Duct-O-Wire RPB Series User manual

PUSH-BUTTON INSERT RATING: 125 VAC, ONE AMP CONTINUOUS PER CONTACT
PUSH BUTTON INSERTS
RPB SERIES
SCHEMATIC & OPERATIONAL DIAGRAMS
INSTRUCTIONS:
1. PEEL OFF THE BACKING OF THE DESIRED LABELS AND PRESS INTO THE LABEL CAVITIES ON THE
STATION FACE. PRESS DOWN FOR ADHESION.
2. MEASURE THE END OF THE CABLE AND REMOVE THE CABLE JACKET BACK FOR PROPER WIRE LENGTH
AND INSERT THROUGH THE CORD GRIP AND GROMMET. ON THE K MODEL, THE CORD GRIP CAN BE CUT
TO MATCH THE CABLE SIZE.
3. STRIP THE WIRES BACK 1/4" AND CONNECT TO THE PROPER TERMINALS. TIGHTEN SECURELY.
4. ON THE RPB MODEL, CONNECT THE GREEN GROUND TO THE BACKPLATE WITH A #6 SCREW.
5. SECURE THE BACK COVER TO THE STATION AFTER WIRING IS COMPLETE.
6. CHECK THE CORD GRIP FOR FIT DEPENDING ON STATION USED.
IMPORTANT:
1. FOLLOW THE WIRING DIAGRAMS SUPPLIED BY THE MANUFACTURER OR CRANE BUILDER CLOSELY.
2. AFTER SAFETY PRECAUTIONS ARE FOLLOWED, CHECK ALL CRANE MOTIONS TO INSURE THAT
WIRING IS CORRECT.
SWITCH CONTACT RATING
PART NUMBER DESCRIPTION VOLTAGE
RB-1 SINGLE SPEED 24 - 125 VAC
RB-2A TWO-SPEED CUMULATIVE 24 - 125 VAC
NOTE: NOT DESIGNED FOR DC CIRCUITS
THE RB-1 AND RB-2A SWITCHES ARE LISTED BY UNDERWRITERS LABORATORIES, INC.
AND C.S.A.
THE SWITCHES SUPPLIED WITH THIS STATION ARE RATED AT CURRENTS SUBSTANTIALLY HIGHER THAN
THOSE NORMALLY ENCOUNTERED IN CONTROL APPLICATIONS. IT SHOULD BE NOTED, HOWEVER, THAT
ELECTRICAL FAILURES IN ASSOCIATED EQUIPMENT CAN CAUSE CURRENTS TO FLOW WHICH FAR
EXCEED EVEN THESE HIGHER RATINGS.
Δ WARNING
MAKE CERTAIN POWER SUPPLY IS
DISCONNECTED BEFORE INSTALLING,
REPAIRING, OR WORKING IN THE
PROXIMITY OF ANY ELECTRICAL
SYSTEM. ONLY QUALIFIED ELECTRICAL
PERSONNEL SHOULD INSTALL OR
REPAIR THESE PRODUCTS.
!
NOT DESIGNED FOR
DC CIRCUITS
1351 W. Second Street 1445 Norjohn Ct., Unit 10
Oconomowoc, WI 53066 Burlington, Ontario, Canada L7L 0E6
Phone: [phone] Phone: [phone]; 800-361-WIRE (9473)
Fax: [phone]
E-mail: [e-mail]
Fax: [phone]
E-mail: [e-mail]
