Dunlop FUZZ FACE FFM1 User manual

92503014289revB FFM1 SILICON MINI DISTORTION
®

CONTROLS
VOLUME knob controls overall
eect volume
FUZZ knob controls amount
of fuzz
FOOTSWITCH toggles on/
bypass (blue LED indicates on)
DIRECTIONS
• Run a cable from your guitar
to the FFM1’s INPUT jack and
another cable from the FFM1’s
OUTPUT jack to your amplier.
• Start with both controls at 12
o’clock.
• Turn the eect on by depressing
the footswitch.
• Rotate the VOLUME knob
clockwise to increase
overall eect volume or
counterclockwise to decrease it.
• Rotate the FUZZ knob clockwise
to increase amount of fuzz or
counterclockwise to decrease it.
DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: [phone] FAX: [phone]
®
DESCRIPTION
• Legendary Fuzz Face tone with
pedalboard-friendly size, AC
power and on/bypass status LED
• Spec’d from our own prized 1970
Fuzz Face pedal
• Bright, aggressive sounding
BC108 transistors
• True bypass
POWER
The FFM1 is powered by one
9-volt battery (open battery door
on underside of pedal to install),
a 9-volt AC adapter such as the
Dunlop ECB003/ECB003EU or
a DC Brick™power supply.
SPECIFICATIONS
Input Impedance 10 kΩ
Output Impedance
Max Volume <16 kΩ
Mid Volume 66 kΩ
Max Gain 55 dB
Bypass True Hardwire
Current Draw 3.4 mA
Power Supply 9 volts DC
FFM1 SILICON FUZZ FACE®MINI
DISTORTION
