ImagePro 8758
Data/Video projector
• Network Connection, RJ-45
• XGA resolution
• 2200 lumens brightness
• HDTV compatible
• Digital keystone correction,
Horizontal & Vertical
• Very quiet operation
• LCD with status Information
8758
Monitor
Out
Kingston
Lock Slot
Computer
RGB, In Audio
Out
Computer
M1-DA
RJ-45
Network
Audio
In (R)
Audio
In (L)
S-Video
In
Computer
Video In
Computer
Audio Out
RS232
IR Sensor
Power
• Business
•Education
View the status of your projector via the LCD window
on top of the unit.

Specifications 8758
Image Element 0.8” polysilicon TFT x3, MLA
Brightness 2200 ANSI lumens
Resolution 1024 x 768 pixels (H X V), XGA
Contrast 400 to 1
Scanning Frequency fh 16-110 kHz, fv 50-85 Hz
Lens Manual zoom, 1.2X
Lens Throw Ratio 1.61 - 1.91 to 1 throw distance
to image width
Keystone Correction Digital, vertical +/-25 deg,
Horizontal +/-15 deg
Computer SVGA, VGA, XGA, and
Compatibility SXGA Compressed,
Mac 13” and Mac 16”
Video Compatibility NTSC, NTSC 4.43, PAL, PAL-M,
PAL-N, PAL60, SECAM, HDTV,
1080i,1080i/50 Hz, 720p, 480i/p
Image Control Freeze function, electronic
magnification and pan
Mouse Control Using USB – using M1-USB
Picture in Picture, PiP Yes, video in computer
Other Feature Mask reveal for images
Projection Modes Front/rear/ceiling
Color Reproduction 24 bit (16.7 million)
Lamp 170 W UHP
Lamp Life 2000 hours
Audio 2 speaker, 2 watt
Throw Distance 60” to 400”
Screen Size, diag. 40” to 300”
Inputs, Video Component, via adapter for M1-D/A
S-video, Min DIN 4-pin,
Composite video, RCA x 1
Audio, Stereo, RCA x 2, for c-video
Inputs, Computer 1 x RGB Signal: D-sub, 15 pin
Computer, Stereo Mini Audio x 1
M1-D/A Computer (DVI)
Outputs Monitor 15 pin, D-sub
Outputs,Control 15 pin D-Sub, RS-232
Audio out, Stereo mini jack
USB, mouse control w M1-D/A
Network connection RJ-45 port
Security Kensington slot
Fan Level Ultra quiet, 34 dB normal
Operating Temp. 50 to 95 deg. F
Power AC 100-240V, AC 50/60 Hz, 260 watt
Size (WxHxD) 11.6” x 4.1” x 10.3”
Weight 7.5 lbs.
Shipping Weight 14 lbs.
Carton Size 16” x 16” x 14”
Accessories Included Remote control, batteries, power
cord, M1-D/A computer and USB cable,
3.5 mm audio cable, RCA x 3
cable,operators manual and
soft carry case
Safety UL/CUL, FCC/DOC Class A,
Optional Accessories Lamp; 456-8758
Rolling briefcase; 185-406, Ceiling
mount, universal; PJF-UNV-S M1 to
Component adapter; SP-M1-ADPT
2YR
A way to present your images anywhere
The Dukane ImagePro 8758™ offers best-in-class
capabilities with intuitive controls. Get outstanding
color saturation and brightness that lasts. Use the net-
work connection to set up any meeting room by
remote monitoring and control.
The high-end features mean that you do less work.
Automatic horizontal and vertical keystone correction,
plus ceiling detection
ensure your image is
proper, with no work
on your part. Automatic
synchronization with
computer and video
sources allows for quick
and smooth transitions.
Key features:
• Light weight
• 2200 lumens brightness
• XGA resolution
• Simple, icon based menu
• HDTV compatible
• Zoom lens
• Automatic ceiling detection
• Network connection
• Picture-In-Picture (PIP)
• LCD window with status information
ImagePro 8758
Portable LCD projector
Audio Visual Products
2900 Dukane Drive
St. Charles, Illinois 60174
www.dukcorp.com/av
Diagonal Width Min. Max. a*
Inches Inches Feet Feet Inches
40 32 4.3 5.1 1.5
60 48 6.4 7.6 2.0
100 80 10.7 12.7 4.0
120 96 12.9 15.3 5.0
150 120 16.1 19.1 6.5
210 168 22.5 26.7 7.0
a* = Distance Below Lens Center line.
Image Size 4:3
Throw Distance
ImagePro is a registered trademark of Dukane Corporation
Toll-free: 800-676-2485
Fax: [phone]
E-mail: [email protected]
#11626-C-04
8758 Image Size Distance Table
Two (2) year limited warranty on parts and labor in North America,
lamp excluded (for other locations, local warranties apply). Includes
Dukane’s FREE 1 year
Peace-of-Mind Loaner Program .
