dun-bri GROUP Raider R65 Series User manual

R65 LED LIGHTBAR
www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the lightbar. This lightbar
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
SPECIFICATIONS
Dimensions (w) x (h) 218mm x 80.7mm
Voltage Range 9-32V
LED Colour Amber
Mounting 4 Bolt with adjustable feet (Magnetic Mount available on 613mm length)
Flash Patterns 14
Approvals ECE R65 TA2, ECE R10, CISPR25 CLASS 3, RoHS, CE
IP Rating IP67
MODELS AVAILABLE
SKU Length (X) Mounting Modules LEDs LED Colour Watts
308.R24CR65 613mm (24”) 4 Bolt 8108 Amber 74W
308.R24CR65MAG 613mm (24”) Mag Mount 8 108 Amber 74W
308.R30CR65 766mm (30”) 4 Bolt 10 132 Amber 82W
308.R42CR65 1070mm (42”) 4 Bolt 14 180 Amber 98W
308.R48CR65 1223mm (48”) 4 Bolt 16 204 Amber 106W
308.R60CR65 1528mm (60”) 4 Bolt 20 252 Amber 122W
v1.1

R65 LED LIGHTBAR
www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
14 FLASH PATTERNS
01 Single Flash (ECE R65) 08 Fast Clockwise
02 Double Flash (ECE R65) 09 Rotate Flash (ECE R65)
03 Triple Flash (ECE R65) 10 Full Cruise
04 Left / Right Flash 11 Both Ends Cruise
05 Slow Anticlockwise 12 Middle Sweep
06 Slow Clockwise 13 Left Sweep
07 Fast Anticlockwise 14 Right Sweep
! WARNING ! - Do NOT look directly at the LEDs when in operation to prevent damage to your eyes.
FLY LEAD WIRING DIAGRAM
Latching Switch (On/Off)
RED Wire (+)
Ground
Battery
YELLOW Wire (+)
(Mode)
BLACK Wire (-)
Ground
Fuse
(Required)
Supplied with 3.5m length of cable
Fuse and switches NOT supplied
Momentary Switch (Change Flash Mode)
TO SWITCH BETWEEN DIM MODE - Hold the yellow mode wire for 3 seconds against the red positive
(+) wire (or hold the mode switch for 3 seconds) until the light turns static to change the brightness.
Change Flash Mode
On / Off
MAGNETIC MOUNT OPERATION
Supplied with 3.5m length of cable

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
MOUNTING + FITTING INSTRUCTIONS
Carefully unpack and inspect the lightbar and all
accessories before installing to ensure there are no
damaged or missing parts.
Plan all cable routing before attempting installation and
ensure voltage compatibility.
Adjust mounting feet to fit your vehicle.
Mounting location must be a smooth, flat surface to
ensure a secure fitting.
Mount centrally and ensure there are no obstructions
limiting visibility to traffic.
Place and remove the lightbar without sliding, to avoid
damaging the vehicle.
If the lightbar slides or moves easily, a proper installation
has NOT been attained.
! CAUTION ! - Disconnect the
battery before wiring up the
lightbar to prevent accidental
shorting and/or electrical
shock.
! CAUTION ! - When drilling into
the vehicle surface, make sure
the area is free from anything
that could be damaged,
including any electrical wires,
fuel lines, upholstery, etc.
MODULE LENS CLEANING
Occasional cleaning is recommended to ensure optimal
light output.
Although tough, polycarbonate scratches easily, so take
care when cleaning.
Clean lens with soap and water or a lens polish using a
soft cloth.
! WARNING ! - Do NOT use
solvents as they may damage
the lens.
! WARNING ! - Do NOT use
high-pressure washers or
automatic car washers. This
lightbar is rated IP67.
! WARNING ! - Do NOT attempt
to attach the lightbar to an ice-
covered vehicle.
! WARNING ! - Do NOT exceed
50mph / 80kph when magnetic
mount lightbar is attached. High
speeds could cause
the mount to fail.

R65 LED LIGHTBAR
www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
TROUBLESHOOTING
Problem Probable Cause Solution
Lightbar does not function
Wiring error Ensure lightbar wiring is correct and all wire
connections are secure
Blown fuse Check wiring and fuse. Replace fuse
LED Module does not
illuminate / dimly illuminates
Defective LED module Replace LED module
Poor connection Check all wiring is secure and the LED
module connection is tight
Incorrect flash pattern Wrong flash configuration Re-progam the flash pattern
