage
Terminal
Power

DSP8 063
Horizontal directivity pattern
D SP8 063
Vertical directivity pattern
FREQ. RESPONSE DISTORTION
(dB SPL、1W、1m) (THD< 1.5% 1W、1m、200Hz~12kHz)
