DUERR-NDT CR 43 NDT User manual

CR 43 NDT / HD-CR 43 NDT
Installation and Operating Instructions
9000-608-21/30

EN

2

3
2013/10/21 9000-608-21/30
Inhalt
Important information
1. General . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Note on conformity . . . . . . . . . . . . . . 4
1.2 General Notes . . . . . . . . . . . . . . . . . 4
1.3 Disposal of appliance . . . . . . . . . . . 5
1.4 Correct Usage . . . . . . . . . . . . . . . . . 5
1.5 Incorrect Usage . . . . . . . . . . . . . . . . 6
1.6 Using Peripheral Devices . . . . . . . . . 6
1.7 Use of cassettes . . . . . . . . . . . . . . . . 6
1.8 Use of software . . . . . . . . . . . . . . . . 6
1.9 Guarantee . . . . . . . . . . . . . . . . . . . . 7
2. Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 General notes on safety . . . . . . . . . . 7
2.2 Electrical safety instructions . . . . . . . 8
3. Warnings and Symbols . . . . . . . . . . . . 9
3.1 Model identification plate . . . . . . . . . 9
4. Delivery contents . . . . . . . . . . . . . . . . 10
4.1 Consumables . . . . . . . . . . . . . . . . . 10
4.2 Special accessories . . . . . . . . . . . . 11
5. System requirements . . . . . . . . . . . . . . 12
5.1 Monitor . . . . . . . . . . . . . . . . . . . . . 12
5.2. Minimum system requirements . . . . 12
6. Technical data . . . . . . . . . . . . . . . . . . 12
6.1 CR 43 NDT / HD-CR 43 NDT . . . . . 12
6.2 Cassettes with integrated
image plates . . . . . . . . . . . . . . . . . . 13
7. Functional layout . . . . . . . . . . . . . . . . 14
7.1 Function of individual components . 15
8. Functional description . . . . . . . . . . . 16
Mounting
9. Transport and packaging . . . . . . . . . 17
10. Carrying the CR 43 NDT . . . . . . . . . . . 17
11. Set-up . . . . . . . . . . . . . . . . . . . . . . . . . 18
11.1 Installation room . . . . . . . . . . . . . . 18
11.2 Set-up alternatives . . . . . . . . . . . . 18
12. Electrical Connection . . . . . . . . . . . . . 19
13. Initial use and start-up . . . . . . . . . . . . 20
13.1 Remove the transport aids . . . . . . 20
13.2 Setting up the appliance . . . . . . . . 20
13.3 Installation and configuration . . . . . 20
Use
14. Cassettes . . . . . . . . . . . . . . . . . . . . . . . 21
14.1 Identification of the cassettes . . . . 21
14.2 Handling of cassettes . . . . . . . . . . 21
15. X-ray . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
15.1 Preparation for X-raying . . . . . . . . . 22
15.2 X-ray exposure . . . . . . . . . . . . . . . 22
15.3 Preparation for reading out the
image data . . . . . . . . . . . . . . . . . . 22
14.3 Storage of cassettes . . . . . . . . . . . 22
15.4 Reading out the image data . . . . . 23
15.5 Erasing the image data . . . . . . . . . 25
16. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 26
16.1 CR 43 NDT / HD-CR 43 NDT . . . . 26
16.2. Cassettes . . . . . . . . . . . . . . . . . . . 26
17. Maintenance . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting
18. Tips for Operators and Technicians . . 28
18.1 Unit fault . . . . . . . . . . . . . . . . . . . . 28
18.2 Error messages . . . . . . . . . . . . . . . 31
EN

49000-608-21/30 2013/10/21
Important
information
1. General
1.1 Note on conformity
This equipment has undergone a test of con-
formity as prescribed under the relevant Euro-
pean Union directive. This equipment conforms
to all requirements.
ETL approval
This Class A digital apparatus complies with
Canadian ICES-003. This equipment has been
tested and found to comply with the limits for a
class A digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide
reasonable protection against harmful interfer-
ence when the equipment is operated in a com-
mercial environment. This equipment generates,
uses, and can radiate radio frequence energy
and, if not installed and used in accordance
with the instruction manual, may cause harmfull
interference to radio communications. Operation
of these equipment in a residential area is likely
to cause harmful interference in which case the
user will be required to correct the interference
at his own expense.
FDA-Registration
Complies with FDA performance standards for
laser products except for deviations pursuant to
Laser Notice No. 50, date (June, 2007).
Classification:
Appliance class I, no application parts, trans-
portable continuous operation. This appliance is
not designed for use in areas where flammable
anesthetic materials are present.
1.2 General Notes
• The Installation and Operating Instructions
constitute part of the appliance. They must
be made available to the operator. Correct
observance of the Installation and Operating
Instructions is a basic requirement for using
the appliance properly and safely, and new
personnel must be instructed accordingly.
These Installation and Operating Instructions
must be handed over to any subsequent
owner or operator of this appliance.
• The safety of the operator and trouble-free
operation of the appliance can only be
ensured where original engineering manufac-
tured parts are used. Furthermore, only the
accessories described in the installation and
operating instructions or approved by Dürr
NDT for use with this appliance may be used.
If accessories are used manufactured by third
parties, then Dürr NDT can no longer provide
any guarantee for safe operation or correc-
tion functioning. No liability on the part of the
manufacture will be accepted in the case
that damage arises through the use of non-
approved accessories.
• Dürr NDT cannot be held responsible for the
appliance with regard to safety, reliability and
function where installation, reset, alterations,
extension or repairs were not carried out
either by or for Dürr NDT or by a third party
specifically approved by Dürr NDT, or if the
appliance is not used and operated according
to the instructions laid down in the Installation
and Operating Instructions.
• These Installation and Operating Instructions
accord with the features of the appliance
and the level of engineering at the time of
first introduction of the model. All circuits,
processes, names, software and appliances
quoted are protected under industrial property
rights.
• This translation of the Installation and Operat-
ing Instructions has been carried out in good
faith. Liability for incorrect translation will not
be accepted. The accompanying German
version of these Installation and Operating
Instructions are to be used as reference; if you
have any doubt as to the correct interpretation
of the instructions, please consult your dealer.
EN

5
2013/10/21 9000-608-21/30
• Any reproduction of these Installation and
Operating Instructions, or parts thereof, in any
medium whatsoever including electronic is
only permitted with the prior written approval
of Dürr NDT.
• Keep original packing for possible return of
the appliance to the supplier. Ensure that the
packaging is stored away from children.
Only the original packing ensures optimum
protection for the appliance during transport.
If a return is required during the warranty
period, Dürr NDT cannot be held liable for
damages during transport that have been
caused by inadequate packaging!
1.3 Disposal of appliance
Device
EU Directive(s) 2002/96/EG - WEEE (Waste
Electric and Electronic Equipment) of 27th Janu-
ary 2003 and their current application in national
law states that products covered by the above
directive within the European Union must be
disposed of as special waste.
For further questions about the proper disposal
of the products, please contact Dürr NDT or the
specialised trade.
Cassettes and image plates
The image plate contains barium compounds.
• Dispose of the image plate properly in accord-
ance with the locally applicable regulations.
• In Europe, dispose of the image plate in ac-
cordance with waste code 090199 "wastes
not otherwise specified". Disposal as domes-
tic waste is not possible.
1.4 Correct Usage
• The appliance is intended exclusively for visual
scanning and processing of image data on an
image plate under industrial conditions.
• The device is only to be used in enclosed, dry
rooms.
• Correct usage of the appliance also involves
observing the Installation and Operating
Instructions and adhering to the instructions
concerning set-up, operating and mainte-
nance.
• Any usage which is not in accordance with
the correct usage above will lead to the
guarantees and warranties becoming null and
void.
• The operator is liable for any damage arising
through incorrect usage.
• Correct usage includes compliance with all
legal provisions applicable at the place of use
with regard work and radiation protection.
• The scanner may only be operated in combi-
nation with cassettes from Dürr NDT.
EN

69000-608-21/30 2013/10/21
1.5 Incorrect Usage
The appliance is not intended for optical scan-
ning of image plates in human and veterinary
medicine.
Any use of the appliance above and beyond
that laid down here s considered to be improper
use of the equipment. Any resulting damage
thus caused is the sole liability of the user. The
manufacturer cannot be held responsible for
damage caused by improper use.
Cassettes from third-party manufacturers are
not compatible with the system and could dam-
age the appliance.
This appliance must not be used in
operating theatres or similar types
of room, where there is a risk of
inflammable materials catching fire.
1.6 Using Peripheral Devices
Only peripheral devices (computers,
monitors, printers) conforming to stand-
ard IEC 60950-1 (EN 60950-1) may be
connected to the appliance.
• Appliances may only be connected together
or connected to other system parts where the
safety of patients, operators and also the envi-
ronment is ensured.
Where there is any element of doubt con-
cerning the safety of connected equipment,
the user must contact the manufacturers
concerned or ask an expert to determine that
the level of safety required for the operator
and the environment is not impaired by the
intended coupling.
1.7 Use of cassettes
Other cassettes are not compatible with the
system and could damage the appliance.
1.8 Use of software
An X-ray software approved by DÜRR NDT
must be used, such as e.g. D-Tect. The use
of third party software requires the express
approval of DÜRR NDT. For further information
refer to our internet site at www.duerr-ndt.de.
See "System requirements for
compu ter systems in combination with
Dürr NDT - CR Systems", Order No.
9000-608-02/01 or on the Internet.
EN

7
2013/10/21 9000-608-21/30
1.9 Guarantee
Content
The guarantee granted herein applies only to
image plates mounted included in image plate
cassettes for scanner family„HD-CR 43 NDT
/ CR 43 NDT“. The guarantee is granted with
regard to damage-free transport of the image
plate in the scanner and the respective image
plate cassette. This means that we guarantee
that the image plate will not show any scratches
or other mechanical damage on the optical side
of the image plate within the Duration as speci-
fied below.
Duration
The guarantee is granted for a period of two
years as of the date of purchase or for 25,000
scan cycles, whatever comes first. Proof needs
to be submitted in the form of a copy of the pur-
chase invoice or other appropriate documents
or through the RFID chip included in the image
plate cassette.
Exclusions
Excluded from guarantee are image plate
cassettes of third-party manufacturers, image
plate cassettes which have had their RFID chip
manipulated and image plate cassettes which
have been subjected to temperatures that could
affect the functionality outside the intended
usage or mechanical damage that could affect
functionality or that have their safe functionality
affected in any way. This guarantee also does
not cover cases of scanner defects caused by
inufficient maintenance or other external factors
of any kind. In addition, the guarantee does not
apply in cases of wear and ear or malfunctioning
caused by increased X-ray or gamma radiation.
Rights
In case of breach of the above-defined guaran-
tee, the client has the right to demand delivery
of a new image plate cassette. All other rights
are excluded, in particular the right to request
damages.
Applicable law
This guarantee is governed by German law.
2. Safety
2.1 General notes on safety
The appliance has been developed and de-
signed in such a way that dangers are effectively
ruled out if operated in accordance with the
intended use. However, we feel it is important to
describe the following safety measures in order
to remove any likelihood of danger.
• When operating this appliance, all local and
national rules and regulations must be ob-
served!
This appliance must not be converted or
altered in any way. Dürr NDT accepts no
liability claims where an appliance has been
converted or altered in any way. In the
interests of safe usage of the appliance, both
operator and owner are responsible for seeing
that all relevant regulations and provisions are
observed.
• Opening an appliance connected to the main
supply results in danger from Class 3B laser
radiation.
• Installation must be carried out by a specialist
authorised by the manufacturer.
• The operator must carefully check the appli-
ance for safety of function and proper working
condition before every use.
• The operator must be trained in the correct
operation of the appliance.
EN

89000-608-21/30 2013/10/21
2.2 Electrical safety instructions
• The appliance may only be connected to a
correctly installed electrical socket.
• Connection to a multi-socket power strip is
not permitted.
• Before connecting to the electricity supply, the
appliance must be inspected and checked to
ensure that the supply voltage and the supply
frequency correspond to that of the local
electrical supply.
• Before initial use and start-up, the appliance
and all supply lines must be checked for any
signs of damage. Damaged supply lines and
connections must be replaced immediately.
• Never touch persons and open connectors of
the appliance simultaneously.
• When using the appliance, observe all the
relevant electrical safety procedures.
Before opening the device, un-
plug at the mains and remove all
power mains plug!
EN

9
2013/10/21 9000-608-21/30
3. Warnings and Symbols
In the operating instructions, the following warn-
ings and symbols have been used:
Information including preventa-
tive measures to protect injury to
persons or damage.
Special information regarding the eco-
nomical use of the equipment and other
information
Unplug at the mains and remove all
power
Warning Laser
Warning: Dangerous
voltage
Do not push the appliance.
Do not sit on the appliance
Do not enter the appliance.
ON/OFF button
Ready for operation
Data transmission
Fault
FCC-Approval
Warning: Laser
Notes on laser source
Laser class1
3.1 Model identification plate
The model identification plate is located on the
rear side of the scanner. The following designa-
tions or signs exist on the model identification
plate:
Caution, observe accompanying docu-
mentation
Warning: Dangerous
voltage
Date of manufacture
Manufacturer
Observe accompanying documentation
Dispose of properly in accordance with
EU Directive (2002/96/EU - WEEE)
IP20 Type of protection
NEMA 1 Type of protection
REF Order number
SN Serial number
CE label without notified body number
ETL-Certification
CONFORMS TO UL STD 61010-1
CERTIFIED TO CAN/CSA STD C22:2
NO 61010-1
Complies with 21 CFR 1040.10 &
IEC 60825-1
EN

10 9000-608-21/30 2013/10/21
4.1 Consumables
Protective sleeves for cassettes
18x24 ....................PRSH1824108
24x30 ....................PRSH2430108
35x43 ....................PRSH3543108
IP-Cleaning Wipes (100 pcs.) . . CCB351A0101
Other cleaning and disinfectants can be
obtained from the company Orochemie
(www.orochemie.de) under the following
names:
Disinfectant wipes B 60
4. Delivery contents
Please compare the completeness of the deliv-
ery with the purchase order.
CR 43 NDT 2133-31
CR 43 NDT . . . . . . . . . . . . . . . . . 2133-000-53
Network cable RJ45 (3 m) . . . . . 9000-119-065
Installation and
Operating Instructions . . . . . . . . 9000-608-21/..
Country-specific:
Mains cable (EUR) . . . . . . . . . . . . 9000-118-17
Mains cable (CH) . . . . . . . . . . . . 9000-119-002
Mains cable (DK) . . . . . . . . . . . . 9000-119-041
Mains cable (GB) . . . . . . . . . . . . . 9000-118-59
Mains cable (AUS) . . . . . . . . . . . 9000-119-037
Mains cable (I) . . . . . . . . . . . . . . 9000-119-036
Mains cable (USA / J) . . . . . . . . 9000-119-039
or
HD-CR 43 NDT 2133-41
HD-CR 43 NDT . . . . . . . . . . . . . . 2133-000-54
Network cable RJ45 (3 m) . . . . . 9000-119-065
Installation and
Operating Instructions . . . . . . . . 9000-608-21/..
Country-specific:
Mains cable (EUR) . . . . . . . . . . . . 9000-118-17
Mains cable (CH) . . . . . . . . . . . . 9000-119-002
Mains cable (DK) . . . . . . . . . . . . 9000-119-041
Mains cable (GB) . . . . . . . . . . . . . 9000-118-59
Mains cable (AUS) . . . . . . . . . . . 9000-119-037
Mains cable (I) . . . . . . . . . . . . . . 9000-119-036
Mains cable (USA / J) . . . . . . . . 9000-119-039
EN

11
2013/10/21 9000-608-21/30
4.2 Special accessories
The parts listed in the following are not included in the scope of delivery.
Please order as required.
Cassette 18x24
Highly sensitive (G CR), normal solvent (H CR) or highly solvent (X HD)
Order number Name Copper thickness
(mm)
2133-010-70 Dürr NDT G CR Cassette 18x24 cm 0,1
2133-010-71 Dürr NDT H CR Cassette 18x24 cm 0,1
2133-010-72 Dürr NDT X CR Cassette 18x24 cm 0,1
Cassettes 24x30
Highly sensitive (G CR), normal solvent (H CR) or highly solvent (X HD)
Order number Name Copper thickness
(mm)
2133-020-70 Dürr NDT G CR Cassette 24x30 cm 0,1
2133-020-71 Dürr NDT H CR Cassette 24x30 cm 0,1
2133-020-72 Dürr NDT X CR Cassette 24x30 cm 0,1
Cassettes 35x43
Highly sensitive (G CR), normal solvent (H CR) or highly solvent (X HD)
Order number Name Copper thickness
(mm)
2133-040-70 Dürr NDT G CR Cassette 35x43 cm 0,1
2133-040-71 Dürr NDT H CR Cassette 35x43 cm 0,1
2133-040-72 Dürr NDT X CR Cassette 35x43 cm 0,1
EN

12 9000-608-21/30 2013/10/21
6. Technical data
6.1 CR 43 NDT / HD-CR 43 NDT
Electrical Rated connection data
Voltage (Vac) . . . . . . . . . . . . . . . . . . . 100 - 240
Frequency (Hz) . . . . . . . . . . . . . . . . . . . 50 - 60
Current consumption (A) . . . . . . . . . . . 2.5 - 1.0
Output (VA) .........................250
Type of protection . . . . . . . . . . . . . . . . . . . IP20
Type of protection . . . . . . . . . . . . . . . . NEMA 1
Protection class .......................1
Transient surge voltage category . . . . . . . . . . . II
Data connections
Network . . . . . . . . . . . . . . . . . LAN 100 Base T
Weight
CR 43 NDT /
HD-CR 43 NDT (kg / lbs) . . . ca. 55 / ca. 121.25
Dimensions
(H/D/W in mm) . . . . . . . . . . . 1130 x 440 x 400
(H/D/W in ) . . . . . . . . . . .44.49 x 17.32 x 15.15
Ambient conditions during storage and
transport
Temperature (°C) . . . . . . . . . . . . . . . -20 to +60
Temperature (°F) . . . . . . . . . . . . . . . -4 to +140
Relative humidity (%) . . . . . . . . . . . . . . . 10 - 80
Ambient temperature during operation
Temperature (°C) . . . . . . . . . . . . . . . +10 to +35
Temperature (°F) . . . . . . . . . . . . . . . +50 to +95
Relative humidity (%) . . . . . . . . . . . . . . . 20 - 80
Atmospheric pressure for operation and
storage
Appliance in operation (hPa) . . . . . . 750 - 1060
Sea level (m) ......................<2000
Sea level (m) . . . . . . . . . . . . . . . . . . .<6 561,67
Storage and transport (hPa) . . . . . . 750 - 1060
Sea level (m) ......................16000
Sea level (foot) . . . . . . . . . . . . . . . . . 52 493.43
5. System requirements
For the operation of the scanner, the following
components and requirements are necessary.
5.1 Monitor
The monitor does not form part of the
scope of supply of the scanner.
Only monitors designed for digital x-ray with
superior light intensity and broader contrast
which conform to standard EN 25580 should be
used. Bright room lighting, direct sunlight and
even reflected light will reduce the diagnostic
usefulness of the x-rays.
5.2. Minimum system requirements
See enclosed information sheet,
order number 9000-608-02
EN

13
2013/10/21 9000-608-21/30
General values
Laser protection class
external . . . . . . . . . . . . . . . . . . 1 (EN60825-1)
Laser protection class
internal . . . . . . . . . . . . . . . . . . 3b (EN60825-1)
Wavelength λ 635 nm 15mW
EN 60825-1:2006-04 +
A1:2002-07+A2:2001-03
Heat output (W) . . . . . . . . . . . . . . . . . . . . .250
Sound level
Stand-by (db(A)) . . . . . . . . . . . . . . . approx. 42
During readout (db(A)) . . . . . . . . . . . approx. 45
Pixel size
HD-CR 43 NDT
can be selected in a range from 12.5 μm to 250
μm
Resolution based on the image plate, theoreti-
cally up to max. approx. 40 line pairs/mm (LP/
mm)
CR 43 NDT
can be selected in a range from 30 μm to 250
μm
Resolution based on the image plate, theoreti-
cally up to max. approx. 15 line pairs/mm (LP/
mm)
Conformity Acceptance Procedure
06/95/EC (Low Voltage Directive)
04/108/EC (EMC Directive)
6.2 Cassettes with integrated
image plates
Storage and transport
Temperature (°C) . . . . . . . . . . . . . . . . . . . . .<33
Temperature (°F) . . . . . . . . . . . . . . . . . . . <93.2
Relative humidity (%) . . . . . . . . . . . . . . . . . .<80
Use
Temperature (°C) . . . . . . . . . . . . . . . . . . 18 - 45
Temperature (°F) . . . . . . . . . . . . . . . . .59 - 93.2
Relative humidity (%) . . . . . . . . . . . . . . . . . .<80
No. of cycles
Cycles/cassette . . . . . . . . . . . . . . . . . . 25,000
A warning message is displayed after
the 25,000 cycles. The cassette can
continue to be used.
After 27,500 cycles, the cassette must
be replaced in order to avoid incorrect
diagnoses or defects.
EN

14 9000-608-21/30 2013/10/21
7. Functional layout
1 2 3
4
5
6
7
8
9
10
11
EN

15
2013/10/21 9000-608-21/30
7.1 Function of individual
components
1 LED white
The appliance is ready for operation.
2 LED blue
LED out: Communication to PC established
LED lit: Communication to PC interrupted.
3 LED red
LED lit: Error
Device fault: Urgent need for action by the
operator
• Switch off the CR 43 for approx. 10 seconds.
• Restart the CR 43.
• If the CR 43 does not start, inform the service
technician.
For further information refer to the sec-
tion Troubleshooting.
4 ON/OFF button
Press the button to switch ON and OFF.
5 LED yellow
Lights up during processing of a cassette.
6 LED green
Lights up when the cassette slide is ready.
Flashes when the process has been completed.
7 Cassette slide
The cassette is inserted into the appliance via
the cassette slide.
8 Cassette
The cassette contains the image plate and pre-
vents the deletion of image data by foreign light
and protects the image plate from mechanical
damages.
9 Cassette lock
The cassette is locked via the recesses during
removal of the image plate.
10 Transponder
Information such as cassette size and se-
rial number of the cassette is stored on the
transponder and is read out when the cassette
is inserted.
11 Opening:
The integrated image plate is taken out of the
cassette via the cassette opening for scanning.
EN

16 9000-608-21/30 2013/10/21
8. Functional description
CR 43 NDT / HD-CR 43 NDT converts the im-
age data on the image plate into a digital image.
X-rays
The cassette with the integral image plate is
placed into the X-ray appliance and exposed.
Scanning the image data
The CR 43 NDT is switched on by pressing the
ON/OFF button. The scan mode is then acti-
vated (via the interfaced PC and the software).
The cassette with the exposed image plate is
then pushed into the cassette slide as far as
possible. The cassette is automatically drawn in
and locked. In the cassette is a transponder that
transmits the identification data of the cassette
to the scanner when the cassette is pushed
in. This ensures that the scanned image is as-
signed with the correct evaluation. The image
plate is drawn automatically onto the scanner
slide by the transport mechanism. The scan-
ner slide with the image plate moves past the
scanner unit where the image data are scanned.
The status of the image scanning is displayed
in a window on the monitor of the interfaced
PC. After scanning, the image plate passes
through the erasure unit. There the image plate
is erased. The image plate is then pushed back
automatically into the cassette by the transport
mechanism.
Image plate
Photomultiplier
Laser source
Reflection
layer
Pentaprism
Rotating disc Parabolic mirror
EN

17
2013/10/21 9000-608-21/30
10
Mounting
Only qualified specialists or persons
trained by Dürr NDT may install,
connect and commission the
appliance.
9. Transport and packaging
• Transport the appliance only in the original
packaging.
• Check that the delivery contents are complete
and check for any signs of transport damage.
• Carefully remove the packaging. Do not use a
knife in order to avoid damaging the surface
and other delicate parts of the appliance.
• Do not expose the CR 43 NDT to severe
vibrations during transport as delicate compo-
nents in the appliance could be damaged.
10. Carrying the CR 43 NDT
Carry the appliance only at the
transport aids (13) installed at the
factory.
If the appliance is carried in any
other way (e.g. on the base, cover,
cassette slide), there is a risk of
injury or delicate parts could be
damaged.
1
13
EN

18 9000-608-21/30 2013/10/21
11. Set-up
11.1 Installation room
• Install the CR 43 NDT only in a closed, dry
and well ventilated room.
• The room temperature must not drop below +
10 °C / 50 °F in winter or exceed + 35 °C / 95
°F in summer.
Danger of short circuit due to build
up of condensation.
The system can only be put into
operation once the appliance has
warmed up to room temperature
and it is dry.
• Installation in a purpose-built room, e.g. in a
boiler room or in a wet room is not permitted.
• Do not expose the appliance to direct sun-
light, e.g. near windows. The ambient light
must be reduced if necessary. The maximum
light intensity is 1500 lux.
• The device is designed for use in laboratory,
test and measurement areas. There must be
no source of interference in the room for set-
up (e.g. strong magnetic field). Interference
fields may cause malfunctions in the appli-
ance.
• This appliance is not equipped with its own
main power switch. Therefore, the appliance
must be set up in such a way that the socket
outlet is easily accessible in case of a possible
fault and that this is situated within the maxi-
mum cable length of 3 m / 118.11 inch.
• Install the appliance is such a way that it does
not cause interference in other appliances
during the scanning process of the and the
RFID system of the CR 43.
• Set up the appliance so that it is not in the
path of the X-rays.
11.2 Set-up alternatives
In order to avoid errors during scanning
of the image data, always install the
appliance horizontally and on a solid
surface where it is not exposed to vibra-
tions.
Table set-up
CR 43 can be set up as a tabletop appliance.
Observe the maximum load-bearing
strength of the table. The table must
have an adequate load-bearing
strength.
The table and appliance must be
set up so that there is no danger of
tipping over.
Mobile use
The appliance can also be installed in a motor
vehicle for mobile use.
The appliance must thereby be
• transported with low vibration level (damped -
decoupled from the vehicle).
• safely installed in the vehicle (withsuitable
mounting kit)
Level adjustment
The front foot (14) with knurled surface is
adjustable.
See point 13.2 Aligning the appliance.
214
EN

19
2013/10/21 9000-608-21/30
12. Electrical Connection
Before start-up, check the mains voltage
against the voltage indicated on the model
identification plate.
The connection ports are located in the recess
on the rear of the appliance.
• Insert the mains cable supplied into the mains
jack on the appliance.
• Plug the mains cable into the mains supply
socket.
EN

20 9000-608-21/30 2013/10/21
18
5
3
4
2
1
This appliance is not equipped with its
own main power switch. Therefore, the
appliance must be set up in such a way
that the socket outlet is easily acces-
sible in case of a possible fault and that
this is situated within the maximum
cable length of 3 m / 118.11 inch.
13. Initial use and start-up
13.1 Remove the transport aids
• When the appliance has been moved to its
intended location, remove the transport aids
by tilting the appliance slightly.
The transport aids should fall out on
their own when the appliance is tilted. If
this is not the case, pull briefly down-
wards on the cord.
13.2 Setting up the appliance
The front foot (14) of the appliance is adjustable.
The adjustment range is ±3mm / 0.12 inch.
• Set up the appliance at its intended location.
• Carefully tilt the appliance slightly to the rear.
Adjust the foot, if necessary, until the appli-
ance is standing firmly on all four feet.
13.3 Installation and configuration
Perform the installation and configura-
tion according to the provided operating
instructions "Installation and Configura-
tion CR 43" Order No. 9000-608-61/.. .
Connections and displays
1 Mains connection:
For connection of the appliance to the mains
power supply.
2 Reset button:
By pressing and holding the Reset button for
15 - 20 seconds while switching on, all net-
work settings for the appliance are set back to
factory settings.
3 Status LEDs:
Display of the device status during the service
4 AUX port:
Programming and test interface. For service
purposes only.
5 Network port:
For connection of the appliance to the net-
work.
3
4
514
EN
