DBG M37 SERIES R65 LED
WARNING MODULE
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the module. This module
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
v1.1
M37 Series
Voltage Range 10-30V
LED Colour Amber
Mounting Surface Mount (2 Screws)
Connection Fly Lead
Flash Patterns 8 for 3-LED version / 12 for 4-LED & 6 LED versions
Syncable? Yes
Dimmer Function No
IP Rating IP67
MODELS AVAILABLE
SKU LEDs Flash Patterns Approvals Dimensions (l) x (h) x (d)
308.HPF303VV 3 8 ECE R65 (Class I), ECE R10 82mm x 30mm x 14mm
308.HPF304VV 412 ECE R65 (Class I), ECE R10 98mm x 30mm x 14mm
308.HPF305VV 6 12 ECE R65 (Class I), ECE R10 130mm x 30mm x 14mm

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
DBG M37 SERIES R65 LED
WARNING MODULE
! WARNING ! - Do NOT look directly at the LEDs when in operation to prevent damage to your eyes.
8 STANDARD FLASH PATTERNS
01 Single Flash (ECE R65 Approved) 05 Six Flash
02 Double Flash 06 Double Flash (Fast)
03 Triple Flash 07 Quad Flash (Fast)
04 Quad Flash 08 Six Flash (Fast)
4 ADDITIONAL FLASH PATTERNS (4-LED & 6-LED VERSIONS ONLY)
09 Single Flash (Left / Right) 11 Triple Flash (Left / Right - Fast)
10 Double Flash (Left / Right) 12 Six Flash (Left / Right)
WIRING DIAGRAM
+VDC
(RED WIRE)
Ground
Battery
Fuse (Required)
Supplied with 220mm length of cable
Fuse and switches NOT supplied
Momentary Switch (Change Flash Pattern)
SYNC
YELLOW WIRE (+)
- VDC
(BLACK WIRE)
Latching Switch (On/Off)
SYNCHRONISATION INSTRUCTIONS - Ensure
all modules are set to the same flash pattern.
Connect yellow wires of all modules together.
TO CHANGE FLASH PATTERNS - Momentarily
apply yellow wire to the +VDC. A simple
momentary switch will be sufficient.

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
MODULE LENS CLEANING
Occasional cleaning is recommended to ensure optimal
light output.
Although tough, polycarbonate scratches easily, so take
care when cleaning.
Clean lens with soap and water or a lens polish using a
soft cloth.
! WARNING ! - Do NOT use
solvents as they may damage
the lens.
! WARNING ! - Do NOT use
high-pressure washers or
automatic car washers. This
module is rated IP67.
MOUNTING + FITTING INSTRUCTIONS
Carefully unpack and inspect the module and all
accessories before installing to ensure there are no
damaged or missing parts.
Use foam gasket and screws provided. Do NOT
overtighten screws.
Plan all cable routing before attempting installation and
ensure voltage compatibility.
Ensure there are no obstructions limiting visibility to
traffic when mounting.
If the module slides or moves easily, a proper installation
has NOT been attained.
! CAUTION ! - Disconnect the
battery before wiring up the
module to prevent accidental
shorting and/or electrical shock.
! CAUTION ! - When drilling into
the vehicle surface, make sure
the area is free from anything
that could be damaged,
including any electrical wires,
fuel lines, upholstery, etc.
! WARNING ! - Do NOT
overtighten screws.
! WARNING ! - Unconnected
wires MUST be sealed to
prevent any water ingress.
